i-Vac SWITCH BOX SB24013-UK-A Bedienungsanleitung
For safe operation and to gain the full benefit of your iVAC Switch Box -
please read through this handbook before use.
Retain this handbook and your proof of purchase for future reference.
13A 15391-0100 ENGLISH-R8 08/19 PAGE 1 of 8
MODEL
SB24013-UK-A
This iVAC S itch Box enables the automatic and remote s itching
of a dust collecting vacuum.
This iVAC S itch Box is intended to be used ith a po er tool
such as a router, planer, sa , grinder or sander and an associated
vacuum.
The intelligent po er sensing, electronic ON and OFF delays
optimise your dust collection and reduce po er consumption.
13A 15391-0100 ENGLISH-R8 08/19 PAGE 2 of 8
Access panel to
IP switches on
rear of box.
PH1 screwdriver
required.
DESCRIPTION AND FEATURES
The two, 13A socket outlets on the Switch Box are specific and labelled TOOL &
VACUUM.
The vacuum turn ON delay of 1 or 2 seconds (configurable – see settings on page
4) is to prevent the start up power surges of the power tool and vacuum coinciding
and overloading your Switch Box and/or power source circuit breakers.
The vacuum turn OFF time of 8 or 16 seconds (configurable – see settings on
page 4) is to clear dust and debris from your power tool, workstation and hose.
The resettable 13A circuit breaker is provided for overload and fault protection.
The 4 mounting tabs enable secure fastening to walls, benches and equipment.
The integral earth terminal is provided for bonding (grounding) accessories, for
static grounding.
The Switch Box is designed to control LVHP vacuums up to 2700 watts and HVLP
extractors up to 1.5 hp. Further details on page 6.
The maximum total load (power tool and the vacuum) is 2900 watts ≈ 13A.
OPERATION
A vacuum plugged in to the
Switch Box is controlled
by 3 user selectable modes:
► AUTO ◄
As the power tool is used the vacuum will automatically switch ON and OFF
► O ◄
The vacuum is permanently OFF regardless of the state of the power tool.
► I ◄
The vacuum is permanently ON regardless of the state of the power tool.
13A 15391-0100 ENGLISH-R8 08/19 PAGE 3 of 8
3 position
MO E
switch
SETTINGS (CONFIGURATION)
For most applications, the factory (default) settings do not need changing.
If required, the Switch Box can
be configured to suit a user's
specific equipment and
application. There are IP
switches that can be set by the
user.
Set the Po er Tool AUTO s itching threshold to Standard, Medium or High
Some power tools draw power even when the motor is not running -
e.g. work lights, standby electronics, speed controllers or ancillary devices.
N.B. - Some experimentation may be required to determine the correct setting.
STANDARD
≈ 150 mA ≈ 35W
MEDIUM
≈ 250 mA ≈ 60W
HIGH
≈ 500 mA ≈ 120W
2 - OFF, 3 - ON, 4 – OFF
(factory settings)
2 - OFF, 3 - OFF, 4 – ON 2 - ON, 3 - OFF, 4 - OFF
Set the Vacuum turn ON delay and OFF time
VACUUM OFF TIME
Useful for long hose lengths
and clean up after working
VACUUM ON DELAY
Useful for extractors with a
high start up power demand
5 - OFF ≈ 16 secs
5 - ON ≈ 8 secs
(factory setting is ON)
6 - OFF ≈ 2 secs
6 - ON ≈ 1 secs
(factory setting is ON)
13A 15391-0100 ENGLISH-R8 08/19 PAGE 4 of 8
IP switches.
Factory settings shown.
3, 5 and 6 are ON
1, 2 and 4 are OFF
IP switch 1 is
reserved for future
applications – Leave
OFF
When accessing the
IP switches through
the rear panel – the
Switch Box must be
safely disconnected
(isolated) from the
mains supply.
SAFETY
Misuse of your Switch Box and any equipment
plugged into it can potentially lead to injury and damage.
o not exceed the maximum total load of 13A (≈ 2900watts)
This is the load of the vacuum and power tool combined.
Overload and fault protection is provided by the 13A circuit
breaker and the 13A plug top fuse, Frequent overloading
indicates a problem that requires investigation – see page 7.
Ensure the power tool and vacuum are plugged into the
correct socket outlet on the Switch Box.
o not connect any hazardous tools or equipment to the
Vacuum outlet on the Switch Box.
o not alter, modify or adapt the Switch Box.
o not open the Switch Box housing.
The Switch Box is suitable for indoor use, in dry environments
only.
The Switch Box must only be connected to an adequately rated
and earthed power source (e.g. A 13A socket outlet) that is RC
protected.
When accessing the IP switches through the rear access panel
– the Switch Box must be safely disconnected from the mains
supply.
Never use the Switch Box with the rear access panel removed.
Use extension leads and power adaptors with extreme caution – they must be
suitably rated, specified, earthed and uncoiled.
Inspect your Switch Box regularly - o not use if the housing, controls, leads or
connectors are damaged or worn.
We strongly recommend appropriate portable appliance testing (PAT) of the
Switch Box, your power tools, vacuums, adaptors and extension leads.
Unplug (isolate) the Switch Box when unattended. e.g. night time and weekends.
13A 15391-0100 ENGLISH-R8 08/19 PAGE 5 of 8
Apply the supplied
CA TION label to
your vacuum to warn
that it can be started,
remotely, by another
person.
Apply the
supplied 13A
label to your 13A
plug
TECHNICAL DATA - SB24013-UK-A
220 - 240V 50/60 Hz AC. Maximum total load is 13A ≈ 2900watts.
Maximum vacuum (LVHP) power is 12A ≈ 2700watts.
Maximum extractor (HVLP) power is 1.5 hp.
Vacuum turn ON delay is configurable – 1 or 2 seconds (factory set to 1).
Vacuum turn OFF time is configurable – 8 or 16 seconds (factory set to 8).
Power tool AUTO switching threshold is configurable – Standard, Medium or High
(factory set to Standard ≈ 35 watts ≈ 0.15A).
Circuit breaker is 13A type 'B', user resettable.
Suitable for continuous operation.
Housing – ABS 94V0 fire retardant.
Housing – 128mm wide. 177mm high (incl fixing tabs). 56mm deep. 580 grams.
Supply lead is ≈ 3 feet, fitted with a UK 13A (BS1363) plug. 13A fuse installed.
Approvals – CE, RoHS.
Protection – IP20, indoor use, dry environments only - Class I, requires earth.
The Switch Box is NOT suitable
for controlling vacuums / extractors
which are NVR (No Volt Release)
protected – see page 7.
NOTE: OL motor starters include
NVR protection.
Vacuums and Extractors that require
a 16A power supply are NOT suitable
for use with this Switch Box.
HVLP extractors over 1.5 hp could cause an overload
to the Switch Box due to their high start-up power demand.
13A 15391-0100 ENGLISH-R8 08/19 PAGE 6 of 8
Typical NVR
Switch
Typical K
16 amp plug
Typical HVLP
(high volume – low pressure)
Extractor
(with NVR)
MAX 1.5 hp
Typical LVHP
(low volume – high pressure)
Vacuum
(without NVR)
MAX 2700 watts
Typical DOL
Motor Starter
with NVR
TROUBLE SHOOTING
NEITHER YOUR VACUUM OR POWER TOOL ARE OPERATING
Cause 1 > The 13A circuit breaker has tripped out or the 13A plug top fuse may have blown -
Your Switch has been subjected to a power overload (i.e. more than 13A ≈ 2900
watts) or there is a fault (i.e. a short circuit in your vacuum or power tool)
Remedy 1A > Reset the circuit breaker on your Switch Box - press it in to reset. Check
that the 13A fuse in the Switch supply plug is not blown
Remedy 1B > Check there is power present at your socket outlet - reset the power supply
circuit MCBs and RC s as required
Cause 2 > Your extractor may draw a very high current during start up - your Switch may
have been subjected to a power overload caused during start-up
Remedy 2 > Try increasing the vacuum turn ON delay to 2 seconds (see settings on page 4)
YOUR VACUUM DOES NOT OPERATE IN AUTO MODE BUT IT DOES OPERATE IN
MANUAL (I) MODE
Cause > The Switch Box AUTO function is only suitable for power tools that draw 35 watts
or more when running. You can confirm this by plugging another (more powerful)
power tool into the Switch Box and operating it
Remedy A > Control your vacuum in the manual mode – ON or OFF (I or O)
Remedy B > Adjust the AUTO switching threshold to a lower setting (see settings on page 4)
YOUR VACUUM OPERATES CONTINUOUSLY IN AUTO MODE WHETHER YOUR POWER
TOOL IS ON OR OFF
Cause > The Switch Box is configured at the factory for power tools that draw less than 35
watts when on standby. Some power tools draw more than 35 watts even when
not running – this is typically power used by work lights, standby electronics,
speed controllers or ancillary devices. You can confirm this by plugging another
power tool into the Switch Box and operating it
Remedy A > You can increase the power tool AUTO switching threshold by configuring the IP
switches (see settings on page 4)
Remedy B > Control your vacuum in the manual mode – ON or OFF (I or O)
YOUR EXTRACTOR SWITCHES ITSELF OFF – THE NVR ON YOUR EXTRACTOR
DISCONNECTS THE MOTOR
Cause > Some vacuums and most extractors are fitted with an NVR (No Volt Release)
switch (also known as Magnetic Switch or OL - see page 6). NVR switches will
automatically disconnect when the supply power is switched off, this is normal
operation. This Switch Box is not suitable for NVR protected vacuums
Remedy > iVAC offers other products in it's range (e.g. the iVAC Pro System) that are suitable
for NVR protected vacuums and extractors.
13A 15391-0100 ENGLISH-R8 08/19 PAGE 7 of 8
GUARANTEE - SB24013-UK-A
The iVAC Switch Box is guaranteed against defects in material and workmanship,
under normal usage, for one year from the date of purchase.
This guarantee is not transferable and does not affect your statutory rights.
This guarantee does not apply in cases of improper use, negligence, lack of
maintenance or accidental damage.
Under the terms of this guarantee a faulty Switch Box will either be repaired or
replaced free of charge.
Liability is limited to the Switch Box only, no other costs will be reimbursed.
This guarantee does not confer any rights other than those expressly set out
above.
SERVICE AND REPAIRS
The iVAC Switch Box can be repaired and maintained in our UK workshop.
Beyond the guarantee period (one year) these repairs are chargeable.
We can provide a quote once the Switch Box has been inspected and tested.
Repair charges will always be lower than a replacement (new) Switch Box.
CONTACT
United Kingdom - Toolovation
www.toolovation.co.uk
01531 636819
Canada (head office) - iVAC
www.ivacswitch.com
13A 15391-0100 ENGLISH-R8 08/19 PAGE 8 of 8
