Ideal Vacuum XGC-520 Bedienungsanleitung

DCM-09232022 - V 1.2

Dual Capacitance Manometer

Gauge Controller (DCM)

USER MANUAL

Model XGC-520 (P1010127)

2019-2022 © Ideal Vacuum Products, LLC | (505) 872-0037 | [email protected] | www.idealvac.com

DCM-09232022 - V 1.22

Ideal Vacuum Products warrants to the original purchaser this product to be free from defects in

workmanship and materials for a period of one (1) year from the original delivery date. The liability

of Ideal Vacuum under this warranty is limited to servicing, adjusting, repairing or replacing any

unit or component part which, at Ideal Vacuum’s sole discretion, is determined to have failed

during normal, intended use. This warranty does not cover improper installation, process related

damage, product used in any way other than dened in this manual, or any misuse, abuse,

negligence, accident, or customer modication to the product. Prior to returning any product, we

require that you contact us by phone or email to determine if the issue can be resolved quickly.

A technical support representative will try to resolve the problem. If we cannot resolve the issue

quickly, we will issue an RMA number and provide product return instructions.

THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED,

INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY AND THE IMPLIED

WARRANTY OF FITNESS FOR USE OR FITNESS FOR A PARTICULAR PURPOSE. IDEAL

VACUUM SHALL NOT BE LIABLE UNDER ANY CIRCUMSTANCES FOR INDIRECT,

SPECIAL, CONSEQUENTIAL OR INCIDENTAL DAMAGES ARISING OUT OF THE USE OF

THE PRODUCT. THE TOTAL LIABILITY OF IDEAL VACUUM SHALL NOT EXCEED THE

PURCHASE PRICE OF THE PRODUCT UNDER ANY CIRCUMSTANCES.

CUSTOMER SERVICE AND SUPPORT

If you have any questions concerning the installation or operation of this equipment, or if you

need warranty or repair service, please contact us. Customer Service and Technical Support is

available weekdays, from 8am-5pm, Mountain Time.

Phone: (505) 872-0037

Fax: (505) 872-9001

Email: [email protected]

[email protected]

Web: idealvac.com

INTELLECTUAL PROPERTY

At Ideal Vacuum we constantly strive to innovate and improve on existing products. Therefore,

specications and information are subject to change without notice. This publication may discuss

features that may not be available in certain revisions of the product. The Ideal Vacuum Logo

is a registered trademark and the slogan “Our Products Develop Tomorrow’s Technologies”

is a trademarks of Ideal Vacuum Products, LLC. Baratron is a registered trademark of MKS

Instruments. Swagelok and VCR are registered trademarks of Swagelok Co. Termite is a

trademark of ITB CompuPhase. Reference to products, trademarks and registered trademarks

owned by other manufacturers is made strictly for informative purposes and are the sole

rights reserved.

WARRANTY

2019-2022 © Ideal Vacuum Products, LLC | (505) 872-0037 | [email protected] | www.idealvac.com

DCM-09232022 - V 1.2 3

TABLE OF CONTENTS

Warranty .......................................................................................................................................2

Customer Service and Support..................................................................................................2

Intellectual Property....................................................................................................................2

Safety............................................................................................................................................5

1. General Information ................................................................................................................6

1.1 Introduction ......................................................................................................................6

1.2 Features...........................................................................................................................7

1.3 Specications...................................................................................................................7

1.4 Dimensional Drawings .....................................................................................................8

1.5 Panel Mounting ................................................................................................................8

1.6 Front Panel Display and Controls ....................................................................................9

1.7 Back Panel Power and I/O Connections........................................................................10

1.8 Ready-made Cables and Adapters ................................................................................10

1.9 Custom Sensor and Remote Cables .............................................................................10

1.10 Sensor Connector Pinouts (DB9)................................................................................... 11

1.11 RS-232 I/O & Relay Connector Pinouts (DB15) ............................................................ 11

2. Installation .............................................................................................................................12

2.1 Mount the Gauge ...........................................................................................................12

2.2 Electrical Connections ...................................................................................................12

3. Operation ...............................................................................................................................13

3.1 Principle of Capacitance Diaphragm Gauge Operation .................................................13

3.2 Navigating Menus and Setting Parameters ...................................................................15

3.3 Menu Flowchart .............................................................................................................16

3.4 Startup ...........................................................................................................................17

3.5 Changing Pressure Measurement Units ........................................................................18

3.6 Full Scale .......................................................................................................................19

3.7 Global Settings and Defaults .........................................................................................19

3.8 Channels, Relays, and Setpoints Overview...................................................................20

3.9 Programming Setpoints .................................................................................................21

3.10 DCM Adjustment ............................................................................................................23

3.11 Zeroing a Gauge ...........................................................................................................23

3.12 Calibrating a Gauge .......................................................................................................24

4. Remote Operation .................................................................................................................25

4.1 Available RS-232 Serial Commands..............................................................................25

4.2 Serial Command Usage.................................................................................................26

4.2.1 Status Query Commands....................................................................................26

4.2.2 Input Commands.................................................................................................28

4.2.3 Reset Commands ...............................................................................................30

4.2.3 Power Commands...............................................................................................30

2019-2022 © Ideal Vacuum Products, LLC | (505) 872-0037 | [email protected] | www.idealvac.com

DCM-09232022 - V 1.24

LIST OF TABLES

Table 1 - Technical specications..............................................................................................7

Table 2 - Front panel feature descriptions.................................................................................9

Table 3 - Available ready-made cables and adapters .............................................................10

Table 4 - DCM DB9 sensor connector pinouts ........................................................................ 11

Table 5 - DB15 RS-232 I/O connector on back of DCM.......................................................... 11

Table 6 - Factory defaults........................................................................................................19

Table 7 - Remote serial commands.........................................................................................25

LIST OF FIGURES

Figure 1 - Dimensional drawings...............................................................................................8

Figure 2 - Rails for panel mounting ...........................................................................................8

Figure 3 - Front panel features..................................................................................................9

Figure 4 - Back panel connectors ...........................................................................................10

Figure 5 - DB9 sensor connector on back of DCM ................................................................. 11

Figure 6 - DB15 RS-232 I/O connector on back of DCM ........................................................ 11

Figure 7 - DB15 male to breakout board adapter.................................................................... 11

Figure 8 - Simplied DCM installation .....................................................................................12

Figure 9 - Inside a capacitance diaphragm gauge ..................................................................13

Figure 10 - Display arrows ......................................................................................................15

Figure 11 - Navigation buttons ................................................................................................15

Figure 12 - Menu owchart .....................................................................................................16

Figure 13 - Power button.........................................................................................................17

2019-2022 © Ideal Vacuum Products, LLC | (505) 872-0037 | [email protected] | www.idealvac.com

DCM-09232022 - V 1.2 5

SAFETY

Do not use the Dual Capacitance Manometer Gauge Controller to

measure the pressure of ammable gases. Under certain unusual

circumstances ignition leading to an explosion could occur.

IMPORTANT SAFETY INFORMATION

Thank you for purchasing this equipment from Ideal Vacuum Products. We want you to operate

it safely.

hRead this manual before installing or operating this equipment.

Failure to follow the warnings and instructions may result in serious

injury or equipment damage.

hKeep this manual in a safe location for future reference.

hThis equipment should only be installed and operated by trained,

qualied personnel, wearing appropriate protective equipment.

hFollow all codes that regulate the installation and operation of this

equipment.

Do not use gauges with straight tubing and compression ttings

in a system that may develop positive pressures. The tube could

be rapidly forced out of the tting causing equipment damage or

injury to personnel.

Do not use the Dual Capacitance Manometer Gauge Controller in

the presence of toxic chemicals, such as organic solvents without

proper ventilation.

2019-2022 © Ideal Vacuum Products, LLC | (505) 872-0037 | [email protected] | www.idealvac.com

DCM-09232022 - V 1.26

1. GENERAL INFORMATION

1.1 INTRODUCTION

The Ideal Vacuum Products (IVP) XGC-520 Dual Capacitance Manometer Gauge Controller

(DCM) is an inexpensive solution for pressure readout of up to two Capacitance Diaphragm

Gauges (CDG’s). The IVP DCM controller provides enhanced accuracy with intelligently designed

features for simple user control and easy system integration.

The IVP DCM is designed to interface with the popular Baratron®CDG’s from MKS and can read

full scale absolute vacuum/pressure ranges from 20 mTorr (2 x 10-4 Torr) to as much as 10,000

Torr (1x104Torr). Because CDG’s measure absolute pressure, they are gas type and composition

independent. Lookup tables and conversion factors are not required.

The DCM controller can supply two gauges, heated or unheated, with dual polarity voltage (±15

VDC at 1A total).

The unit has two analog output relays, each of which can be assigned to either of the two gauge

channels, and programmed to energize when a setpoint is reached. This exibility allows the user

to easily set up automated tasks, such as valve activation or energizing a turbomolecular pump

when an appropriate backing pump pressure is achieved.

Pressure measurement units (Torr, mTorr, mBar or Pa) can be set individually for each of the two

gauges.

All user dened settings are stored in non-volatile memory and do not have to be re-entered every

time power is cycled.

Our DCM is conveniently housed in a compact 1/8-DIN extruded aluminum enclosure for benchtop

or rack panel mounting.

The brilliant, blue LCD display is easy to read and displays vital system and controller information

at a glance. The intuitive front panel membrane switch interface allows the user to access and

adjust all parameters quickly.

Remote communication and control is achieved by RS-232 serial terminal software. Connection

is made via the rear-mounted DB15 or USB-B connectors. A variety of sensor and serial cables

are available.

The DCM has a built in universal power supply which accepts an input of 100-240 VAC, 50/60Hz

though its standard C14 receptacle. Included is a 2 meter long (6 ft.) 115 VAC input power cord

with US plug 5-15P to C13 Connector. For use in other countries, the user must supply a suitable

power cord.

2019-2022 © Ideal Vacuum Products, LLC | (505) 872-0037 | [email protected] | www.idealvac.com

DCM-09232022 - V 1.2 7

1.3 SPECIFICATIONS

Table 1 - Technical specifications

PARAMETER MEASURE/TYPE

Number of Gauges Controlled Up to 2

Units of Measure Torr, mTorr, mBar, Pa (default = Torr)

User Selectable Pressure Ranges 10 (2x10-4 to 1x104 Torr) (default = 1000 Torr)

Maximum Pressure 104 Torr

Useful Measuring Range 4 decades

Numeric Display 2 digits after decimal. If value is > 1000 or

< 1.00, display switches to E notation

Audible Beeper On/off (default = on)

Voltage to Gauge(s) ±15 VDC

Max. Supplied Current to

Gauge(s)

1A combined

Input Voltage to controller 0-10 VDC for full measuring range of gauge

Setpoints 2 (default=off)

Setpoint Relays 2A @ 30VDC, >10 K Ω, NO/NC

Rear Panel Connections C14 power input wih 3A quick acting fuse

DB9-F, for sensor gauge(s)

USB-B for I/O serial communications

DB15-F, RS-232 I/O serial and relay outputs

Serial Communications 9600 baud

8-N-1, no hardware handshake

Operating Temperature Range 0 to 50° C

Enclosure Size 1/8-DIN

Input Power 100-240 VAC, 50/60 Hz

1.2 FEATURES

hControls up to two (2) capacitive diaphragm sensor gauges (CDG)

hInterfaces with popular MKS Baratron sensor gauges with full scale measurement ranges from

20 mTorr to 10,000 Torr

hGas type and composition independent – no need for lookup tables and conversion factors

hCompact 1/8-DIN enclosure for benchtop or rack panel mounting

hBrilliant Blue LCD readout display

hIntuitive interface makes setting parameters quick and easy

hTwo setpoint output relays for automated control of other equipment

hUser selectable pressure units (Torr, mTorr, mBar, and Pa)

hSerial communication for remote control through DB9 and USB-B ports

2019-2022 © Ideal Vacuum Products, LLC | (505) 872-0037 | [email protected] | www.idealvac.com

DCM-09232022 - V 1.28

1.4 DIMENSIONAL DRAWINGS

Figure 1 - Dimensional drawings

1.5 PANEL MOUNTING

Standard 1/8 DIN enclosure panel cut out dimensions are 1.772” x 3.622” (45mm x 92mm).

Maximum panel thickness is 3/8” (10mm). To mount the DCM in a panel, unscrew the two 4-40

set screws at the back of the DCM Use a 0.050” hex wrench. Slide the rails out of the slots. Slide

the DCM through the front of the panel, back rst. Slide the two rails back into the slots. Replace

the set screws and tighten until the rails hold the DCM snug in the panel.

Figure 2 - Rails for panel mounting

side rail side rail

set screw set screw

2019-2022 © Ideal Vacuum Products, LLC | (505) 872-0037 | [email protected] | www.idealvac.com

DCM-09232022 - V 1.2 9

1.6 FRONT PANEL DISPLAY AND CONTROLS

Table 2 - Front panel feature descriptions

ITEM No. DESCRIPTION

1 Ideal Vacuum part number

2 Power on/off button

3 Navigation buttons

4 Select/enter button

5 Navigation direction arrows

6 Menu item or value

7 Current pressure units

8 Gauge channel

9 Saved setpoint indicator

10 Relay on indicator

Figure 3 - Front panel features

DCM-09232022 - V 1.210

1.9 CUSTOM CABLES

If you are making your own sensor cables, follow these guidelines:

hUse only quality, metal braided, fully shielded, cables between the controller and gauge(s).

hFoil or spiral shielded cables perform worse than braided, and signal degradation may occur.

hCables must be properly grounded at both ends.

hConnectors must have a metal case or be fully shielded.

hThe cable’s shield must contact the case on its entire circumference.

hThe shield wire must be grounded before the signal wires exit the connector.

hThe ground wire should be the absolute minimum length within the connector.

1.7 BACK PANEL POWER AND I/O CONNECTIONS

The back of the DCM has the power, communication, and sensor gauge connections. The DCM

has a built-in universal power supply rated for 100-240 VAC, 50/60 Hz. The DCM accepts a

C13 plug. The RS-232 I/O (multi purpose) connector is a 15 pin D-Sub. It is used for both serial

communication and for the two analog relay outputs. The USB-B connector is used for remote

serial communications and for software updates. The 9 pin D-Sub connector is used to connect

the CDG sensor gauges.

Figure 4 - Back panel connectors

1.8 READY-MADE CABLES AND ADAPTERS

PART # DESCRIPTION

P102063 Sensor cable, connects two gauges to DCM,10 ft., DB9 -M to two DB15-F

P102061 Sensor cable, connects two gauges to DCM, 10 ft. DB9-M to two DB9-F

P1011364 Serial cable, connects remote computer to DCM, 10 ft., DB15-M to DB9-F

P1012796 USB cable, connects remote computer to DCM, 10 ft. USB-A to USB-B

P1012800 DB15-M to terminal block breakout for splitting out relays and RS232 cables

Table 3 - Available ready-made cables and adapters

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Ideal Vacuum Controller Handbücher

Ideal Vacuum

Ideal Vacuum XactGauge XGC-320 Bedienungsanleitung

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung
