IBM System Storage TS3100 and TS3200 Tape Libraries 1

򔻐򗗠򙳰®

IBM System Storage TS3100 and TS3200 Tape

Libraries

IBM Storage at-a-glance guide

The IBM® System Storage®TS3100 and TS3200 Tape Libraries are well-suited for handling the backup,

restore, and archive data-storage needs for small-to-medium environments.

The TS3100 and TS3200 Tape Libraries are shown in Figure 1.

Figure 1. TS3100 (3573 L2U) Tape Library and TS3200 (3573 L4U) Tape Library

The TS3100 library with its use of one Ultrium LTO-5 Full-High tape drive or up to two Ultrium LTO-5

Half-High tape drives and 24 tape cartridge capacity can store up to 72 TB compressed (36 TB native).

The TS3200 48 tape cartridge capacity and use of up to two Ultrium LTO-5 Full-High tape drives or up to

four Ultrium LTO-5 Half-High tape drives scales to 144 TB compressed (72 TB native). The IBM Ultrium

LTO-5 tape drive supports up to 140 MBps native data-transfer.

Both libraries come standard with a bar-code reader, supporting the libraries operation in sequential or

random access mode. The design of the remote library management through a standard web interface

offers flexibility and greater administrative control of storage operations. Path Failover, a new optional

feature for the libraries, is designed to provide automatic control path failover to a preconfigured

redundant control path in the event that a host adapter or control path drive is lost, without aborting the

current job in process.

Did you know?

The TS3100 and TS3200 Tape Libraries are designed for storage management, capacity, performance,

data protection, reliability, affordability, and application requirements. They are functionally rich,

high-capacity, entry-level tape-storage solutions that incorporate the latest generation of LTO IBM Ultrium

5 tape technology.

Both IBM TS3100 and TS3200 Models are excellent solutions for large-capacity or high-performance tape

backup with or without random access. They are also excellent choices for tape automation for IBM

Power Systems™, IBM System x®, and other open systems.

IBM System Storage TS3100 and TS3200 Tape Libraries 2

Highlights

The IBM TS3100 and TS3200 are designed to take advantage of Linear Tape-Open (LTO) technology to

cost effectively handle growing storage requirements:

The TS3100 uses one LTO Full-High tape drive or up to two LTO Half-High tape drives and 24-tape

cartridge capacity. The library is configured with two removable cartridge magazines, one on the left

side (12 data cartridge slots) and one on the right (12 data cartridge slots). Additionally, the left

magazine includes a single mail slot to help support continuous library operation while importing and

exporting media.

The TS3200 scales with the use of up to two LTO Full-High tape drives or up to four LTO Half-High

tape drives and 48 tape cartridge capacity. The library is configured with four removable cartridge

magazines, two on the left side (24 data cartridge slots) and two on the right (24 data cartridge slots).

Additionally, the lower left magazine includes a three-slot I/O station to help support continuous library

operation while importing and exporting media.

LTO Technology

The IBM Ultrium LTO-5 tape drive supports up to 140 MBps native data-transfer. IBM LTO standards

leadership continues with the LTO-4 tape drive doubling the storage capacity of its predecessor and the

LTO-5 tape drive doubling the storage capacity of the LTO-4 tape drive with 3.0 TB compressed (1.5 TB

native) on LTO-5 media. Both drives are backward compatible (read and write) with their predecessor

LTO media and have read capability of LTO media two generations back. They both have speed

matching and channel calibration for improved performance. They support the leading operating systems

and popular backup software.

Security

Data is one of the most highly valued resources in a competitive business environment. Protecting that

data, controlling access to it, and verifying its authenticity while maintaining its availability are priorities in

our security–conscious world. Increasing regulatory requirements are also helping to drive the need for the

adequate security of data. Ultrium LTO-4 and LTO-5 drive technology helps address security and

compliance requirements with its continued Write Once Read Many (WORM) and Application Managed

Encryption (AME) capability.

Advanced encryption through Library Managed Encryption (LME) and System Managed Encryption

(SME) are available as optional Transparent LTO Encryption feature 5900. For key management for

encryption, IBM Tivoli® Key Lifecycle Manager (TKLM) V2 is required. Whether encryption is

application- or hardware-based, vital data can securely be stored to help ensure compliancy with data

security, information disclosure, and privacy regulations for data at rest.

IBM System Storage TS3100 and TS3200 Tape Libraries 3

IBM Linear Tape File System (LTFS)

LTFS is the first file system that works in conjunction with LTO generation 5 tape technology to set a new

standard for ease-of-use and portability for open systems tape storage. This drive is the first LTO

generation to introduce media partitioning, which allows LTO-5 media to be divided into segments,

improving accessibility by providing the ability to quickly locate data to retrieve or update.

With LTFS, accessing data stored on an IBM tape cartridge became as easy and intuitive as using a USB

flash drive. With LTFS file manager, reading data on a tape cartridge is as easy as dragging and

dropping. Users can run any application designed for disk files against tape data without being concerned

that the data is physically stored on tape. Built on the LTO Ultrium 5 format standard, IBM Linear Tape

File System Library Edition provides a direct, intuitive, graphical access to data stored in IBM tape drives

and libraries using LTO generation 5 tape cartridges.

Benefits of LTFS Library Edition (LE) are as follows:

The graphical user interface helps reduce complexity by enabling an icon-based view of an LTO-5

library, including tape cartridges and files using the operating system's file manager.

LE helps reduce costs because it does not require any additional tape management software or

utilities.

The file system API of the operating system is used to provide a basic read/write interface to the tape

library for applications without any additional operating system enhancements such as “plug-ins” or

service packs.

“Mount-less” cartridge inquiry for fast access is achieved after the tape library is inventoried. Tape

cartridges do not have to be remounted to retrieve content index data, and basic cartridge information

like volume name, serial number, etc.

LTFS LE software can be ordered concurrently with hardware, or as software only for installed

supported tape libraries. LTFS LE for LTO-5 drives can be ordered as PID software base order

number 5639-LT1. The feature number is 5806.

IBM System Storage TS3100 and TS3200 Tape Libraries 4

Part number information

Table 1 lists part numbers and feature codes for the TS3100 and TS3200.

Table 1. TS3100 and TS3200 ordering information

TS3100 TS3200 Description HVEC MTM

Yes No Tape Library Model L2U Driveless 35732UL 3573 L2U

No Yes Tape Library Model L4U Driveless 35734UL 3573 L4U

Drive options Part number Feature code

Yes Yes 6 Gbps SAS 46X2683 8245

Yes Yes

Ultrium 5 Full-High

8 Gbps Fibre Channel 46X2682 8244

Yes Yes 6 Gbps SAS 46X2685 8247

Yes Yes

Ultrium 5 Half-High

8 Gbps Fibre Channel 46X2684 8248

Yes Yes LVD SCSI 95P5002 8143

Yes Yes 3 Gbps SAS 95P5006 8145

Yes Yes

Ultrium 4 Full-High

4 Gbps Fibre Channel 95P5004 8144

Yes Yes 6 Gbps SAS 46X7117 8149

Yes Yes

Ultrium 4 Half-High

8 Gbps Fibre Channel 46X6912 8148

Yes Yes Ultrium 3 Half-High 6 Gbps SAS 46X7122 8049

Optional feature codes

Yes Yes Path Failover (at least 2 drives required) 45E9503 1682

Yes Yes Transparent LTO Encryption 45E3081 5900

Yes Yes Rack mount 23R6998 7002

Yes Yes Right-side magazine set 23R6999 8106

Yes No Left-side magazine 45E2237 8109

No Yes Left-side magazine, upper 45E2225 8107

No Yes Left-side magazine, lower 45E2231 8108

Yes Yes Ultrium 5 media 5-packs 46C2084 8505

Yes Yes Ultrium 4 media 5-packs 95P4278 8405

Yes Yes

Ultrium tape cartridges

WORM media*

Ultrium 3 media 5-packs 95P2020 8305

Yes Yes Ultrium Cleaning Cartridge 23R7008 8002

No Yes Additional Power Supply 23R7263 1901

* Ultrium 3, 4, and 5 WORM media and tape cartridge options can be ordered at

http://www.ibm.com/systems/storage/media/tapemediacenter/

The IBM Ultrium WORM cartridges (Machine Type 3589) were designed for applications, such as

archiving and data retention, and for applications that require an audit trail. IBM Ultrium 3, 4, and 5 Tape

Drive WORM support allows vital data to be stored in a non-erasable, non-rewritable format provided for

IBM System Storage TS3100 and TS3200 Tape Libraries 5

these t

pes of applications. The IBM Ultrium WORM cartrid

es work with the IBM S

stem Stora

e LTO

Ultrium Tape Drives to help prevent the alteration or deletion of user data. In addition, IBM has taken

several steps to reduce the possibility of tampering with the information:

The bottom of the cartridge is molded in a different color than rewritable cartridges.

The special cartridge memory helps protect the WORM nature of the media.

A unique format is factory-written on each WORM cartridge.

Table 2 lists the cabling ordering information for the TS3100 and TS3200.

Table 2. TS3100 and TS3200 cabling ordering information

Cables Part number

4.5 m VHDCI/HD68 SCSI Cable 23R7134

10.0 m VHDCI/HD68 SCSI Cable 23R7135

13.0 m LC/LC Fibre Cable 23R7137

25.0 m LC/LC Fibre Cable 23R7138

LC-SC Fibre Cable Interposer 23R7140

2M SAS/Mini-SAS 1x Cable 95P4711

2M Mini-SAS/Mini-SAS 1x Cable 95P4713

SAS/Mini-SAS 4x Interposer 95P4994

Mini-SAS/Mini-SAS 4x Interposer 95P4996

Table 3 lists the common specifications for the TS3100 and TS3200.

Table 3. TS3100 and TS3200 specifications

Specifications

Tape drive type IBM Ultrium LTO-5 Full-High and Half-High

IBM Ultrium LTO-4 Full-High and Half-High

IBM Ultrium LTO-3 Half-High

Tape drive physical capacity Up to 3.0 TB per cartridge compressed; 1.5 TB native with LTO-5 media

Up to 1.6 TB per cartridge compressed; 800 GB native with LTO-4 media

Up to 800 GB per cartridge compressed; 400 GB native with LTO-3 media

Data transfer rate (per drive) Up to 140 MBps native with LTO-5 tape drive

Up to 120 MBps native with LTO-4 tape drive

Up to 80 MBps native with LTO-3 tape drive

Attachment support 8 Gbps fibre channel and 6 Gbps SAS interfaces

LVD SCSI (LTO-4 Full-High)

4 Gbps fibre channel and 3 Gbps SAS interfaces (LTO-4 Full-High)

Warranty Three-year, customer-replaceable unit (CRU) service in most countries

Operating environment

Temperature 50 to 113 degrees F (10 to 45 degrees C)

Relative humidity 10% RH to 80% RH (non-condensing)

Electrical power 4.0 amps at 100 V ac; 2.0 amps at 240 V ac 0.1 KVA

IBM System Storage TS3100 and TS3200 Tape Libraries 6

Table 4 lists the unique specifications of the TS3100.

Table 4.

TS3100 unique specifications

TS3100 specifications

Number of drives 1 Full-High or up to 2 Half-Highs

Number of tape

cartridges

Number of mail slots 1

Library physical

capacity

Up to 72 TB per tape library compressed; 36 TB native with Ultrium LTO-5 media

Up to 38.4 TB per tape library compressed; 19.2 TB native with Ultrium LTO-4 media

Up to 19.2 TB per tape Library compressed; 9.6 TB native with Ultrium LTO-3 media

Dimensions (W x H x D)

Stand-alone 17.6 in (447.5 mm) x 3.84 in (97.6 mm) x 31.9 in (810 mm)

Rack-mount 17.6 in (447.5 mm) x 3.44 in (87.6 mm) x 29.13 in (740 mm)

Weight 33 lb. (15 kg) without rack mount

What’s in the TS3100 shipment group box?

The box contains the following items:

Tape Library Model L2U Driveless

12 data cartridge left magazine

12 data cartridge right magazine

IBM Ultrium Drives (ordered separately)z

Power Cord (must be selected)z

One IBM Ultrium Cleaning Cartridge (universal)z

IBM System Storage TS3100/TS3200 Tape Setup, Operator and Service Guide

IBM System Storage TS3100/TS3200 Tape Library Installation Quick Reference

Quality Hotline Cardz

Device Driver readme sheetz

Safety pointer multi-language readme sheetz

License Agreement for Machine Codez

NLS Translated Safety CDz

Misc Documents CDz

IBM System Storage TS3100 and TS3200 Tape Libraries 7

Table 5 lists the unique specifications for the TS3200.

Table 5. TS3200 unique specifications

TS3200 specifications

Number of drives Up to 2 Full-Highs or up to 4 Half-Highs

Number of tape

cartridges

Number of mail slots 3

Library physical

capacity

Up to 144 TB per tape library compressed; 72 TB native with Ultrium LTO-5 media

Up to 76.8 TB per tape library compressed; 38.4 TB native with Ultrium LTO-4 media

Up to 38.4 TB per tape Library compressed; 19.2 TB native with Ultrium LTO-3 media

Dimensions (W x H x D)

Stand-alone 17.6 in (447.5 mm) x 7.29 in (185.2 mm) x 31.9 in (810 mm)

Rack-mount 17.6 in (447.5 mm) x 6.89 in (175.2 mm) x 29.13 in (740 mm)

Weight 47 lb. (21.3 kg) without rack mount

What’s in the TS3200 shipping box?

The box contains the following items:

Tape Library Model L4U Driveless

12 data cartridge left upper magazine

12 data cartridge left lower magazine

Two 12 data cartridge right magazines

IBM Ultrium Drives (ordered separately)z

Power Cord (must be selected)z

One IBM Ultrium Cleaning Cartridge (universal)z

IBM System Storage TS3100/TS3200 Tape Setup, Operator and Service Guide

IBM System Storage TS3100/TS3200 Tape Library Installation Quick Reference

Quality Hotline Cardz

Device Driver readme sheetz

Safety pointer multi-language readme sheetz

License Agreement for Machine Codez

NLS Translated Safety CDz

Misc Documents CDz

IBM System Storage TS3100 and TS3200 Tape Libraries 8

Supported hardware platforms

Supported hardware platforms for the TS3100 and the TS3200 are:

IBM BladeCenter®

IBM Power Systems™z

IBM System p®z

IBM System i®z

IBM System x®z

IBM System z®and S/390®z

Advanced Micro Devices (AMD)

Hewlett Packard

Intel (x86 and x86

64)

Sun

Supported operating systems

Supported operation systems for the TS3100 and the TS3200 are:

IBM AIX® 7.1 or later

IBM i 7.1 or laterz

IBM VIOS 2.2.0 or later with client IBM iz

HP HP-UX 11iv3 or laterz

Microsoft Windows Server 2003 SP2 or laterz

Microsoft Windows Server 2008 SP2 or laterz

Microsoft Windows Server 2008 R2 or laterz

Novell SUSE Linux Enterprise 11 SP1 or laterz

Red Hat Linux Enterprise 5.5 or laterz

Oracle Solaris 10 or laterz

Check the latest support levels and configuration information for LTO drives, platforms, operating

systems, and attachments at the Systems Storage Interoperation Center (SSIC):

http://www.ibm.com/systems/support/storage/config/ssic

IBM System Storage TS3100 and TS3200 Tape Libraries 9

Supported software products

The TS3100 and TS3200 supported software products are:

IBM: Backup Recovery and Media Services (BRMS)

IBM: High Performance Storage System (HPSS)

IBM: Linear Tape File System Library Edition

IBM: Tivoli Storage Manager

IBM: Tivoli Key Lifecycle Manager (TKLM)

Atempo: Time Navigator 4.1/4.2

BakBone Software: NetVault

CommVault Systems: Galaxy

CA: ARCserve Backup

EMC: NetWorker

Front Porch Digital: DIVArchive

HP: OpenView Storage Data Protector 5.5/6.0/6.1

Microsoft System Center Data Protection Manager 2007

Symantec: Backup Exec 12.5 and 2010

Symantec: NetBackup

Thales Encryption Manager for Storage: TEMS

Yosemite: Backup

For current IBM software products and independent software vendor products supporting TS3100 and the

TS3200, see the Independent Software Vendor (ISV) matrix for 3592 and LTO drives:

ftp://public.dhe.ibm.com/storage/tape/lto

isv

matrix.pdf

IBM System Storage TS3100 and TS3200 Tape Libraries 10

Warranty period and warranty service

Every TS3100 and TS3200 is covered by the following warranty:

System three-year, customer-replaceable unit (CRU) service in most countriesz

Optional IBM features initially installed in an IBM system carry the same warranty and warranty service

support category as the system. If installed after the initial system installation, they carry the balance of

the system warranty or the optional feature warranty, whichever is greater.

Customer-replaceable unit (CRU) service

IBM provides replacement CRUs for you to install. CRU information and replacement instructions are

included with your machine and are available from IBM upon your request.

Table 6 lists the various warranty options for the TS3100 and TS3200 tape libraries.

Table 6. Warranties and maintenance

IBM ServicePac® TS3100 L2U TS3200 L4U

Warranty and maintenance option

3 Year Onsite Repair 24x7 4 Hour Response 42V1346 42V1541

3 Year Onsite Repair 9x5 Next Business Day 42V1345 42V1540

5 Year Onsite Repair 24x7 4 Hour Response 42V1347 42V1542

Maintenance agreement

1 Year Onsite Repair 24x7 4 Hour Response 42V1349 42V1544

1 Year Onsite Repair 9x5 Next Business Day 42V1348 42V1543

2 Year Onsite Repair 24x7 4 Hour Response 42V1351 42V1546

2 Year Onsite Repair 9x5 Next Business Day 42V1350 42V1545

Remote technical support

RTS for Tape Devices- 1yr 91Y8855 91Y8855

RTS for Tape Devices- 3yr 91Y8856 91Y8856

Note: Each ServicePac is country-specific and is valid only when purchased and registered in the country

in which IBM service will be provided. Refer to the IBM ServicePac Worldwide Product Matrix at the

following location for a complete list of the ServicePac part numbers specific to your country:

https://www-304.ibm.com/sales/gss/download/spst/servicepac/extProductSelectorWWW.do

Andere Handbücher für System Storage TS3100

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere IBM Lagerung Handbücher

IBM

IBM Ultrastar 36LP Bedienungsanleitung

IBM

IBM Storwize V7000 Unified2073-720 Bedienungsanleitung

IBM

IBM LTO Generation 3 Bedienungsanleitung

IBM

IBM DJNA-352500 Bedienungsanleitung

IBM

IBM DDS Generation 6 Bedienungsanleitung

IBM

IBM Internal ZIP Drive Bedienungsanleitung

IBM

IBM 1402 Bedienungsanleitung

IBM

IBM System Storage DS3300 Betriebsanleitung

IBM

IBM E Server x336 Series Bedienungsanleitung

IBM

IBM Travelstar 6GT Bedienungsanleitung

IBM

IBM XIV STORAGE SYSTEM Handbuch

IBM

IBM DR550 Bedienungsanleitung

IBM

IBM SYSTEM STORAGE EXP3000 - INTEROPERABILITY MATRIX... Bedienungsanleitung

IBM

IBM SAN768B-2 Handbuch

IBM

IBM Elastic Storage System 3000 Bedienungsanleitung

IBM

IBM TotalStorage 3580 L33 Bedienungsanleitung

IBM

IBM C1B 1.12 Brick On Sled Carrier 128-pin HPC Bedienungsanleitung

IBM

IBM SAN Volume Controller 2145-8F2 Handbuch

IBM

IBM DDS Gen 5 Bedienungsanleitung

IBM

IBM Storwize V5000 Bedienungsanleitung

IBM

IBM Cloud Object Storage System Slicestor 2212... Bedienungsanleitung

IBM

IBM N6270 Bedienungsanleitung

IBM

IBM DR550 V3.0 Bedienungsanleitung

IBM

IBM System storage DS6000 Series Bedienungsanleitung

Beliebte Lagerung Handbücher anderer Marken

QNAP

QNAP TS 32PXU Series Bedienungsanleitung

LaCie

LaCie RUGGED RAID Bedienungsanleitung

Freecom

Freecom CLS DOCK Bedienungsanleitung

PNY

PNY Attache P-FD64MBATT3 Bedienungsanleitung

HP StorageWorks MSL2024 Bedienungsanleitung

OLT

OLT 6x6 Maximizer Bedienungsanleitung

Transcend

Transcend JetFlash 160 Bedienungsanleitung

LaCie

LaCie RUGGED MINI Bedienungsanleitung

Thunderbolt

Thunderbolt 600 Bedienungsanleitung

Panasonic

Panasonic LB-DH8 series Handbuch

Intel

Intel RAID High Availability Bedienungsanleitung

LaCie

LaCie 12big Thunderbolt 3 Bedienungsanleitung

Spectra Logic

Spectra Logic T-Series Spectra T50e Bedienungsanleitung

Panasonic

Panasonic LKM-F931-1 Bedienungsanleitung

Tabernus

Tabernus Enterprise Erase E2400 Bedienungsanleitung

Rocstor

Rocstor COMMANDER 3F series Bedienungsanleitung

HP P9000 Bedienungsanleitung

Western Digital

Western Digital Ultrastar Data60 Bedienungsanleitung
