Installation and Operating Manual

IK8951WE

F Rated Combi Fridge Freezer White

Please

read these instructions carefully before attempting to install or use

this appliance.

It is advisable to keep these instructions in a safe place for future

reference.

Iceking: Henry John House Northway Industrial Estate Northway Lane Ashchurch

Tewkesbury Gloucestershire GL20 8JH T: 01527 888133 E:

W: www.ice-king.co.uk

INTRODUCTION:

Thank you for choosing this ICEKING appliance. It has been designed to give years

of trouble-free use provided it is installed and maintained correctly.

Please read these instructions carefully before installing or using your appliance. It

is advisable to keep your purchase and installation receipts with these instructions

in a safe place for future reference.

Included is some important safety information in addition to guidelines and

recommendations that will enable you to take full advantage of all the functions

available.

This quality appliance has been tested and certified to meet all applicable UK

electrical and safety standards.

This appliance must be installed and connected in accordance with current

regulations by a qualified electrician.

After unpacking the appliance ensure that there is no visible damage.

If the appliance has been damaged during transit, do not use it, contact your

retailer immediately.

YOUR 2-YEAR MANUFACTURER'S GUARANTEE:

THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS.

Your new ICEKING appliance carries a free guarantee which protects you against the cost

of repairs during the first 24 months from date of purchase provided that: any claim is

accompanied by evidence of the model reference, model serial number and proof of

purchase, such as a Sales Receipt, showing that the appliance was purchased within

the 24 months prior to the date of claim.

YOUR GUARANTEE IS VALID ONLY IN THE UK.

To Register your Appliance simply complete the card in your appliance pack and return

it with a stamp affixed or alternatively register your Appliance at www.ice-

king.co.uk/register-your-product

SERVICE HELP-LINE

Should your appliance develop a fault, please call the

Iceking Service Helpline on:

01527-888133

Please remember to have all your product details available, including the

model number, serial number, date of purchase and your retailer’s details

before registering a fault.

Your service call cannot progress without this information.

WHAT IS NOT COVERED UNDER THE

GUARANTEE:



Any appliance not correctly installed and operated in accordance with

the manufacturer's instructions.



Any appliance that is used for anything other than domestic purposes.



Any defect caused by accident, misuse, unauthorised modification or

inexpert repair.



Cost of Call-out where a fault cannot be found with the appliance.



Cost of Call-out for work covering routine maintenance, such as, but

not exclusively, cleaning of filters or defrosting.



Cost of Call-out for work required to correct the alignment of doors

following door reversal procedures carried out by you.



Use of the appliance by anyone other than the Householder.



Use in any commercial environment.



Consumable items, such as, but not exclusively, fuses in plugs, bulbs

and breakable items which require routine replacement.



Repair costs incurred that have not been authorised by Repairtech

and/or carried out by a non-approved Repairtech engineer.

CONTENTS:

Section 1. First Steps

Section 2. Installation

Section 3.

General Safety and Use

Section 4. Description of the Appliance

Section 5. Daily Use

Section 6.

Maintenance

Section 7. Trouble Shooting

Section 8. Servicing

FIRST STEPS:

Unpack the appliance and check to see if there is any damage. Do

not connect the appliance if it is damaged. Report the damage

immediately and retain the packing.

If there is no damage to the appliance remove all packaging and

securing tape from the appliance and dispose of it correctly (see

‘Environmental Protection’ Page 26).

If this appliance is to replace an old refrigerator with a lock, you

must as a safety measure break or remove the lock and/or door

before disposal.

Disconnect the mains plug from the mains socket. Cut off the

mains cable as close to the appliance as possible and discard.

Your old appliance contains insulation gases and refrigerant that

must be disposed of correctly. Please ensure that the refrigerant

circuit is not damaged before the appliance is taken away for

correct disposal, in line with current legislation. If there is any

doubt contact your Local Authority for instructions.

This appliance may contain the refrigerant isobutene (R600a). This

is a natural gas with a high level of environmental compatibility;

however, caution is required as isobutene is a flammable gas. It is

essential to ensure that refrigerant tubes are not damaged during

transportation and the installation of the appliance. In the event

that the refrigerant circuit is damaged, avoid naked flames or

sources of ignition and ventilate the room in which the appliance

is situated.

INSTALLATION:

In the interest of safety and to ensure correct use, before installing the

appliance, read this user manual carefully.

To avoid unnecessary mistakes and accidents, it is important to ensure

that all people using the appliance are thoroughly familiar with its

operation and safety features.

Save these instructions and make sure that they remain with the

appliance if it is moved or sold, so that anyone using it throughout

its’ life will be properly informed of the appliance use and safety. Please

note that this warranty is not transferrable.

The manufacturer accepts no responsibility for incorrect installation or

use.

IMPORTANT! This appliance must be left to stand in an upright position for

at least 4 hours before being switched on for the first time.

This appliance has been designed for Domestic Use only.

Wash the interior of the appliance with lukewarm water containing a

small amount of bicarbonate soda (5ml to 0.5 litres of water).

For electrical connection carefully follow the instructions given.

There must be adequate air circulation around the Appliance to avoid

overheating. To achieve sufficient ventilation, follow the instructions

relevant to installation.

Wherever possible the spacers of the product should be against a wall to

avoid the possibility of touching or catching parts that may become hot,

such as the compressor or condenser.

REAR SPACERS:

The rear of your new appliance will have either an exposed condensor (Fig.3)

or a concealed condenser or ‘flat-back’ (Fig.2).

Your Appliance may come supplied with spacers fitted to the rear or you may

be supplied with two plastic spacers similar to those shown in Fig.3a or 3b. Fit

these to the rear of the appliance as shown (Fig.3a & 3b). When fitted, the

spacers will ensure an air gap between the condenser and the rear wall.

If the appliance does not come supplied with spacers fitted or you are not

supplied with plastic spacers to fit yourelf, simply ensure that a gap of

approximately 50mm is maintained behind the condenser

Connect the plug to an adjacent 13amp socket outlet and ensure that

the appliance is not trapping the supply cable.

Make sure that the plug is accessible after the installation of the

appliance.

Position the appliance in a dry atmosphere and out of direct sunlight.

Do not position next to a cooker or other sources of heat, i.e. radiator.

Leave a minimum gap of 2cm between the appliances in order to avoid

condensation.

Please ensure that there is an ‘air-gap’ between the appliance and the

rear and side walls.

Do not place or store heavy items on the top of this appliance.

Ensure that the appliance is positioned on a firm flat floor.

This appliance must be level.

Ensure that the appliance is upright and wheels/feet are in firm

contact with the floor so that the cabinet is stable.

This appliance has been designed and manufactures to operate

efficiently within an ambient temperature range of +16°C to +32°C.

Top

Cover

Upper Hinge

Assembly

Left

Foot

Lower Hinge and Foot

Assembly

REVERSING THE DOOR:

Please note that your appliance may be supplied with the doors left or right hand hinged.

The door opening can be reversed from “right hand hinged” to “left

hand hinged” if required.

Warning! When reversing the door, the appliance must not be

connected to the mains. Remove the plug from the mains

beforehand.

Middle Hinge

Assembly

Top Cover

Left Foot

Upper Hinge

Assembly
