IBM 1 GB Microdrive Storage Card Bedienungsanleitung

IBM storage products

Page 1

IBM Technology Group Support Center version 1.1

Ibm

Quick installation guide

IBM Microdrive™

CF+ Type II

Models: DSCM-11000

DSCM-10512

DSCM-10340

Handling precautions

•Follow these suggestions to optimize the use of

your IBM Microdrive, as well as those devices

in which it is installed:

•Do not seal the breather hole! Sealing the

breather hole may result in loss of data.

•Do not press on the drive! Do not apply any

force to the drive during handling or installation.

•Always handle the drive with care to prevent

damage from shock, vibration, or electrostatic

discharge (ESD).

•Handle the drive carefully by the edges. Do not

touch any exposed printed circuit board.

•Do not write on the label or remove it. Do not

apply additional labels.

•Always carry the drive in its plastic case.

•Do not drop the drive.

•Do not expose the drive to wet conditions.

•Do not place the drive near a strong magnetic

field.

•Do not expose the drive to extreme tempera-

tures.

•Do not use the drive in CF+TM Type II slots

without an ejection mechanism.

•The Microdrive may become hot during opera-

tion. Be careful when removing the drive from

the host device immediately after operation.

Quick installation procedure

Note: Back up all data before beginning installation!

Refer to the manual that came with your computer,

camera, or other device to determine if it is compatible

with the CF+ Type II or the PC card type II drive/inter-

face adapter and to find instructions on inserting and

removing the IBM microdrive.

ŸUsing the IBM Microdrive with a PC card adapter

With a PC card adapter the IBM Microdrive can be

installed in devices such as digital cameras or PCs that

have a PC card type II slot. If your Microdrive did not

come with a PC card, it can be purchased separately.

With both facing upward (the arrow at the upper left

corner of the Microdrive), slide the IBM Microdrive firmly

along the track into the PC card adapter. [If either is not

facing upward, the Microdrive will not fit into the track.]

Note: When inserting or removing the PC card, hold the

PC card, not the IBM Microdrive.

ŸUsing the IBM Microdrive without a PC card adapter

The IBM Microdrive is compatible with the CF+ Type II

standard and can be used in devices with the CF+ Type

II slot without a card adapter. Refer to the manual

shipped with the device to determine its slot type.

If your PC does not recognize the IBM Microdrive

With the Plug & Play feature of Windows® 98 and 95

your PC should automatically recognize the IBM

Microdrive. If it does not do so, do the following:

1. In Windows select Start and Settings.

2. Click Control Panel.

3. Click the Hardware icon, click Next.

4. Select No in the Hardware Wizard, click Next.

5. Select Hard disk controller as the hardware type,

click Next.

6. Specify Standard IDE/ESDI hard disk controller

Operating systems

The IBM Microdrive has been tested for general

compatibility with the following operating systems:

•Windows 98

•Windows 95

•Windows CE

•Apple® OS (refer to the URL below for the

applicable operating systems)

Other operating systems may be compatible with the

IBM Microdrive but have not been tested.

Product information

The latest product information can be obtained from

http://www.ibm.com/storage/microdrive

This includes

•technical tips

•complete product specifications

•a list of compatible devices

iBM®

www.ibm.com/harddrive

IBM Technology Group Support Center

Telephone: 888.426.5214 or 507.286.5825

E-mail: [email protected]

Singapore Technology Group Support Center

Telephone: (65)6418.9595 or 1800.418.9595

E-mail: [email protected]

UK Technology Group Support Center

Telephone: 44.1475.898.125

E-mail: [email protected]

Germany Technology Group Support Center

Telephone: 49.7032.153050

E-mail: [email protected]

IBM Systems Storage Division

5600 Cottle Road

San Jose CA 95193

www.ibm.com/storage

Printed in the United States of America

09-2000

IBM is the registered trademark of International Business Machines Corporation and

Microdrive is the trademark of International Business Machines Corporation.

Other company, product, and service names may be trademarks or service marks of others.

Produced by the IBM Technology Group Support Center.

Hark disk drive specifications, IBM Microdrive with CF Type II interface, version 1.0,

DSCM-11000/10512/10340

Product Description data represents IBM’s design objectives and is provided for comparative

purposes; actual results may vary based on a variety of factors. This product data does not

constitute a warranty. Questions regarding IBM’s warranty terms or methodology used to

derive this data should be referred to the IBM Technology Group Support Center.

Data is subject to change without notice.

Date: 25 September, 2000

Page 2

IBM Technology Group Support Center version 1.1
