Huawei E8278 Bedienungsanleitung

1

Thank you for choosing the LTE Mobile WiFi Smart. The

LTE Mobile WiFi Smart allows you to access a wireless

network at high speeds.

Note:

This guide briefly describes the appearance of the LTE Mobile WiFi Smart and the

procedures for using the LTE Mobile WiFi Smart. For details about how to set the

management parameters, see help information on the web management page.

2

Connection Scenarios

Scenario 1: One-device Internet access using

computer

Scenario 2: Multi-device Internet access

using Wi-Fi (connected to a computer)

3

Scenario 3: Multi-device Internet access using Wi-Fi (connected to the power adapter)

4

Getting to Know Your LTE Mobile WiFi Smart

The following figure shows the LTE Mobile WiFi Smart. It is provided only for your reference.

The actual product may be different.

1

5

6

2

3

4

5

USB connector

It connects the LTE Mobile WiFi Smart to a computer.

Wi-Fi indicator

It indicates the status of a Wi-Fi network.

Steady green: A Wi-Fi connection is set up.

Off: The Wi-Fi function is turned off or fails, or the LTE Mobile WiFi Smart has been

removed.

SMS indicator

It indicates the status of an SMS.

Steady green: There are unread messages in your inbox.

Blinking green once every 2s: The message storage is full.

Off: The LTE Mobile WiFi Smart is powered off, there are no unread messages, or the

message storage is not full.

6

2G/3G/LTE indicator

It indicates the LTE Mobile WiFi Smart's status.

Blinking green twice every 2s: The LTE Mobile WiFi Smart is powered on.

Blinking green once every 0.2s: The software of the LTE Mobile WiFi Smart is being

upgraded.

Blinking green once every 2s: The LTE Mobile WiFi Smart is registered with a 2G network.

Steady green: The LTE Mobile WiFi Smart is connected to a 2G network .

Blinking blue once every 2s: The LTE Mobile WiFi Smart is registered with a 3G network.

Steady blue: The LTE Mobile WiFi Smart is connected to a 3G network.

Blinking cyan once every 2s: The USB Stick is registered with a LTE network.

Steady cyan: The USB Stick is connected to a 3G+/LTE network.

Off: The LTE Mobile WiFi Smart is removed.

microSD card slot

It holds a microSD card.

7

SIM card slot

It holds a Subscriber Identity Module (SIM) card.

Getting Started

Installing the SIM Card

1. Slide the cover off.

2. Insert the SIM card into the card slot.

3. Slide the cover back onto the LTE Mobile WiFi Smart until it snaps into place.

8

Inserting the microSD Card

Insert the microSD card into the USB Stick, as shown in the following figure.

Note:

The microSD card is an optional accessory. If it is not provided in the package, you can

buy one yourself.

Ensure that the beveled edge of the SIM card is properly aligned with that of the SIM card

slot and the microSD card is inserted according to the direction as labeled on the microSD

card slot.

9

Do not remove the microSD or SIM card when the card is in use. Otherwise, the card as

well as your USB Stick may get damaged and the data stored on the card may be

corrupted.

Do not use any SIM card that is not standard or is incompatible with the LTE Mobile WiFi

Smart. Otherwise, the card as well as your LTE Mobile WiFi Smart may get damaged and

the data stored on the card may be corrupted.

Using the Power Adapter

Connect the LTE Mobile WiFi Smart to the power adapter's USB port, and connect the power

adapter to a power outlet.

10

Note:

Only use power adapters compatible with the LTE Mobile WiFi Smart and provided by a

designated manufacturer (HW-050200xxW: The first x represents U, E, B, A, or J, depending

on your region. The second x represents generation number.). For details about the specific

adapter model, contact an authorized dealer. Use of an incompatible power adapter or one

from an unknown manufacturer may cause the LTE Mobile WiFi Smart to malfunction, fail,

or could even cause a fire. Such use voids all warranties, whether expressed or implied, on

the product.

The power adapter is an optional accessory. If it is not included in the product package,

purchase one separately.
