HydroSure YL21025 Bedienungsanleitung
TWO OUTLET TAP TIMER
1. This timer is only designed for outdoor use to control
sprinklers or irrigation systems for watering, and can
not be used for industrial purposes which in contact
with food, chemicals and pesticides.
2. Operating water pressure is from 0 bar to 8 bars
(0 psi to 116 psi).
3. Use with clean and freshwater only whose
temperature shall be above 1℃ and below 60℃.
4. Protect timer during winter season or freezing
conditions. Remove from tap and drain water inside,
remove batteries and keep indoors.
5. Timer is water resistant, NOT water proof. The timer
must be installed above ground and vertically to the
tap. DO NOT submerge it in water.
6. DO NOT pull the hose while attached to the timer, to
avoid damage to timer.
7. If timer doesnot work, please read through instruction
to double check or contact your store service before
returning to the store.
PROTECT TIMER FROM DAMAGE
1. To start manual watering, set
Run Time to ON
2. To stop manual watering, set
Run Time to OFF
3. When done, set Run Time to
other desired setting
EXAMPLE 3: Now is 6:00 am, your setting is Frequency
=4 and Run Time=15, which means to water for 15
minutes every 4 hours, so timer will start watering at
10:00 am.
Then at 8:00 am, you change the settings to Frequency
=6 and Run Time=15, which means to water for 15
minutes every 6 hours, so the start watering time is
changed into 2:00 pm.
Clock time
6:00AM
Frequency
4hours
Run Time
15minutes
Start watering time
10:00AM
Clock time
8:00AM
Frequency
6hours
Run Time
15minutes
Start watering time
2:00PM
MANUAL WATERING
NINGBO YILIN AGUATECH CO.LTD
www.yilingarden.com
+86-574-87450066/87450069
No.158 Duantang West Rd,Ningbo 315012
EXAMPLE 1: If you want the first watering to start at
7:00 am, then you make settings at 7:00 pm of the day
(12 hours before).
EXAMPLE 2: If you want the first watering to start at
6:00 am, then you make settings at 6:00 am of the day
(24 hours before).
WHEN MAKING CHANGES AFTER INNITIAL SETTINGS:
• Wait for min 3 seconds for timer to validate new
settings after each change, which is indicated by
quick flashing of the led indicator
• Changing Frequency or Run Time will change start
time, which means the next watering time will be
recalculated.
EXAMPLE 1: To water 2 times a day for 15 minutes, set
Frequency to 12 and Run Time to 15. First watering will
start 12 hours after the knobs are set.
EXAMPLE 2: To water 1 time a day for 30 minutes, set
Frequency to 24 and Run Time to 30. First watering will
start 24 hours after the knobs are set.
