Huawei 5G CPE Pro Bedienungsanleitung

Quick Start

Démarrage rapide

Kurzanleitung

Avvio rapido

Snelstartgids

Início rápido

Inicio rápido

Contents

English............................................................................ 1

Français........................................................................ 18

Deutsch.........................................................................36

Italiano......................................................................... 55

Nederlands................................................................... 73

Português..................................................................... 91

Español....................................................................... 109

Product overview

Power button LAN port

LAN/WAN port Power input

Ambient light strip Hi/WPS button

Wi-Fi® indicator 4G signal indicator

5G signal indicator SIM card slot

Reset button

English

Setup

1Make sure you use the correct SIM card.

mini-SIM (2FF) micro-SIM (3FF) nano-SIM (4FF)

2Open the SIM card cover.

SIM Card

3Insert the SIM card gently into the SIM card slot in the

direction shown in the ﬁgure below until it clicks. Then close

the SIM card cover.

SIM Card

lTo remove the SIM card, gently press the SIM card in

until it clicks. The card will automatically pop out.

lDo not insert or remove a SIM card when the router

is running, as this may affect performance or

damage the SIM card.

4Connect the power adapter to the router.

MAIN

DIV

LAN1

LAN2/WAN

The indicators will turn on when the router has successfully

connected to a network.

5G signal indicator

Green: Strong.

Yellow: Moderate.

Red: Weak.

4G signal indicator

Green: Strong.

Yellow: Moderate.

Red: Weak.

If both the 5G signal indicator and 4G signal indicator

are off, it indicates there is no network connection.

Please refer to the FAQs in this guide.

Connecting to your router's Wi-Fi

network

Wi-Fi Password:YYYYYY

Wi-Fi Name:XXXXXXXXX

Wi-Fi Password

Wi-FiPassword：

Wi-FiPassword:

Wi-FiName:

Once the router has connected to a mobile data network, you

can connect your computer or mobile phone to the router's

Wi-Fi network to access the Internet. Please refer to the label

on the bottom of the router for the default Wi-Fi network

name (Wi-Fi Name) and password (Wi-Fi Password).

lWhen the Wi-Fi indicator is steady on, Wi-Fi is enabled.

To enable or disable Wi-Fi, refer to the router's web-

based management page.

lEnsure that you promptly change the Wi-Fi network

name and password on the web-based management

page to prevent unauthorized access to your Wi-Fi

network. Once you have changed the password, you

will need to reconnect to the router's Wi-Fi network.

Managing your router

You can manage the router using the web-based management

page. Please refer to the label on the bottom of the router for

the default IP address, password and so on.

More information can be found in the web-based

management page.

lEnsure that you promptly change the default login

password for the web-based management page to

prevent unauthorized users from changing the router's

settings.

lYou can also manage your router using the HUAWEI

SmartHome App. Scan the QR code below to

download.

Optional conﬁgurations

The features described in this section are for reference

purposes only. Your router may not support all of these

features.

Connecting computer

You can connect a computer to the router to access the

Internet.

MAIN

DIV

LAN1

LAN2/WAN

Accessing the Internet through an Ethernet port

You can connect the router to a wall-mounted Ethernet port

using an Ethernet cable to connect to the Internet.

Conﬁgure the relevant settings on the web-based

management page before connecting to the Internet through

an Ethernet port. For details, please contact your carrier.
