Quidway®S5100-EI Series Intelligent and Resilient Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://datacomm.huawei.com 1
Quidway®S5100-EI series Intelligent and
Resilient Switches Product Specification
Name S5124P-EI S5148P-EI S5126C-EI S5150C-EI
Fixed port
24 10/100/1000
Mbps electric
ports
4 Gigabit SFP
Combo ports
48 10/100/1000
Mbps electric
ports
4 Gigabit SFP
Combo ports
24 10/100/1000
Mbps electric
ports
4 Gigabit SFP
Combo ports
48 10/100/1000
Mbps electric
ports
4 Gigabit SFP
Combo ports
Extended slot 0 0 2 2
Extended
module
N/A
(1) 1 port stack 10GE Module
(2) 1 port Xenpak 10GE Module
(3) 1 ports XFP 10GE module
Performance
Wire speed
L2 switching
Port Switch
capacity: 48Gbps
Throughput:
35.71Mpps
Port Switch
capacity: 96Gbps
Throughput:
71.42Mpps
Port Switch
capacity: 88Gbps
Throughput:
65.47Mpps
Port Switch
capacity:
136Gbps
Throughput:
101.19 Mpps
Switching
Fabric 48Gbps 96Gbps 88Gbps 136Gbps
Flash 16M 16M 16M 16M
Switching
mode Store and forward
Forwarding
Latency <40µs
Jumbo Frame Support 9K
Attribute S5100-EI
MAC address
table
Address self-learning
IEEE 802.1D standard
Up to 16K MAC addresses
Up to 1k static MAC addresses
Support black hole MAC addresses
VLAN
4k VLAN (IEEE802.1Q)
Voice VLAN
GVRP
Support port-based VLAN
Quidway®S5100-EI Series Intelligent and Resilient Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://datacomm.huawei.com 2
Attribute S5100-EI
Support protocol-based VLAN
Support policy-based VLAN
Stack
For S5100-C-EI only:
Up to 16 units in one stacking group
Stacking bandwidth 40 Gbps
Support HGMP V2 stack
Link
aggregation
Support dynamic aggregation of Gigabit Ethernet (GE) ports
Support dynamic aggregation of 10GE ports
dynamic link aggregation through Link Aggregation Control Protocol (LACP)
Support manual link aggregation
Support static link aggregation
Support up to 25 aggregation groups, each supporting 8 GE or 2 10GE ports
Support load balancing and non-load balancing (when lack of hardware
aggregation resources)
Mirroring
Support traffic mirroring
Support VLAN-based mirroring
Support MAC address–based mirroring Support port mirroring
Support multi-source port mirroring
STP/RSTP
/MSTP
IEEE 802.1D Spanning Tree Protocol (STP)
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
IEEE 802.1s Multiple Spanning Tree Protocol instances (MSTP)
Support intra-domain maximum-weight spanning trees (up 16 spanning tree
instances)
Support STP Root Guard
Support BPDU Guard
Flow control IEEE 802.3x (full duplex)
Back-pressure based flow control (half duplex)
Broadcast storm
suppression Support port-based broadcast storm suppression
QinQ Support VLAN-VPN or double tag
Support port-based QinQ
Support selective QinQ
Multicast
Support 1K multicast MAC addresses
Support Internet Group Management Protocol (IGMP) Snoopingv1/v2
Up to 256 multicast groups in a VLAN, and up 1,024 multicast groups in the
entire system
Support multicast VLANs
Support dropping known multicast packets
Support outbound packet filtering for known multicast packets
Support manual configuration of multicast MAC addresses
Network
Protocol
DHCP Snooping (Dynamic Host Configuration Protocol Snooping)
DHCP Client
ARP (Address Resolution Protocol)
Quidway®S5100-EI Series Intelligent and Resilient Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://datacomm.huawei.com 3
Attribute S5100-EI
NTP (Network Time Protocol)
BOOTP (Bootstrap Protocol)
Convergence
Quality of
service (QoS)/
Access control
list (ACL)
Packet tagging based on 802.1p or DSCP preference
L2~L4 Packet filter providing filtering based on source/destination MAC
address, source/destination IP address, port, protocol, VLAN, VLAN range,
MAC address range, or invalid frame
Mirroring remote ports (Support RSPAN)
Support priority mapping
Support priority marking
Support traffic statistics
Support port trust mode
Each port supports eight queues
Support SP/SDWRR/SP+SDWRR queue scheduling
Support traffic shaping for ports and queues
Support port-based/flow-based rate limiting, with the minimum granularity of 1
kbps
Support numeral-expressed standard ACL
Support numeral-expressed extendedACL
Support numeral-expressed layer 2ACL
Support ACL application
Support real-time update ofACL rules based on time range changes
Security
Network Login
Support hierarchical management and password protection of users
Support Centralized MAC address authentication
Support Port isolation
Support MAC address black hole
Support MAC Address Learning Limit
Prevent unauthorized access to the network by binding of MAC and PORT
Support SSH(Secure Shell) v2
Support Port security
Up to 256 users under a single port
Support port-based and MAC address–based authentication
Support MAC address authentication and Fabric synchronization
Support Trunk port authentication
Support IEEE 802.1X user authentication
Version checking (802.1 X supplicant system)
Guest VLAN
802.1 X PEAP/EAP/TLS/TTLS
802.1X
Automatic QoS
ACL filtering
Uplink speed limiting
AAA & Radius Support AAA authentication
Support RADIUS authentication
Quidway®S5100-EI Series Intelligent and Resilient Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://datacomm.huawei.com 4
Attribute S5100-EI
Management/ Maintenance
System
Configuration
and
Management
Support CLI (Command Line Interface) configuration mode
Support Configuration via the console port
Support Local/Remote configuration via Telnet
Support Remote configuration via modem dial-up
Support System configuration with SNMP v1, 2 and 3
Support HGMP V2
Support RMON (Remote Monitoring) v1, 1/2/3/9 groups of MIBs
Web-based network management
System
Maintenance
and debugging
Detailed alarm/debug information output
Support Ping and Tracert
Support remote maintenance via Telnet Modems and SSH
Support NQA
Support System log
Hierarchical alarm management and alarm filtering
Support DLDP (Device Link Detection Protocol)
Loopback detection on ports
Support VCT(Virtual Cable Test)
Information
center Exporting switch synchronization information
Setting the format of time stamps to be sent to log hosts
Description S5124P-EI S5148P-EI S5126C-EI S5150C-EI
Outline
dimension 43.6 × 260 × 440 mm (1.72 × 10.2 ×
17.3 in.) 43.6 × 300 × 440 mm (1.72 × 11.8 × 17.3
in.)
Weight < 4 kg (< 8.8 lb) 4 kg (8.8 lb) 4 kg (8.8 lb) < 5 kg (< 11 lb)
Power supply
S5100-EI series support bothAC and DC power inputs
AC input:
Rated voltage range: 100 VAC to 240 VAC, 50 Hz or 60 Hz
Max voltage range: 90 VAC to 264 VAC, 47 Hz or 63 Hz
DC input:
Rated voltage range: -48 V to -60 V
Max voltage range: -36 V to -72V
Maximum power
consumption 39 W 78 W 54 W 97 W
MTBF (Years) 22.0 21.1 13.3 12.1
Noise parameter 46.7dBA 50.2dBA 50.1dBA 51.5dBA
Environment Operation temperature: 0°C ~ 45°C
Operating humidity: 5% to 85% non-condensing
Relative humidity: 10% ~ 90%, non-condensing
