Hyper HYPERDRIVE NEXT Bedienungsanleitung
HYPERDRIVE®NEXT
10 Port Business
Class USB-C®Dock
USER GUIDE
Safety Instructions 1
Copyright 1
Trademarks 1
Regulatory Compliance 2
FCC Conditions 2
CE 2
WEEE Information 2
Introduction 3
Package Contents 3
Requirements 3
Product Compatibility 3
Operating System 3
Product Overview 4
Specifications 5
Warranty 6
Safety Warnings 8
Compatibility 8
Technical Support 9
Table of Contents
1
Before attempting to connect, operate or adjust
this product, please save and read the User Guide
completely. The style of the product shown in this
User Guide may be dierent from the actual unit due
to various models.
Copyright
This document contains proprietary information protected
by copyright. All rights are reserved. No part of this guide
may be reproduced by any mechanical, electronic or
other means, in any form, without prior written permission
of the manufacturer.
Trademarks
Hyper, the ++Hyper logo, and HyperDrive are trademarks
or registered trademarks of Targus International LLC
in the U.S. and in certain other countries. USB-C is a
registered trademark of USB Implementers. MacBook is a
trademark of Apple Inc., registered in the U.S. and other
countries. All trademarks and registered trademarks are
the property of their respective owners or companies.
© 2023 Targus International LLC,1211 North Miller Street,
Anaheim, CA 92806 USA. All rights reserved.
2
Regulatory Compliance
FCC Conditions
This equipment has been tested and found to comply
with Part 15 Class B of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not
cause harmful interference. (2) This device must accept
any interference received and include interference that
may cause undesired operation.
CE
This equipment is in compliance with the requirements of
the following regulations: EN 55032/EN 55024: CLASS B
WEEE Information
For EU (European Union) member users: According to
the WEEE (Waste electrical and electronic equipment)
Directive, do not dispose of this product as household
waste or commercial waste. Waste electrical and electronic
equipment should be appropriately collected and recycled
as required by practices established for your country. For
information on recycling of this product, please contact your
local authorities, your household waste disposal service or
the shop where you purchased the product.
CAN ICES-003(B)/NMB-003(B)
Package Contents
• HyperDrive Next 10 Port Business Class USB-C Dock
• User Guide
Product Compatibility
• MacBook Air/Pro (M1/M2 & Intel powered)
MacBook OS 10.15 or Later
• Chrome OS laptop with Thunderbolt 4, USB4,
USB 3.0 or later Type C with DP Alt-Mode
• Windows OS laptop with Thunderbolt 4, USB4,
USB 3.0 or later Type C with DP Alt-Mode
Introduction
The HyperDrive® Next 10 Port Business Class USB-C
Dock is great for travel & business, and support multiport
function to connect your USB-C laptop to multiple
device. The dock can be seamless to connect 10 kinds of
devices, with this USB-C multiport dock you can connect
HDMI display, 4K60Hz monitors, standard SD card, RJ45
Gigabit Ethernet cable, USB-C PD to your laptop. The
USB-C PD port can connect to a 100W PD 3.0 adapter
to provide PD passthrough charging to your computer.
Hyper also implement eco smart system to use recyclable
materials on the product to support green earth and
healthy environment.
3
Operating System
• Windows 7 and above, Chrome OS R90 and above,
macOS 10.10 and above
4
Product Overview
Item Description
1. DC-IN Port Connects to a Power Adapter
2. USB-C PD Port Connects to a USB-C Power Charger
(Optional)
3. USB-A Port x 2 Connects to a USB-A device
4. USB-C Data Port Connects to a USB-C device
5. SD Card Reader Connects to a standard SD card
6. Ethernet Port Connects to Ethernet network
7. 3.5mm Audio Port Connects to a headset
8. HDMI Port
(DP Alt mode) Connects to a HDMI monitor
9. HDMI Port
(USB mode) Connects to a HDMI monitor
12 65 78 9
4
3
5
Item Description
10. USB-C to USB-C Cable Connects to Dock USB-C
Host Port & host computer
11. Power Button On/O button
12. USB-C Host Port Connects to a host computer
13. K Nano Lock Kensington Nano Security Slot
14. K Lock Kensington Security Slot
Powering the Dock and LED Indication
The HyperDrive Next 10 Port Business Class USB-C
Dock can be powered by external USB-C PD charger or
DC power adapter. The LED light lit up when the power
source is plugged into it.
11
12 14
10 13
HDMI1 (DP alt mode) HDMI2 (USB mode)
Single Port
Connected
4K/60Hz No connect
No connect 4K/30Hz
Dual Ports
Connected 4K/60Hz 4K/30Hz
Multi-Display Support
Up to 2nd extended display output is supported if the
host device supports DisplayPort Alt Mode.
* Max resolution can be achieved if the host device
and display support DP1.4.
** To use the USB mode to Video, you need to install the
driver for all operating systems except Chrome OS.
The InstantView driver ocial website:
http://www.siliconmotion.com/downloads/index.html
HDMI resolutions of the display mode
Specifications
Interface DC-IN Supports up to 150W Power adapter
USB-C Data USB 3.2 Gen2 10Gbps
USB-C PD USB-C PD3.0 (Support up to 100W)
SD Card
Reader
Support standard SD card 4.0
312MB/s
USB-A USB 3.2 Gen2 10Gbps
Ethernet
Port
Supports 10/100/1000Mbps
3.5mm
Audio Port
Supports standard headset
HDMI port
(USB mode)
Supports up to 4K30Hz
HDMI port
(DP Alt
mode)
Supports up to 4K60Hz
Dimension
& Weight
Length
Width
Height
170mm / 6.69inch
83mm / 3.27inch
16.5mm / 0.65inch
Weight 240g / 0.53lb
(USB-C cable 9g / 0.02lb)
8
2 YEAR LIMITED WARRANTY
We pride ourselves on the quality of our products. For
complete warranty details and a list of our Worldwide
oces, please visit www.HyperShop.Com. Hyper
product warranty does not cover any device or product
that is not manufactured by Hyper (including, but not
limited to, laptops, smartphones, devices, or any other
product that may be used in connection with the Hyper
product). ©2023 Hyper Products Inc 46721 Fremont
Blvd, Fremont, CA 94538. All rights reserved.
GARANTIE LIMITÉE DE 2 ANSY
Nous sommes fiers de la qualité de nos produits. Pour
plus de renseignements sur la garantie complète et
une liste de nos bureaux à travers le monde, veuillez
consulter www.HyperShop.com. La garantie des
produits Hyper ne couvre pas les appareils ou produits
qui ne sont pas fabriqués par Hyper (y compris,
mais sans s’y limiter, les ordinateurs portables, les
smartphones, les appareils ou tout autre produit
pouvant être utilisé en relation avec le produit Hyper).
©2023 Hyper Products Inc 46721 Fremont Blvd,
Fremont, CA 94538. Tous droits réservés.
GARANTÍA LIMITADA DE 2 AÑOS
Nos enorgullecemos de la calidad de nuestros
productos. Consulte toda la información sobre la
garantía y la lista de nuestras oficinas en todo el mundo
en www.HyperShop.com La garantía del producto Hyper
no cubre ningún dispositivo o producto que no esté
fabricado por Hyper (incluidos, entre otros, laptops,
smartphones, dispositivos o cualquier otro producto
que pueda utilizarse en relación con el producto de
Hyper). ©2023 Hyper Products Inc 46721 Fremont Blvd,
Fremont, CA 94538. Reservados todos los derechos.
