IBM 20X Bedienungsanleitung

ThinkPad 4X/4X/20X

CD-ReWritable

Ultrabay 2000 Drive

User's Guide

OPTIONS

by IBM

Note: Before using this information and the product it supports, be sure to read

the information under Appendix C, “Product warranties and notices” on page 2-2.

First Edition (May 2000)

The following paragraph does not apply to the United Kingdom or any country where such

provisions are inconsistent with local law: INTERNATIONAL BUSINESS MACHINES

CORPORATION PROVIDES THIS PUBLICATION “AS IS” WITHOUT WARRANTY OF

ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE

IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR

PURPOSE. Some states do not allow disclaimer of express or implied warranties in certain

transactions, therefore, this statement may not apply to you.

This publication could include technical inaccuracies or typographical errors. Changes are

periodically made to the information herein; these changes will be incorporated in new editions of

the publication. IBM may make improvements and/or changes in the product(s) and/or the

program(s) described in this publication at any time.

This publication was developed for products and services offered in the United States of America.

IBM may not offer the products, services, or features discussed in this document in other

countries, and the information is subject to change without notice. Consult your local IBM

representative for information on the products, services, and features available in your area.

Requests for technical information about IBM products should be made to your IBM reseller or

IBM marketing representative.

Note to U.S. Government Users — Documentation related to restricted rights — Use, duplication

or disclosure is subject to restrictions set forth in GSA ADP Schedule Contract with IBM Corp.

Contents

Safety: Read first ................................ iv

Product registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi

About this book ................................ vi

Part 1: Installation and user’s guide ................ 1-1

Part 2: Appendixes . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Appendix A. Product specifications . . . . . . . . . . . . . . . . . . . . . 2-1

Appendix B. Help and service information ................. 2-1

Online technical support ............................ 2-1

Telephone technical support .......................... 2-2

Appendix C. Product warranties and notices ................ 2-2

Warranty Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12

Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12

Electronic emission notices .......................... 2-12

Safety: Read first

Before installing this product, read the Safety Information.

Antes de instalar este produto, leia as Informações de

Segurança.

Před instalací tohoto produktu si přečtěte příručku bezpečnostních instrukcí.

Læs sikkerhedsforskrifterne, før du installerer dette produkt.

Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta

Safety Information.

Avant d'installer ce produit, lisez les consignes de sécurité.

Vor der Installation dieses Produkts die Sicherheitshinweise

lesen.

Prima di installare questo prodotto, leggere le Informazioni

sulla Sicurezza

Lees voordat u dit product installeert eerst de

veiligheidsvoorschriften.

Les sikkerhetsinformasjonen (Safety Information) før du

installerer dette produktet.

iv IBM ThinkPad 4X/4X/20X CD-RW Ultrabay 2000 Drive

Antes de instalar este produto, leia as Informações sobre

Segurança.

Pred inštaláciou tohto zariadenia si pečítaje Bezpečnostné predpisy.

Antes de instalar este producto lea la información de

seguridad.

Läs säkerhetsinformationen innan du installerar den här

produkten.

Product registration

Thank you for purchasing OPTIONS by IBM . Please take a few moments to register

your product and provide us with information that will help IBM to better serve you in

the future. Your feedback is valuable to us in developing products and services that

are important to you, as well as in developing better ways to communicate with you.

http://www.ibm.com/pc/register

IBM will send you information and updates on your registered product unless you

indicate on the Web site questionnaire that you do not want to receive further

information.

About this book

This manual contains information on the IBM ThinkPad 4X/4X/20X CD-RW Ultrabay

2000 Drive. It is divided into the following parts:

Part 1: Installation and user’s guide

This section contains product and software descriptions, installation

requirements, installation instructions, handling and operating information,

and problem solving in the following languages:

English

German

French

Spanish

Italian

Brazilian Portuguese

Japanese

Part 2: Appendixes

This section contains the product specifications, help and service

information, the product warranties and notices.

Note: The illustrations in this manual might be slightly different from your hardware.

vi IBM ThinkPad 4X/4X/20X CD-RW Ultrabay 2000 Drive

Part 1: Installation and user’s guide

This guide contains information on installing and using the drive. For problem-solving

information, go to “Problem solving”on page 1-10.

Product description

The IBM ThinkPad 4X/4X/20X CD-RW Ultrabay 2000 Drive can write to and

read from CD-ReWritable (CD-RW) and CD-Recordable (CD-R) discs, and can read

mass-produced, stamped CDs. The drive is compatible with Multi-Read (MR)

CD-ROM and DVD-ROM drives that can read CD-RW discs and other media types,

and with older non-MR CD-ROM drives that can read only CD-R and CD-ROM discs.

The drive writes to CD-RW and CD-R discs at different speeds. The drive can write

to a CD-RW or CD-R disc at up to four times the standard CD-ROM speed, recording

data at up to 1200 KB1per second. At this rate, the drive can record approximately

650 MB2of information on a CD-RW or CD-R disc in about 18 minutes. The drive

can also read data at up to 20 times the standard CD-ROM speed, or 6000 KB per

second.

Note: To use the drive’s CD-recording function, you must install the Easy CD

Creator/DirectCD software (included) for Microsoft Windows 2000

Professional, Windows 98, Windows 95, or Microsoft Windows NT 4.0

Workstation. For more information on the Easy CD Creator/DirectCD

software, see “Software description”on page 1-2.

In addition to this book, the option kit includes:

CD-ReWritable drive

Carrying case

Blank CD-RW disc

Blank CD-R disc

Easy CD Creator/DirectCD software CD

Laser Safety Guide for CD-ROMs

Note: Your option kit might also contain an update diskette for Adaptec software.

Contact your place of purchase if an item is missing or damaged. Be sure to retain

your proof of purchase. It might be required to receive warranty service. See

Appendix B, “Help and service information”on page 2-1 for technical support

information.

1KB equals approximately 1024 bytes when referring to data transfer speeds.

2MB equals approximately 1000000 bytes when referring to storage capacity.

Software description

The Easy CD Creator/DirectCD software CD contains programs that work with

Windows 2000, Windows 98, Windows 95, and Windows NT 4.0. You can use the

programs with your CD-ReWritable drive to create audio and data CDs, to copy CDs,

and to make jewel-case inserts or CD labels. This manual provides basic instructions

on using the software to create CDs. For more information on using the software, go

to the online user’s guide on the software CD.

Installation requirements

To install the CD-ReWritable drive, your computer must meet the following minimum

requirements:

ThinkPad A or T series computer with Ultrabay 2000 drive bay

32 MB of Memory

3.5-inch diskette drive

Windows 2000, Windows 98, Windows 95, or Windows NT 4.0 operating system

Locating the drive controls

The following diagram shows the location of the controls on the front of the drive.

1Power light

This light is visible when drive is in use.

2Eject button

Press this button to eject the CD when the drive is in use.

3Manual eject hole

Use this emergency release to eject the CD when the Eject button does not work.

For more information on manually ejecting a CD, go to “Manually ejecting a CD”

on page 1-5.

1-2 IBM ThinkPad 4X/4X/20X CD-RW Ultrabay 2000 Drive

Installing the drive

The ThinkPad 4X/4X/20X CD-RW Ultrabay 2000 Drive works with any ThinkPad

computer that has an Ultrabay 2000 drive bay.

Your ThinkPad computer includes an online user’s guide that provides drive

installation instructions specific to your computer. To correctly install the CD-RW

Drive into the Ultrabay 2000 drive bay in your ThinkPad computer, be sure to use the

instructions given in the online user’s guide.

Using the drive

This section provides information on how to handle and care for CDs and your

CD-RW drive, how to load CDs into your CD-RW drive, and how to get started using

the Easy CD Creator and DirectCD software applications.

Before you begin

Review the following guidelines before using the drive:

Movement of your ThinkPad while formatting or writing a disc may cause data

errors. Also, minimize typing while formatting or writing to a disc, as this may

also cause data errors.

For best results:

–Keep the ThinkPad on a flat surface when writing to a disc.

–Use the CD-RW drive when the ThinkPad is plugged into an ac outlet. If

the battery runs out while writing to a disc, the disc may be damaged.

–Turn screensavers off. Using a screensaver may interrupt the formatting and

writing process.

The read and write results of the CD-RW drive depend upon the quality and

characteristics of the CD-R and CD-RW media used. Poor results may be

obtained with some CD-R and CD-RW suppliers.

Handling and caring for a CD

Carefully handle and clean CDs, especially writable media types such as CD-R and

CD-RW discs, so that they remain readable. You can prolong the life of your CDs by

using the following precautions.

Attention: Wiping a CD using a circular motion can cause loss of data.

Part 1: Installation and user’s guide 1-3

Handle the CD by the edges or the center hole. Do not touch the surface of the

CD.

To remove dust or fingerprints, wipe the CD from the center to the edge with a

soft, lint-free cloth.

Do not write on the surface.

Do not place the CD in direct sunlight.

Do not use commercial cleaners to clean the CD.

Do not bend the CD.

Caring for the CD-RW drive

To protect your CD-ReWritable drive during operation, observe the following

precautions:

Remove any CD from the drive before moving the drive.

Do not insert foreign objects into the drive.

Do not stack objects on the drive.

Do not remove the drive cover or attempt to service the drive.

Do not operate the drive under any of the following conditions:

–High temperature, high humidity, or direct sunlight

–Excessive vibration, sudden shock, or inclined surface

–Excessive dust

1-4 IBM ThinkPad 4X/4X/20X CD-RW Ultrabay 2000 Drive

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere IBM CD/CDR-Laufwerk Handbücher

IBM

IBM ThinkPad Multi-Burner Ultrabay Slim Drive Bedienungsanleitung

IBM

IBM 4304493 Bedienungsanleitung

IBM

IBM LTO Ultrium 4 Bedienungsanleitung

IBM

IBM OPTIONS P09N4108 Bedienungsanleitung

IBM

IBM 48X-20X Bedienungsanleitung

IBM

IBM 73P4518 Bedienungsanleitung

IBM

IBM 19K4206PT1 Bedienungsanleitung

IBM

IBM 10K3791 Betriebsanleitung

IBM

IBM 37L1388 Bedienungsanleitung

IBM

IBM 22P7035 Bedienungsanleitung

IBM

IBM 22P9218 Bedienungsanleitung

IBM

IBM 22P6959 Bedienungsanleitung

IBM

IBM 04K0058 Bedienungsanleitung

IBM

IBM OPTIONS 24X MAX IDE Bedienungsanleitung

IBM

IBM 48X Max Bedienungsanleitung

IBM

IBM 22P6975 Bedienungsanleitung

IBM

IBM ThinkPad Ultrabay 2000 Drive Bedienungsanleitung

IBM

IBM 28L2234 Bedienungsanleitung

IBM

IBM 71P7279 Bedienungsanleitung

IBM

IBM 22P6969 Bedienungsanleitung

IBM

IBM 22P6979 Bedienungsanleitung

IBM

IBM HH SATA Multi-Burner Bedienungsanleitung

IBM

IBM USB 2.0 CD-RW/DVD-ROM Combo Drive Bedienungsanleitung

IBM

IBM USB 2.0 CD-RW/DVD-ROM Combo Drive Bedienungsanleitung

Beliebte CD/CDR-Laufwerk Handbücher anderer Marken

Philips

Philips CDD3610 Bedienungsanleitung

QPS

QPS Que!Fire Bedienungsanleitung

LG GCC-4241N Bedienungsanleitung

Plextor

Plextor 12X-3 Leitfaden

Samsung

Samsung SN-324B Bedienungsanleitung

Teac

Teac CD-211E Bedienungsanleitung

SmartDisk

SmartDisk Firewire CD-R/W Bedienungsanleitung

Axis

Axis CD-ROM SERVER Bedienungsanleitung

LG CRD-8322B Bedienungsanleitung

Memorex

Memorex 32023234 - 52x32x52x External USB2.0 CD... Montageanleitung

Yamaha

Yamaha CD Recordable/Rewritable Drive CRW3200 Bedienungsanleitung

Sony

Sony CRX230AE Bedienungsanleitung

Sony

Sony CRX - 160E Bedienungsanleitung

Panasonic

Panasonic KX-LD742 Bedienungsanleitung

Pioneer

Pioneer BDR-S13U-X Bedienungsanleitung

Panasonic

Panasonic LK-MC606BP Bedienungsanleitung

Panasonic

Panasonic CF-VCW Series Bedienungsanleitung

LG CRD-8320B Bedienungsanleitung
