Hyco ZEN ZEN3LLT Bedienungsanleitung

Zen

Boiling Water Tap

ZE 3LLT, ZE 3LHT,

ZE 3LLTP and ZE 3LHTP

Instruction Manual

Version 5.0 Dec 2014

ZEN_Layout 1 30/12/2014 09:06 Page 1

PLEASE READ THESE I STRUCTIO S BEFORE

COMME CI G I STALLATIO . UPO COMPLETIO

OF I STALLATIO E SURE THE I STRUCTIO S ARE

LEFT WITH THE USER/MAI TAI ER OF THE PRODUCT.

Zen Boiling Water Tap

MODELS ZE 3LLT, ZE 3LHT, ZE 3LLTP, ZE 3LHTP

1. I TRODUCTIO

Thank you for purchasing a Hyco Zen Boiling Water Tap. The Zen is a stylish,

modern, time and space saving addition to any kitchen replacing the need for

a traditional kettle, counter top or wall mounted boiling water unit.

Please note the Zen is a storage type heater - it cannot deliver a continuous

flow of hot water.

ZEN_Layout 1 30/12/2014 09:06 Page 2

2. IMPORTA T SAFETY POI TS

ALWAYS SWITCH OFF THE MAI S BEFORE COMME CI G

I STALLATIO .

O LY CO ECT THE HEATER TO A SI GLE PHASE SUPPLY WITH

A MAI S VOLTAGE AS SPECIFIED O THE RATI G LABEL.

THE SUPPLY CORD CA OT BE REPLACED BY THE USER. IF THE

CORD IS DAMAGED THE APPLIA CE SHOULD BE RETUR ED TO

THE MA UFACTURER OR A AUTHORISED SERVICE AGE T FOR

REPLACEME T.

THE HOSES A D PIPES SUPPLYI G THIS HEATER MUST OT COME I

CO TACT WITH A Y FIXED WIRI G OR THE SUPPLY CHORD.

DO OT CARRY THE APPLIA CE BY THE POWER CORD.

A RCD CIRCUIT BREAKER IS STRO GLY RECOMME DED.

THIS U IT DISPE SES BOILI G WATER.

THE TA K U IT MUST BE PLACED O A SOLID SURFACE WHERE IT

WILL OT BE K OCKED OVER CAUSI G DAMAGE TO THE WATER

HOSES OR ELECTRICAL CO ECTIO S.

THE HEATER MUST OT BE USED I A AREA SUBJECT TO FLAMMABLE

VAPOURS SUCH AS PAI T, SOLVE T OR PETROL.

THIS PRODUCT IS OT SUITABLE FOR OUTDOOR USE OR USE I

DAMP CO DITIO S.

DO OT USE I AMBIE T TEMPERATURES EXCEEDI G 30°C.

ALLOW 20MM SPACE AROU D THE TA K TO WALLS FOR COOLI G

AIR CIRCULATIO .

THE HEATER MUST BE FITTED WITH A RELIEF VALVE.

THE RELIEF VALVE MUST BE TESTED REGULARLY TO REMOVE SCALE

DEPOSITS.

ZEN_Layout 1 30/12/2014 09:06 Page 3

WATER MAY DRIP FROM THE PRESSURE RELIEF VALVE, THIS MUST BE

LEFT OPE TO ATMOSPHERE.

THIS APPLIA CE CA BE USED BY CHILDRE AGED 12 A D ABOVE

A D PERSO S WITH REDUCED PHYSICAL, SE SORY OR ME TAL

CAPABILITIES OR LACK OF EXPERIE CE A D K OWLEDGE IF THEY

HAVE BEE GIVE SUPERVISIO OR I STRUCTIO CO CER I G

THE USE OF THIS APPLIA CE I A SAFE WAY.

CHILDRE SHALL OT PLAY WITH THE APPLIA CE.

CHILDRE SHALL OT CLEA OR MAI TAI THE APPLIA CE

WITHOUT SUPERVISIO .

BEFORE CO DUCTI G A Y USER MAI TE A CE THE PRODUCT

SHOULD BE ISOLATED FOR THE ELECTRICAL SUPPLY A D THE OPE

THE TAP U TIL THE WATER RU S COLD.

DO OT MODIFY OR MISUSE THE PRODUCT I A Y WAY OR SERIOUS

I JURY COULD OCCUR.

ZEN_Layout 1 30/12/2014 09:06 Page 4

3. I STALLATIO OVERVEW

Figure 1 below shows the correct installation for models ZE 3LLT, ZE 3LHT,

ZE 3LLTP, ZE 3LHTP.

O LY USE THE SUPPLIED FITTI G, DO OT ATTEMPT TO MODIFY THE

PRODUCT I A Y WAY OR SERIOUS I JURY MAY RESULT.

COMPLETE THE PLUMBI G I STALLATIO BEFORE CO ECTI G

TO ELECTRICITY SUPPLY.

USE THE SUPPLIED EXPA SIO TA K, RELIEF VALVE, HOSES A D TAP.

ORDI ARY PARTS MAY OT TAKE THE HIGH TEMPERATURES WHICH

MAY CAUSE I JURY OR DAMAGE TO PROPERTY.

THE PIPE WORK TO THE RELIEF VALVE SHOULD BE MADE WITH 15MM

COPPER PIPE WITH SOLDERED JOI TS.

THE HOSES A D PIPES SUPPLYI G THIS HEATER MUST OT COME I

CO TACT WITH A Y FIXED WIRI G

THIS WATER HEATER MUST BE FITTED WITH A PRESSURE RELIEF VALVE.

WATER MAY DRIP FROM THE PRESSURE RELIEF VALVE, THIS MUST BE

LEFT OPE TO ATMOSPHERE (A TU DISH IS RECOMME DED) I A

FROST FREE E VIRO ME T.

Mains

To waste

To tank

inlet

White

washer

Black

washer

ZEN_Layout 1 30/12/2014 09:06 Page 5

4. PLUMBI G CO ECTIO S

Step 1 - Tank Positioning

Allow 20mm space around the tank to walls for cooling air circulation.

Position the tank vertically beneath the tap in a position such that the flexible hoses

can comfortably reach the tap and water supply.

E SURE THE FLEXIBLE HOSES DO OT TWIST OR KI K.

Step 2 - Tap Installation

Determine a convenient location to mount the tap. This can be an existing hole in the

sink top (if the sink is particularly thin the large black washer may be needed. The

washer should be placed on the underside of the sink.), or you may choose to drill

another hole (32mm diameter) either through the sink or the counter top.

The tap can be installed on to sink/counter top that is up to 50mm thick.

Place the tap into the hole ensuring the o ring is correctly seated in the

groove on the base of the tap.

While holding the base of the tap, tighten the clamping nut using a basin spanner.

This process is illustrated below.

ZEN_Layout 1 30/12/2014 09:06 Page 6

Step 3 - Connect Tap to Tank

Fit the outlet flexible hose to the connection protruding from the base of the tap

using the supplied washer (white). Be careful not to strip or loosen the ends of the

copper pipe in the base of the tap.

Connect the other ends of the flexible hoses to the back of the heater using the pro-

vided washers.

The lead from the tap connects into the back of the unit just above the inlet and out-

let hoses.

Step 4 Connect to Water S pply

This product must be fitted with a relief valve. Figure 1 shows the recommended

installation. The pipe work to the relief valve should be made with 15mm copper pipe

with soldered joints. Once the installation has been completed as shown in figure 1,

the water can be turned on. Open the tap until water flows from the tap. Close the

tap and check the installation for leaks.

5. ELECTRICAL CO ECTIO

REMI DER - DO OT PROCEED U LESS YOU ARE SURE THE TA K IS

FULL OF WATER. DAMAGE OR PERSO AL I JURY COULD OTHERWISE

RESULT.

Plug unit into 13A switched mains socket ensuring the supply chord does not come in

contact with the flexible hoses or pipe work.

ZEN_Layout 1 30/12/2014 09:07 Page 7

6.OPERATI G THE WATER HEATER A D TAP

THIS APPLIA CE CA BE USED BY CHILDRE AGED 12 A D ABOVE

A D PERSO S WITH REDUCED PHYSICAL, SE SORY OR ME TAL

CAPABILITIES OR LACK OF EXPERIE CE A D K OWLEDGE IF THEY

HAVE BEE GIVE SUPERVISIO OR I STRUCTIO CO CER I G THE

USE OF THIS APPLIA CE I A SAFE WAY.

The unit will power up and begin to heat as soon as the power is turned on.

The status ring on the base of the tap will light up red or green depending on the

temperature of the water in the tank. Red status ring means the water is heating up

and a green status ring means the water is up to temperature and is ready for use.

To open the tap slide the safety catch away from the tap and rotate handle of the tap.

If the status light begins to flash red this means the temperature controller has

detected a fault.

The unit should be isolated from the power supply and the water supply shut off.

For pattern recognition

models (ZE 3LLTP, ZE 3LHTP),

the status ring may be green

and fade on and off slowly,

this indicates the heater

is in a predicted none use

period. To exit this mode

open the tap and allow

water to flow until the

status ring flashes green.

Then the heater will

recover back to boiling

shortly after.

Status ring

Safety catch

Handle

ZEN_Layout 1 30/12/2014 09:07 Page 8

7. DRAI I G

THE U IT MUST BE DRAI ED IF IT MAY BE EXPOSED TO FREEZI G

TEMPERATURES.

To drain:

• Disconnect from the electricity supply by unplugging the heater

• Open the tap until the water runs cold

• Isolate the water supply

• Disconnect the water pipes from the supply and tap.

• Unplug the tap connector lead from the back of the heater

• Pour the water out of the tank over a bucket or sink

• Turn the unit upside down and allow the water to flow out of the tap hose until

the flow stops.

To reassemble the heater, follow the installation instructions.

DO OT CO ECT TO ELECTRICITY SUPPLY WITHOUT RE-FILLI G

TA K AS PER SECTIO 4.

8. MAI TE A CE

BEFORE CO DUCTI G A Y USER MAI TE A CE THE PRODUCT

SHOULD BE ISOLATED FROM THE ELECTRICAL SUPPLY A D THE

OPE THE TAP U TIL THE WATER RU S COLD.

THE RELIEVE VALVE MUST BE REGULARLY TESTED, TO DO THIS TWIST

THE RED CAP U TIL WATER FLOWS FROM THE VALVE. IF THE VALVE IS

SCALED UP IT MUST BE REPLACED.

THE SUPPLY CORD CA OT BE REPLACED BY THE USER. IF THE

CORD IS DAMAGED THE APPLIA CE SHOULD BE RETUR ED TO

THE MA UFACTURER OR A AUTHORISED SERVICE AGE T FOR

REPLACEME T.

CHILDRE SHALL OT CLEA OR MAI TAI THE APPLIA CE WITH

OUT SUPERVISIO .

The tap and water tank can be cleaned with a lint free damp cloth. Do not use any

abrasive or caustic cleaning products as this will damage the surface of the product.

ZEN_Layout 1 30/12/2014 09:07 Page 9

9. SPECIFICATIO S

Model ZE 3LLT, ZE 3LHT, ZE 3LLTP, ZE 3LHTP

Power 1550W

Voltage 230V 50Hz ac

Dimensions (h x w x d) tank 459mm x 220mm x 181mm

Max supply pressure 1MPa

(before pressure reducing valve)

Max supply pressure 0.3MPa

(after pressure reducing valve)

Min supply pressure 0.1MPa

Maximum tank pressure 0.6MPa

Capacity 3L

Ambient operating temperature 5-300C
