I-team I-fogger Bedienungsanleitung

i-team Professional b.v.

Hoppenkuil 27b, 5626 DD Eindhoven, The Netherlands

Telephone: +31402662400

Email: [email protected]

Internet: www.i-teamglobal.com

i-fogger®

Effortless 360° disinfection

User manual

Original user manual, written in the English Language

Future Cleaning Technologies B.V.

Hoppenkuil 27b, 5626 DD Eindhoven, The Netherlands

Telephone: +31402662400

Email: [email protected]

Internet: www.i-teamglobal.com

Model: 3.5

Date: 29/09/2020

Product code: IFG.FCT.0000B

Version: v.1.0

Preface

Thank you for purchasing the i-fogger®. The i-fogger disinfects surfaces and entire spaces quickly. The

mobile unit creates and disperses a disinfectant aerosol (mist) to reduce the number of airborne

micro-organisms and viruses. Bonus: it’s also easy to apply disinfectant to surfaces that are difficult

to reach.

Please read this manual carefully for important information and operating instructions before using

the i-fogger. Save this manual for future reference. This i-fogger will provide excellent performance.

The best results will be obtained when the i-fogger is:

•regularly maintained per the i-fogger preventive maintenance instructions in this manual;

•operated with reasonable care and caution;

•maintained with manufacturer-supplied parts.

When this manual refers to “the manufacturer”, this means: Future Cleaning Technologies B.V, an

affiliate company of i-team in Eindhoven, the Netherlands. When this manual mentions “the

partner”, your local i-team resell and support service partner is referred to.

Purpose of the user manual

The purpose of the user manual is to provide the user with information in such a way that during the

life of the i-fogger, the machine is used correctly, efficiently and safely, even in the event of

reasonably foreseeable misuse, as described in section 1.2 of this manual.

The user manual contains instructions regarding:

•personal operator safety;

•intended and non-intended use of the i-fogger;

•instructions for daily use;

•maintenance instructions;

•storage conditions;

•disposal of the i-fogger.

These instructions must be considered to avoid risks that could lead to physical and/or material

damage.

Target audience

This user manual is intended for operators of the i-fogger and their supervisors, as well as partners

and importers.

Operators of the i-fogger

The i-fogger may only be operated by a person who has correctly read and understood the

instructions in this manual or is trained by an experienced operator who has read and understood

the instructions in this manual.

Reading guide

The following symbols and terms are used throughout this manual to alert the reader to

safety issues and important information:

Symbol

Term

Explanation

WARNING

Indicates a hazardous situation which, if the safety

instructions are not followed, can lead to injuries of the

operator or bystanders, light and/or moderate damage

to the product or the environment.

CAUTION

Indicates a hazardous situation which, if the safety

instructions are not followed, can lead to light and/or

moderate damage to the product or the environment.

STRONG MAGNET

Indicates the machine contains strong magnets. These

can cause pacemakers to stop or cause electronic data

to be damaged, for instance on information stored on

access passes.

BATTERIES

Indicates a battery-operated machine. Batteries must

be charged according to the instructions in this manual

and the instructions at the charger.

PACEMAKER

Indicates operators and maintenance crew wearing

pacemakers should keep a minimal distance of 6 in / 15

cm. In this specific case operators may not use the

machine.

PROTECTIVE

EYEWEARE

Indicates protective eyewear is advised, for instance

when filling the machine with cleaning solution.

WASH HANDS

Indicates operators are advised to wash their hands, for

instance after filling and/or draining the cleaning

solution.



5
Content
Preface .................................................................................................................................................................... 3
Purpose of the user manual.................................................................................................................................... 3
Target audience ...................................................................................................................................................... 3
Operators of the i-fogger ........................................................................................................................................ 3
Reading guide.......................................................................................................................................................... 4
Content ................................................................................................................................................................... 5
1Introduction.................................................................................................................................................... 7
1.1 Intended use of the product.................................................................................................................. 8
1.2 Non-intended use of the product.......................................................................................................... 8
1.3 Lifespan.................................................................................................................................................. 9
1.4 Modifications......................................................................................................................................... 9
1.5 Specifications....................................................................................................................................... 10
1.6 Warranty.............................................................................................................................................. 11
1.7 Identification ....................................................................................................................................... 11
2Description ................................................................................................................................................... 12
2.1 Control panel ....................................................................................................................................... 13
2.2 Spray gun self reset button ................................................................................................................. 13
2.3 Spray nozzles ....................................................................................................................................... 14
3Safety............................................................................................................................................................ 15
3.1 General safety instructions.................................................................................................................. 15
3.2 Risks during operation......................................................................................................................... 15
3.2.1 The disinfectant solution................................................................................................................. 15
3.2.2 The battery...................................................................................................................................... 15
3.2.3 Strong magnets ............................................................................................................................... 15
3.2.4 Personal protection......................................................................................................................... 16
4Transport and storage.................................................................................................................................. 17
5Assembly and installation............................................................................................................................. 18
5.1 Unboxing.............................................................................................................................................. 18
5.2 Assembly.............................................................................................................................................. 19
5.2.1 Attaching the right spray nozzle for the job.................................................................................... 20
6Operation ..................................................................................................................................................... 21
6.1 Before you start................................................................................................................................... 21
6.1.1 Checking and topping up the disinfectant solution level ................................................................ 21
6.2 Operation procedure........................................................................................................................... 22
6.2.1 After operation................................................................................................................................ 24

6.2.2 Removing the disinfectant solution tank ........................................................................................ 24

6.2.3 Removing the spray nozzle.............................................................................................................. 24

6.3 Cleaning and storage ........................................................................................................................... 25

6.3.1 Flushing the spray nozzle ................................................................................................................ 25

6.3.2 Flushing the disinfectant solution tank and cleaning the exterior.................................................. 25

6.3.3 Storage ............................................................................................................................................ 26

7Maintenance ................................................................................................................................................ 27

8Troubleshooting ........................................................................................................................................... 28

9Decommissioning and disposal .................................................................................................................... 29

10 Attachments................................................................................................................................................. 30

10.1 CE Certificate ....................................................................................................................................... 30

1Introduction

The i-fogger® is an easy and safe machine to use, this manual helps you get started and explains the

operation and maintenance procedure.

The i-fogger has been designed as a comfortable, ergonomic backpack, allowing complete freedom

of movement and easy usability. An ergonomic spray gun is attached to the unit, which ensures fast,

reliable and easy operation. Centralized controls are located on top of the machine. Everything you

need lies within the reach of your fingertips. The lid of the disinfectant solution tank is available in 4

different colors to easily identify different disinfectants.

This manual is intended for those who work with the i-fogger and perform daily maintenance. The

manual must be read in full before the first actions. This manual describes the correct method of use,

safety measures, maintenance and transport.

i-team Global continuously improves all their products based on user experience and feedback. Any

deviations between the texts and/or images from the manual and your i-fogger can therefore arise

from the difference in model or from possible changes due to continuous development and

innovation.

1.1 Intended use of the product

The i-fogger® is a specialized machine for disinfecting surfaces and entire spaces, see Figure 1.

The i-fogger is, for example, suitable to use in cinemas, airplanes, cruise ships and shopping malls.

The i-fogger must be used in a dry environment.

In order to spray different sizes of aerosol (mist) particles, 4 different types of spray nozzles are

provided. These spray nozzles are easy to replace. To select the right spray nozzle, see section 2.3.

1.2 Non-intended use of the product

WARNING

Non-intended use can have consequences for the safety of operators and bystanders

and will void the warranty on the product.

The i-fogger is not intended to be used in moist or wet environments such as saunas and other areas

where fog or moisture is already present in the air.

Do not use the i-fogger in enclosed spaces with little ventilation.

Do not use the i-fogger in spaces were people are present.

Figure 1

1.3 Lifespan

CAUTION

To ensure proper and safe operation throughout the life of the i-fogger®, it is

recommended to have an authorised i-team partner check the machine after the first 50

hours of use and then every 125 hours afterwards. To check the used operating hours,

please check the hour meter on the main control panel. See section 2.1.

1.4 Modifications

It is not permitted to make modifications to the design of the i-fogger without consultation and

permission from the manufacturer. This affects the warranty, see section 1.6 of this manual.

1.5 Specifications

Product size body unit (L x W x H):

230 x 200 x 600 mm

Weight including battery:

8.2 kg

Weight without battery:

7.9 kg

Hose length:

1.2 m

Tank capacity:

3.5 L

Spray distance:

4 –5 m

Spray volume:

100 –175 ml/min

Droplet size:

20-150 µm

Pump specifications:

DC 24 V, 5 W, 100 ml/min

Material main body:

LDPE

Material spray gun:

Aluminium

Power source:

i-power® 9 or i-power® 14 battery

Battery spec i-power 9:

24 V 8.8 Ah

Battery spec i-power 14:

25.2 V 14 Ah

Run time i-power 9:

≈ 30 min

Run time i-power 14:

≈ 50 min

Figure 2
