Quick Start Guide

MRD-LX1N

华为信息资产

仅供TÜV Rheinland 公司使用

严禁扩散

Know Your Device

Before using the device, familiarize yourself with its basic

operations.

lTo power on your device, press and hold the power button

until the screen turns on.

lTo power off your device, press and hold the power button,

and then touch .

lTo restart your device, press and hold the power button,

and then touch .

lPress and hold the power button for 10 or more seconds to

forcibly restart your device.

NFC

Headset jack Micro-USB port

Tips App Power button

Volume button

lCheck out the pre-installed Tips app and master all the

great features on your device.

华为信息资产

仅供TÜV Rheinland 公司使用

严禁扩散

Getting Started

Do not insert or remove the SIM card when your device

is powered on.

Ensure that the card is correctly aligned and that the

card tray is level when you insert it into your device.

Be careful not to scratch your device or hurt yourself

when using the eject pin.

Store the eject pin out of the reach of children to

prevent accidental swallowing or injury.

Do not use cut or SIM or microSD cards with

your device as these may not be recognized and could

damage the card tray (slot).

If your SIM card does not match your device, please

contact your carrier.

Follow the instructions in the following to set up your

device. Please use the eject pin included.

华为信息资产

仅供TÜV Rheinland 公司使用

严禁扩散

Dual Card Dual Standby Single

Pass (dual-SIM devices only)

Your device supports only dual card dual standby single pass,

which means you cannot use both SIM cards for calls or data

services simultaneously.

lWhen you are on a call using SIM card 1, SIM card 2 cannot

be used to make or answer calls. If someone calls SIM card

2, the caller will hear a voice message similar to "The

subscriber you dialed is out of the service area" or "The

subscriber you dialed cannot be connected for the moment,

please try again later." The actual message will vary by

service provider.

lWhen you are using SIM card 1's data service, SIM card 2's

data service will be disabled.

Your device's single pass feature helps reduce power

consumption and increase your device's standby time. It is not

related to your service provider's network conditions.

lYou can enable call forwarding between SIMs on the

device to avoid missed calls.

华为信息资产

仅供TÜV Rheinland 公司使用

严禁扩散

For More Information

If you encounter any problems while using your device, you

can obtain help from the following resources:

lVisit http://consumer.huawei.com/en to view device

information, frequently asked questions and other

information.

lVisit http://consumer.huawei.com/en/support for the most

up-to-date contact information for your country or region.

Go to Settings and touch System > About phone > Legal to

view legal information for your product.

Go to Settings and touch System > About phone > Legal >

Safety information to view safety information for your

product.

Go to Settings and touch System > About phone >

Authentication info to view regulatory information for your

product.

Go to Settings and touch System > Certication logos to

view more information on certication logos for your product.

All pictures and illustrations in this guide, including but

not limited to the device color, size, and display content,

are for your reference only. The actual device may vary.

Nothing in this guide constitutes a warranty of any kind,

express or implied.

华为信息资产

仅供TÜV Rheinland 公司使用

严禁扩散

Safety Information

Please read all of the safety information carefully before using

your device to ensure its safe and proper operation and to

learn how to dispose of your device properly.

Operation and safety

l To prevent possible hearing damage, do not

listen at high volume levels for long periods.

lUsing an unapproved or incompatible power adapter,

charger, or battery may damage your device, shorten its

lifespan, or cause a re, explosion, or other hazards.

lIdeal operating temperatures are 0 °C to 35 °C. Ideal

storage temperatures are -20 °C to +45 °C.

lPacemaker manufacturers recommend that a minimum

distance of 15 cm be maintained between a device and a

pacemaker to prevent potential interference with the

pacemaker. If using a pacemaker, hold the device on the

side opposite the pacemaker and do not carry the device in

your front pocket.

lKeep the device and the battery away from excessive heat

and direct sunlight. Do not place them on or in heating

devices, such as microwave ovens, stoves, or radiators.

lObserve local laws and regulations while using the device.

To reduce the risk of accidents, do not use your wireless

device while driving.

lWhile ying in an aircraft or immediately before boarding,

only use your device according to instructions provided. Use

of a wireless device in an aircraft may disrupt wireless

networks, present a hazard to aircraft operation, or be

illegal.

lTo prevent damage to your device's parts or internal

circuits, do not use it in dusty, smoky, damp, or dirty

environments or near magnetic elds.

lWhen charging the device, make sure the power adapter is

plugged into a socket near the devices and is easily

accessible.

lUnplug the charger from electrical outlets and the device

when not in use.

lDo not use, store or transport the device where ammables

or explosives are stored (in a gas station, oil depot, or

华为信息资产

仅供TÜV Rheinland 公司使用

严禁扩散

chemical plant, for example). Using your device in these

environments increases the risk of explosion or re.

lDispose of this device, the battery, and accessories

according to local regulations. They should not be disposed

of in normal household waste. Improper battery use may

lead to re, explosion, or other hazards.

Disposal and recycling information

The crossed-out wheeled-bin symbol on your product, battery,

literature or packaging reminds you that all electronic products

and batteries must be taken to separate waste collection

points at the end of their working lives; they must not be

disposed of in the normal waste stream with household

garbage. It is the responsibility of the user to dispose of the

equipment using a designated collection point or service for

separate recycling of waste electrical and electronic equipment

(WEEE) and batteries according to local laws.

Proper collection and recycling of your equipment helps ensure

electrical and electronic equipment (EEE) waste is recycled in a

manner that conserves valuable materials and protects human

health and the environment, improper handling, accidental

breakage, damage, and/or improper recycling at the end of its

life may be harmful for health and environment. For more

information about where and how to drop off your EEE waste,

please contact your local authorities, retailer or household

waste disposal service or visit the website http://

consumer.huawei.com/en/.

Reduction of hazardous substances

This device and its electrical accessories are compliant with

local applicable rules on the restriction of the use of certain

hazardous substances in electrical and electronic equipment,

such as EU REACH, RoHS and Batteries (where included)

regulations. For declarations of conformity about REACH and

RoHS, please visit our web site http://consumer.huawei.com/

certication.

EU regulatory conformance

Body worn operation

The device complies with RF specications when used near

your ear or at a distance of 0.50 cm from your body. Ensure

that the device accessories, such as a device case and device

华为信息资产

仅供TÜV Rheinland 公司使用

严禁扩散

holster, are not composed of metal components. Keep the

device away from your body to meet the distance requirement.

The highest SAR value reported for this device type when

tested at the ear is

MRD-LX1N 0.33 W/kg

And when properly worn on the body is

MRD-LX1N 1.05 W/kg

Statement

Hereby, Huawei Technologies Co., Ltd. declares that this device

MRD-LX1N is in compliance with the essential requirements

and other relevant provisions of Directive 2014/53/EU.

The most recent and valid version of the DoC (Declaration of

Conformity) can be viewed at http://consumer.huawei.com/

certication.

This device may be operated in all member states of the EU.

Observe national and local regulations where the device is

used.

This device may be restricted for use, depending on the local

network.

Restrictions in the 2.4 GHz band:

Norway: This subsection does not apply for the geographical

area within a radius of 20 km from the centre of Ny-Ålesund.

Frequency Bands and Power

(a) Frequency bands in which the radio equipment operates:

Some bands may not be available in all countries or all areas.

Please contact the local carrier for more details.

(b) Maximum radio-frequency power transmitted in the

frequency bands in which the radio equipment operates: The

maximum power for all bands is less than the highest limit

value specied in the related Harmonized Standard.

The frequency bands and transmitting power (radiated and/or

conducted) nominal limits applicable to this radio equipment

are as follows:

MRD-

LX1N

GSM900:35dBm,GSM1800:32dBm,WCDMA900

/2100:25.7dBm,LTE Band

1/3/7/8/20:25.7dBm,Wi-Fi 2.4G:

20dBm,Bluetooth:10dBm

Accessories and Software Information

Some accessories are optional in certain countries or regions.

Optional accessories can be purchased from a licensed vendor

as required. The following accessories are recommended:

华为信息资产

仅供TÜV Rheinland 公司使用

严禁扩散

Adapters: HW-050100X01 (X represents the different plug

types used, which can be either C, U, J, E, B, A, I, R, Z or K,

depending on your region)

Batteries: HB405979ECW

Earphones: 1293-3283-3.5mm-322、MEND1532B528A02

The product software version is MRD-LX1N: 5.0.1.57

（SP1C900E64R1P3）. Software updates will be released by the

manufacturer to x bugs or enhance functions after the

product has been released. All software versions released by

the manufacturer have been veried and are still compliant

with the related rules.

All RF parameters (for example, frequency range and output

power) are not accessible to the user, and cannot be changed

by the user.

For the most recent information about accessories and

software, please see the DoC (Declaration of Conformity) at

http://consumer.huawei.com/certication.

FCC Regulatory Compliance

Body worn operation

The device complies with RF specications when used near

your ear or at a distance of 1.50 cm from your body. Ensure

that the device accessories, such as a device case and device

holster, are not composed of metal components. Keep the

device away from your body to meet the distance requirement.

Certication information (SAR)

This device is also designed to meet the requirements for

exposure to radio waves established by the Federal

Communications Commission (USA).

The SAR limit adopted by the USA is 1.6 W/kg averaged over

one gram of tissue. The highest SAR value reported to the FCC

for this device type complies with this limit.

The highest SAR value reported to the FCC for this device type

when using it at the ear is

MRD-LX1N 0.66 W/kg

And when properly worn on the body is

MRD-LX1N 0.47 W/kg

And when using the Wi-Fi hotspot function is

MRD-LX1N 0.47 W/kg

FCC statement

This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable

华为信息资产

仅供TÜV Rheinland 公司使用

严禁扩散

protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to

try to correct the interference by one or more of the following

measures:

--Reorient or relocate the receiving antenna.

--Increase the separation between the equipment and receiver.

--Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

--Consult the dealer or an experienced radio/TV technician for

help.

This device complies with Part 15 of the FCC Rules. Operation

is subject to the following two conditions: (1) this device may

not cause harmful interference, and (2) this device must accept

any interference received, including interference that may

cause undesired operation.

Caution: Any changes or modications to this device not

expressly approved by Huawei Technologies Co., Ltd. for

compliance could void the user's authority to operate the

equipment.

华为信息资产

仅供TÜV Rheinland 公司使用

严禁扩散

Inhaltsverzeichnis

Andere Huawei Handy Handbücher

Huawei

Huawei 725 Vodafone Bedienungsanleitung

Huawei

Huawei U5130 Bedienungsanleitung

Huawei

Huawei LYO-L02 Bedienungsanleitung

Huawei

Huawei Y7 Prime TRT-L21A Bedienungsanleitung

Huawei

Huawei Ascend D2 Bedienungsanleitung

Huawei

Huawei Ascend II Bedienungsanleitung

Huawei

Huawei C6000 Bedienungsanleitung

Huawei

Huawei P9 Lite 2017 Bedienungsanleitung

Huawei

Huawei P7-L10 Bedienungsanleitung

Huawei

Huawei Ascend D1 quad XL Bedienungsanleitung

Huawei

Huawei U8950 Betriebsanleitung

Huawei

Huawei C5110 Bedienungsanleitung

Huawei

Huawei G7600 Bedienungsanleitung

Huawei

Huawei ANA-NX9 Bedienungsanleitung

Huawei

Huawei Ascend II M865C Bedienungsanleitung

Huawei

Huawei Y9 2019 Bedienungsanleitung

Huawei

Huawei P30 lite Bedienungsanleitung

Huawei

Huawei U120 Bedienungsanleitung

Huawei

Huawei Honor 9 Bedienungsanleitung

Huawei

Huawei Honor View 10 Bedienungsanleitung

Huawei

Huawei Aero Bedienungsanleitung

Huawei

Huawei Ascend Mate Bedienungsanleitung

Huawei

Huawei U8652-51 Bedienungsanleitung

Huawei

Huawei Honor U8860 Bedienungsanleitung

Beliebte Handy Handbücher anderer Marken

Zte

Zte BLADE A520 Bedienungsanleitung

Nokia

Nokia Lumia 620 Bedienungsanleitung

Blackbe;rry

Blackbe;rry KEYone Bedienungsanleitung

Bea-fon

Bea-fon X5 Premium Bedienungsanleitung

Blackbe;rry

Blackbe;rry 8707 Series Bedienungsanleitung

Blackbe;rry

Blackbe;rry Storm Betriebsanleitung

LG LM-X420QN Bedienungsanleitung

LifeWatch

LifeWatch V Bedienungsanleitung

Bea-fon

Bea-fon SILVER LINE SL860 Bedienungsanleitung

IKI Mobile

IKI Mobile KF4.5i Bedienungsanleitung

Hitech

Hitech HT-850 Bedienungsanleitung

Yezz

Yezz Fashion F10 Bedienungsanleitung

Point Mobile

Point Mobile PM60 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Q10 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Bold 9900 Bedienungsanleitung

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Bedienungsanleitung

LG LM-K420EMW Bedienungsanleitung

ISAFE MOBILE

ISAFE MOBILE IS655.2 Bedienungsanleitung
