Huawei E220 Bedienungsanleitung

No part of this manual may be reproduced or transmitted in any form or by any means

without prior written consent of Huawei Technologies Co., Ltd.

Trademarks

and HUAWEI are trademarks of Huawei Technologies Co., Ltd. All other

trademarks mentioned in this manual are the property of their respective holders.

Notice The information in this manual is subject to change without notice. Every effort has been

made in the preparation of this manual to ensure accuracy of the contents, but all

statements, information, and recommendations in this manual do not constitute the

warranty of any kind, expressed or implied.

Table of Contents

Getting Started............................................................................................................................... 1

Computer Configuration Requirements........................................................................................ 1

Preparing E220.............................................................................................................................. 2

Installation Instructions................................................................................................................. 2

Safety Information......................................................................................................................... 5

Thank you for choosing E220 HSDPAUSB

Modem (hereinafter referred to as the E220)

from Huawei.

The E220 provides the following functions:

yInternet accessing

yShort messaging service (SMS)

yContacts

Note: This manual briefly describes the basic

functions of the E220. For further

functions as well as warnings and

precautions, refer to User Manual.

Getting Started

1. Getting to Know the E220

The following figure shows the E220 profile.

USB interface

USIM/SIM card slot

Indicator

Note: The figure is for your reference only.

2. Indicator

This indicator indicates the status of E220.

yOff: The E220 is powered off.

yGreen, Blinking twice every 2.7 seconds: The

E220 is searching for a network or no

network is available.

yGreen, Blinking twice every 2.7 seconds: The

GSM network is normal.

yBlue, Blinking once every 2.9 seconds: The

WCDMA network is normal.

yGreen: GPRS data service is established.

yCyan: HSDPA data service is established.

yBlue: WCDMA data service is established.

3. Computer Configuration

Requirements

To use the E220, configure a computer

according to the following items:

yCentral processing unit (CPU): Pentium 4, 1

GHz or above

yMemory: 128 MB RAM or above

yHard disk: 50 MB or above

yOperating system (OS): Windows XP,

Windows 2000, or Windows Vista

yUniversal serial bus (USB) modem interface:

USB 2.0 full speed

yDisplay resolution: 800 %600 or above

(1024 %768 is recommended)

Note:

yImproper configuration may degrade the

computer performance.

yFor Windows XP, it is recommended to

install patches such as Service Pack 2 or

above.

yFor Windows 2000, it is recommended to

install patches such as Service Pack 4 or

above.

Preparing E220

1) Remove the UMTS subscriber identity

module/subscriber identity module

(USIM/SIM) card slot from the E220.

Then insert the USIM/SIM card into the

card slot, as shown in the following

figure. Make sure that the USIM/SIM

card is fully in place.

2) Insert the card slot into the E220, as

shown in the following figure.

Installation Instructions

The installation procedures of the E220

Manager vary with operating systems (OSs).

Refer to the actual installation instructions

during the installation process.

1. Connecting the E220 with

a Computer

Note: First, power on a computer. Then

connect the E220 with the computer.

Otherwise, the normal installation of the

E220 can be affected.

The following figure is the sketch map of the

data cable.

Auxiliary USB

data cable

Mini-USB

data cable Mini-USB

connector

1) Plug the mini-universal series bus (USB)

connector into the E220.

2) Plug the connectors of the main USB

data cable and the auxiliary USB data

cable into the USB interfaces of the

computer.

3) The OS automatically detects and

recognizes the new hardware and

displays on the status area of the

desktop, indicating that the E220 is

connected to the computer successfully.

2. Installing the E220

Manager

1) Connect the E220 to a computer.

2) The installation wizard automatically

starts. If the installation wizard does not

respond, double-click the AutoRun.exe

file in the driver path to manually install

the E220 Manager.

3) Follow the instructions to install the

E220 Manager.

Note: Do not disconnect the E220 during the

installation process.

4) If the installation succeeds, the shortcut

icon of the Manager appears on the

desktop.

ASSISTANT

POWER

ASSISTANT

POWER

3. Removing the E220

To remove the E220, use the hardware deleting

function of Windows.

1) Double-click on the status area of

the desktop; the "Safely Remove

Hardware" prompt is displayed.

2) Select "Huawei Mass Storage USB

Device" to stop.

3) At the prompt, remove the E220.

Safety Information

Please read the safety information carefully to

ensure the correct and safe use of your wireless

device.

General Recommendations for Use

Always handle your wireless device with care

and keep it in a clean and dust-free place. Do

not expose your wireless device to open flames

or lit tobacco products.

yAlways keep your wireless device dry.

yDo not drop, throw or try to bend your

wireless device.

yDo not paint or scratch your wireless device.

yDo not attempt to disassemble your wireless

device. Doing so will void warranty. Only

authorized personnel are allowed to do so.

yThis product requires a minimum distance of

1.5 cm from the body when in operation.

yKeep your wireless device in normal

temperature. Your wireless device can only

operate between -5ºC and +55 ºC.

yUse approved accessories only. Do not

connect your wireless device to any

incompatible products.

Obey Laws and Regulations

Do not operate your wireless device where it

may be unsafe to do so or where you are

required not to do so.

To deactivate your wireless device, close all

applications using the wireless device first and

then remove the wireless device from your PC.

Obey all local laws, regulations, rules, orders,

signs and notices while using the wireless

device. Signs about the use of mobile phones

should also be obeyed as referring to other

wireless equipment including wireless devices.

Deactivate in Explosive Areas

Deactivate your wireless device where the air is

potentially explosive. It is rare, but your PC

could generate sparks.

Deactivate in Blasting Areas

Deactivate your wireless device where blasting

is in progress. Remote-controlled RF devices

are often used at construction sites to set off

blasting.

Deactivate in Aircrafts

Deactivate your wireless device before

boarding or in any aircraft. Wireless devices

can cause interference in aircrafts.

Deactivate at Hospitals

Obey regulations or rules at hospitals.

Deactivate your wireless device near medical

equipment. Wireless devices can cause

interference to cardiac pacemakers, implanted

defibrillators or other medical equipment.

Deactivate near Hearing Devices

Deactivate your wireless device near hearing

devices. People with hearing aids may

experience interfering noises near wireless

devices.

Recommendations for Children

Do NOT allow children to play with your

wireless device. They could hurt themselves or

others, or could accidentally damage the

wireless device. Your wireless device contains

small parts with sharp edges that may cause an

injury or a choking hazard.

Deactivate While Driving

Do not use the wireless device while driving.

Immunity to Interference

Your wireless device is immune to interferences

caused by audible signals.

Cleaning and Maintenance

yBefore you clean or maintain the wireless

device, close all applications using wireless

device and remove your wireless device from

your PC.

yClean your wireless device with a piece of

soft antistatic cloth.

yIf the wireless device or any of its accessories

does not work, turn to an authorized service

center for help.

Environmental Protection

Observe the local regulations regarding the

disposal of your packaging materials, old

wireless device and its accessories. Please

promote their recycling.

SIM/USIM Cards

While inserting or removing the SIM card,

protect yourself against electrostatic discharge

(ESD). Do not touch the connector of the SIM

card. As a precaution, always make sure that

the wireless device is already in your hand

before you insert or remove the SIM card.

Restart on ESDs

Software will attempt to re-initialize a

connection once a substantial electrostatic

discharge causes the device to reset. If the

software is not operational after an ESD, restart

the modem software application.

Agency/Regulatory Information

The wireless device is approved for use in

many regions of the world. In these regions, the

device meets all radio frequency exposure

requirements. The following approvals and

notices apply in specific regions as noted.

CE Approval (European Union)

The wireless device is approved to be used in

the member states of the EU. Huawei declares

that the wireless device is in compliance with

the essential requirements and other relevant

provisions of the Radio and

Telecommunications Terminal Equipment

Directive 1999/5/EC (R&TTE Directive).

Radio Frequency Exposure

To ensure compliance at all times with the

R&TTE Directive* 1999/5/EC, the wireless

device can be held in the hand but still requires

a minimum distance of 1.5 cm from the body

when in operation. For body-worn use, it must

be suitably mounted so that it is at least 1.5 cm

away from the body. Mounting accessories (for

example, belt clips) cannot be made of metal.

Do not put the wireless device in your pocket.

* The general public RF exposure limits

referenced in the R&TTE Directive are

consistent with the published Guidelines of the

International Commission on Non-Ionizing

Radiation Protection (ICNIRP) 1998. ICNIRP

is a formally recognized non-governmental

organization in Non-Ionising Radiation

Protection for the World Health Organisation

(WHO), the International Labour Organisation

(ILO) and the European Union (EU). For more

information, visit the ICNIRP website at

www.icnirp.de.

Certification Information (SAR)

THIS DEVICE MEETS THE

GOVERNMENT'S REQUIREMENTS FOR

EXPOSURE TO RADIO FREQUENCY

ELECTROMAGNETIC FIELD.

Your wireless device is a low-power radio

transmitter and receiver. When it is running, it

emits low levels of radio frequency energy

(also known as radio waves or radio frequency

fields).

Governments around the world have adopted

comprehensive international safety guidelines,

developed by scientific organizations, e.g.

ICNIRP (International Commission on

Non-Ionizing Radiation Protection) and IEEE

(Institute of Electrical and Electronics

Engineers Inc.), through periodic and thorough

evaluation of scientific studies. These

guidelines establish permitted levels of radio

wave exposure for the public. The levels

include a safety margin designed to assure the

safety of all persons, regardless of age and

health, and to account for any variations in

measurements.

Specific Absorption Rate (SAR) is the unit of

measurement for the amount of radio frequency

energy absorbed by the body when using a

wireless device. The SAR value is determined

at the highest certified power level in

laboratory conditions, but the actual SAR level

of the wireless device while operating can be

well below the value. This is because the

wireless device is designed to use the minimum

power required to reach the network.

All models of Huawei’s wireless device are

designed to meet radio frequency exposure

guidelines such as European Council

Recommendation and Federal Communications

Commission Notice (United States).

European Council Recommendation: Before

a wireless device model is available for sale to

the public, it must be tested according to the

technical standard-EN 50361 and not exceed

the limit established by the European Council

Recommendation: 1999/519/EC for safe

exposure.

The SAR limit adopted by the 1999/519/EC is

2.0 watts/kilogram (W/kg) averaged over ten

gram of tissue. The highest SAR value for this

device type when tested is 1.20 W/kg.

[EN 50361 scope states “This basic standard

applies to any electromagnetic field (EM)

transmitting devices intended to be used with

the radiating part of the equipment in close

proximity to the human ear including mobile

phones, cordless phones, etc. The frequency

range is 300 MHz to 3 GHz. Therefore, the

above text does not address primary use of the

wireless device product.]

Federal Communications Commission

Notice (United States): Before a wireless

device model is available for sale to the public,

it must be tested and certified to the FCC that it

does not exceed the limit established by the

government-adopted requirement for safe

exposure.

The SAR limit adopted by the USA and Canada

is 1.6 watts/kilogram (W/kg) averaged over one

gram of tissue. The highest SAR value reported

to the FCC and IC for this device type when

tested for use is 0.59W/kg. [There is no

reference to the specific reference standard or

its applicability to the intended use of the

product]

FCC Statement

This equipment has been tested and found to

comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable

protection against harmful interference in a

residential installation. This equipment

generates, uses and can radiate radio frequency

energy and, if not installed and used in

accordance with the instructions, may cause

harmful interference to radio communications.

However, there is no guarantee that interference

will not occur in a particular installation. If

Andere Handbücher für E220

Inhaltsverzeichnis

Andere Huawei Modem Handbücher

Huawei

Huawei Beeline E1550 Bedienungsanleitung

Huawei

Huawei EC315 Bedienungsanleitung

Huawei

Huawei SmartAX MT883 Bedienungsanleitung

Huawei

Huawei USB modem Bedienungsanleitung

Huawei

Huawei EchoLife HG556a Montageanleitung

Huawei

Huawei E3372 Bedienungsanleitung

Huawei

Huawei E303 Bedienungsanleitung

Huawei

Huawei B593 Bedienungsanleitung

Huawei

Huawei Vodafone Pocket Wi-Fi 4G Technisches Datenblatt

Huawei

Huawei Airbox Auto Bedienungsanleitung

Huawei

Huawei Broadband E219 Bedienungsanleitung

Huawei

Huawei EchoLife HG8240 Bedienungsanleitung

Huawei

Huawei LTE E8372 Bedienungsanleitung

Huawei

Huawei E2010 Montageanleitung

Huawei

Huawei E397 Bedienungsanleitung

Huawei

Huawei E182E HSPA+ Fehlerbehebungshandbuch

Huawei

Huawei SoftBank 005HW Bedienungsanleitung

Huawei

Huawei SmartAX MT880a Bedienungsanleitung

Huawei

Huawei 4G Dongle Bedienungsanleitung

Huawei

Huawei E156G Bedienungsanleitung

Huawei

Huawei HG532D Bedienungsanleitung

Huawei

Huawei E353S-6 Bedienungsanleitung

Huawei

Huawei E169 Bedienungsanleitung

Huawei

Huawei HiLink K3773 Bedienungsanleitung

Beliebte Modem Handbücher anderer Marken

Davicom

Davicom DM562AP Bedienungsanleitung

EpiValley

EpiValley TATA indicom SXC-1080 Bedienungsanleitung

Zte

Zte WiMAX Bedienungsanleitung

Intelimax

Intelimax MA-2060 Bedienungsanleitung

SMC Networks

SMC Networks D3CM1604V Gebrauchs- und Pflegehandbuch

Telstra

Telstra Wi-Fi 4G Advanced Pro X Bedienungsanleitung

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Bedienungsanleitung

Samsung

Samsung AceLink SAM-335A Bedienungsanleitung

Enfora

Enfora Enabler-G Kurzanleitung zur Einrichtung

iRZ

iRZ ATM2-232 Bedienungsanleitung

Zhone

Zhone 6310 Bedienungsanleitung

Paradyne

Paradyne Hotwire 7976 Bedienungsanleitung

US Robotics

US Robotics 3453C Bedienungsanleitung

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Bedienungsanleitung

Zte

Zte MF823 Bedienungsanleitung

Four-Faith

Four-Faith F1403 Bedienungsanleitung

Sierra Wireless

Sierra Wireless AIRLINK MP595W Bedienungsanleitung

Gemtek

Gemtek WiMAX WIXFBR-103 Bedienungsanleitung
