Huawei HG231f Bedienungsanleitung

Wireless-N Router

Quick Start

Connecting Cables

Thank you for purchasing HUAWEI Wireless-N Router (hereinafter referred to as the router). Take

using an Asymmetric Digital Subscriber Line (ADSL) modem for accessing the Internet as an example,

Figure B shows the method for connecting the router. For details about the connection, see the User

Guide contained in the CD-ROM.

Tip

Figure A and Figure B take the SmartAX MT880d ADSL CPE from Huawei Technologies as an example of

the ADSL modem on the ADSL broadband network.

Installing the Router Support

The following figure shows the method

for installing the router support. The

design of the router support can prevent

you from installing the support on the

router incorrectly. While installing the

router support, make sure that you

insert the two ends of the support in the

correct orientation. You will hear a click

sound if the support is locked into place.

Internet

POWER

LAN

RESET

POWER

LAN

RESET

Internet

PC ADSL ModemLaptopADSL ModemPC

Figure B: Connection after

using the router

Figure A: Connection before

using the router

Getting Started

To power on the router, connect the power adapter to the POWER interface of the router and

then to a power socket. If the router works properly, the indicators on the front panel turn on. The

following table lists the meanings of the indicators.

Conﬁguring the Router

If you configure the router for the first time, you need to configure the router. After logging in to the

Web-based configuration utility, you can use the setup wizard provided by the utility to configure the

router quickly. To configure the router through the setup wizard, do as follows:

Check the connections between your PC and the router and between the router and theStep 1

network access device (such as an ADSL modem) as prompted, ensure that these connections

are proper, and then click Next.

SetStep 2 Connection Type based on your network type, set the other parameters corresponding

to this type, and then click Next.

Set WLAN parameters, and then clickStep 3 Next.

ClickStep 4 Submit.

Tip

For more information about the functions and the configuration of the router, see the User Guide

contained in the CD-ROM.

When it is on, you can infer that the router is connected to the PC over

the Ethernet interface.

When it is on, you can infer that the router is

powered on.

If it is on in white, you can infer that the router is connected to the Internet properly.

If it is on in orange, you can infer that the router needs further conﬁgurations. For

details, see section 4.

If it is on, you can infer that the

WLAN function is enabled.。

Issue: 01 (2010-04-01) Part Number: 201167

THIS DOCUMENT IS FOR INFORMATION PURPOSE ONLY, AND DOSE NOT CONSTITUTE ANY KIND OF WARRANTIES.
