iBell Tools IBL BM18-60 Bedienungsanleitung
1
2
1. GENERAL POWER TOOL SAFETY WARNINGS __________
2. SCREWDRIVER SAFETY WARNINGS ___________________
3. PRODUCT OVERVIEW ________________________________
4. PRODUCT SPECIFICATIONS __________________________
5. SETUP ________________________________________________
6. PRODUCT FUNCTIONS _______________________________
7. GENERAL OPERATION ________________________________
8. TROUBLESHOOTING __________________________________
TABLE OF CONTENTS
IBL BM18-60
3
6
10
11
12
17
20
23
3
Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
Do not operate power tools in explosive atmospheres, such as
in the presence of flammable liquids, gases or dust. Power
tools create sparks which may ignite the dust or fumes.
Keep children and bystanders away while operating a power
tool. Distractions can cause you to lose control.
Power tool plugs must match the outlet. Never modify the plug
in any way. Do not use any adapted plugs with earthed(grounded)
power tools. Modified plugs and un-matching outlets will increase
the risk of electric shock.
Avoid body contact with earthed or grounded surfaces, such as
pipes, radiators, ranges and refrigerators. There is an increased
risk of electric shock if your body is earthed or grounded.
Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep it away from heat, oil, sharp edges
or moving parts.
When operating a power tool outdoors, use an extension cord
suitable for outdoor use. Use of a cord suitable for outdoor use
reduces the risk of electric shock.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING! Read all safety warnings, instructions,
illustrations and specifications provided with this power tool.
Failure to follow all instructions listed below may result in
electric shock, fire and/or serious injury. Save all warnings and
instructions for future reference. The term “power tool” in the
warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool
WORK AREA SAFETY
ELECTRICAL SAFETY
IBL BM18-60
4
Stay alert, watch what you are doing and use common sense
when operating a power tool. Do not use a power tool while you
are tired or under the influence of drugs or alcohol. A moment of
inattention while operating power tools may result in serious
personal injury.
Use personal protective equipment. Always wear eye protection.
Protective equipment such as a dust mask, non-skid safety shoes,
hard hat, or hearing protection used for appropriate conditions will
reduce personal injuries.
Prevent unintentional starting. Ensure the switch is in the off-
position before connecting to power source and/or battery pack,
picking up or carrying the tool.
Remove any adjusting key or wrench before turning the power
tool on. A wrench or a key left attached to a rotating part of the
power tool may result in personal injury.
Do not overreach. Keep proper footing and balance at all times.
This enables better control of the power tool in unexpected
situations.
Dress properly, say no to loose clothing or jewellery. Keep your
hair, clothing away from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
If devices are provided for the connection of dust extraction
and collection facilities, ensure these are connected and
properly used. Use of dust collection can reduce dust-related
hazards.
Have your power tool serviced by a qualified repair-person
using only identical replacement parts.This will ensure that the
safety of the power tool is maintained.
When servicing a power tool, use only identical replacement
parts. Follow instructions in the maintenance section of this
manual. Use of unauthorized parts or failure to follow maintenance
instructions may create a risk of shock or injury.
PERSONAL SAFETY
IBL BM18-60
SERVICE
5
Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer
at the rate for which it was designed.
Do not use the power tool if the switch does not turn it on and
off. Any power tool that cannot be controlled with the switch is
dangerous and must be repaired.
Disconnect the plug from the power source and/or the battery
pack from the power tool before making any adjustments,
changing accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool
accidentally.
Store idle power tools out of the reach of children and do not
allow persons unfamiliar with the power tool or these
instructions to operate the power tool. Power tools are dangerous
in the hands of untrained users.
Keep cutting tools sharp and clean. Properly maintained cutting
tools with sharp cutting edges are less likely to bind and are easier
to control.
Use the power tool, accessories and tool bits etc. in accordance
with these instructions, taking into account the working
conditions and the work to be performed. Use of the power tool
for operations different from those intended could result in a
hazardous situation.
Keep handles and grasping surfaces dry, clean and free from oil
and grease. Slippery handles and grasping surfaces do not allow
for safe handling and control of the tool in unexpected situations.
Use power tools only with specifically designated battery
packs. Use of any other battery packs may create a risk of injury
and fire.
Battery of the tools should be recharged only with the charger
specified by the manufacturer. A charger that is suitable for one
type of battery pack may create a risk of fire when used with
another battery pack.
POWER TOOL USE AND CARE
IBL BM18-60
6
Hold power tool by insulated gripping surfaces, when
performing an operation where the fastener may contact hidden
wiring.
Wear personal protective devices when impact drilling or
hammering. Exposure to the work can cause hearing loss and eye
problems. Wear safety goggles or other eye protection.
Hammering and drilling operations cause chips to fly.
Use clamps or other practical way to secure and support the
work piece to a stable platform. Holding the work by hand or
against your body is unstable and may lead to loss of control.
Accessories and tools get hot during operation. Wear gloves when
touching them.
Do not operate this tool for long periods of time. Vibration
caused by tool action may be harmful to your hands and arms. Use
gloves to provide extra cushion and limit exposure by taking
frequent rest periods.
Always use respiratory protection appropriate for the dust
exposure. Avoid prolonged contact with dust from drilling, and
other activities. Wear protective clothing and wash exposed areas
with soap and water. Allowing dust to get into your mouth, eyes,
or lay on the skin may promote absorption of harmful chemicals.
When not in use, place tool on its side on a stable surface where
it will not cause a tripping or falling hazard. Some tools with
large battery packs will stand upright on the battery pack but may
be easily knocked over.
Adopt the correct working practices in order to reduce the
exposure to vibration. While working with this power tool,
hand/arm vibrations occur.
Never attempt to open the product housing for any reason. If
the plastic housing of the product breaks open or cracks,
immediately discontinue its use and do not recharge it.
Always be alert when using this product, so that you can recognise
and handle risks early. Fast intervention can prevent serious injury
and damage to property.
IMPACT DRIVER SAFETY WARNINGS
IBL BM18-60
7
Do not charge or use the battery pack in explosive atmospheres,
such as in the presence of flammable liquids, gases or dust.
Inserting or removing the battery pack from the charger may ignite
the dust or fumes.
Never force the battery pack into the charger. Do not modify the
battery pack in any way to fit into a non-compatible charger as
battery pack may rupture causing serious personal injury. Consult
the chart at the end of this manual for compatibility of batteries
and chargers.
Do not store battery pack in locations where the temperature
may reach or exceed 104 °F (40 °C) (such as outside sheds or
metal buildings in summer). For best life store battery packs in
a cool, dry location.
Do not splash or immerse the battery in water or other liquids.
Do not store the battery packs in a tool with the trigger switch
locked on. Never tape the trigger switch in the ON position.
Damaged battery packs should be returned to the service centre
for recycling.
Never attempt to open the battery pack for any reason. If the
battery pack case is cracked or damaged, do not insert into the
charger. Do not crush, drop or damage the battery pack
If battery contents come into contact with the skin, immediately
wash area with mild soap and water. If battery liquid gets into the
eye, rinse water over the open eye until irritation ceases.
Do not attempt to charge the battery pack with any chargers
other than the one in this tool-box. The charger and battery pack
are specifically designed to work together.
Protect the charger against moisture and wet conditions. There
is a danger of electric shock.
Pull by the plug rather than the cord when disconnecting the
charger. This will reduce the risk of damage to the electric plug
and cord.
BATTERY PACKS
BATTERY CHARGER
IBL BM18-60
8
Charge/operate and store the product in an ambient
temperature of 15-25°C to ensure the longest battery life and best
performance. Do not charge/operate or store the battery in
temperatures below 5°C and above 40°C.
Do not place any object on top of the charger or place the
charger on a soft surface that might block the ventilation slots
and result in excessive internal heat. Place the charger in a
position away from any heat source. The charger is ventilated
through slots in the top and the bottom of the housing.
Do not disassemble the charger; take it to an authorized service
centre when service or repair is required. Incorrect reassembly
may result in a risk of electric shock, electrocution or fire.
Do not operate the charger with a damaged cord or plug.
Disconnect the charger from the outlet before attempting any
cleaning. This will reduce the risk of electric shock. Removing the
battery pack will not reduce this risk. Never attempt to connect 2
chargers together.
The charger is designed to operate on standard 100-240V
household electrical power. Do not attempt to use it on any other
voltage. This does not apply to the vehicular charger
Even if you are operating this product in accordance with all the
safety requirements, potential risks of injury and damage remain.
The following dangers can arise:
Health defects resulting from vibration emission if the product is
being used over long periods of time or not adequately managed
and properly maintained.
Injuries and damage to property due to broken cutting attachments
or the sudden impact of hidden objects during use.
Danger of injury and property damage caused by other objects or
due to natural reactions or calamities.
RESIDUAL RISKS
IBL BM18-60
9
On the product or on the packing box, the rating label and within
these instructions you will find among others the following symbols
and abbreviations. Familiarize yourself with them to reduce hazards
like personal injuries and damage to property.
SYMBOLS
Caution / Warning
Wear protective
gloves
This product is of protection class II. That means it is
equipped with enhanced or double insulation
Wear hearing and eye protection
Approx. 1 hr charging time
Indoor use only
IBL BM18-60
Do note expose battery packs to heat in excess of 40ºC.
Do not charge or store the battery pack in temperatures
below 0°C and above 40°C
Do not dispose of battery packs in fire. They will
explode and cause injury
Do not dispose of battery packs in water bodies or
immerse in water
Inhaltsverzeichnis
Andere iBell Tools Bohren Handbücher
