IBM CI5VGM Series Bedienungsanleitung

CI5VGM Series

Full-Size Pentium All-in-one CPU Card

Version 1.0A

Industrial CPU Card

PC-Based Computer Boards for Industrial Automation

User’s Manual

ii CI5VGM User’s Manual

This publication is protected by copyright and all rights are reserved. No

part of it may be reproduced or transmitted by any means or in any form,

without prior consent of the original manufacturer.

The information in this document has been carefully checked and is

believed to be accurate. However, the original manufacturer assumes no

responsibility for any inaccuracies that may appear in this manual. In no

event will the original manufacturer be liable for direct, indirect, special,

exemplary, incidental, incidental or consequential damages resulting

from any defect or omission in this manual, even if advised of possibility

of such damages. The material contained herein is for informational

purposes only.

Acknowledgments

Award is a registered trademark of Award Software International, Inc.

Cyber 9520/25 is a trademark of Trident Technologies Inc.

IBM, PS/2 are trademarks of International Business Machines

Corporation.

Intel and Pentium are registered trademarks of Intel Corporation.

Microsoft Windows is a registered trademark of Microsoft Corporation.

MVP3 is a registered trademark of VIA Technologies Inc.

All other product names or trademarks are properties of their respective

owners.

Contents

CI5VGM User’s Manual iii

Contents

Chapter 1 Introduction............................................. 1

Checklist.....................................................................3

Description.................................................................3

Features......................................................................4

Specifications.............................................................4

Intelligence.................................................................7

Board Dimensions .....................................................8

Chapter 2 Installations........................................... 10

CPU Installation......................................................11

Memory Installation................................................12

Jumpers on the CI5VGM.......................................14

Connectors on the CI5VGM...................................24

Watchdog Timer Configuration ............................37

Chapter 3 BIOS Configuration.............................. 38

Chapter 4 Audio Driver Installation Guide.......... 65

Chapter 5 VGA Driver Installation Guide........... 77

Chapter 6 System Monitor Utility......................... 97

Chapter 7 LANDesk Client Manager ................. 105

Chapter 8 Ethernet Setup User’s Guide............. 113

Appendix................................................................. 126

A. I/O Port Address Map.....................................127

B. Interrupt Request Lines (IRQ).......................128

Chapter 1 Introduction

CI5VGM User’s Manual 1

Below are additional information for LCD Panel Type Select

and settings for newer CPUs

SW3: LCD Panel Type Select

1 2 3 4 TFT LCD Panel

ON ON ON ON 640x480 –18

OFF ON ON ON 800x600 –18

ON OFF ON ON 1024x768 –18

OFF OFF ON ON 1024x768 –18+18

ON ON OFF ON 1280x1024 –18+18

1 2 3 4 DSTN LCD Panel

ON ON ON OFF 640x480 –16

OFF ON ON OFF 800x600 –16

ON OFF ON OFF 1024x768 –16

OFF OFF ON OFF 1024x768 –24

ON ON OFF OFF 1280x1024 –24

Settings for New Cyrix/AMD CPUs

on off off on off off off off

95MHz 63MHz 3.5x

MII-400

(333MHz)

off off off on off off off off

100MHz 66MHz 3.5x

MII-433

(350MHz)

on off off on on off on off

95MHz 63MHz 4x

MII-450

(380MHz)

off off off on on off on off

100MHz 66MHz 4x

MII-466

(400MHz)

on off off on off on on off

95MHz 63MHz 5x K6-2/475

K6-3/475

off off off on off on on off

100MHz 66MHz 5x K6-2/500

K6-3/500

Chapter 1 Introduction

2 CI5VGM User’s Manual

Introduction

This manual is designed to give you information on the CI5VGM CPU

card. It is divided into the following sections:

Checklist.......................................................................................3

Description....................................................................................3

Features.........................................................................................4

Specifications................................................................................4

Intelligence ...................................................................................7

Board Dimensions.........................................................................8

The topics covered in this chapter are as follows:

 Checklist

 Description

 Features

 Specifications

 Layout of Key Components and Dimensions

Chapter 1 Introduction

CI5VGM User’s Manual 3

Checklist

Please check that your package is complete and contains the items below.

If you discover damaged or missing items, please contact your dealer.

•

••

•

The CI5VGM Industrial CPU Card

•

••

•

This User’s Manual

•

••

•

1 IDE Ribbon Cable

•

••

•

1 Floppy Ribbon Connector

•

••

•

2 Serial Port Ribbon Cable and 1 Parallel Port Attached to a

Mounting Bracket

•

••

•

1 Audio Output Ribbon Cable and EXTVGM Daughter Card

Audio I/O Connector (supplied onlyif the CPU card has the audio

capability)

•

••

•

1 Diskette Containing VIA PCI IDE Driver and Flash Memory

Utility, VIA IRQ Routing Driver, VIA VxD Driver

•

••

•

2 Diskettes Containing Trident 9520/25 VGA Driver

•

••

•

2 Diskettes Containing Intel 82558B LAN Driver

•

••

•

5 Diskettes Containing YAMAHA 715 Audio Driver

•

••

•

1 Diskette Containing System Monitor Utility

•

••

•

1 Optional CD containing Intel LANDesk Client Manager

Description

The CI5VGM is a Pentium Industrial CPU card based on the VIAMVP3

chipset and is fully designed for harsh industrial environment. It features

a Socket 7 processor connector that is compatible with Pentium-level

processors from Intel, Cyrix, AMD and IDT. With three DIMM sockets

on board, this card accommodates up to 384MB of system memory.

The CI5VGM comes with Winbond’s W83781D hardware monitoring

device that monitors system and CPU temperature, system voltages, and

CPU and chassis fan speeds to prevent system crashes by warning the

user of adverse conditions. The power management feature provides

power savings by slowing down the CPU clock, turning off the monitor

screen and stopping the HDD spindle motor.

Chapter 1 Introduction

4 CI5VGM User’s Manual

Features

•

••

•

Socket 7, CPU Speed 90~550MHz

•

••

•

Bus Speed 60/66/75/83/95/100MHz

•

••

•

VIA MVP3 AGPset

•

••

•

Up to 384MB of system memory, ECC function supported

•

••

•

Trident 9520/25 AGP VGA chipset for LCD & CRT display

•

••

•

YAMAHA 715 Audio Chip

•

••

•

16 level programmable watchdog timer, from 0-30 seconds

•

••

•

High speed bi-directional SPP/ECP/EPP parallel port

•

••

•

ISA High Drive

•

••

•

2MB~72MB DiskOnChip support

•

••

•

Hardware Monitoring

•

••

•

Win95 shut-off, Modem ring-on via ATX power

•

••

•

10/100M Base-T Ethernet interface, IEEE 802.3 compliance

specification

•

••

•

Port 80 display LED

•

••

•

COM2 supports RS232/433/485

Specifications

•

••

•

Processor Socket: Socket 7 connector

•

••

•

Processor:

Intel Pentium 120/133/150/166/200

Intel Pentium MMX (P55C) 166/200/233

Cyrix 6x86/6x86L P150+/P166+/P200+

Cyrix 6x86MX PR166/PR200/PR233/PR266

Cyrix 6x86MII PR266/PR300/PR333/PR366

AMD K5 PR166

AMD K6 166/200/233/266/300

AMD K6-2/300/333/350/366/380/400/450

IDT WinChip C6 180/200/225MHz

IDT WinChip2-3D 200/225/266MHz

•

••

•

Chipset: VIA MVP3 AGPset with PCI EIDE and RTC built-in

•

••

•

Secondary Cache: 1 MB

Chapter 1 Introduction

CI5VGM User’s Manual 5

•

••

•

Memory Sockets:

Three 168-pin DIMM sockets

Memory types: SDRAM (Synchronous DRAM)

DIMMs: EDO DRAM or SDRAM (Synchronous DRAM)

DIMM Size: 8MB, 16MB, 32MB, 64MB, 128MB

•

••

•

BIOS: Y2K compliant Award BIOS, PnP support

•

••

•

FLASH EEPROM (256KB) for BIOS update

•

••

•

ISA Plug and Play (PnP) extension

•

••

•

Power management

•

••

•

DMI BIOS Support:

Desktop Management Interface (DMI) allows users to download

system hardware-level information such as CPU type, CPU

speed, internal/external frequencies and memory size.

•

••

•

Multi I/O: Winbond W83877TF

•

••

•

Parallel Port: One high-speed parallel port, SPP/EPP/ECP mode

•

••

•

Serial Port: Two 16550 UART compatible ports with COM1 as

RS232 and COM2 jumper configurable as RS232/422/485

•

••

•

Enhanced IDE: Two Bus Mastering EIDE mode, up to 4 devices,

Two EIDE interfaces for up to four devices, support PIO Mode 3/4

or Ultra DMA/33 IDE Hard Disk, LS-120 and ATAPI CD-ROM.

•

••

•

FDD Interface: Two floppy drives (360KB, 720KB, 1.2MB,

1.44MB, 2.88MB)

•

••

•

AGP bus CRT/LCD: Trident 9520/25 chipset

•

••

•

Embedded 2MB/2.5MB (9520/9525) SDRAM display

memory

•

••

•

Simultaneous CRT & LCD display

•

••

•

LCD panel supports DSTN/TFT

•

••

•

1600x1200x256 colors CRT resolution

•

••

•

Up to 1280x1024x64K colors resolution for color active

matrix TFT panels (12, 18, and 24bit analog) or (12+12),

(18+18) double pixel/CLK interface

•

••

•

USB Interface: Two USB pin-header connectors, compliant with

USB Specification Rev. 1.0

Chapter 1 Introduction

6 CI5VGM User’s Manual

•

••

•

Onboard Audio (optional): The onboard audio consists of a

YAMAHA YMF715-S (OPL3-SA3) single audio chip that

integrates OPL3 and its DAC, 16bit Sigma-delta CODEC,

MPU401 MIDI interface, joystick with timer, and a 3D enhanced

controller including all the analog components which is suitable

for multimedia application.

•

••

•

DiskOnChip: The M-Systems flask disk supports systemboot and

storage capacity from 2MB to 72MB.

•

••

•

Watchdog Timer: 16-level, programmable

•

••

•

I/O port 0443H to enable watchdog.

•

••

•

I/O port 0441H to disable watchdog.

•

••

•

Time-out timing select 0/2/4/6/8/10/12/14/16/18/20/22/

24/26/28/30 seconds (+/-20%).

•

••

•

PCI Bus Ethernet Interface: Intel 82558B

•

••

•

PCI local bus Ethernet controller

•

••

•

IEEE802.3u auto-negotiation for automatic speed selection

•

••

•

10/100Mbps operation in a single port PCI bus master

architecture

•

••

•

Wake On LAN function support on board

•

••

•

Green Function: Power management via BIOS, activated through

mouse/keyboard movement

•

••

•

Keyboard and Mouse Connectors: PS/2 type mini-DIN that

supports PC/AT; supports a 5-pin external keyboard connector

•

••

•

IrDA Interface: Pin-header connector for the optional IrDA

external connector

•

••

•

PICMG Compliance: Fully compliant to PICMG standards

•

••

•

Environmental and Mechanical:

•

••

•

AT Power Supply: Max. 15A @+5V

•

••

•

ATX Power Supply: Min 1A @+5VSB, Max15A@+5V

•

••

•

Temperature: 0°C to 60°C

•

••

•

Humidity: 5% to 95%

•

••

•

Dimensions: 338mm x 122mm

Inhaltsverzeichnis

Andere IBM Computerhardware Handbücher

IBM

IBM BladeCenter S SAS RAID Controller Module Bedienungsanleitung

IBM

IBM PowerPC 405GP Bedienungsanleitung

IBM

IBM Power S1014 Bedienungsanleitung

IBM

IBM 0367 Bedienungsanleitung

IBM

IBM 4764 Bedienungsanleitung

IBM

IBM 1 GB Microdrive Storage Card Bedienungsanleitung

IBM

IBM eserver 225 Series Bedienungsanleitung

IBM

IBM Power Systems 8247-42L Bedienungsanleitung

IBM

IBM Power System POWER7 Series Kurzanleitung

IBM

IBM MPC603EC Bedienungsanleitung

IBM

IBM 1620 1 Bedienungsanleitung

IBM

IBM Computer Gebrauchsanweisung

IBM

IBM 6611 Bedienungsanleitung

IBM

IBM 4331 Bedienungsanleitung

IBM

IBM M791 Series Bedienungsanleitung

IBM

IBM eserver Cluster 1350 Montage- und Wartungsanleitung

IBM

IBM QLogic 4Gb Fibre Channel Expansion Card Bedienungsanleitung

IBM

IBM ATA 133 Bedienungsanleitung

IBM

IBM Power Systems 9223-22S Bedienungsanleitung

IBM

IBM 9332 Bedienungsanleitung

IBM

IBM PCI Cryptographic Coprocessor Leitfaden

IBM

IBM Advanced SerialRAID/X Bedienungsanleitung

IBM

IBM SAN Volume Controller 2145-CF8 Handbuch

IBM

IBM Redbooks 2/4 Port Ethernet Expansion Card Bedienungsanleitung

Beliebte Computerhardware Handbücher anderer Marken

EMC2

EMC2 VNX Series Betriebsanleitung

Panasonic

Panasonic DV0PM20105 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Bedienungsanleitung

Gigabyte

Gigabyte B660M DS3H AX DDR4 Bedienungsanleitung

Raidon

Raidon iT2300 Bedienungsanleitung

National Instruments

National Instruments PXI-8186 Bedienungsanleitung

Hauppauge

Hauppauge WinTV-HVR-2250 Bedienungsanleitung

Kontron

Kontron CP6002 Bedienungsanleitung

Manhattan

Manhattan 702843 Bedienungsanleitung

Aphex

Aphex 230 Bedienungsanleitung

AMD

AMD Phenom II Betriebshandbuch

Intel

Intel NUC 12 Pro Bedienungsanleitung

dbx

dbx Zone Pro 1260 Bedienungsanleitung

Galaxy

Galaxy GHDX2-2430S-24F4D Bedienungsanleitung

Intel

Intel AXXRMFBU4 Bedienungsanleitung

Kontron

Kontron DIMM-PC/MD Bedienungsanleitung

ST X-NUCLEO-SAFEA1B Betriebsanleitung

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Bedienungsanleitung
