Huawei HG523a Bedienungsanleitung

HUAWEI HG523a Home Gateway

User Guide

HUAWEI TECHNOLOGIES CO., LTD.

HUAWEI HG523a Home Gateway

V100R001

User Guide

Issue 01

Date 2011-11-11

Part Number 202456

Huawei Technologies Co., Ltd. provides customers with comprehensive

technical support and service. Please feel free to contact our local office

or company headquarters.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website: http://www.huawei.com

Email: terminal@huawei.com

rights reserved.

No part of this document may be reproduced or transmitted in any form or by any means

without prior written consent of Huawei Technologies Co., Ltd.

The product described in this manual may include copyrighted software of Huawei

Technologies Co., Ltd and possible licensors. Customers shall not in any manner

reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse

engineer, lease, assign, or sublicense the said software, unless such restrictions are

prohibited by applicable laws or such actions are approved by respective copyright

holders under licenses.

Trademarks and Permissions

, , and

are trademarks or registered trademarks of Huawei

Technologies Co., Ltd.

Other trademarks, product, service and company names mentioned are the property of

their respective owners.

Notice

Some features of the product and its accessories described herein rely on the software

installed, capacities and settings of local network, and may not be activated or may be

limited by local network operators or network service providers. Thus the descriptions

herein may not exactly match the product or its accessories you purchase.

Huawei Technologies Co., Ltd reserves the right to change or modify any information or

specifications contained in this manual without prior notice or obligation.

NO WARRANTY

THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS’’. EXCEPT AS

REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER

EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR

CONTENTS OF THIS MANUAL.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE

SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL,

INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS,

BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.

Import and Export Regulations

Customers shall comply with all applicable export or import laws and regulations and will

obtain all necessary governmental permits and licenses in order to export, re-export or

import the product mentioned in this manual including the software and technical data

therein.

Contents

1Warnings and Precautions ....................................................................... 1

2Connecting the Cables and Getting Started............................................ 4

2.1 Connecting One Telephone ..........................................................................4

2.2 Getting Started .............................................................................................5

3Setting the Network-Access Parameters ................................................. 5

3.1 Accessing the Network through the Embedded PPP Dial-Up Software on the

HG523a ...............................................................................................................5

3.2 Accessing the Network through the PPP Dial-Up Software on Your

Computer .............................................................................................................6

4Configuring the Wireless Network Connection...................................... 7

4.1 Setting Up a Wireless Connection Through the WPS Button ......................7

4.2 Setting Up a Wireless Connection Manually................................................8

5Configuring the HG523a ........................................................................ 10

5.1 Changing the Administrator Password Used for Logging In to the

Web-Based Configuration Utility ......................................................................10

5.2 Enabling or Disabling the Wireless Network Function ..............................10

5.3 Changing the Wireless Network Name and the Access Password .............11

5.4 Changing the IP Address Used for Logging In to the Web-Based

Configuration Utility .........................................................................................11

5.5 Restoring Default Settings..........................................................................12

6FAQs......................................................................................................... 12

7Appendix.................................................................................................. 15

7.1 Indicators....................................................................................................15

7.2 Interfaces and Buttons................................................................................17

7.3 Default Settings..........................................................................................17

7.4 Technical Specifications.............................................................................17

1 Warnings and Precautions

Thank you for purchasing the HG523a Home Gateway (hereinafter referred to as the

HG523a).

To use the device properly and safely, read these warnings and precautions carefully

and strictly observe them during operation.

Unless specified, the device described in this section includes the device

and its accessories.

Basic Requirements

During storage, transportation, and operation of the device, keep it dry and prevent

it from colliding with other objects.

Do not dismantle the device. In case of any fault, contact an authorized service

center for assistance or repair.

Without authorization, no organization or individual can change the mechanical,

safety, or performance design of the device.

When using the device, observe all applicable laws and regulations and respect the

legal rights of other people.

Environmental Requirements for Using the Device

Before connecting and disconnecting cables, stop using the device, and then

disconnect it from the power supply. Ensure that your hands are dry during

operation.

Keep the device far from sources of heat and fire, such as a heater or a candle.

Keep the device far from electronic appliances that generate strong magnetic or

electric fields, such as a microwave oven or a refrigerator.

Place the device on a stable surface.

Place the device in a cool and well-ventilated indoor area. Do not expose the device

to direct sunlight. Use the device in an area with a temperature ranging from 0°C to

40°C.

Do not block the openings on the device with any object. Reserve a minimum space

of 10 cm around the device for heat dissipation.

Do not place any object (such as a candle or a water container) on the device. If any

foreign object or liquid enters the device, stop using the device immediately, power

it off, remove all the cables connected to it, and then contact an authorized service

center.

During thunderstorms, power off the device, and then remove all the cables

connected to it to prevent it from getting damaged due to lightning strikes.

Precautions for Using Wireless Devices

The antenna(s) used for this transmitter must be installed to provide a separation

distance of at least 20 cm from all persons.

Do not use the device where using wireless devices is prohibited or may cause

interference or danger.

The radio waves generated by the device may interfere with the operation of

electronic medical devices. If you are using any electrical medical device, contact

its manufacturer for the restrictions on the use of the device.

Do not take the device into operating rooms, intensive care units (ICUs), or

coronary care units (CCUs).

Areas with Inflammables and Explosives

Do not use the device where inflammables or explosives are stored, for example, in

a gas station, oil depot, or chemical plant. Otherwise, explosions or fires may occur.

In addition, follow the instructions indicated in text or symbols.

Do not store or transport the device in the same box as inflammable liquids, gases,

or explosives.

Accessory Requirements

Use only the accessories supplied or authorized by the device manufacturer.

Otherwise, the performance of the device may get affected, the warranty for the

device or the laws and regulations related to telecommunications terminals may

become null and void, or an injury may occur.

Do not use the power adapter if its cable is damaged. Otherwise, electric shocks or

fires may occur.

Ensure that the power adapter meets the specifications indicated on the device

nameplate.

Ensure that the power adapter meets the requirements of Clause 2.5 in

IEC60950-1/EN60950-1 and it is tested and approved according to national or local

standards.

The socket-outlet shall be installed near the equipment and shall be easily

accessible.

Safety of Children

Keep the device and its accessories out of the reach of children. Otherwise, they may

damage the device and its accessories by mistake, or they may swallow the small

components of the device, causing suffocation or other dangerous situations.

Maintenance

If the device is not used for a long time, power it off, and then remove all the cables

connected to it.

If any exception occurs, for example, if the device emits any smoke or unusual

sound or smell, stop using the device immediately, power it off, remove all the

cables connected to it, and then contact an authorized service center.

Do not trample, pull, or overbend any cable. Otherwise, the cable may get damaged,

causing malfunction of the device.

Before cleaning the device, stop using it, power it off, and then remove all the

cables connected to it.

Use a clean, soft, and dry cloth to clean the device shell. Do not use any cleaning

agent or spray to clean the device shell.

2 Connecting the Cables and Getting

Started

2.1 Connecting One Telephone

If your telephone line is used for both the broadband network access and a telephone

connection, take the following figure as a reference for connecting the cables.

1. Power adapter 2. Computer

3. Telephone 4. Splitter

5. Telephone jack on the wall a. Modem interface

b. Phone interface c. Line interface

If the wireless network function is used on the HG523a for the network

access, you do not need to connect the network cable.

2.2 Getting Started

To power on the HG523a, press the ON/OFF button on the side of the HG523a.

After you power on the HG523a, the ADSL indicator blinks (for less than three

minutes), which indicates that the HG523a is being activated. Later, the ADSL

indicator turns solid on. The Power indicator is also solid on, which indicates that the

HG523a is working properly.

3 Setting the Network-Access Parameters

By configuring the HG523a and your computer, you can choose any of the following

methods to surf the Internet:

Accessing the Network through the Embedded PPP Dial-Up Software on the

HG523a

Accessing the Network through the PPP Dial-Up Software on Your Computer

3.1 Accessing the Network through the

Embedded PPP Dial-Up Software on the HG523a

If you select this method for accessing the network, the HG523a starts to set up a

dial-up connection automatically after the startup. You can access the network after you

power on your computer. You do not need to install any special dial-up software on

your computer or perform dial-up operations on your computer. To configure the

HG523a and your computer for the network access, do as follows:

Step 1 Log in to the Web-based configuration utility of the HG523a.

1. Launch the Internet Explorer on your computer. Enter http://192.168.1.1

in the address bar, and then press Enter.

2. In the displayed dialog box, enter the user name and the password, and

then click Login.

By default, both the user name and the password are admin. After the user name and

the password are verified, you can access the Web-based configuration utility.

Step 2 Enable the embedded dial-up function.

1. In the navigation tree on the left of the Web-based configuration utility,

choose Advanced > Basic > WAN.

2. Click New.

Inhaltsverzeichnis

Andere Huawei Tor Handbücher

Huawei

Huawei HG635 Bedienungsanleitung

Huawei

Huawei ICE D-20 EC506 Bedienungsanleitung

Huawei

Huawei HG532c Bedienungsanleitung

Huawei

Huawei EchoLife HG520s Bedienungsanleitung

Huawei

Huawei HG256 Bedienungsanleitung

Huawei

Huawei EchoLife HG520s Bedienungsanleitung

Huawei

Huawei EchoLife HG550 Bedienungsanleitung

Huawei

Huawei RRU3201 Bedienungsanleitung

Huawei

Huawei B311-221 Technische Daten

Huawei

Huawei Sunrise Internet Box 5G Bedienungsanleitung

Huawei

Huawei Echolife EG8245Q Bedienungsanleitung

Huawei

Huawei eSpace IAD208E(M) Bedienungsanleitung

Huawei

Huawei B315s-608 Bedienungsanleitung

Huawei

Huawei HG532e Bedienungsanleitung

Huawei

Huawei eA260 Series Bedienungsanleitung

Huawei

Huawei EchoLife HG532 Bedienungsanleitung

Huawei

Huawei eA380 Bedienungsanleitung

Huawei

Huawei eA660 Series Technische Daten

Huawei

Huawei B311-521 Technische Daten

Huawei

Huawei HG552a1 Bedienungsanleitung

Huawei

Huawei IAD108A Bedienungsanleitung

Huawei

Huawei HG532s Bedienungsanleitung

Huawei

Huawei E960 HSDPA Bedienungsanleitung

Huawei

Huawei HG622 Bedienungsanleitung

Beliebte Tor Handbücher anderer Marken

LST

LST M500RFE-AS Bedienungsanleitung

Kinnex

Kinnex Media Gateway Bedienungsanleitung

2N Telekomunikace

2N Telekomunikace 2N StarGate Bedienungsanleitung

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Bedienungsanleitung

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Bedienungsanleitung

Telsey

Telsey CPVA 500 - SIP Bedienungsanleitung

RTA

RTA 460A-NNA4 Technisches Datenblatt

Shaw

Shaw Gateway HDPVR Bedienungsanleitung

ABB

ABB VSN900 Kurzanleitung

Commander

Commander Pulse Bedienungsanleitung

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Bedienungsanleitung

NETGEAR

NETGEAR C6300BD Bedienungsanleitung

Amit

Amit CDW531AM Bedienungsanleitung

HMS

HMS Netbiter EasyConnect EC150 Bedienungsanleitung

AT&T

AT&T U-verse 3801 Gebrauchs- und Pflegehandbuch

Logic IO

Logic IO RTCU MX2 turbo Bedienungsanleitung

Suttle

Suttle MediaMAX MXM-521 Bedienungsanleitung

RTA

RTA 460MCBC-N2E Technisches Datenblatt
