Hydrofarm RAPTOR Bedienungsanleitung

INSTRUCTION MANUAL

REFLECTOR

Raptor Reflector

Specications:

• Size: 39.5” x 30.5” x 9”

• Weight: 39 lbs.

• Professionally engineered and designed German 95% reectivity hammertone aluminum.

• Four-sided full specular interior coverage for maximum reector efciency.

• Strong, uniform light pattern-ideal for low clearance mounting with optimum light delivery.

• Fully air sealed reector using high quality silicon based foam.

Installation

1. Carefully remove the reector unit from the box, set it aside and prepare the hanging

location with the appropriate light hanger materials. Use caution when installing the Rap-

tor reector. Due to its large size and weight, Hydrofarm recommends hanging the raptor

using heavy duty light hangers or rope ratchets only.

2. To install, remove, or change the grow lamp, allow the lamp and reector to cool com-

pletely, detach any ducting from the ange opposite the socket, and reach through the

opening to access the bulb.

DO NOT ATTEMPT TO REMOVE OR LOOSEN THE LENS FRAME WHEN THE

REFLECTOR IS HANGING

Cleaning the Lens

1. To clean the lens, unplug your ballast from the power source and disconnect the reec-

tor. Wait until your reector has cooled down completely, carefully remove it from the

hanging location and set it lens side up on a stable surface. It is highly recommended to

place a soft towel or cloth between the surface of placement and the reector to prevent

cosmetic damage.

2. Remove the lens frame mounting screws. Clean the lens using an appropriate glass

cleaning solution. Use a warm, mild soap and water solution to clean the surface of the

specular and outside housing of the reector if desired. Dry with a soft towel and/or com-

pressed air. Ensure the reector unit is completely dry before reconnecting to the ballast

and turning on the lamp.
