pH/ORP Digital Analyzer Controller
Operating Manual

D400 Series Operating Manual
2◀◀
|
Contents
Preface .........................................................................................................................................................................................................................................3
Features...........................................................................................................................................................................................................................................3
Technical Specications ...................................................................................................................................................................................................... 4
Typical Application.................................................................................................................................................................................................................. 4
Instrument Connection........................................................................................................................................................................................................5
Dimension......................................................................................................................................................................................................................................5
Instrument Installation .........................................................................................................................................................................................................6
Keypad Descriptions...............................................................................................................................................................................................................7
Display Descriptions ...............................................................................................................................................................................................................8
Menu Structure ..........................................................................................................................................................................................................................9
Calibration....................................................................................................................................................................................................................................10
pH Buffer Reading vs Temperature............................................................................................................................................................................12
Field Calibration .......................................................................................................................................................................................................................12
Measurement Settings (Quick Start).........................................................................................................................................................................13
SimplCal® Calibration (Quick Start) ............................................................................................................................................................................14
Field Calibration (Quick Start) ........................................................................................................................................................................................ 15
Calibration Adjusment (Quick Start) .........................................................................................................................................................................16
Alarm / Relay Settings (Quick Start)...........................................................................................................................................................................17
Output Settings (Quick Start).........................................................................................................................................................................................18
Measurement Settings (Quick Start).........................................................................................................................................................................19
MODBUS RTU General Information..........................................................................................................................................................................20
MODBUS RTU Transmission Mode.............................................................................................................................................................................21
MODBUS RTU CRC Check ...............................................................................................................................................................................................22
Implementation of MODBUS RTU in Instrument .......................................................................................................................................... 22
Data Format...............................................................................................................................................................................................................................24
Read Instruction Mode ......................................................................................................................................................................................................26
Daily Maintenance ................................................................................................................................................................................................................26
Troubleshooting......................................................................................................................................................................................................................27
Warranty.......................................................................................................................................................................................................................................27

D400 Series Operating Manual
3◀◀
|
Preface
Please read this manual carefully before use.
When receiving the instrument, please open the package carefully, check whether the instrument and accessories are damaged by trans-
portation and whether the accessories are complete. If any abnormalities are found, please contact our after-sales service department or
regional customer service center, and keep the package for return processing.
This instrument is an analytical measurement and control instrument with highly precision.Only skilled,trained or authorized person should
carry out installation, setup and operation of the instrument.Ensure that the power cable is physically separated from the power supply
when connection or repair. Once the safety problem occurs, make sure that the power to the instrument is off and disconnected.
For example,
1. Apparent damage to the analyzer
2. The analyzer does not work properly or provides specied measurements
3. The analyzer has been stored for a long time in an environment where the temperature exceeds 70°C
The analyzer must be installed by licensed professionals in accordance with relevant local specications, and instructions are included in
the operation manual. Comply with the technical specications and input requirements of the controller.
Features
The instrument is equipped with different types of pH or ORP sensors. Widely used in power plants, petrochemical industry, metallurgical
electronics, mining, paper industry, biological fermentation engineering, medicine, food and beverage, environmental protection water
treatment, aquaculture, modern agricultural planting and other industries. The pH (acidity and alkalinity) value, ORP (redox potential) value
and temperature value of water solution were continuously monitored and controlled.
Large color LCD display
Intelligent menu operation
Multiple automatic calibration
Double high resistance measurement mode, stable and reliable
Manual and automatic temperature compensation
Three relay control switches
High & low alarm and hysteresis control
4-20mA (2-wire), 4-20mA (4-wire direct to controller), or 4-20mA + RS485
Multi parameter display simultaneously shows – pH, Temp, mV, etc.
Password protection

D400 Series Operating Manual
4◀◀
|
Technical Specifications
Measuring Range pH: -2 – 16pH |ORP: -2000 – +2000mV
Unit pH |mV
Resolution pH: 0.001pH |ORP: 1mV
Basic Error pH: 0.001pH |ORP: 1mV
Temperature 14 – 302°F | -10 – 150°C (Sensor Selection Dependant)
Temperature Resolution 0.18°F | 0.1°C
Temperature Accuracy ±0.54°F | ±0.3°C
Temp. Compensation 32 – 302°F | -10 – 150°C
Temp. Compensation Manual or Automatic
Stability pH: 0.01pH/24h |ORP: 1mV/24h
Output Two 4–20mA |20–4mA |0–20mA
Communication RS485 MODBUS RTU
Relay Control Contact 5A 240VAC |5A – 28VDC
Power Supply 85 – 265VAC |9 – 36VDC | Power Consumption 3W
Working Temperature 14 – 140°F | -10 – 60°C
Relative Humidity ≤ 90%
Waterproof Rating IP65
Weight 0.5kg
Dimensions 98 × 98 × 130mm
Installation Opening Size 93 X 93mm
Installation methods Panel |Pipe |Wall
Typical Application

D400 Series Operating Manual
5◀◀
|
Instrument Connection
N/C NO 1
N/C COM 1
Temp NC 1
Temp NO 2
Input COM 2
Ref NC 2
N/C pH/ORP
N/C
N/C Pow DC+
(9–36V)
Cur 1+ Pow DC-
Com - Pow PE
Cur 2+
RS-485 B
RS-485 A
Pow ACL
(85–265V)
Pow AC N
Pow PE
Terminal Function Terminal Function
N/C No Connection NO 1 High set relay working position
N/C No Connection COM 1 Alarm relay common
Temp Temperature Sensor NC 1 High set relay resting position
Temp Temperature Sensor NO 2 Low set relay working position
Input Measurement COM 2 Alarm relay common
Ref Reference NC 2 Low set relay resting position
N/C No Connection
N/C No Connection Pow DC + (9 – 36V) DC power + (9 – 36V)
N/C No Connection Pow DC - DC power -
Cur 1 + Current output 1+ Pow PE Earth wire
Com - Current output common
Cur 2 + Current output 2+ Pow ACL (85 – 265V) Live wire
RS485 B Communication Terminal Pow AC N Neutral wire
RS485 A Communication Terminal Pow PE Earth wire
Dimension

D400 Series Operating Manual
7◀◀
|
Keypad Descriptions
Keypad Operation Tips:
Short Press: press the button and release immediately. if not specied below,
means short press.
Long Press: press the button for 3 seconds and then release it.
Press and hold: hold the button for a while and press the button until the right data is displayed then release the button.

D400 Series Operating Manual
8◀◀
|
Display Descriptions
Check all pipe connections and electrical connections before use. The instrument will display as shown in the gure below after the power
is turned on.
pH / ORP
4.01 pH
25.0 °C
C1 14.51 mA
SP1 SP2
Main measurment + Unit
Relay 1
[blue is off and red is on]
Instrument type
Temp. + Unit
Automatic temp. comp.
Relay 2 Current 1
Current 2
Sensor Communication
Warning
pH / ORP
235mV
25.0 °C
C1 14.51 mA
SP1 SP2
Measurement Mode
Configure
Calibration
Set Points
Output
System
pH / ORP
Programming Mode
pH / ORP
Calibration Mode

D400 Series Operating Manual
9◀◀
|
Menu Structure
Press [MENU] key to enter programming mode:
If the monitor prompts you to enter the calibration security password, press the or key to set the calibration security password, and
then press the [ENT] key to conrm the calibration security password. No initial password here, please enter directly by pressing the
[ENT] key.
Item Display Selection Sub Menu
Congure
Sensor
Type pH
ORP
Unit pH
mV
Temperature
Temperature Sensor
NTC2.252 kΩ
NTC10 kΩ
Pt100
Pt1000 (Default)
Temperature Offset 0.0000
Temperature Input Automatic
Manual
Temperature Unit °C
°F (Default)
Calibration
Standard
Solution
Calibration
USA : 7.00,4.01,10.01 [ ] 7.00 [ ] 4.01 [ ] 10.01
NIST : 6.86,4.01,9.18 [ ] 6.86 [ ] 4.01 [ ] 9.18
ORP Standard Solution 235mV (Default)
Field Calibration
Field Calibration Enter Value
Offset Adjustment Enter Value
Slope Adjustment Enter Value
Calibration
Adjustment
Offset Adjustment 1 Offset 2 Adjustment
Slope Adjustment 1 Slope 2 Adjustment
Set Points
Relay 1
Status ON
OFF
High/Low Setpoint
High Alarm
Low Alarm
Clean
Limit Value 0.00 (Default)
Hysteresis 00.000
Relay 2
Status ON
OFF
High/Low Setpoint
High Alarm
Low Alarm
Clean
Limit Value 0.00 (Default)
Hysteresis 00.000

D400 Series Operating Manual
10◀◀
|
Item Display Selection Sub Menu
Output
Current 1
Channel Main
Temperature
Output Option
4-20mA (Default)
0-20mA
20-4mA
Upper Limit 00.00
Lower Limit 00.00
Current 2
Channel Main
Temperature
Output Option
4-20mA (Default)
0-20mA
20-4mA
Upper Limit 00.00
Lower Limit 00.00
Output RS485
Baud Rate
4800BPS
9600BPS (Default)
19200BPS
Parity Check
None
Odd
Even
Stop Bit 1 Bit
2 BIT
Network Node 000001
System
Language English
Date/Time Year-Month-Day
Hour-Minute-Second
Display
Display Speed
Low
Standard (Default)
Medium
High
Backlight Power Saving [Enter Value]
Long Bright
Information
Soft Version 19-1.0
Password Settings 0000
Serial Number
Factory Default No Keep User Settings
Yes Reset back to Factory Default
Calibration
Press [MENU] to enter the calibration menu and select
Output
Standard Calibration
USA:7.00,4.01,10.01 Automatic Note: calibrate 7.00 rst
USA:7.00,4.01,10.01 Automatic Note: calibrate 6.86 rst
USA:7.00,4.01,10.01 235mV(Default)
Field Calibration
USA:7.00,4.01,10.01 Enter Value
Enter Value
Slope Adjustment Enter Value
