IControl Technicolor TCA200 Bedienungsanleitung

TouchScreen User Guide

Technicolor TCA200 Android

Release 5.1.1.2

December 19, 2012

the uControl logo, OpenHome, and Converge and all other uControl products and technology names are

trademarks or registered trademarks of iControl Networks, Inc. All other products or services mentioned

herein are trademarks of their respective companies.

Compliances

FCC Notice

FCC ID: JI5-RB6741

FCC IDs are visible on labels located on battery door and inside battery compartment

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which can

be determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is con-

nected.

Consult the dealer or an experienced radio/TV technician for help.

FCC Caution

Changes or modifications not expressly approved by the party responsible for compliance could void the

user's authority to operate the equipment.

This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: (1) This

device may not cause harmful interference, and (2) this device must accept any interference, including

interference that may cause undesired operation of the device

This device and its antenna(s) must not be co-located or operation in conjunction with any other

antenna or transmitter.

IMPORTANT NOTE:

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.

This equipment should be installed and operated with minimum distance 20cm between the radiator &

your body.

TouchScreen User Guide

Compliances

IC Notice / Avis IC

IC: 4137A-RB6741

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003

This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the

following two conditions: (1) this device may not cause interference, and (2) this device must accept any

interference, including interference that may cause undesired operation of the device.

This device and its antenna(s) must not be co-located or operation in conjunction with any other

antenna or transmitter.

The term "IC" before the equipment certification number only signifies that the Industry Canada

technical specifications were met.

Déclaration d'Industrie Canada

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de

licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de

brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le

brouillage est susceptible d'en compromettre le fonctionnement.

Cet appareil et son antenne (s) ne doit pas être co-localisés ou fonctionnement en association avec une

autre antenne ou transmetteur.

Le terme « IC » avant le numéro d'homologation ne signifie seulement que les normes d'Industrie

Canada ont été respectées.

IMPORTANT NOTE:

IC Radiation Exposure Statement:

This devise is only authorized for use in a mobile or fixed application. At least 20cm (8 inches) of

separation distance between the touchscreen and the user’s body must be maintained at all times to

ensure compliance with the Industry Canada RF Exposure Requirements.

Informations d'Exposition aux RF

Cet appareil est uniquement pour une utilisation dans une application mobile ou fixe. Au moins 20

centimètres de distance de séparation entre l’écran tactile et le corps de l’utilisateur doit être maintenue

en tout temps pour assurer la conformité avec les exigences de la Industrie Canada, l’ exposition.

Device Purpose

Fire/Alarm Central Panel

UL and ULC Notices

This device complies with UL 985, UL1023, UL1635, ULC S545, ULC C1023.

Limitations of Security Products

Security products and alarm systems do not offer guaranteed protection against burglary, fire, or other

emergencies. They may fail to warn for diverse reasons, including (but not limited to): power failure, dead

batteries, improper installation, coverage, coverage areas overlooked during installation, defeat by

technically sophisticated intruders, component failure, or inadequate maintenance. Alarm systems

should be checked weekly to ensure that all devices are working properly.

AN ALARM SYSTEM IS NOT A SUBSTITUTE FOR INSURANCE.

Conditions Resulting In False Alarms

Any installation of the RB6741-Z not in accordance to this manual may result in the occurrence of false

alarms.

Conditions Resulting In Impaired Operation

Any installation of the RB6741-Z not in accordance to the National Electric Code (NFPA70) may result in

improper operation as described in this manual.

Protective Features

The stand, RB6741-BT, included with the RB6741-Z Touchscreen protects against unwanted tampering of

the device. Only operate the RB6741-Z Touchscreen with the protective stand attached.

US Version Only: Use the RB6741-Z power adapter with restraining bracket to secure the plug in adapter

to the receptacle. Only use the RB6741-Z with the power adapter and restraining bracket properly

installed.

TouchScreen User Guide

Revisions

The following revisions were made to this document with this release.

Table 1: Changes to this Document

Document Section Description

Managing Sensors Added: Subscribers can add and delete environmental devices

(lights/thermostats), key fobs, and Wi-Fi repeaters.

Changed:Up to 64 environmental devices and security sensors can be paired

to the TouchScreen.

Added:A warning that under certain circumstances it is possible for

subscribers to exceed this number but that it should not be done without the

assistance of a Service Provider rep since the system will act unexpectedly

under certain circumstances (such as Low Power Mode). See the Home

Installation Guide for details.

Low Power Mode Added: This section now clarifies that when the TouchScreen goes into deep

sleep when the battery power is very low, generally rules are disabled.

There are some circumstances in which rules are still operation. See the Home

Installation Guide for details.

Removed: Previous releases of this document state that after the

TouchScreen goes into deep sleep when the battery is really low, it reboots 90

seconds after power is restored. This was true for QNX-based devices, but is

not true for Android-based devices.

6
Contents
Compliances 2
FCC Notice 2
Federal Communication Commission Interference Statement 2
FCC Caution 2
IC Notice / Avis IC 3
Industry Canada Statement 3
Déclaration d'Industrie Canada 3
Device Purpose 3
UL and ULC Notices 3
Limitations of Security Products 4
Conditions Resulting In False Alarms 4
Conditions Resulting In Impaired Operation 4
Protective Features 4
Revisions 5
Welcome to the TouchScreen 9
Understanding Security Network Components 9
Understanding the Security Zone Types 11
Understanding Alarms 12
Configuring the TouchScreen 13
Subscriber Portal 14
Using the TouchScreen 15
Understanding the TouchScreen Controls 15
Understanding the Screen 16
Security Status Header 17
System & Zone Trouble Header 18
Content Area 24
Home Screen 24
Low Power Mode 25
Show Security Cameras and Live Video 26
Managing Your System Security 28
Understanding Arming Modes 28
Arm Away Mode 29
Arm Stay Mode 29
Arm Night Mode 30
Understanding Your Protection Against Smash & Grab Attacks 30
Arming and Disarming the System 31
Arming the System from the TouchScreen 31
Disarming the System & Understanding What Happens During an Alarm 34
To disarm the system from the TouchScreen: 35
Sending an Emergency Alarm 36
Testing Your Alarms 37
Managing Connectivity Between the TouchScreen and the Central Monitoring Stations 40
Viewing Signal Strength 40
Testing Your Connectivity 41
Managing the Passcodes in your Security System 41
Managing your Keypad Codes 41
TouchScreen User Guide

Revisions
7
Managing Your Secret Word 44
Managing Connectivity between Your Home Devices and the Internet 45
View Your Security Account Information 49
Managing Devices 50
Managing Sensors 50
Disable a Sensor 50
Viewing Your Zone Event History 52
Changing the Order that Security Zones are Listed in the TouchScreen 54
Managing Cameras 54
Adding Cameras to the Security System 58
Adding Key Fobs to the Security System 65
Editing Key Fobs 69
Managing Environmental Devices 69
Managing Lights 70
Managing Thermostats 73
Managing Wi-Fi Repeaters 74
Maintaining & Configuring the TouchScreen Device 77
Reboot the TouchScreen 77
Understanding and Configuring Screen Brightness & Screen Dimming 77
Configuring the Screen Brightness Settings 78
Configuring Automatic Screen Dimming and Night Mode Dimming 78
Configuring the Screensaver 80
Configuring the Tones and Volume Levels 80
Cleaning the TouchScreen Screen 82
Viewing Technical Specifications of Your TouchScreen 82
Managing TouchScreen Apps 83
Installing TouchScreen Apps 84
Reordering Apps on the Home Screen 85
Uninstalling Apps 85
Appendix A: TouchScreen Installation and Maintenance 87
Installing the Technicolor TouchScreen 87
Battery Requirements 91
Replacing the Battery 91
Recommendations for Sensor Installation and Placement 93
Door/Window Sensors and Glass Break Detectors 93
Glass Break Detectors 93
Motion Detectors 93
Evacuation Plan 95
Additional Emergency Preparations 95
Smoke Detector Installation Recommendations 96
Camera Installation Recommendations 96
Appendix B: Using the Key Pad 97
Checking System Status 97
Arming the System 97
Arm Away Mode 97
Arm Stay 97
Disarming the System 98
Sending an Emergency Police Alarm 98

Mounting the Key Pad 98

Changing the Batteries in the Key Pad 99

To Reset the Key Pad to Default 99

Appendix C: Wi-Fi Repeater Placement 100

Appendix D: Quick Reference Tables 101

TouchScreen User Guide

Welcome to the TouchScreen

The purpose of this document is to explain how to do the following in the OpenHome Converge system:

Understand and operate the TouchScreen device

Arm and disarm your security system

Send a panic alarm

View system status and arm/disarm the system

Manage connectivity between the TouchScreen and the Central Monitoring Stations

Manage pass codes

Manage security zones

Manage emergency dispatch contact information

View history logs

View account information

Understanding Security Network Components

Your security network is made up of devices that consist of anything that communicates with the

TouchScreen, such as Door/Window sensors, lighting devices, thermostats, Panel Interface devices, key

pads, and key fobs. The TouchScreen communicates with sensors by radio frequency. Optional cameras

communicate with the security network router wirelessly. The TouchScreen maintains communication

with the system servers through the Internet and by cellular.

The following graphic shows how the network is set up.

Figure 1: Security Network

The following table describes the equipment that may be included with your security system.

Table 1: Security Network Components

Description

Security

Network Router

This is the hub of your security network. This device is installed

between your broadband modem and your home network

router.

TouchScreen The device used to interface with your security system.

Sensors Multiple types of sensors are available:

Doorway/window sensors monitor the opening and clos-

ing of potential entry and exit points.

Motion detectors monitor movement within the prem-

ises.

Carbon monoxide sensors trigger if carbon monoxide is

detected.

Flood sensors trigger if water comes in contact with the

sensor.

Glassbreak sensors trigger if a window is broken.

Smoke detectors trigger when smoke is detected.

Cameras Up to six cameras can be installed in your security system.

Cameras can be configured to take a series of pictures if a

particular sensor is faulted.

Panel interface This device connects to a traditional home security system and

allows you to control its components from the TouchScreen.

Thermostats This device is used to remotely control the indoor temperature of

the premises.

Lights These devices can be remotely controlled using the security

system.

Wi-Fi Repeater This device extends the range of the security network router to

connect to devices that require Wi-Fi connectivity.

Siren Repeater This device is used to connect to sensors and devices that require

RF connectivity. It also functions as a siren.

TouchScreen User Guide

Andere Handbücher für Technicolor TCA200

Inhaltsverzeichnis

Andere iControl Sicherheitssystem Handbücher

iControl

iControl Piper Bedienungsanleitung

Beliebte Sicherheitssystem Handbücher anderer Marken

Inner Range

Inner Range Concept 2000 Bedienungsanleitung

Climax

Climax Mobile Lite R32 Montageanleitung

CADDX

CADDX NX-6 Bedienungsanleitung

FBII

FBII XL-31 Series Bedienungsanleitung

Johnson Controls

Johnson Controls PENN Connected PC10 Bedienungsanleitung

Aeotec

Aeotec Siren Gen5 Bedienungsanleitung

Blaupunkt

Blaupunkt SA 2700 Bedienungsanleitung

IDEAL

IDEAL Accenta Betriebsanleitung

AJAX

AJAX DoubleButton Bedienungsanleitung

Swann

Swann SW-P-MC2 Bedienungsanleitung

Ecolink

Ecolink Siren+Chime Bedienungsanleitung

Digital Monitoring Products

Digital Monitoring Products XR150 Bedienungsanleitung

EDM

EDM Solution 6+6 Wireless-AE Bedienungsanleitung

Highway Safety Group

Highway Safety Group EA401 Bedienungsanleitung

Siren

Siren LED GSM Bedienungsanleitung

Detection Systems

Detection Systems 7090i Montageanleitung

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Bedienungsanleitung

Siemens

Siemens FDM273 Bedienungsanleitung

iControl Technicolor TCA200 Bedienungsanleitung

Beliebte Sicherheitssystem Handbücher anderer Marken
