EMF 450 Series

Flake ICE Maker

EMF 450 on a B55 Bin

ICE-O-Matic ®is the Best ICE Making Solution for:

Hard Water, Food Safety and Tight Spaces

✓Produces up to 552 lbs. (251 Kgs.)* of ICE per day

✓Constructed from sturdy, corrosion-resistant

300 series stainless steel

✓ Only 16 inches wide

✓Available with an air-or water-cooled condenser

*Rated at 70 ° (21°) Air / 50° (10°) Water

Problem

ICE-O-Matic®Tough

Constructed with a brass evaporator and rugged stainless

steel transport system enclosed in polyurethane insulation

Solution

Operating Environments

Built to last?

Tight-Fitting Spaces

Kitchen space utilization

Maximum ICE

Maximum ICE production in a minimum amount of space:

• No additional side clearance required on a

30 inch wide bin

• Maximum ICE production in a 16 inch wide cabinet

• Works on all industry dispensers and bins

Dirty Air Filter

Forget to change the air filter?

Filter-Free Air

No air filter to change

Dependable ICE

ICE-O-Matic Flake ICE Makers remove excess water by

pushing the flaked ICE through an extrusion process.

The result is high quality flaked ICE which is ideal for

medical, supermaket or restaurant applications.

Poor Ice Quality

Ice is too wet and soft

EMF 450 EMF 405

Conds. Air Temp. Water Temp. °F (°C) Air Temp. Water Temp. °F (°C)

Unit °F (°C) 80°(27°) 70°(21°) 50°(10°) °F (°C) 80°(27°) 70°(21°) 50°(10°)

90° (32°) 346 (157) 372 (169) 418 (190) 90° (32°) 302 (137) 348 (158) 355 (161)

80° (27°) 383 (174) 412 (187) 453 (206) 80° (27°) 315 (143) 358 (162) 379 (172)

70° (21°) 413 (188) 444 (202) 488 (222) 70° (21°) 355 (161) 368 (167) 432 (196)

90° (32°) 439 (200) 472 (215) 504 (229)

80° (27°) 446 (203) 480 (218) 528 (240)

70° (21°) 467 (212) 502 (228) 552 (251)

All specifications and performance data are subject

to normal manufacturing variances.

ICE PRODUCTION CHART POUNDS (KILOGRAMS) PER 24 HOURS

Air

Cooled

Water

Cooled

EMF450AS Air 488 (222) 372 (169) 12.0 (45) n/a 5.4 5511 115/60/1 3 14.1 15 175 (80)

EMF450WS Water 552 (251) 472 (215) 12.0 (45) 76.0 (288) 3.7 6182 115/60/1 3 12.9 15 175 (80)

EMF405AS Air 432 (196) 348 (158) 12.0 (45) n/a 4.6 1580 220-240/50/1 3 6.4 15 175 (80)

See Bin specification sheet for information on ICE storage bins

Please note: air-cooled units require 6” (152 mm) clearance for air intake and exhaust.

Water Used-Gals. (Lits.) Kilowatts

ICE Production ICE Production per 100 lbs. of ICE Used per

per 24 hrs. at per 24 hrs. at 90° Air/70° Water 100 lbs. of ICE Min. Max. Shipping

Model Cond. 70° Air/50° Water 90° Air/70° Water 90° Air Voltage No. of Circuit Fuse Weight

No. Unit lbs. (Kgs.) lbs. (Kgs.) 70° Water Btuh Characteristics Wires Amp. Size lbs. (Kgs.)

ICE Prod. Cond.

Use Use

60 Hz

50 Hz

ORDERING AND SPECIFICATION INFORMATION

Dimensions and Air Flow

Air Out -

Both Sides

of ICE Maker

16"

(406 mm)

82"

(2083 mm)

Air in -

Front of

of ICE Maker

23.5"

(597 mm)

32"

(813 mm)

31"

(787 mm) 30"

(762 mm)

EMF 450 Series Flake ICE Maker - Modular

OPERATING LIMITS

Ambient Temp. Range

Air & Water 50° - 104°F (10° - 40°C) 60Hz

50° - 110°F (10° - 43°C) 50Hz

Water Temp. Range 40° - 80°F (4.5° - 27°C)

Water Pressure ICE Maker Min. 20 psi (1.4 bar)

Water in Max. 60 psi (6.9 bar)

Condenser Inlet Water Min. 20 psi (1.4 bar)

(Water cooled only) Max. 60 psi (6.9 bar)

We reserve the right to make changes in design and construction at any time

without obligation.

2003© ICE-O-Matic Rev Code: 2004A-06/03-SS

ICE-O-Matic 11100 E. 45th Avenue, Denver, CO 80239

Tel. 303 371-3737 Fax. 303 371-6296 www.iceomatic.com

7/8" (22mm) DIA Hole

for Electrical

Connection to

Control Box

ICE Maker Water Out

1/2" (13mm) I.D.

Plastic Tubing

Ice Maker Water In

1/4" (6mm) Male Flare

Condenser Water Out

3/8" (10mm) Copper Tubing

Water Cooled Only

Condenser Water In

3/8" (10mm) Copper Tubing

Water Cooled Onl

6.38"

(162mm)

3.88" (99mm)

2.25" (57mm)

1.38" (35mm)

21.88"

(556mm)

23.88"

(607mm)

29.75"

(756mm)

1.88"

(48mm)

16.00"

(406mm)

REAR VIEW

ICE Maker Water In

1/4 " (6mm) Male Flare

ICE Dispense Area

"To Bin" in Bottom

of Machine-5.50"

(140mm) DIA

4.00"

(102mm)

4.50" (114mm)

TOP VIEW
