Quidway® S3500 Series Security Intelligent Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 1
Quidway® S3500 Series Security Intelligent Switches
Product Specification
Software Specifications
Feature S3528G/S3528P S3552G/S3552P/S3552F S3552F-HI
Performance
Switching
capacity 12.8Gbps 17.6Gbps 17.6Gbps
Switching
Fabirc 32Gbps 32Gbps 32Gbps
Throughput 9.53Mpps 13.1Mpps 13.1Mpps
Layer 2 Switching
MAC Address 12K MAC addresses
Latency <10µs
VLAN 4K VLANs (IEEE 802.1Q)
GVRP (GARP VLAN Registration Protocol)
Support Port-Based VLAN, Protocol-Based VLAN, IP Subnet-Based VLAN
Link
Aggregation Support FE (Fast Ethernet) port aggregation
Support GE (Gigabit Ethernet) port aggregation
Supports maximum of 6 groups aggregation (each group can contain up to eight
FE ports or up to two GE ports)
Traffic control IEEE 802.3x full-duplex flow control
Back pressure flow control for half-duplex
STP/RSTP/
MSTP IEEE 802.1D Spanning Tree Protocol (STP)
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
MCE N/A N/A Support
Layer 3 Switching
IP Routing 512 Route Interfaces
4K IP Router
Static Routing
RIP (Routing Information Protocol), v1 and v2;
supports Split Horizons
OSPF (Open Shortest Path First), v1 and v2;
BGP4 (Boarder Gateway Protocol)
ECMP(Equal Cost Multi-path): 3 paths
512 Route Interfaces
64K IP Router
Static Routing
RIP (Routing Information
Protocol) v1 and v2
supports Split Horizons
OSPF (Open Shortest
Path First) v1 and v2
BGP4 (Boarder Gateway
Protocol)
IS-IS (Intermedia System
Quidway® S3500 Series Security Intelligent Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 2
Feature S3528G/S3528P S3552G/S3552P/S3552F S3552F-HI
- Intermedia System)
ECMP(Equal Cost
Multi-path) : 3 paths
Multicast
256 Multicast Routes
IGMP (Internet Group Management Protocol)
snooping on Layer 2 interfaces
IGMP v1 and v2
GMRP (GARP Multicast Registration Protocol)
PIM-DM (Protocol Independent Multicast-Dense
Mode)
PIM-SM (Protocol Independent Multicast-Sparse
Mode)
2K Multicast Routes
IGMP (Internet Group
Management Protocol)
snooping on Layer 2
interfaces
IGMP v1 and v2
GMRP (GARP Multicast
Registration Protocol)
PIM-DM (Protocol
Independent
Multicast-Dense Mode)
PIM-SM (Protocol
Independent
Multicast-Sparse Mode)
Network
Protocol
DHCP Relay (Dynamic Host Configuration Protocol Relay)
TP (Network Time Protocol)
DHCP Server
DHCP Client
TCP/IP protocol stack
ARP
Resilience VRRP (Virtual Router Redundancy Protocol)
Convergence
Priority
Queues Eight hardware queues per port
QoS (Quality of
Service) / ACL
(Access
Control List)
Support 1K flow rules
Flow-based QoS profiles
Ingress and Egress:
• DSCP (Diffserv Code Point)
• Type of Service (ToS)
• Local precedence: physical port, source/destination MAC address,
VLAN information, Ethernet type, Layer 3 protocol, source/destination
IP address, DSCP, datagram type
Support CAR (Committed Access Rate)
Flow control granularity:
• 8Kbit/s increments
• Rate-limiting based on port
ACLs for traffic classification:
• 128 flows per GE port
• 64 flows per FE port
Quidway® S3500 Series Security Intelligent Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 3
Feature S3528G/S3528P S3552G/S3552P/S3552F S3552F-HI
WRED (Weighted Random Early Detect/Discard)
Support flexible queuing algorithms:
• SP (Strict Priority) Queuing
• WRR (Weighted Round Robin)
• SP + WRR
Security
Network Login
IEEE 802.1X user authentication
Support Portal authentication
SSH v1.5(Secure Shell)
Dynamic VLAN, Guest VLAN
DHCP Relay Security
RADIUS/HWTACACS
PEAP (Protected Extensible Authentication Protocol)/TLS (Transport Layer
Security)
Management
System
Configuration
and
Management
Support CLI (Command Line Interface) configuration mode
Management Support Configuration via the console port
Support Local/remote configuration via Telnet
Support Remote configuration via modem dial-up
Support System configuration with SNMP v1, 2, and 3
Support RMON (Remote Monitoring) v1 1, 2, 3 and 9 groups of MIB
Support Quidway network management system
Support WEB management system
Support Hierarchical alarms
Support System log
Support HGMP (Huawei Group Management Protocol) v2
Support HGMP v1 Server
System
maintenance
Detailed alarm/debug information
Support Ping and Traceroute
Support remote maintenance via Telnet
Support HGMP v1 Server
Hardware Specifications
Port
Configuration S3528G S3552G S3528P S3552P S3552F/S3552F-HI
Fixed ports
(1) 24 10/100M
BASE-TX
Ethernet ports
(2) 1 console
port
(1) 48 10/100M
BASE-TX
Ethernet ports
(2) 1 console
port
(1) 24 10/100m
BASE-TX
Ethernet ports
(2) 1 console
port
(1) 48 10/100M
BASE-TX
Ethernet ports;
(2) 1 console
port
1 console port
Quidway® S3500 Series Security Intelligent Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 4
Port
Configuration S3528G S3552G S3528P S3552P S3552F/S3552F-HI
Extended
Slot
4 GIBC
extended
module slots
4 GIBC
extended
module slots
4 SFP
extended
module slots
4 SFP
extended
module slots
(1) 1*4 GBIC extended
module slots
(2) 6 extended module
slots supporting 3
kinds of FE extended
module with 8 ports
in front
Extended
Module
(1) GBIC-T
(2) GBIC-SX(0.55km)
(3) GBIC-LX(10km)
(4) GBIC-LH30(30km)
(5) GBIC-LH40(40km)
(6) GBIC-ZX70(70km)
(7) GBIC-STACK
(1) SFP-T
(2) SFP-SX(0.55km)
(3) SFP-LX(10km)
(4) SFP-LH30(30km)
(5) SFP-LH40(40km)
(6) SFP-ZX70(70km)
(1) GBIC-T
(2) GBIC-SX (0.55km)
(3) GBIC-LX (10km)
(4) GBIC-LH30 (30km)
(5) GBIC-LH40 (40km)
(6) GBIC-ZX70 (70km)
(7) GBIC-STACK
(8) 8*100Base-TX
(RJ-45) module
(supports 100m)
(9) 8*100Base-FX
(LC) module (multi
mode supports 2km)
(10) 8*100Base-FX
(LC) module
(single mode
supports 15km)
Attribute S3528G/S3528P S3552G/S3552P S3552F/S3552F-HI
Outline dimensions
(mm)（H×W×D）42mm x 436mm x
240mm 42mm x 436mm x
360mm 86mm x 436mm x
390mm
Weight 4kg 5kg 6kg
RPS redundancy power Support Support Support
Maximum system
power consumption 40W 45W 54W
Input voltage AC : 100V～240V , 50/60Hz
DC: -40 ~ -60V
Noise parameter S3528P/G: 52.5dBA
S3552P/G: 53.0Dba
S3552F: 56dBA
Quidway® S3500 Series Security Intelligent Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 5
Attribute S3528G/S3528P S3552G/S3552P S3552F/S3552F-HI
Environment Working temperature: 0°C ~ 45°C
Storage temperature: -40°C ~ 70°C
Relative humidity: 10%~90%, non-condensing
