Huawei Y7p Bedienungsanleitung

User Guide

Contents

Exciting Features

Featured Usage Tips 1

Camera Tips 2

More Features 5

New Device

New Device Conguration 8

Gestures and Operations

HiVision 10

Screenshots and Screen Recording 11

Split-screen 13

Home Screen

Navigation Bar 16

Use Shortcut Switches to Quickly Enable Frequently Used

Features

Notication Panel and Status Bar 18

Screen Lock and Unlock 20

Go Back to Basics with Simple Mode 22

Home Screen Management 22

Contacts

Share Contacts Using Electronic Business Cards 25

Search Contacts 26

Managing Contacts 26

Dialing

Basic Calling Functions 28

VoLTE 29

Use VoWi-Fi for a New Calling Experience 30

Camera

Basic Camera Functions 31

AI enhanced, Intelligent Photo Scene Identication 33

Use Portrait Mode to Shoot Like a Pro 34

Use Wide Aperture Mode to Highlight Your Shooting Subjects 34

Use Panorama Mode to Take Panoramic Photos 34

Use Pro Mode to Take Scenic Photos 35

Light Painting Mode 36

More Capture Modes 41

Gallery

Photo Management 43

Optimizer

Use Optimize 46

Manage Mobile Data Usage 46

Enable Smart Power Saving 46

Use Auto-launch to Prevent Unwanted App Activities 47

Enable Virus Scanner 47

Add Email Accounts 49

Manage Email Accounts 49

Manage VIP Email Contacts 50

Import Important Events to Calendar 50

Calendar

Navigate the Calendar 51

View Global Holidays 51

Clock

Use the Clock 52

Notepad

Manage Your Notes to Keep Your Records in Order 53

Utilities

Check Your Screen Time 54

Recorder 54

Phone Clone 55

Device Connection

Bluetooth 57

Phone Projection 58

Transfer Data between Your Phone and Computer 59

Huawei Share 60

Security and Privacy

Face Unlock 63

Fingerprint 64

Enable or Disable Location Services 66

Enable App Lock 66

Wi-Fi and Network

Wi-Fi 67

Connecting to the Internet 70

Share Your Mobile Network with Other Devices 70

Contents

Apps and Notications

App Twin: Log In to Two Social Media Accounts at Once 72

Customize App Permissions to Use Your Phone Your Way 72

Sound and Display

Set Up Do Not Disturb Mode 73

Congure the Sound Settings 73

Enable Eye Comfort Mode 74

More Display Settings 74

Storage

Enable Memory Cleanup 76

Smart Assistance

Access Phone Functions from Anywhere with Navigation Dock 77

System

Change Input Method 78

Accessibility 78

General Settings 78

System Update

Update the Phone System Online 81

Legal Notice

Legal Notice 82

Personal Information and Data Security 83

Obtaining help 84

Get More Information 84

Contents

iii

Exciting Features

Featured Usage Tips

Enroll Your Facial Information and Enable Face Unlock

Face unlock allows you to unlock your Phone quickly and securely, without the need of a

password.

•Face unlock can only be used when the owner account is logged in. It is not supported

by PrivateSpace.

•Face unlock is not available if the lock screen password has not been entered for three

or more days in a row, or if your Phone has been remotely locked or restarted.

•When using Face unlock, keep your eyes open, and face your Phone straight on from a

distance of 20–50 cm (about 8–20 in.). In order to scan your face accurately, avoid

using this feature when you are in a dark environment or facing direct light.

1Open Settings. Go to Security & privacy > Face recognition and enter your lock

screen password.

If you haven't set up a lock screen password, set one rst. Besides the 6-digit PIN, you

can set up other types of passwords: Pattern, 4-digit PIN, Custom PIN, or Password.

2Selecting Enable raise to wake will allow the screen to turn on and unlock when you pick

up your Phone and hold it to your face. If you do not need this feature, leave it deselected.

Touch Get started, and enroll your face.

3If you are concerned that face unlock may fail due to a change in appearance after

makeup or a haircut, or you want to enroll an entirely dierent face, go to the Face

recognition screen, touch Set an alternate look and follow the onscreen instructions just

like you did when registering your face initially.

4Face unlock modes:

•Select an unlock method: On the Face recognition screen, touch Unlock device. If

you select Direct unlock, your Phone identies your facial features and unlocks your

screen when the screen is on. If you select Slide to unlock, after your Phone identies

your facial features, you can slide the lock screen to unlock. Selecting O will disable

Face unlock.

•Smart display of lock screen notications: Enable Show notications. On the lock

screen, your Phone hides notication details and displays them only after recognizing

the owner's face.

•Access App lock: Enable Access app lock to access App lock and locked apps using

Face unlock.

Access Phone Functions from Anywhere with Navigation Dock

In order to close an app or return to the home screen, you must use the navigation bar at the

bottom of your Phone. You can enable the Navigation dock feature on your Phone to avoid

using navigation buttons and to comfortably operate your device with one hand.

Open Settings. Go to System > System navigation > Navigation dock and enable

Navigation dock. The Navigation dock will appear on the screen. You can then drag it to

your preferred location. The Navigation dock can perform the following actions:

•Back: Touch the Navigation dock once to go back one step, or touch it twice to go back

two steps.

•Home: Touch and hold the Navigation dock and then release it to go to the home screen.

•View background apps: Touch and hold the Navigation dock and then swipe left or right

to view any apps that are running in the background.

Use Shortcut Switches to Quickly Enable Frequently Used Features

Want to quickly enable or disable mobile data or hotspot? You can enable frequently used

features by using shortcut switches.

Touch the shortcut

switch to enable

the corresponding

feature

Touch and hold to

enter settings

Rearrange shortcut

switches

Camera Tips

AI enhanced, Intelligent Photo Scene Identication

AI enhanced can automatically identify your current photography scene and intelligently

adjust the color and brightness of the photo, so you don't need to repeatedly adjust your

camera for the perfect shot.

AI enhanced is a preset camera feature on your Phone that intelligently identies your

current photography scene and automatically adjusts the color and brightness of your photo

to help you achieve better eects.

AI enhanced provides you with the following features:

•Intelligently identies photographing scenes and improves photo eects: AI enhanced

supports multiple scenes, such as the stage, beach, blue sky, greenery, and text scenes. After

smart identication, AI enhanced automatically adjusts the color and brightness of the

Exciting Features

camera and recommends an optimal mode (such as the portrait, greenery, or text mode) to

improve photo eects.

•Enable AI enhanced to automatically congure and adjust camera settings: When you

open the camera and enter Standard camera mode, touch

to enable AI enhanced as

required. Once enabled, this feature will intelligently identify the photography scene, which

saves you the trouble of repeated manual adjustments.

•AI enhanced is automatically disabled when you switch to Portrait mode, Wide

aperture mode, or Moving picture mode.

Use Portrait Mode to Shoot Like a Pro

Go to Camera > Portrait, adjust the following settings, then touch to take a portrait.

•Blur and lighting eects: Touch the icon in the viewnder and select a blur or lighting

eect.

A light source (such as a neon or street light) in a relatively well-lit background will

contribute to better results. Taking photos at long distance will reduce the eect.

•Beauty eect: Touch in the viewnder and drag the slider to adjust beauty settings. A

larger value will produce a more distinct beauty eect.

To disable the beauty eect, touch the icon in the viewnder and drag each setting

to its lowest value.

Use Panorama Mode to Take Panoramic Photos

Panoramas provide a wider viewing angle than ordinary photos, letting you take sweeping

landscape shots.

To capture a panorama shot, the camera takes multiple photos of objects within our visual

eld and stitches them together into a single photo.

When taking a panorama, nd a wide, open space that is some distance away from the

subject and try to avoid backgrounds that are all in one color.

1Go to Camera > More > Panorama.

2Touch at the bottom of the screen to congure the shooting direction.

3Hold your Phone steady, and then touch to start shooting. Slowly move the Phone in

the direction indicated, holding the device steady and ensuring that the arrow stays level

with the center line.

4Touch when you are nished. The camera will automatically stitch the photos

together to create a panorama.

Exciting Features

Use Pro Mode to Take Scenic Photos

Go to Camera > More > Pro.

Adjust metering based on the subject of the shot: On the Pro mode screen, touch and

select a metering mode accordingly.

Metering Mode Application Scenario

Matrix The subjects are broad landscapes and seas.

Center The subject is in the center and stands out from the

background.

Spot The subject to be highlighted is relatively small, such as a

ower or a tree.

Adjust brightness based on the shooting environment:

•Adjust ISO: On the Pro mode screen, touch and adjust the slider.

To avoid excessive image noise, an ISO value below 400 is recommended. The

recommended ISO value for the daytime is between 100 to 200, but may exceed 400

for some night scenes.

•Adjust shutter speed: On the Pro mode screen, touch (shutter speed) and adjust the

slider.

The recommended shutter speed for static scenes (such as mountains) is between 1/80

and 1/125 of a second. For moving scenes (such as waves), select a relatively fast

shutter speed and use a tripod for best results.

•Adjust EV compensation: On the Pro mode screen, touch

and adjust the slider.

Adjust AWB: On the Pro mode screen, touch

"8#

and adjust the slider.

Exciting Features

•When shooting in bright sunlight, select . In low light environments, select .

•Touch



to adjust the color temperature. If you want to give your photo a warm,

cozy, nostalgic tone, increase the K value. For a cool, calm, or futuristic tone, reduce the

K value.

Select Focus mode based on the subject of the shot: On the Pro mode screen, touch

and adjust the slider.

Focus Mode Application Scenario

AF-S mode Static scenes (such as mountains)

AF-C mode Moving scenes (such as owing water and waves)

MF mode Protruding objects (such as a close-up of a ower)

Keep your device steady when shooting: On the Pro mode screen, touch and enable

Horizontal level. A horizontal guiding line will appear on the viewnder. If a dotted line

appears, the camera is not yet parallel with the horizontal level. When the dotted line

overlaps with the solid line, the camera is now parallel with the horizontal level.

•In Pro mode, changing a specic setting will sometimes cause other settings to change

as well. Adjust them according to your actual requirements.

•The recommended settings above are for reference only. Adjust them according to

actual usage conditions to achieve your desired eect.

More Features

Enable App Lock

App lock allows you to set a password for your important apps. Once you restart your Phone

or unlock the screen, you will be asked to enter your App lock password when opening these

apps. App lock adds an extra layer of protection for your private information and prevents

unauthorized access to important apps on your Phone.

Enable App lock: Open Settings. Go to Security & privacy > App lock. When you rst

access App lock, select Lock screen password or Custom PIN as your App lock verication

password. Enter your password as prompted and on the App lock screen, toggle on the

switch for the apps you want to lock.

Set your App lock password: Touch on the App lock screen, then touch Password type.

Select Lock screen password or Custom PIN.

Set Your Home Screen Wallpaper

Tired of default wallpapers? Set a photo you like as your home screen wallpaper to

personalize your home screen.

Exciting Features

Open Settings, and then go to Home screen & wallpaper > Wallpaper. You can:

Set a picture as your home screen wallpaper: Touch Gallery or select a preset wallpaper in

your device, and follow the onscreen instructions to select Lock screen, Home screen or

Both.

Set a photo as your wallpaper from Gallery: Have a great photo you want to set as your

wallpaper? In Gallery, open the photo that you like, go to > Set as > Wallpaper,

and follow the onscreen instructions to set the photo as your home screen wallpaper.

Manage Your Home Screen Widgets

Want to quickly add widgets such as screen lock, weather, notepad, clock, contacts, or

calendar to your home screen? You can add, move or delete home screen widgets to tidy up

your home screen and ease your usage experience.

Add widgets: Pinch in with your ngers on the home screen to enter home screen editing

mode. Touch Widgets, touch and hold a widget and drag it to an empty area on the home

screen, or touch the widget you want.

Check that there are enough empty spaces on the home screen for the widget. If there is

not enough space, add an empty screen page or free up some space on the current home

screen page.

Delete widgets: Touch and hold a widget on the home screen until your Phone vibrates, and

then select Remove.

Move widgets: Touch and hold a widget on the home screen until your Phone vibrates. Drag

the widget to any position on the screen.

Use App Drawer to Store Apps

Want to store your apps in one location on your home screen to make your home screen

look cleaner? You can enable app drawer on your home screen to store all your apps and free

up space on your home screen.

Open Settings, go to Home screen & wallpaper > Home screen style, and select

Drawer. If you want to switch back to a standard home screen, select Standard.

Add an app icon from app drawer to the home screen: After you enable app drawer,

touch on the home screen to enter the app list. From the app list, touch and hold

the app icon that you want to add until your Phone vibrates, and then drag it to the

desired position on the home screen.

Enable Memory Cleanup

Your Phone may slow down over time as your storage space gets smaller. Use Memory

cleanup to free up storage space, improve system performance, and keep your Phone running

smoothly.

Exciting Features

Andere Handbücher für Y7p

Inhaltsverzeichnis

Andere Huawei Handy Handbücher

Huawei

Huawei MAO-LX9 Bedienungsanleitung

Huawei

Huawei M886 Bedienungsanleitung

Huawei

Huawei H892L Bedienungsanleitung

Huawei

Huawei DRA-LX3 Bedienungsanleitung

Huawei

Huawei Honor 7X Bedienungsanleitung

Huawei

Huawei NEN-LX1 Bedienungsanleitung

Huawei

Huawei M328 Bedienungsanleitung

Huawei

Huawei Ascend D1 quad XL Bedienungsanleitung

Huawei

Huawei Y7 2019 Duos Bedienungsanleitung

Huawei

Huawei C8655 Bedienungsanleitung

Huawei

Huawei Y5II Bedienungsanleitung

Huawei

Huawei Y7 Prime TRT-L21A Bedienungsanleitung

Huawei

Huawei U1300 Bedienungsanleitung

Huawei

Huawei P40 Pro+ Bedienungsanleitung

Huawei

Huawei Ascend G750 Bedienungsanleitung

Huawei

Huawei U8220 Bedienungsanleitung

Huawei

Huawei U8815-51 Bedienungsanleitung

Huawei

Huawei Y3 II Bedienungsanleitung

Huawei

Huawei Ascend Y550 Bedienungsanleitung

Huawei

Huawei C2857 Bedienungsanleitung

Huawei

Huawei honor COR-L29 Bedienungsanleitung

Huawei

Huawei P50 Pocket Bedienungsanleitung

Huawei

Huawei C7300 Bedienungsanleitung

Huawei

Huawei Y3 Lite Bedienungsanleitung

Beliebte Handy Handbücher anderer Marken

Zte

Zte BLADE A520 Bedienungsanleitung

Nokia

Nokia Lumia 620 Bedienungsanleitung

Blackbe;rry

Blackbe;rry KEYone Bedienungsanleitung

Bea-fon

Bea-fon X5 Premium Bedienungsanleitung

Blackbe;rry

Blackbe;rry 8707 Series Bedienungsanleitung

Blackbe;rry

Blackbe;rry Storm Betriebsanleitung

LG LM-X420QN Bedienungsanleitung

LifeWatch

LifeWatch V Bedienungsanleitung

Bea-fon

Bea-fon SILVER LINE SL860 Bedienungsanleitung

IKI Mobile

IKI Mobile KF4.5i Bedienungsanleitung

Hitech

Hitech HT-850 Bedienungsanleitung

Yezz

Yezz Fashion F10 Bedienungsanleitung

Point Mobile

Point Mobile PM60 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Q10 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Bold 9900 Bedienungsanleitung

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Bedienungsanleitung

LG LM-K420EMW Bedienungsanleitung

ISAFE MOBILE

ISAFE MOBILE IS655.2 Bedienungsanleitung
