Product Instruction Manual
Blade
Automatic Hand Dryer
BLADESL (Silver), BLADEWH (White)
v23.1.1
Overview
Thank you for purchasing a Hyco Blade hand dryer. The Blade is a hands in, high speed,
automatic hand dryer that is suitable for a variety of public washroom applications. It gives
fast dry times, low sound levels and the integral HEPA lter ensures hygienic operation.
Please read and follow these instructions to ensure that installation and operation are as
simple and safe as possible.
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
The appliance must be permanently connected to the electrical supply through an
appropriately rated isolating switch with a contact separation in all poles.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualied persons in order to avoid a hazard.
This appliance should only be installed and maintained by a competent person in
accordance with any local electrical regulations.
Only connect the appliance to an electrical supply that meets the specication
detailed on the rating label.
This appliance is not designed for outdoor use or use in very damp conditions.
Ensure any future maintenance or modications to the appliance complies with the
guidelines in these instructions.
Important Safety Points
2
The appliance is intended for drying hands only; it should not be used for any other
purpose.
To avoid malfunction, do not install the appliance in the following environments:
-Temperatures below -10° C or above 40°C.
-Locations exposed to direct sunlight or strong light.
Ensure the mounting surface is suitable for the weight of the product.
Ensure there are no hidden cables or pipework before commencing any drilling.
Isolate the electrical supply before undertaking any maintenance.
Allow the appliance to cool down before undertaking any maintenance.
Do not use abrasive materials or chemicals to clean this appliance.
Use a soft damp cloth when cleaning, avoid excessive use of liquids.
3
1. Installation Preparation
4
Select Mounting Position
• Select a suitable position to mount the appliance.
• Decide the height of the mounting bracket install. Recommended heights from the
oor to the top of the mounting bracket are:
780 mm - Women
800 mm - Men
To avoid malfunction, do not install the appliance in the following environments:
- Temperatures below -10 ˚C or above 40˚C.
- Locations exposed to direct sunlight or strong light.
Ensure there are no hidden cables or pipework before commencing any drilling.
Ensure the mounting surface is suitable for the weight of the appliance.
Prepare for Mounting
• Using the mounting template supplied, mark and drill the four holes for the
mounting bracket (see Diagram 1).
• Mark and drill the two lower locking screw holes.
• Insert six wall plugs into the holes and secure the mounting bracket rmly with the
supplied screws.
Diagram 1
5
• Make provisions for the electrical wiring (if required) prior to hanging the appliance
onto the mounting bracket.
• Electrical connection is class II
• The appliance is supplied with a pre-wired power cable.
2. Electrical Connection
This appliance should only be installed and maintained by a competent person in
accordance with any local electrical regulations.
The appliance must be permanently connected to the electrical supply through an
appropriately rated isolating switch with a contact separation in all poles.
3. Installation
• Before mounting the appliance onto the mounting bracket, remove the air lter and
drain tank (see Diagram 2).
• Oer the appliance up to the mounting bracket and ensure it engages into the slots
correctly.
• Secure the appliance in its nal mounting position using the two locking screw holes
located at the base of the appliance.
• Ret the air lter and drain tank.
• Check that the appliance is fully secured to the mounting surface upon completion.
6
Diagram 2
4. Operation
• Remove the drain tank to access the power switch which is located at the front,
bottom left of the hand dryer. Ensure power switch is on.
• The appliance has intelligent temperature control - heating element switches o
when ambient room temperature is above 25°C.
Hand Dryer Usage
• Shake o excess water from hands into the sink/ basin prior to inserting them into
the hand dryer.
• The hand dryer will stop working after 25 seconds of continuous operation. Remove
hands fully to reset and re-insert to begin operating again.
Stretch out both hands
and insert them all the
way in.
Pull them back slowly. Repeat as required until
hands are dry.
7
5. Cleaning and Maintenance
This appliance should only be installed and maintained by a competent person in
accordance with any local electrical regulations.
Isolate the electrical supply before undertaking any maintenance work.
Allow the appliance to cool down before undertaking any maintenance.
Do not use abrasive materials or chemicals to clean this appliance.
Use a soft damp cloth when cleaning, avoid excessive use of liquids.
• Routinely check the level of the drain tank and empty as often as required.
• To clean the drain hole, pour a small amount of water down it and clean using the
exible pipe brush supplied.
• Periodically remove and clean the lter. Remove dust and particles with a soft brush
or vacuum cleaner. Wash with clean water and allow to dry before replacing.
8
Drain tank
Fill level
Air lter
Drain hole
9
6. Advanced Information
• The appliance is supplied with a pre-wired power cable.
• If an alternative supply cable is required, remove the terminal block cover and replace
the existing cable.
• Access to the terminal block is gained via the front panel. Remove the drain tank and
lter then remove the 2 screws at the base of the cover.
• Hold the lower part of the front panel and pull up and away.
• The front panel is held by 4 secure brackets which must be pulled away.
This appliance should only be installed and maintained by a competent person in
accordance with any local electrical regulations.
The appliance must be permanently connected to the electrical supply through an
appropriately rated isolating switch with a contact separation in all poles.
Terminal block
Power cable
Clamping plate
10
8. Troubleshooting
Problem Likely Fault(s) Solution
No air ow Is there power to the unit? Ensure power to the unit is on
and the power on/ o switch is
turned on.
No air ow Have hands been inserted
correctly?
Ensure hands are fully inserted.
Air ow once hands are removed Check the sensor is free of dirt or
any other objects.
Clean sensor/ remove objects.
Only cold air ow Is the room temperature above
25°C?
If the room temperature is above
25°C the heating element will
automatically switch o to save
energy.
7. Specication
Model BLADESL BLADEWH
Power 1.6kW 1.6kW
Voltage 230V~ 230V~
Electrical connection Class II Class II
IP rating IP24 IP24
Finish Silver White
Weight 5.8kg 5.8kg
Dimensions (h x w x d) 556 x 296 x 175 mm 556 x 296 x 175 mm
