Hyundai I20 Active 2016 Bedienungsanleitung



! 

,+$%'(&*

%(*'+*%*#+

+#((#%'(&*

All information in this Owner's Manual is current at the time of publication.

However, Hyundai Motor India Limited reserves the right to make changes

at any time without prior notice and without obligation to incorporate such

changes so that our policy of continual product improvement may be carried

out.

This manual applies to all variants of this vehicle and includes descriptions

and explanations of optional as well as standard equipment.

As a result, you may find material in this manual that does not apply to your

specific vehicle.

This manual is provided in non-writable PDF format and can be viewable on

any computer or Device compatible with windows 7 & above and PDF read-

er. Avoid direct sunlight to CD & do not keep it in high temperature zone i.e

more than 70 degree celcius.



Your HYUNDAI should not be modified in any way. Such modifications may adversely affect

the performance, safety or durability of your HYUNDAI and may, in addition, violate condi-

tions of the limited warranties covering the vehicle. Certain modifications may also be in vio-

lation of regulations established by the Department of Transportation and other government

agencies in your country.

Your vehicle is equipped with electronic fuel injection and other electronic components. It is

possible for an improperly installed/adjusted two-way radio or cellular telephone to adversely

affect electronic systems. For this reason, we recommend that you carefully follow the radio

manufacturer's instructions or consult your HYUNDAI dealer for precautionary measures or

special instructions if you choose to install one of these devices.

CAUTION: MODIFICATIONS TO YOUR

TWO-WAY RADIO OR CELLULAR TELEPHONE INSTALLATION



This manual includes information titled as DANGER, WARNING, CAUTION and NOTICE.

These titles indicate the following:

SAFETY AND VEHICLE DAMAGE WARNING

DANGER indicates a hazardous situa-

tion which, if not avoided, will result in

death or serious injury.

DANGER

WARNING indicates a hazardous situa-

tion which, if not avoided, could result in

death or serious injury.

CAUTION indicates a hazardous situa-

tion which, if not avoided, could result in

minor or moderate injury.

CAUTION

NOTICE indicates a situation which, if not

avoided, could result in vehicle damage.

NOTICE

WARNING



FOREWORD

Thank you for choosing HYUNDAI. We are pleased to welcome you to the growing number of discriminating people who

drive HYUNDAI. The advanced engineering and high-quality construction of each HYUNDAI we build is something of

which we're very proud.

Your Owner's Manual will introduce you to the features and operation of your new HYUNDAI. It is suggested that you read

it carefully because the information it contains can contribute greatly to the satisfaction you receive from your new car.

The manufacturer also recommends that service and maintenance on your vehicle be performed by an authorized

HYUNDAI dealer.

HYUNDAI MOTOR INDIA LIMITED

Note :

Because future owners will also need the information included in this manual, if you sell this HYUNDAI, please

leave the manual in the vehicle for their use. Thank you.

in any retrieval system or transmitted in any form or by any means without the prior written permission of HYUNDAI

Motor Company.

Severe engine and transaxle damage may result from the use of poor quality fuels and lubricants that do not meet

HYUNDAI specifications. You must always use high quality fuels and lubricants that meet the specifications listed

on Page 10-4 in the Vehicle Specifications section of the Owner's Manual.

CAUTION

We want to help you get the greatest

possible driving pleasure from your

vehicle. Your Owner’s Manual can

assist you in many ways. We strongly

recommend that you read the entire

manual. In order to minimize the

chance of death or injury, you must

read the DANGER, WARNING and

CAUTION sections in the manual.

Illustrations complement the words

in this manual to best explain how to

enjoy your vehicle. By reading your

manual, you will learn about fea-

tures, important safety information,

and driving tips under various road

conditions.

The general layout of the manual is

provided in the Table of Contents.

Use the index when looking for a

specific area or subject; it has an

alphabetical listing of all information

in your manual.

Sections: This manual has ten chap-

ters plus an index. Each section

begins with a brief list of contents so

you can tell at a glance if that section

has the information you want.

Your safety, and the safety of others,

is very important. This Owner's

Manual provides you with many safe-

ty precautions and operating proce-

dures. This information alerts you to

potential hazards that may hurt you

or others, as well as damage to your

vehicle.

Safety messages found on vehicle

labels and in this manual describe

these hazards and what to do to

avoid or reduce the risks.

Warnings and instructions contained

in this manual are for your safety.

Failure to follow safety warnings and

instructions can lead to serious injury

or death.

Throughout this manual DANGER,

WARNING, CAUTION, NOTICE and

the SAFETY ALERT SYMBOL will

be used.

This is the safety alert sym-

bol. It is used to alert you to

potential physical injury haz-

ards. Obey all safety mes-

sages that follow this symbol

to avoid possible injury or

death. The safety alert sym-

bol precedes the signal words

DANGER, WARNING and

CAUTION.



  



*($'!#(%'*

DANGER indicates a hazardous

situation which, if not avoided, will

result in death or serious injury.

DANGER

WARNING indicates a hazardous

situation which, if not avoided,

could result in death or serious

injury.

WARNING



*($'!#(%'*

NOTICE indicates a situation which,

if not avoided, could result in vehicle

damage.

Petrol engine

Unleaded

Your new vehicle is designed to use

only unleaded fuel having an Octane

Rating of RON (Research Octane

Number) 91 / AKI (Anti-Knock Index)

87 or higher.

Your new vehicle is designed to

obtain maximum performance with

UNLEADED FUEL, as well as mini-

mize exhaust emissions and spark

plug fouling.

Leaded (if equipped)

For some countries, your vehicle is

designed to use leaded petrol.

When you are going to use leaded

petrol, we recommend that you ask

an authorized HYUNDAI dealer

whether leaded petrol in your vehicle

is available or not.

Octane Rating of leaded petrol is

same with unleaded one.

NOTICE

NEVER USE LEADED FUEL. The

use of leaded fuel is detrimental to

the catalytic converter and will

damage the engine control sys-

tem’s oxygen sensor and affect

emission control.

Never add any fuel system clean-

ing agents to the fuel tank other

than what has been specified (We

recommend that you consult an

authorized HYUNDAI dealer for

details.)

CAUTION

CAUTION indicates a hazardous

situation which, if not avoided,

could result in minor or moderate

injury.

CAUTION

  

•Do not "top off" after the nozzle

automatically shuts off when

refueling.

•Always check that the fuel cap is

installed securely to prevent fuel

spillage in the event of an acci-

dent.

WARNING



*($'!#(%'*

Diesel engine

Diesel fuel

Diesel engine must be operated only

on commercially available diesel fuel

that complies with EN 590 or compa-

rable standard. (EN stands for

"European Norm"). Do not use

marine diesel fuel, heating oils, or

non-approved fuel additives, as this

will increase wear and cause dam-

age to the engine and fuel system.

The use of non-approved fuels and /

or fuel additives will result in a limita-

tion of your warranty rights.

Diesel fuel of above cetane 51 is

used in your vehicle. If two types of

diesel fuel are available, use summer

or winter fuel properly according to

the following temperature conditions.

• Above -5°C (23°F) ... Summer type

diesel fuel.

• Below -5°C (23°F) ... Winter type

diesel fuel.

Watch the fuel level in the tank very

carefully : If the engine stops through

fuel failure, the circuits must be com-

pletely purged to permit restarting.

Do not let any petrol or water enter

the tank. This would make it neces-

sary to drain it out and to bleed the

lines to avoid jamming the injection

pump and damaging the engine.

- Diesel Fuel

(if equipped with DPF)

It is recommended to use the regu-

lated automotive diesel fuel for diesel

vehicle equipped with the DPF sys-

tem.

If you use diesel fuel including high

sulfur (more than 50 ppm sulfur) and

unspecified additives, it can cause

the DPF system to be damaged and

white smoke can be emitted.

Biodiesel

Commercially supplied Diesel blends

of no more than 7% biodiesel, com-

monly known as "B7 Diesel" may be

used in your vehicle if Biodiesel

meets EN 14214 or equivalent spec-

ifications. (EN stands for "European

Norm"). The use of biofuels exceed-

ing 7% made from rapeseed methyl

ester (RME), fatty acid methyl ester

(FAME), vegetable oil methyl ester

(VME) etc. or mixing diesel exceed-

ing 7% with biodiesel will cause

increased wear or damage to the

engine and fuel system. Repair or

replacement of worn or damaged

components due to the use of non

approved fuels will not be covered by

the manufactures warranty.

• Never use any fuel, whether

diesel, B7 biodiesel or otherwise,

that fails to meet the latest petrole-

um industry specification.

• Never use any fuel additives or

treatments that are not recom-

mended or approved by the vehi-

cle manufacturer.

NOTICE

No special break-in period is need-

ed. By following a few simple precau-

tions for the first 1,000 km (600

miles) you may add to the perform-

ance, economy and life of your vehi-

cle:

• Do not race the engine.

• While driving, keep your engine

speed (rpm, or revolutions per

minute) between 2,000 rpm and

4,000 rpm.

• Do not maintain a single speed for

long periods of time, either fast or

slow.

Varying engine speed is needed to

properly break-in the engine.

• Avoid hard stops, except in emer-

gencies, to allow the brakes to seat

properly.

• Don't tow a trailer during the first

2,000 km (1,200 miles) of opera-

tion.



*($'!#(%'*









  

IBi Eng 1_PA RHD 1.qxd 19-01-2015 16:20 Page 1



IBi Eng 1_PA RHD 1.qxd 19-01-2015 16:20 Page 2

Inhaltsverzeichnis

Andere Hyundai Automobil Handbücher

Hyundai

Hyundai Accent HCI 2019 Bedienungsanleitung

Hyundai

Hyundai IX35 Bedienungsanleitung

Hyundai

Hyundai Tiburon Bedienungsanleitung

Hyundai

Hyundai Grand i10 NIOS Bedienungsanleitung

Hyundai

Hyundai ACCENT Bedienungsanleitung

Hyundai

Hyundai Grand i10 NIOS Bedienungsanleitung

Hyundai

Hyundai ELANTRA Bedienungsanleitung

Hyundai

Hyundai 2012 Santa Fe Sport Bedienungsanleitung

Hyundai

Hyundai 2001 Tiburon Bedienungsanleitung

Hyundai

Hyundai VELOSTER 2019 Bedienungsanleitung

Hyundai

Hyundai SONATA hybrid 2016 Bedienungsanleitung

Hyundai

Hyundai Sonata LF Bedienungsanleitung

Hyundai

Hyundai Tucson 2005 Bedienungsanleitung

Hyundai

Hyundai Tucson 2022 Bedienungsanleitung

Hyundai

Hyundai 2009 Entourage Bedienungsanleitung

Hyundai

Hyundai Getz 2004 Bedienungsanleitung

Hyundai

Hyundai 2012 Sonata Hybrid Bedienungsanleitung

Hyundai

Hyundai IONIQ ELECTRIC Bedienungsanleitung

Hyundai

Hyundai Sonata 2020 Bedienungsanleitung

Hyundai

Hyundai EON Bedienungsanleitung

Hyundai

Hyundai GENESIS 2013 Bedienungsanleitung

Hyundai

Hyundai ACCENT Bedienungsanleitung

Hyundai

Hyundai ELANTRA 208 Bedienungsanleitung

Hyundai

Hyundai 2012 Sonata Hybrid Bedienungsanleitung

Beliebte Automobil Handbücher anderer Marken

Toyota

Toyota 2000 Tundra Bedienungsanleitung

CITROËN

CITROËN DS4 DSign Bedienungsanleitung

Lexus

Lexus 2015 CT 200h Bedienungsanleitung

Cadillac

Cadillac CTS 2008 Bedienungsanleitung

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Bedienungsanleitung

Porsche

Porsche Boxster S Bedienungsanleitung

GMC

GMC 2010 Savana 1500 Cargo Bedienungsanleitung

KIAM

KIAM SPORTAGE 2014 Stücklistenhandbuch

GMC

GMC 2013 Terrain Montageanleitung

GMC

GMC T-Series 1999 Bedienungsanleitung

Mercury

Mercury 1998 Mystique Bedienungsanleitung

Mercury

Mercury 2007 Mariner Bedienungsanleitung

Mazda

Mazda 2007 Mazdaspeed 3 Leitfaden

Mazda

Mazda 2014 CX-5 Bedienungsanleitung

GMC

GMC Chevrolet Express 2022 Bedienungsanleitung

GMC

GMC 1997 Jimmy Bedienungsanleitung

Chevrolet

Chevrolet 2012 Malibu Bedienungsanleitung

Cadillac

Cadillac 2010 Escalade Bedienungsanleitung

Hyundai i20 Active 2016 Bedienungsanleitung

Beliebte Automobil Handbücher anderer Marken
