Human Eyes 3D 360 VR CAMERA Bedienungsanleitung

Table of Content

Proprietary. Humaneyes Technologies 1

Table of Content

2 Proprietary. Humaneyes Technologies

Table of Content

ENGLISH.....................................................................................................................................4

Safety ...................................................................................................................................5

Package Contents ...............................................................................................................8

Description ..........................................................................................................................9

Operation ...........................................................................................................................11

Indications .........................................................................................................................16

Capturing with Your Camera............................................................................................17

Specifications....................................................................................................................19

Warranty.............................................................................................................................20

Regulations and Disposal ................................................................................................23

ESPAÑOL .................................................................................................................................25

Seguridad...........................................................................................................................26

Contenido del paquete......................................................................................................30

Descripción........................................................................................................................31

Funcionamiento.................................................................................................................33

Indicaciones.......................................................................................................................38

Capturar con la cámara ....................................................................................................39

Especificaciones ...............................................................................................................41

Garantía..............................................................................................................................42

Normativas y desecho ......................................................................................................45

FRANÇAIS.................................................................................................................................47

Sécurité ..............................................................................................................................48

Contenu de la boîte...........................................................................................................52

Description ........................................................................................................................53

Utilisation...........................................................................................................................55

Table of Content

Proprietary. Humaneyes Technologies 3

Voyants.............................................................................................................................. 60

Enregistrement avec la caméra....................................................................................... 61

Caractéristiques ............................................................................................................... 63

Garantie............................................................................................................................. 64

Réglementation et élimination......................................................................................... 67

DEUTSCHE ............................................................................................................................... 69

Sicherheit .......................................................................................................................... 70

Lieferumfang..................................................................................................................... 74

Eigenschaften................................................................................................................... 75

Betrieb ............................................................................................................................... 77

Statusanzeigen ................................................................................................................. 82

Aufnahmen mit Ihrer Kamera .......................................................................................... 83

Technische Daten............................................................................................................. 85

Garantie............................................................................................................................. 86

Vorschriften und Entsorgung.......................................................................................... 89

中文 ........................................................................................................................................... 91

安全 .................................................................................................................................... 92

包装内容 ............................................................................................................................. 96

描述 .................................................................................................................................... 97

操作 .................................................................................................................................... 99

指示 .................................................................................................................................. 104

使用摄像机拍摄................................................................................................................ 105

规格.................................................................................................................................. 107

保修 .................................................................................................................................. 108

法规和处置........................................................................................................................ 111

ENGLISH

4 Proprietary. Humaneyes Technologies

ENGLISH

Welcome,

Humaneyes VR Camera is a 3D 360 VR camera – it captures full spherical videos and photos in

stereoscopic 3D. The footage is stitched to a spherical format using proprietary stitching technology

developed for use with the camera.

The camera is provided together with Vuze Camera App and Humaneyes VR Studio.

Vuze Camera App is designed to control the camera remotely and manage media stored on the internal SD

card.

Humaneyes VR Studio edits captured media using spherical editing tools and renders and stitches media

using proprietary stitching technology.

Support and Contact Information

Should you have technical issues concerning the camera please contact us directly:

Humaneyes Technologies

Email to: support@vuze.camera

www.vuze.camera

Date: March 13, 2017

Document #: DOC00001A

Document Revision: Rev_A14

Proprietary. Humaneyes Technologies

Safety

Proprietary. Humaneyes Technologies 5

Safety

Please read the following safety information before using your camera. Attention to these warnings will help

prevent personal injuries and damage to the product.

This camera should be used in a responsible manner for its intended purpose. Humaneyes Technologies

shall not assume responsibility for damages caused by disregarding these safety guidelines.

Before use, please check there are no signs of damage to the camera. If the camera appears damaged, do

not operate it and contact customer service at www.vuze.camera/contact/

The basic safety instructions and the product documentation should be kept in a safe place and passed on

to subsequent users.

The following safety signs and symbols are used in the manual:

Storage, Service, Cleaning and Caring

The camera should be stored at an ambient temperature between -20 to 60 °C (-5 to 140 °F) and relative

humidity under 95%.

Indicates a hazardous situation which, if not avoided, may result in death or injury.

Indicates the possibility of incorrect operation which can result in damage to the product.

Indicates information related to safety or system proper use.

•The camera should be kept out of the reach of children, infants and pets. A strap

or cord wound around a child’s neck may result in asphyxiation.

•Care should be taken of possible loose or broken parts that could cause injury. If

internal components become exposed as a result of damage to the camera do not

touch them and contact customer support immediately.

Safety

6 Proprietary. Humaneyes Technologies

Charger Electrical Safety

We recommend you charge the camera in an ambient temperature from 0° to 30°C

(30 to 85 °F) while the camera is off. We recommend to use the original camera charger under the

suggested operating conditions for optimal charging time.

•When not in use, avoid placing or storing the product in the following places or

under the following conditions:

oExposed to direct sunlight.

oInside a car.

oIn a humid environment or exposed to dust.

•Before cleaning the camera disconnect it completely from the power supply and

make sure the interface panel cover is closed. Use a soft, non-linting cloth to clean

the product. Never use chemical cleaning agents such as alcohol, acetone or

diluents for cellulose lacquers.

•This camera does not contain any user replaceable or serviceable parts. Do not

take apart or attempt to service the camera yourself. The internal battery is not

user replicable. Never remove the cover or any part of the housing of the camera.

In the event of an equipment malfunction, all repairs must be performed either by

Humaneyes Technologies or by an authorized agent. For service information

contact Humaneyes Technologies customer support at www.vuze.camera/contact

•Be careful not to subject the camera to high impact. If the camera was subject to a

fall or other high impact, check the camera carefully for any damage. If any

damage is visible the use of the camera must be stopped immediately.

•This product contains an internal non-replaceable Li-ion polymer battery.

•The following information on electrical safety must be observed, failing to follow these

instructions may lead to electric shock, fire and/or serious personal injury or death.

•Never use the charger if the power cable is damaged. Check the power cable on a

regular basis to ensure that it is in proper operating condition.

•Before charging the camera and plugging the charger into the main power supply,

always ensure that the nominal voltage setting on the charger matches the nominal

voltage of the AC supply network.

•Do not insert the charger plug into electrical outlets that are dusty or dirty. Insert the

plug firmly and all the way into the outlet. Otherwise, sparks that result may lead to fire

and/or injuries.

•Do not insert any metallic or wet objects into the camera interfaces. Only the intended

cable and memory cards should be inserted in the camera interfaces.

Safety

Proprietary. Humaneyes Technologies 7

Operation

The camera operating ambient temperature is 0 to 40 °C (30 to 100 °F) and relative humidity under 95%.

The camera may be operated only under the operating conditions as specified by Humaneyes

Technologies. The camera should not be operated in extreme conditions.

The camera should not be used near dangerous or flammable gasses or in any location where instructed

not to use cameras or connective devices.

When the camera is used for an extended period and/or at high ambient temperature and/or exposed to

direct sunlight it is normal for the camera body to feel warm. Take care when placing the camera on

elevated surfaces and avoid placing it on unstable surfaces.

•Do not overload any outlets, extension cords or connector strips; doing so can cause a

fire or electric shocks.

•Do not insert or remove the plug with wet hands.

•Never remove the cover or any part of the housing of the charger, doing so will expose

circuits and components and can lead to electric shock, injuries, fire or damage to the

product.

•Stop using the camera immediately if it emits smoke or a strange smell, or otherwise

behaves abnormally.

•Avoid overheating the camera. Do not cover or obstruct the airflow around the camera

while operating. Use the camera in ambient temperatures as advised in the

specifications only.

•Do not place the camera on heat-generating surfaces, or near heat emitting devices or

direct flame. Verify that there is sufficient clearance between the product and any other

warm air exhaust.

•Disregarding these guidelines could lead to overheating, possibly resulting in burns or

damage to your camera.

•The camera adheres to the IP64 protection standard and as such is dust tight and

splash proof. This splash protection does not hold if the interface panel cover is open. If

the interface panel cover is open, take extra care to avoid damp environments or

possible liquid penetration and keep clear of dust or other elements that could

penetrate your camera.

•Even when the cover is closed, it is recommended to avoid using the camera in

extremely wet environments.

•If the necessary precautions are not taken you may suffer electric shock or the camera

itself may be damaged, which can also lead to personal injury.

Package Contents

8 Proprietary. Humaneyes Technologies

Package Contents

Check the package contents for damage. If any item is damaged, do not use the camera

and contact support at www.vuze.camera/contact

Description

Proprietary. Humaneyes Technologies 9

Description

3D 360 Camera

Interface Panel

The camera’s Interface Panel, hidden behind the cover, has various interfaces and indicators. These

interfaces are intended for connection to various external devices.

Open the cover to reveal the interface panel.

Standard ¼”-20

tripod socket

Capture button

On/Off button

Interfaces Panel

Lens x8

Microphone x4

Description

10 Proprietary. Humaneyes Technologies

Handle

1. Fold the handle to the open position:

2. Screw the small handle to the tripod socket.

For storage and when not in use, fold the handle flat against the camera.

WiFi On/Off button

Micro SD card slot Micro USB interface Charging/PC

Battery charge status LED

WiFi status LED

Inhaltsverzeichnis

Sprachen:

Andere Human Eyes Digitalkamera Handbücher

Human Eyes

Human Eyes Vuze XR Bedienungsanleitung

Beliebte Digitalkamera Handbücher anderer Marken

Mercury

Mercury 350K Bedienungsanleitung

Pentax

Pentax Optio LS 465 Bedienungsanleitung

Sanyo

Sanyo VPC-S1085 Bedienungsanleitung

GE SMART A1255 Bedienungsanleitung

Point Grey

Point Grey Gazelle Bedienungsanleitung

Nikon

Nikon COOLPIX A Bedienungsanleitung

Pentax

Pentax P-5 Bedienungsanleitung

BlazeVideo

BlazeVideo A280 Bedienungsanleitung

Sony

Sony MCA-20 Bedienungsanleitung

Sony

Sony Alpha DSLR-A290 Bedienungsanleitung

ATIK Cameras

ATIK Cameras One Bedienungsanleitung

CohuHD Costar

CohuHD Costar 3930 Series Bedienungsanleitung

Leica

Leica M10-R Bedienungsanleitung

FujiFilm

FujiFilm FinePix A700 Bedienungsanleitung

Lorex

Lorex LNZ81P25 Series Bedienungsanleitung

GE J1470S Bedienungsanleitung

Sony

Sony A6700 Benutzerhandbuch

Canon

Canon EOS ELAN7 Bedienungsanleitung
