Beeline USB-modem

Easy access to the Internet

with a Beeline USB-modem

User Manual

Thank you for choosing

Beeline USB-modem!

It is so easy to connect the modem and access the

Internet that you can do it on your own. Our step-by-

step instruction will help you make sure that you did

everything correctly.

Note:

Detailed description of USB-modem operating rules is in the “Help” section

included in the menu of the Software to be installed in the PC for work with

the modem.

Contents:

Modem information 2

System requirements 3

SIM-card installation 4

Connection of the modem to the computer 5

Recommendations on operating the modem 7

Modem information

USB-modem Model

Huawei E 1550 HSDPA USB-modem

USB-modem packaging arrangement

• USB-modem;

• Beeline SIM-card with a special tariff plan;

• USB extension cord – 20 cm;

• Micro SDcard (option);

• User Manual;

• Warranty Certificate.

Modem Characteristics

• Easy installation;

• High speed while operating on HSDPA and UMTS standards ( up to 3.6 Mbit/sec while

downloading and 384 Kbit/sec while sending).

• Compatibility with EDGE/GPRS/GSM data transfer standards (up to 236 Kbit/sec).

• Work within the range of HSDPA/UMTS at 2100Mhz and EDGE/GPRS/GSM

(850/900/1800/1900 MHz).

• Indication of the connection status and signal power.

• Integrated connector for Micro SD memory cards.

Modem indicator

Modem availability and connection status are always evident for you – it is enough just

to look at the indicator.

Indicator status

Green light double blinking

It blinks in green light once every two seconds

It blinks in blue light once every two seconds

It glows with even green light

It glows with even blue light

It glows with even light-blue light

No indication

Meaning

Searching for the network or SIM-card absence

It is registered in 2G network.

It is registered in 3G network.

Data transfer in 2G network.

Data transfer in 3G network in accordance with UMTS technology.

Data transfer in 3G network in accordance with HSDPA technology.

No electric power supply

System requirements

• Central Processing Unit (CPU): Pentium 4, frequency - 1GHz or higher;

• The random-access memory (RAM) of 128 Mb or higher;

• Operating system (OS): Windows XP Windows 2000, Windows Vista 32 bits,

or Mac OS 10.4. and higher;

• Universal serial bus (USB)of modem interface;

• Free space on the hard disc should be no less than 50 Mb.

• The display resolution should be 800x600 or higher (1024x768 is recommended).

Note to the system requirements:

• Improper configuration of the system may worsen the work effectiveness of your

computer with the modem.

• It is recommended to install the updating package Service Pack 2 or higher for

Windows XP operating system.

• It is recommended to install the updating package Service Pack 4 or higher for Win

dows 2000 operating system.

Data transfer rate indicators

The data transfer rate when using GPRS technology is from 14.4 Kbit/sec up to 115 Kbit/

sec. EDGE technology ensures the data transfer rate up to 384 Kbit/sec. The data transfer

rate depends on remoteness of the base station, loading of data transfer channels, voice

channels, building density, wall materials and weather conditions. On average, in the pro-

cess of using the Beeline USB-modem set, the data transfer rate may reach 200 Kbit/sec.

“Data transfer rate indicators are not the basis for return of the USB-modem set.”

SIM-card installation

Take the holder frame of the SIM-card out of the modem. Then insert the Beeline SIM-

card into the holder frame as shown in the Figure. Make sure that the SIM-card fits right.

After that, insert the SIM-card holder frame into the modem.

Connection of the modem to the computer

Connect the modem USB-connector to any free USB-port of the computer.

Software installation

Beeline USB-modem application’s installation will soon start automatically. In order to

successfully complete the installation, please follow the tips and do not break the con-

nection of the modem with the computer.

If the Beeline USB-modem application’s installation does not start automatically, then

install it manually:

1. Open the window “My computer” by double clicking on the icon “My Computer”

on the desktop. If there is no icon “My Computer” on the desktop, please click on

“Start” in the left lower corner of the screen and find the icon “My Computer” in

the pop-up menu. .

2. Open the disc named Beeline in the window “My computer”.

3. Find AutoRun.exe file in the opened window and run it.

4. After that follow the tips of the installation program and do not break the connection

of the modem with the computer.

Software start

Now you can connect to the Internet network using the «Beeline USB-modem» application.

Open the application using the icon located on your computer’s desktop: double click on it

with the left button of your mouse and select the «Connection» section . During the first

installation of the modem, a message that is necessary to activate your SIM-card will appear

if you use it for the first time. In order to activate the SIM-card, click on the «Activate» key

in the pop-up window. Then click on the «Connect» button. In a few seconds you computer

will be connected to the Internet.

Work in the Internet

On your computer’s desktop, find the browser icon (usually, it is Internet Explorer denoted

by sign ), double click on it with the left button of your mouse, after that enter the

address of the Internet site you need in the field “Address”. For example, www.beeline.kg.

To leave the Internet, click on the «Disconnect» key in the «Connection» section

in the «Beeline USB-modem» application.

Extraction of the USB-modem

1. Close down the «Beeline USB-modem» software.

2. Then double click on in the message area. The dialog box «Safely remove

hardware» will appear.

3. Select the needed device and then click on «Stop».

4. When the message «The device may be safely removed», take the modem out of

the USB port.

Software deletion

Open the menu Start> select the Control Panel > then click on the Add or Remove

Programs> find the Beeline USB-modem program and click on «Remove» in order to

uninstall the program product applications.

Note:

• Before removing the product software, exit it.

• After removal of the application, restart the computer and re-install the application.

Recommendations on operating the modem

• Always handle the modem with care, keep it in places free of dirt and dust. Do not

expose the modem to open flame or burning tobacco products.

• Always keep the modem dry.

• Do not drop the modem, do not throw it and do not try to bend or curve it.

• Do not scratch the modem and do not coat it with paint.

• Do not try to disassemble the modem. If this requirement is violated, the quality

warranty of the device will be annulled. Only the authorized personnel has the right

to do it.

• Keep the minimum distance at 1.5 cm from your body when the modem is working.

• Keep the modem at a normal temperature. The modem can work only at the following

temperatures: from - 5°C to +55°C.

• Use the approved accessories only. Do not connect the modem to incompatible devices.

Work in the Internet

• Do not use the modem in places where it is unsafe to use it or where its use is

prohibited.

• To disconnect the modem, first close all applications which use the modem, and then

disconnect the modem from the computer.

• When using the modem, please comply with all local laws, instructions, guidelines,

regulations, orders, signs and notes. It is also necessary to follow the requirements of

signs related to use of mobile telephones, since they refer to other wireless equipment

including wireless communication devices.

• Disable the modem in places where the atmosphere is potentially explosive. This

happens very rarely, but a computer can generate sparks.

• Disable the modem in places where demolitions are carried out. At construction sites,

they often use radio-controlled remote control devices for demolitions.

• Disable the modem on board the aircraft. Wireless devices can cause interferences

with the aircraft equipment work.

• Disable the modem in medical institutions.

• Comply with the instructions and regulations of medical institutions. Disable themo

dem when you are near a medical institution. Wireless devices can cause interferences

with the work of heart pacemakers, implanted defibrillators and other medical equip

ment.

• Disable the modem near hearing aid devices. People using hearing aid devices may be

exposed to interferences near wireless communication devices.

• DO NOT ALLOW children to play with the modem. They can hurt themselves or other

people or accidentally damage the modem. The modem contains small parts with

sharp edges; one can get hurt or suffocate.

• Do not use the modem while driving a car.

• The modem is insensitive to interferences caused by sound signals.

Troubleshooting

Fault (sign) Possible cause Possible solution

The indicator does not

glow in the modem.

The indicator does not

glow with green or blue

light. The modem did not

find the Beeline network.

There are some connec-

tion errors.

The modem is not con-

nected to the computer’s

USB port.

The power signal is insuf-

ficient.

When connecting the mo-

dem to the USB port there

was no SIM-card.

Check whether the modem

is property connected

to the USB port. If the

modem does not work, try

to connect it to another

USB port.

Bring the modem to the better

reception area (for instance, to

the window). Use the exten-

sion cord.

Disconnect the modem from

the computer. Install a Beeline

SIM-card into the modem and

connect the modem to the

computer.
