Icon Time TotalPass P600 Bedienungsanleitung

TotalPass®P600

QUICK

START

GUIDE

UNPACK THE BOX

Thank you for choosing Icon Time, we appreciate your business.

Below are the contents included with your TotalPass P600 time clock.

If anything is missing, please contact our support line for a replacement:

1-800-847-2232.

15’Ethernet Cable 15’USB Cable

Please Note: The comprehensive User Guide can be downloaded from our

website support page: https://www.icontime.com/support/

TotalPass P600

Time Clock

2 Keys

2 Screws

Power Supply

Back View with

Mounting Bracket

15 Proximity

Badges

2REGISTER YOUR PRODUCT

Registering your product activates your 30 days of free setup support,

which includes:

• Unlimited telephone and email support

• Remote login assistance

• Troubleshooting

Registering your product also ensures that you will be notiﬁed about

software updates.

To register your product, please visit:

https://www.icontime.com/registration/

3MOUNT YOUR TIME CLOCK TO THE WALL

1. Determine your desired height for the clock.

2. Use the 2 wall mount screws provided and

attach the bracket to the wall.

3. Insert the key and turn it clockwise a

quarter of a turn.

4. Push the time clock onto the mounting

bracket so that the tabs ﬁt into the 3

matching slots on the back of the clock.

5. Slide the clock downward until the tabs

click into place.

6. Use the key to lock the clock to the

mounting bracket.

7. Remove the key.

4SET THE DATE AND TIME

1. Plug the power supply into the port located on the bottom of the clock.

2. Plug the power supply into a wall outlet.

3. The display will read: Set Date/Time.

4. Press or on the time clock to select the current month. Press Enter.

5. Follow the same procedure to advance through each step as prompted to

complete the date and time setup. If you make a mistake, press Clear on

the time clock to go back and correct the entry.

6. Once you’ve completed these steps, the time clock will display:

Date and Time Set.

If the clock detects a Wi-Fi connection, the display will read:

Network Detected Press Enter.

TotalPass P600 Time Clock Power Supply Wall Outlet

5CHOOSE YOUR CONNECTION OPTION

TotalPass P600 Time Clock

The TotalPass P600 time clock includes three connection options:

Wi-Fi, Ethernet, or USB.

6CONNECT USING WI-FI

Wi-Fi Connection

1. If your wireless network is detected

automatically, press Enter and go to Step 5.

(If a wireless network is not immediately

detected, please go to Step 6.)

2. Press on the time clock to enter Supervisor Mode.

3. Enter the default security code: 00 00 00.

4. Use the on the time clock to scroll and go to

Network Settings. Press Enter.

5. Go to Wi-Fi Settings. Press Enter.

6. Go to View Networks. Press Enter.

7. Select your Network from the list. Press Enter.

8. Enter your Network Password using the on the time clock to scroll

through your character options.

Use the key to change the character set to lowercase,

uppercase, # or symbol.

Press Enter to accept a single character.

When you have entered your password, press Enter twice to save it.

Note: Write down the IP Address shown and go to the instructions for

Logging Into Your Time Clock.

7CONNECT USING ETHERNET

System Requirements

• Available network port on your router,

modem, or switch.

1. Plug the Ethernet cable into the port located

on the bottom of your clock.

2. Connect the other end of the Ethernet cable into

an available port on your router, switch, or wall port.

3. Disconnect the power supply from the time clock and

reconnect it again to power cycle the time clock.

4. Check to see that the green and amber Ethernet link

lights turn on where the Ethernet cable plugs into the clock.

This veriﬁes that your time clock is connected to your network.

If the lights do not turn on, check the cable connections.

Note: A network connection is not required at all times.

A Network connection is required for accessing the time

clock application and running reports.

5. Press on the time clock to enter Supervisor Mode.

6. Enter the default security code: 00 00 00.

7. Press to scroll and ﬁnd the View IP Address option. Press Enter.

8. Write down the clock’s assigned IP address below for reference.

IP Address:

8CONNECT TO YOUR PC USING USB

System Requirements:

• Windows PC (Vista or above)

• An available USB Port on the PC

1. Plug the USB cable into the USB port located on the bottom of your clock.

2. Plug the other end of the USB cable into the USB port on your PC.

3. Download the USB Communication Drivers from our website and follow

the directions for installation provided on the webpage.

4. After installing the drivers, open your Web browser and navigate to:

http://totalpass.timeclock or http://172.20.20.1

Important: USB connection is compatible with Windows Vista and

above. If you are using a Mac, give us a call for alternative options.

9LOG INTO YOUR TIME CLOCK

1. Open your computer’s web browser and enter the clock’s IP address in the

address bar. Press Enter.

2. Set your Password.

• Enter your New Password

• Conﬁrm your New Password

3. For instructions on adding employees and completing setup, click the

Help menu on the navigation bar and download the User Guide.
