Hugyfot Pro Bedienungsanleitung
Hugyfot housing for GoPro Hero3
Pro Version
Depth rang
Max 100m
www.hugyfot.com
Step 1: Set up the housing to install the GoPro camera
Step 2: Install the GoPro camera (remove baery and baery lid)
Step 3: Install dummy baery and circuit board
1 2 3
squeeze pull up turn outwards
1 2 3
squeeze push downturn inwards
user manual
Maintenance
- rinse housing aer each dive
- clean and grease main O-rings
prior to each dive
Hugyfot housing for GoPro Hero3
Hugyfot housing for LCD Screen
www.hugyfot.com
Step 4: Install baery in back lid and connect to circuit board
Step 1: Install LCD screen in housing
Step 5: Close latches on both sides together
Step 2: Close latches on both sides together
Camera housing
LCD monitor housing
M6 M6
1/4 Withworth
(tripod)
M6 M6
1/4 Withworth
(tripod)
M6
M4M4
M3
oponal red lter goes here
oponal mount ball goes here
M3
M6 M4M4
oponal mount ball goes here
oponal mount ball goes here
