iCanServer540R User’s Guide

Rev1.0 (Nov. 2006)

iCanServer540R User’s Guide

Note

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures :

zReorient or relocate the receiving antenna.

zIncrease the separation between the equipment and receiver.

zConnect the equipment into and outlet on a circuit different from that to which

the receiver is connected

zConsult the dealer or an experienced radio/TV technician for help.

If you would like to use the iCanServer540R A/V server for security, monitoring, please check

the legal regulations within the country.

Use only the power adapter provided with the iCanServer540R.

Do not disassemble iCanServer540R. You will be excluded from After Service when

disassembled.

Be careful not to cause any physical damage by dropping or throwing the iCanServer540R A/V

Server. Especially keep the A/V server out of reach from children.

iCanerver540R is designed for indoor use only. When using iCanServer540R outdoors or in n

environment that exceeds the limited range, you must separately use a water-resistant case.

Directions

Rev.1.0 (Nov. 2006) 2

iCanServer540R User’s Guide

Any changes or modifications in construction of this device which are not expressly

approved by the party responsible for compliance could void the user’s authority to

operate the equipment.

Caution

None of the parameters in administrative page should be changed while iCanServer540R

is recording video or while you are playing back recorded video from iCanServer540R.

Caution

Rev.1.0 (Nov. 2006) 3

iCanServer540R User’s Guide

Table of Contents

1. Introduction ............................................................................................................................................ 6

1.1. Overview .......................................................................................................................... 6

1.2. Features of iCanServer540R ......................................................................................... 6

1.3. Applications of iCanServer540R ................................................................................... 7

2. Product Description ............................................................................................................................... 8

2.1. Contents .......................................................................................................................... 8

2.2. Preview ............................................................................................................................ 8

2.3. Physical description ........................................................................................................ 9

2.4. PC Requirements .......................................................................................................... 11

2.5 Quick Installation Guide ................................................................................................ 11

3. Connecting iCanServer540R to Network ........................................................................................... 14

3.1. Connecting to LAN ........................................................................................................ 14

3.2. Connecting to xDSL/Cable Modem ............................................................................. 15

4. IP-Installer ............................................................................................................................................ 17

4.1. Main window of IP-Installer ........................................................................................ 17

5. Configuring the A/V Server in Administration Mode ........................................................................ 18

5.1. Log On ............................................................................................................................ 18

5.1.1. Using Internet Explorer.............................................................................. 18

5.1.2. Log on from “iNVR”.................................................................................... 18

5.1.3. Controlling DVR ........................................................................................ 19

5.1.4. User ID and Password................................................................................ 19

5.2. Basic Setup .................................................................................................................... 20

5.3. Network Configuration ................................................................................................. 23

5.4. User Admin & Time Setup ........................................................................................... 26

5.5. Sensor & Capture Setup .............................................................................................. 29

5.6. Alarm Device Setup ...................................................................................................... 31

5.7. Motion Region Setup .................................................................................................... 33

5.8. PTZ Setup ...................................................................................................................... 35

5.9. Upgrade & Reset ........................................................................................................... 37

5.10. Status Report .............................................................................................................. 39

6. Tips for Using iCanServer540R .......................................................................................................... 40

6.1. Alarm Input/Output ...................................................................................................... 40

6.2. Trouble Shooting ........................................................................................................... 41

6.3. Web Viewer .................................................................................................................... 43

Rev.1.0 (Nov. 2006) 4

iCanServer540R User’s Guide

6.4. How To Upgrade Your iCanServer540R System ....................................................... 45

6.5. How to Replace Hard Disk on iCanServer540R ........................................................ 47

Rev.1.0 (Nov. 2006) 5

iCanServer540R User’s Guide

1. Introduction

1.1. Overview

The iCanServer540R is a state-of-the-art 4-channel recording video server and A/V server

supporting 4 channel D1 video. By combining standard A/V codec technologies such as MPEG4

and ADPCM, embedded web server, embedded streaming server, various network protocols and

Hard Disk manipulation technologies, iCanServer540R offers quality service required for a

premium grade DVR and A/V server. An example of the operations is : simultaneous video

recording, on-line streaming and video playback which no other DVR has ever done before. The

iCanServer540R can be connected, controlled and monitored from a remote location through an

IP address. iCanServer540R can acquire various analog video data from CCTV cameras, DVD, or

TV tuners. Based on Embedded Software Solution the iCanServer540R ensures high performance

and stability and provides wide range of applications to the owners.

Dual streaming mode provides an ideal environment when low speed network is used for

connecting iCanServer540R. This feature assures high quality video recording on the HDD, while

providing lower quality on-line streaming data to connected user.

1.2. Features of iCanServer540R

y4-channel real time Video/Audio streaming based on MPEG-4 video and ADPCM audio.

y4-channel real time Video/Audio recording into own HDD.

y1channel Bidirectional Audio between iCanServer540R and Client PC for two-way

communication

yThe viewer assisted recording and playback functions.

yMonitor output for displaying live video from the camera. (Composite or S-Video)

yEmergency record button at the front panel (URGENT switch). Connector for connecting

extended switch for emergency recording control.

y4 Alarm sensor inputs/2 relay outputs

yMotion detection – Up to 3 motion detection regions/channel.

Motion detection is considered as an alarm condition that initiates video recording on the

HDD. A brief e-mail message can be sent to the owner upon owner’s selection.

yResolution :

NTSC : Up to 704x480 (704x480, 352x240, 176x144

PAL/SECAM : Up to 704x576(704x576, 352x288, 176x144)

yRemote Software Upgrade over Network

yEasy to use and provides convenience to users

Rev.1.0 (Nov. 2006) 6

iCanServer540R User’s Guide

yMajor features of DVR mode operation

¾Uninterrupted recording mode by overwriting mode when HDD is full

¾Variety of recording mode(Manual, Scheduled, Event triggered)

¾Fast and convenient video search mode (Calendar based, Search filters)

¾System status display function : Date/Time, Storage mode, Remaining storage space,

etc.

¾Alarm sensing (sensor and motion detection) and alarm recording.

¾Powerful user interface program

¾Compact size : World smallest size 4 channel DVR

¾Time-Search-Slider Control for moving to arbitrary time while playing back

¾High data compression ratio.

¾Quadplex feature - Simultaneous operation of recording, playback, search, and on-

line

¾Download and store feature of recorded A/V data

¾Dual streaming feature : This feature is provided to provide high quality video

recording on local HDD while providing low speed on-line streaming video to users

connected through low speed network.

¾Web Hard Disk to store user data

1.3. Applications of iCanServer540R

ySecurity surveillance (buildings, stores, factories, parking lots, banks, government facilities,

military, etc.)

yReal time Internet broadcasting (resort areas, events, etc.)

yRemote monitoring (hospitals, kindergartens, traffic, public areas, etc.)

yTeleconference (Bi-directional video conference)

yRemote Learning

yWeather and environmental observation

Rev.1.0 (Nov. 2006) 7

iCanServer540R User’s Guide

2. Product Description

2.1. Contents

Open the package and check if you have the followings:

Components Description Remarks

iCanServer540R Recording feature and A/V server

Power adapter Input : 100~250V 50-60Hz

Output : +12V, 3.0A

AC power cable AC 250V, 10A~16A

LAN cable 2m LAN cable – Crossover type For direct connection

between the server and

PC.

CD Software & User’s Guide

Quick Reference Guide Installation guide For quick installation of

iCanServer540R.

2.2. Preview

iCanServer540R IP-Installer iNVR

iCanServer540R

Recording Video Server

PC software to allocate an IP

address to the iCanServer540R

PC software to view and record

the A/V streaming data

transmitted from

iCanServer540R and controlling

DVR mode operation of

iCanServer540R.

Rev.1.0 (Nov. 2006) 8

iCanServer540R User’s Guide

2.3. Physical description

2.3.1. Front panel

Figure 2-1. Front panel of iCanServer540R

yURGENT Switch

Press this button switch to start or stop manual recording in urgent condition. The recording

status will change upon pressing the switch. There are two pins to connect extended switch

for the same purpose at the rear panel.

yStatus indicator:

There are three status indicator LEDs. They are HDD, LAN and Power from the left.

HDD : HDD lamp lits on when HDD is being accessed.

LAN : Link indicator, continuous green light means that LAN is in normal state. When there

is traffic on the LAN, orange light flickers.

Power : Status indicator shows the status of the iCanServer540R in three different colors.

1Green : The green light indicates that the iCanServer540R is operating properly. If the

green light is continuously on, it means that the iCanServer540R is ready to

transmit data via network. If the green light blinks, it means that there is

traffic between LAN and iCanServer540R.

2Red : The red light indicates that the hardware of the iCanServer540R is not operating

properly.

3Orange : The orange light indicates that the software of the iCanServer540R is not

operating properly.

When applying power to iCanServer540R, power indicator temporarily lights on

with red color and then returns to green. This is the normal condition.

Rev.1.0 (Nov. 2006) 9

iCanServer540R User’s Guide

2.3.2. Rear panel

Figure 2-2. Rear Panel of iCanServer540R

y10/100base-T : 10/100 Mbps Ethernet connector (RJ-45).

yLine/Mic In (#1-#4) : They are used to connect external audio source or microphone to

iCanServer540R. There are 4 Line/Mic. In connectors.

Use Standard stereo earphone jack for the connection.

yLine Out : It is used for connecting external speakers with built in amplifier. Audio from

remote site is output through Line out in bi-directional audio mode.

UseStandardstereo earphone jack for the connection.

yVideo1- Video4 : 4 Video input (composite NTSC, PAL, SECAM)

yTerminator : Enable termination by 75 Ohm resister for each video input when switched on.

Leavethe terminatorto ONposition when nootherdeviceis sharingthesame

video line. If the the specific video is sharing same video with other devices

and located at mid position along video line, leave the terminator to OFF

position.

yCOMP : Live video from the camera can be displayed on a local monitor with Composite

vidoe input. To use Composite video monitor, go to Admin -> Basic Set Up ->

Output Video Type to select “Composite”.

yFactory Default Button :It is used for resetting iCanServer540R to shipment state from

factory. Factory Default Button is hidden underneath a tiny

hole located at the upper left part of P/T/Z RS-232 & RS-

485 connector. Press the button by tools having sharp tip.

yP/T/Z RS-232 & RS-485 : It is used for connecting P/T/Z device with RS-232 or RS-485

interface standard. Pin assignments are

Pin 2 – RS-232 In

Pin 3 – RS-232 Out

Pin 5 – RS-232 GND

Pin 8 – RS-485 Negative (-) input

Rev.1.0 (Nov. 2006) 10

Inhaltsverzeichnis

Andere iCanTek Server Handbücher

iCanTek

iCanTek iCanServer440R Bedienungsanleitung

Beliebte Server Handbücher anderer Marken

HP AlphaServer ES47 Bedienungsanleitung

Dell

Dell PowerEdge R410 Bedienungsanleitung

PowerNAS

PowerNAS CMA Bedienungsanleitung

Supero

Supero FatTwin F617R3-FT Bedienungsanleitung

MSI

MSI P1-109N-L70 Bedienungsanleitung

Dell

Dell PowerEdge XE9640 Handbuch

Dell

Dell PS4100 Montageanleitung

EtroVISION

EtroVISION EV3151 Bedienungsanleitung

NEC

NEC Express5800/T110j Bedienungsanleitung

HP ProLiant Gen9 Bedienungsanleitung

Compaq

Compaq ProLiant 3000 Handbuch

Dell

Dell PowerEdge 3YPMN Bedienungsanleitung

iRobo

iRobo IPC2U Bedienungsanleitung

Nortel

Nortel 1000 Con?guration guide Bedienungsanleitung

Asus

Asus AP7500 Bedienungs- und Wartungshandbuch

Avid Technology

Avid Technology AirSpeed 5000 Bedienungsanleitung

HP Integrity rx2600 Installationsanleitung

Milestone

Milestone Husky IVO 350T Bedienungsanleitung

iCanTek iCanServer540R Bedienungsanleitung

Beliebte Server Handbücher anderer Marken
