Huawei WiFi Q2 Pro Bedienungsanleitung

Quick Start Guide

Contents

Quick Start Guide ...................................................................... 1

Guide de démarrage rapide ..................................................... 15

Kurzanleitung ........................................................................... 30

Guida di avvio rapido ............................................................... 44

Snelstartgids ............................................................................ 58

Guia de início rápido ................................................................ 73

Guía de inicio rápido ................................................................ 88

Quick Start Guide

After conguring the base router, simply plug the satellite router into

a power supply to access the Internet.

H button Power port

RESET button

(EU version)

LAN port: Connect

to a wired Internet

device, such as a

computer.

WAN port: Connect to optical

modems, broadband modems, etc.

LAN port: Connect to a wired

Internet device, such as a computer.

Indicator

Getting Started

Base router

Satellite router

(UK version)

RESET button

LAN port: Connect

to a wired Internet

device, such as a

computer.

Step 2: Connect the cables

Take out the base router, then connect the Ethernet cable and power supply.

Optical/broadband/cable modem

Wall port

Wall socket

HUAWEI WiFi Q2 Pro

Insert the cable to the

WAN port on the router

Using a power

strip is not

recommended

Internet

from your broadband provider

Do not bundle the Ethernet cable and the power cable together. Otherwise, the router's signal

may be affected.

Search for “HUAWEI SmartHome” in an app store, or scan the QR code below with

your phone to download and install the HUAWEI SmartHome app.

Step 1: Install the HUAWEI SmartHome app

If the HUAWEI SmartHome app is already installed on your phone, make sure you have the

latest version of the app.

Step 3: Set up the base router

Method 1: Congure the router on the SmartHome app

Connect your mobile phone to the router's Wi-Fi

® (no password). Check for the

Wi-Fi name on the bottom of the router.

WiFi

Connected

Open the HUAWEI SmartHome app.

After the app has detected the router,

touch CONFIGURE.

Touch SET UP.

If the prompt box does not appear, touch +.

2 3

CONFIGURE

LATER

SET UP

4If your Internet connection does not require an account and password:

Please skip to the next step.

If you remember your broadband account and password:

Enter your broadband account and password.

If you have forgotten your broadband account and password:

Obtain the broadband account and password from the old router. Take

another Ethernet cable and connect the WAN port of the old router to the

LAN port of the new router.

Or contact your carrier and obtain a broadband account and password.

Step 1

VLAN

Broadband account

Broadband password

CONNECT

RETRIEVE

Step 1 Step 1

VLAN

Broadband account

Retrieving…

Broadband password

Broadband account

Broadband password

CONNECT CONNECT

RETRIEVE

If you need to congure VLAN on your network, contact

your broadband carrier to conrm the VLAN parameters,

and enable the VLAN switch on the screen.

If you need to congure VLAN on your network, contact your broadband carrier to

conrm the VLAN parameters, and enable the VLAN switch on the screen.

Step 2

Wi-Fi name

Wi-Fi password

Use Wi-Fi password

as router password

Prioritize 5 GHz

Network settings

Enable Prioritize 5 GHz: The

2.4 GHz and 5 GHz Wi-Fi

names are the same. You will

automatically connect to the

faster Wi-Fi network.

Reconnect to the router's Wi-Fi to access

the Internet.

If the router cannot be congured on the

app, congure the router on the web-

based management page by following the

instructions in Method 2.

Set a new Wi-Fi name, Wi-Fi password, and management password for the

new router. You can use the Wi-Fi password as the router's management

password.

NEXT NEXT

Method 2: Congure the router on the web-based management page

Connect your mobile phone to the router's Wi-Fi (no password). Check for the

Wi-Fi name on the bottom of the router.

WiFi

Connected

Open the browser and you will be automatically redirected to the web-

based management page (if the page is not displayed automatically, enter

"192.168.3.1" in the browser address bar). Follow the onscreen instructions to

congure the router.

Let's Start

After conguring the base router, plug the satellite router into the room where Wi-

Fi coverage is needed. Wait for approximately two minutes until the indicator turns

steady blue to access the Internet.

Step 4: Connect the satellite router to the power supply

Wall socket

Using a power strip is not recommended

Some power strips have EMI lters that may

prevent the satellite router from accessing the

Internet.
