Huawei Maxis Wi-Fi 6 Betriebsanleitung
1
How to use Wi-Fi 6 Router as Wi-Fi 6
EasyMesh
Whole Home Wi-Fi Coverage with mesh Wi-Fi
Get stronger, faster Wi-Fi connection in every room by pairing 2 or more Maxis Fibre.
Step 1
Connect the power cord to the Maxis Wi
-
Fi 6 Router and wall socket. Do the same
for the Maxis Wi
-
Fi 6 EasyMesh.
Turn on the power at the wall and on the
Maxis Wi-Fi 6 Router and
Maxis Wi-Fi 6
EasyMesh.
Take a break for a minute and wait for the indicators to come on.
Connect the Power Cord
Note: Do not access the web page of the Maxis
Wi-Fi
6 EasyMesh after it is
powered on; otherwise, Maxis
Wi-Fi
6EasyMesh will fail to switch to the bridge
mode.
2
Click WLAN/WPS
Wi-Fi 6 Router
1. Make sure
the Maxis Wi-Fi 6 Router and
Maxis
Wi-Fi
6 EasyMesh are powered on
and wait for them to start.
2. Keep a distance 1-2 meters between
Wi-Fi 6
Router and Wi
-
Fi 6 EasyMesh to
avoid interference when pairing.
3. Press the WLAN/WPS button on the Maxis
Wi-Fi
6 EasyMesh for more than 10
seconds, and then release the button.
4. Press the WLAN/WPS button on
Wi-Fi
6 Router for 1-2 seconds. The WLAN
indicator
blinks.
5. Wait for several seconds,
Wi-Fi
6 EasyMesh restarts automatically, and all
indicator
s will turn o.
6. After
Wi
-
Fi
6 EasyMesh restarts, Wi-Fi 6 EasyMesh successfully switches to the
bridge mode and connects to Wi-Fi 6 Router automatically. The Internet indicator
of Wi-Fi 6 EasyMesh will be
steady on
.
7. Place
Wi-Fi
6 EasyMesh in proper position. For details, see Step 3.
Step 3
We recommend selecting locations:
• 1-2 rooms away from your Maxis
Wi-Fi
6 EasyMesh.
• That avoid corners, electronics and metal objects. (like microwaves, fridges)
• That are about halfway between a
Wi-Fi
deadspot and your Maxis
Wi-Fi
6
EasyMesh.
Select the best location for your Maxis Wi-Fi 6 EasyMesh
Click WLAN/WPS
Wi-Fi 6
EasyMesh
Step 2
Connect Maxis Wi-Fi 6 EasyMesh to Maxis Wi-Fi 6 Router
3
Step 4
To restore the device to factory setting, press the reset button in the back of
Wi-Fi
6
Router or Wi
-
Fi 6 EasyMesh
for over 6 seconds.
(using a needle for easier pressing)
The indicators in the front will be blinking temporarily and the device will reboot to
factory settings.
• The previous
Wi-Fi
settings will be reset to factory setting same as the information
of the label at the bottom of device after
pressing the reset button.
- Wi-Fi : SSID, Password
- Web UI : Username, Password
• If you want to keep your previous settings,
please write them here and set them again
after completing factory reset.
Notes : Returning to factory setting
Wi-Fi 6
EasyMesh
Wi-Fi 6 Router
Wi-Fi 6
EasyMesh
Wi-Fi 6
EasyMesh
Connect your mobile phone, pad, or PC to the default Wi-Fi SSID name of Maxis
Wi-Fi
6 Router. To obtain the default SSID and key, check the nameplate at the
bottom of Maxis
Wi-Fi
6 Router.
To better secure your WLAN, promptly change the SSID and key.
Connect to the Wi-Fi Network
Since every home is dierent, we recommend you to try a couple of spots for your
Maxis
Wi-Fi
6 EasyMesh to get the best coverage. Hope the diagrams below helps
with positioning.
4
- Wi-Fi Network
SSID : …………………………………………………………
Password : ……………………………………………………
- WebUI
Username : ………………………………………….….….…
Password : ……………………………………………………
* You can use factory reset if you want to remove the mesh pairing/setting.
Download the Maxis app to manage, optimize and troubleshoot you home Wi-Fi.
Copyright © Huawei Technologies Co., Ltd. 2022. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any
means without prior written consent of Huawei Technologies Co., Ltd.
Looking for more?
Finding the right spot for your Maxis
Wi-Fi
6 EasyMesh can take a couple of tries.
Give these tips a go if you’re having trouble extending
Wi-Fi
coverage throughout
your home.
• Once your Maxis
Wi-Fi
6 Router and Maxis
Wi-Fi
6 EasyMesh are connected for the
rst time, you can safely power the Wi
-
Fi 6 EasyMesh o and move it to another
location in your home.
They will automatically reconnect when both are switched on, if they are in range.
• If the WLAN/WPS indicator on the Wi
-
Fi 6 EasyMesh does not turn on, it may be
too far away from the Router. Bring the Wi
-
Fi 6 EasyMesh closer to the Router and
try again.
• Try to put your Wi
-
Fi 6 EasyMesh away from the ground. (on a shelf or desk if
possible)
• Try to limit the number of walls or obstructions between the Wi
-
Fi 6 EasyMesh and
the Router. Nearby electronics can interfere with Wi-Fi as much as solid walls.
Tips for your experience
