Huawei G6003 Bedienungsanleitung
G6003
GSM Mobile Phone
User Guide
Copyright © Huawei Technologies Co., Ltd. 2011. All
rights reserved.
Trademarks and Permissions
, , and are trademarks or registered
trademarks of Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names mentioned
are the property of their respective owners.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT
AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY
KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE
ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO
CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY
SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES,
OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR
ANTICIPATED SAVINGS.
1
1 Getting to Know Your Phone
Your Phone
1 Earpiece 11 Charger jack
2 Screen 12 Sym key
3 Audio player key 13 Input switch key
4 Left soft key 14 Enter key
5 Call/Answer key 15 Delete key
6 Keypad 16 End/Power key
7 Fn key 17 Right soft key
8 A/a key 18 Message key
9 Space key 19 OK/Confirm key
10 Headset jack 20 Navigation keys
The figure above shows the appearance of your phone and is
provided only for your reference.
2
Keys and Functions
Press… To…
Make a call from SIM card in standby mode.
Answer a call.
View dialled logs of SIM card in standby mode.
Power on or power off the phone (by pressing
and holding the key for about 3s).
End or reject a call.
Return to standby mode.
(Left soft key)
Access the main menu in standby mode.
Select a highlighted item.
(Right soft key)
Access Phonebook in standby mode.
Return to the previous menu.
Access Audio player in standby mode.
Access Messaging in standby mode.
Access the main menu in standby mode.
Confirm a selection.
Scroll to the desired icon in the main menu (by
pressing , , , and ).
Access the next menu from a submenu screen
(by pressing ).
Return to the previous menu from a submenu
screen (by pressing ).
3
Press… To…
–
–
Enter numbers, letters, and symbols.
Call the voicemail in standby mode (by pressing
and holding the 1key for about 3s).
Select a submenu (by pressing the corresponding
number key).
Enter a space in text editing mode.
Lock the keypad in standby mode (by pressing
and holding the key for about 3s).
Switch between input methods in text editing
mode.
Switch between upper and lower case in text
editing mode.
Access FM radio in standby mode (by pressing
and holding the key for about 3s).
Display the Select symbol list in text editing
mode.
Screen Icons
Icon Indicates…
Signal strength.
New text messages.
New multimedia messages.
Call forwarding enabled.
4
Icon Indicates…
Missed calls.
New voicemail messages.
Alarms enabled.
Keypad locked.
Battery power level.
General profile activated.
Meeting profile activated.
Outdoor profile activated.
Headset connected to the phone.
5
2 Getting Started
Installing SIM Cards and the Battery
When inserting a SIM card, ensure that the golden contact area on
the SIM card is facing downward and that the beveled edge of the
SIM card is properly aligned with that of the SIM card slot.
Removing the Battery and SIM Cards
Before removing the battery and SIM card, ensure that your phone is
powered off.
Installing a microSD Card
Before installing or removing a microSD card, power off the
phone. Once the phone is powered on, it will indicate whether
the microSD card has been installed properly.
You can install a microSD card to expand the memory capacity of
your phone. When inserting the microSD card, ensure that the
golden contact area on the microSD card is facing downward.
6
Charging the Battery
To charge the battery:
1. Connect the charger to the phone.
2. Connect the charger to a power socket.
3. Wait until the battery is fully charged.
While the battery is charging, the charging icon is animated.
When the charging icon animation stops, the battery is fully
charged.
4. Disconnect the charger from the power socket and then from the
phone.
Working with the Main Menu
1. In standby mode, press (Menu) to access the main menu.
2. Use to scroll to the desired submenu, and then press
to access the submenu.
3. Press or to scroll to an option, and then press
(OK) or to select the option.
7
4. Press (Back) to return to the previous menu.
To return to the standby mode, press .
Automatically Switching Between Profiles
You can set your phone to activate different profiles at different
times. The phone can automatically switch between profiles up to
three times per day.
1. Select Menu > User profiles > Profile Switch Timing.
2. Scroll to a time, and then press (Edit) to select the profile to
be activated at the specified time.
3. Press (Done) to save the settings.
Phone Lock
The phone lock protects your phone from unauthorized use. By
default, the phone lock is disabled. Once the phone lock is enabled,
you are required to enter the phone code each time you power on
the phone.
To enable the phone lock:
1. Select Menu > Settings > Security settings >Phone lock.
2. Enter the phone code, and then press (OK).
You can change the default phone code (1234) to any numeric string
of four to eight digits.
To change the phone code:
1. Select Menu > Settings > Security settings >Change password >
Phone password.
2. Enter the old phone code, and then press (OK).
3. Enter the new phone code, and then press (OK).
4. Enter the new phone code again to confirm it.
8
If you forget the phone code, contact the service provider.
PIN and PUK
The personal identification number (PIN) protects your SIM card from
unauthorized use. The PIN unblocking key (PUK) unlocks a blocked
PIN. Both the PIN and the PUK are provided with the SIM card. For
details, contact your service provider.
To enable the PIN lock:
1. Select Menu > Settings > Security settings > SIM security
settings >SIM lock.
2. Enter the PIN, and then press (OK).
3. If you enter an incorrect PIN a pre-defined number of consecutive
times, the phone prompts you to enter the PUK.
4. If you enter an incorrect PUK a pre-defined number of
consecutive times, the SIM card becomes permanently invalid. In
that case, contact your service provider for a new SIM card.
Locking the Keypad
To lock the keypad, press and hold in standby mode for 3s. To
unlock the keypad, press (Unlock) and then .
If the Auto keypad lock function is enabled and if the phone is in
standby mode for a preset period, the phone locks the keypad
automatically.
To enable the Auto keypad lock function, select Menu > Settings >
Security settings >Auto keypad lock, scroll to a period, and then
press (OK) to select the period.
When the keypad is locked, you can press to answer a
call or make an emergency call.
