Iberna Gea IDC60 Bedienungsanleitung
IDC60
English 1-15
Français 16-25
Deutsch 26-35
Italiano 36-45
®
®
05651919English.qxd 14/09/2004 11:37 Page 2
05651919English.qxd 14/09/2004 11:37 Page 3
05651919English.qxd 14/09/2004 11:37 Page 4
#
ENGLISH
4
1
3
4
2
5
SUPPLY CORD
AIR OUTLETS
IN BASE
AIR INLET
VENTS
7
6
05651919English.qxd 14/09/2004 11:37 Page 5
5
9
10
12
11
8
134
a
56
2
05651919English.qxd 14/09/2004 11:38 Page 6
ENGLISH
6
Safety reminders
User’s manual. This machine should
only be used for its intended purpose
as described in this manual. Ensure
that it is fully understood before
operating.
Installation. Never install the dryer
against curtains and be sure to prevent
items from falling behind or collecting
beneath the dryer. If the floor is
carpeted stand the machine on a piece
of hardboard.
Ventilation. Check regularly that the
air flowing through the dryer is not
restricted:
Check the fluff filter after use, and
clean, if necessary.
The inlets and outlets should be kept
free from obstructions.
If the dryer is used frequently the
period between checks should be
reduced accordingly.
Water container. Empty the container
after every drying cycle. Use both
hands when carrying a full water
container.
Dryness. Clothes should be spin dried
or thoroughly wrung before they are
put into the tumble dryer. Clothes that
are dripping wet should NOT be put
into the dryer.
Lighters and matches must not be
left in pockets and NEVER use
flammable liquids near the machine.
Foam plastic, foam rubber and
rubber-like material are not suitable
for tumble drying. Articles made from
these materials MUST NOT be placed
in the dryer.
Glass fibre curtains should never be
put in this machine. Skin irritation
may occur if other garments are
contaminated with the glass fibres.
Garments treated with flammable
cleaning sprays or liquids such as
petrol, must not be put in this
machine.
Lint or fluff must not be allowed to
collect on the floor around the outside
or beneath the machine.
Cool down period. The drum inside
may be very hot. Always allow the
dryer to complete the cool down
period before removing the laundry.
Faults. Do not continue to use this
machine if it appears to be faulty.
After use. Remove the plug from the
electricity supply. Always remove the
plug before cleaning the appliance.
Supply cord. If the supply cord on
this appliance is damaged, it must be
replaced by a special cord which is
only available from Service or an
authorised Dealer.
Service. To ensure the continued safe
and efficient operation of this
appliance we recommend that any
servicing or repairs are only carried
out by an authorised service engineer.
05651919English.qxd 14/09/2004 11:38 Page 7
Safety reminders 6
Electrical requirements 7
Installation requirements 8
Preparing the load 8
Clothes preparation 8
Maximum drying weight 8
Sorting the load 8-9
Do not tumble dry 9
Energy saving 9
Opening the door 9
Filter 9
Water container 10
Condenser 10
Drying guide 11
Controls & indicators 12
Operation 13
Cleaning the dryer 14
Technical specification 14
European directive 2002/96/EC 14
Trouble shooting 15
Before using the tumble dryer for the
first time:
●please read this instruction book
thoroughly.
●remove all items packed inside drum.
●wipe the inside of the drum and door
with a damp cloth to remove any dust
which may have settled in transit.
IMPORTANT: This dryer must only be
used for drying household textiles and
garments where a water solution has
been used for the cleaning process.
DO NOT tumble dry fabrics treated
with dry cleaning fluids.
Electrical requirements
This appliance is fitted with a moulded-on
non-rewireable plug.
The plug should be accessible for
disconnection after the appliance has been
installed.
IMPORTANT: The wires in the mains
lead are coloured in accordance with the
following code:
Blue - NEUTRAL
Brown - LIVE
Green-and-yellow - EARTH
If the supply cord on this appliance is
damaged, it must be replaced by a
special cord which is only available
from Service or an authorised Dealer.
7
ENGLISH
PLEASE READ THESE INSTRUCTIONS THOROUGHLY
This appliance must be operated in accordance with the instructions given in this manual.
It is for domestic use only in drying household textiles and garments where a water
solution has been used in the cleaning process. It MUST NOT be used with dry cleaning
fluids. For your safety, this dryer must be correctly installed.
If there is any doubt about installation, call the national Service number for advice.
WARNING!
ELECTRICITY CAN BE
EXTREMELY DANGEROUS.
THIS APPLIANCE MUST BE
EARTHED.
05651919English.qxd 22/12/2005 19:39 Page 9
ENGLISH
Installation
requirements
IMPORTANT: This dryer must be
installed such that the air inlets and
outlets are not restricted (fig. 1).
1 – Supply cord
2 – Air inlets
3 – Air outlets
There should be a gap of at least 12 mm
(0.5 inches) between the sides, rear and
base of the machine and the surrounding
walls, cabinets and floor.
To ensure adequate ventilation the space
between the bottom of the machine and the
floor must not be obstructed.
NEVER install the dryer up against
curtains.
Prevent items from falling or collecting
behind and beneath the dryer as these may
obstruct the air inlets and outlets.
Preparing the load
Before using the dryer for the first time
wipe the inside of the drum and door with
a damp cloth.
Make sure that the laundry you are going
to dry is suitable for drying in a tumble
dryer, as shown by the care symbols on
each item.
Clothes preparation
Check that all fastenings are closed and
that pockets are empty. Turn the articles
inside out. Place clothes loosely in the
drum to make sure that they don’t get
tangled.
Do not overload the drum, particularly
when drying large items, otherwise, the
laundry may stick to the drum and not dry
evenly.
Maximum drying
weight
● Cottons Max. 6 kg
● Synthetics Max. 3 kg
Sort the load as
follows:
A) By care symbols
On the collar or inside seam:
Suitable for tumble drying.
Tumble drying at high temperature.
Tumble drying at low temperature only.
Do not tumble dry.
B) By amount and thickness
Whenever the load is bigger than the
dryer capacity, separate clothes
according to thickness (e.g. towels
from thin underwear).
8
05651919English.qxd 14/09/2004 11:38 Page 10
C) By type of fabric
Cottons/linen: Towels, cotton jersey,
bed and table linen.
Synthetics: Blouses, shirts, overalls,
etc. made of polyester or polyamid, as
well as for cotton/synthetic mixes.
D) By drying level
●Sort into: iron dry, cupboard dry, etc.
●For delicate articles press the HEAT
SETTING button to select low drying
temperature ( ).
●For airing or drying very delicate
articles select the airing option button
.
Do not tumble dry:
Woollens, silk, delicate fabrics, nylon
stockings, delicate embroidery, fabrics
with metallic decorations, garments with
PVC or leather trimmings, training shoes,
bulky items such as sleeping bags, etc.
IMPORTANT: Do not dry articles
which have been treated with a dry
cleaning fluid or rubber clothes (danger
of fire or explosion).
Energy saving
Only put into the tumble dryer laundry
which has been thoroughly wrung or spin-
dried. The drier the laundry the shorter the
drying time thus saving electricity.
ALWAYS try to dry the maximum weight
of laundry, this will save time and
electricity.
NEVER exceed the maximum weight, this
will waste time and electricity.
ALWAYS check that the filter is clean
before every drying cycle as this aids
efficiency.
NEVER put dripping wet items into the
tumble dryer, this may damage the
appliance and waste time and efficiency.
Opening the door
Pull on handle to open the door (fig. 2).
This is a safety feature to prevent
entrapment of minors in the drum.
To restart the dryer, close the door and
press the ON button .
Filter
IMPORTANT: To maintain the
efficiency of the dryer check that the
fluff filter is clean before each drying
cycle.
1. Pull the filter upwards (fig. 3).
2. Open filter as shown (fig. 4).
3. Gently remove lint using a soft brush
or your fingertips.
4. Snap the filter together and push back
into place.
Filter Care Indicator
Lights when the filter needs cleaning.
If the laundry is not drying check that the
filter is not clogged.
9
ENGLISH
WARNING!
WHEN THE TUMBLE DRYER IS
IN USE THE DRUM AND DOOR
MAY BE VERY HOT.
05651919English.qxd 14/09/2004 11:38 Page 11
ENGLISH
Water Container
The water removed from the laundry
during the drying cycle is collected in a
container at the bottom of the dryer.
When the container is full the EMPTY
WATER indicator ( ) on the control
panel will light and the container MUST
be emptied.
Note: Very little water will collect during
the first few cycles of a new machine as an
internal reservoir is filled first.
We recommend that the container be
emptied after each drying cycle.
To empty the water container:
1. ENSURE THE MACHINE IS
SWITCHED OFF. Gently pull the
bottom of the kickplate so that it
unclips from the dryer. The top section
can then be unhinged allowing the
kickplate to be completely removed
(fig. 5).
2. Pull firmly on the drawer front
handgrip and slide the water container
out of the dryer (fig. 6). Support the
container with both hands. When full,
the water container will weigh about
4 kg (fig. 7).
3. Open the lid located on the top of the
container and empty the water (fig. 8).
4. Refit the lid and slide the water
container back into position. PUSH
FIRMLY IN PLACE.
Condenser
IMPORTANT: Always switch off and
remove the plug from the electricity
supply before cleaning the condenser.
To maintain the efficiency of the dryer
regularly check that the condenser is
clean.
To remove the condenser:
1. Remove the kickplate (fig. 5).
2. Turn the two locking levers anti-
clockwise (fig. 9).
3. Pull out the condenser unit (fig. 10).
4. Gently remove any dust or fluff with a
cloth, then wash the unit by holding it
under a running tap (fig. 11) turning it
so that water flows between the plates,
to remove any dust or fluff.
5. Refit the condenser ensuring it is
pushed firmly into place. Lock the two
levers by turning them clockwise.
6. Refit the kickplate.
10
