1. COMMANDS

1.1 Command Notation

[Name] The name of the command.

[Format] The code sequence.ASCII,Hex, Decimal 3 kinds of formats, default Decimal format.

[Range] Gives the allowable ranges for the arguments.

[Description] Describes the command’s function.

[Details] Describes the usage of the command in detail.

[Notes] Provides important information on setting and using the printer command,ifnecessary.

[Default] Gives the default values, if any, for the commandparameters.

[Reference] Lists related commands.

2. HT

[Name] Horizontal tab

[Format] ASCII HT

Hex 09

Decimal 9

[Description] Moves the print position to the next horizontal tab position.

[Details]

•

This command is ignored unless the next horizontal tab position hasbeen set.

•

If the next horizontal tab position exceeds the printing area, the printer sets the

printing position to [Printing area width + 1].

•

Horizontal tab positions are set with ESC D.

•

If this command is received when the printing position is at [printing area width

+ 1], the printer executes print buffer-full printing of the currentline and

horizontal tab processing from the beginning of the next line.

•

The default setting of the horizontal tab position for the paper roll is font A

(12

╳

24) every 8th character (9th, 17th, 25th, ... column).

[Reference] ESC D

3. LF

[Name] Print andline feed

[Format] ASCII LF

Hex 0A

Decimal 10

[Description] Prints the data in the print buffer and feeds oneline based on the currentline

spacing.

[Note] This command sets the print position to the beginning of the line.

[Reference] ESC 2, ESC 3

PROGRAM MANUAL

Thermal receipt printer TP-80

4. FF

[Name] Print and return to standard normal mode in page mode

[Format] ASCII FF

Hex 0C

Decimal 12

[Description] Prints the data in the print buffer collectively and returns to normal mode.

[Details] The buffer data is deleted after being printed.

The printing area set by ESC W is reset to the default setting.

The printer does not execute paper cutting.

This command sets the print position to the beginning of the line.

This command is enabled only in page mode.

[Reference] ESC FF,ESC L,ESC S

5. CAN

[Name] Cancel print data in page mode

[Format] ASCII CAN

Hex 18

Decimal 24

[Description] In page mode, deletes all the print data in the current printable area.

[Details] This command is enabled only in page mode.

If data that existed in the previously specified printing area also exists in the

currently specified printing area, it is deleted.

[Reference] ESC L,ESC W

6. DLE EOT n

[Name] Real-time status transmission

[Format] ASCII DLE EOT n

Hex 10 04 n

Decimal 16 4 n

[Range] 1 n4

[Description] Transmits the selected printer status specified by n in real-time, according to the

following parameters:

n = 1: Transmit printer status

n = 2: Transmit off-line status

n = 3: Transmit error status

n = 4: Transmit paper roll sensor status

[Details] The status is transmitted whenever the data sequence.

This command should not be used among the command that consists of 2 or

more bytes.

Even though the printer is not selected using ESC = (select peripheral device),

this command is effective.

The printer transmits the current status. Each status is represented by onebyte

data.

The printer transmits the status without confirming whether the host computer

can receive data.

The printer executes this command upon receiving it.

This command is ony available for serial port printer. The printer executes this

command upon receiving it any status.

n = 1: Printer status

Bit 0/1 Hex Decimal Function

0 0 00 0 Fixed to “0”.

1 1 02 2 Fixed to “1”.

2 0 00 0 One or two drawer open

1 04 4 Two drawers closed

3 0 00 0 On-line

1 08 8 Off-line

4 1 10 16 Fixed to “1”.

5,6 Undefined.

7 0 00 00 Fixed to “0”.

n = 2: Off-line status

Bit 0/1 Hex Decimal Function

0 0 00 0 Fixed to “0”

1 1 02 2 Fixed to “1”.

2 0 00 0 Cover is closed.

1 04 4 Cover is open.

3 0 00 0 Not press FEED button.

1 08 8 press FEED button

4 1 10 16 Fixed to “1”

5 0 00 0 No paper-end

1 20 32 Paper end

6 0 00 0 No error.

1 40 64 Error occurs.

7 0 00 0 Fixed to “0”

n = 3: Error status

Bit 0/1 Hex Decimal Function

0 0 00 0 Fixed to “0”

1 1 02 2 Fixed to “1”

2 - - - Undefined.

3 0 00 0 No auto-cutter error.

1 08 8 Auto-cutter error occurs.

4 1 10 16 Fixed to “1”

5 0 00 0 No unrecoverable error.

1 20 32 Unrecoverable error occurs.

6 0 00 0 Normal print head temperature and voltage

1 40 64 Abnormal print head temperature and voltage

7 0 00 0 Fixed to “0”

n = 4: Continuous paper sensor status

Bit 0/1 Hex Decimal Function

0 0 00 0 Fixed to “0”.

1 1 02 2 Fixed to “1”.

2,3 0 00 0 Paper enough

1 0C 12 Paper near-end

4 1 10 16 Fixed to “1”.

5,6 0 00 0 Paper enough

1 60 96 Paper end

7 0 00 0 Fixed to “0”.

[Reference] DLE ENQ, GS a, GS r

7. DLE ENQ n

[Name] Real-time request to printer

[Format] ASCII DLE ENQ n

Hex 10 05 n

Decimal 16 5 n

[Range] 1 n2

[Description] Responds to a request from the host computer. n specifies the requests as

follows:

n Request

1 Recover from an error and restart printing from the line where the error occurred

2 Recover from an error after clearing the receive and print buffers

[Details] This command is effective only when an auto-cutter error occurs.

The printer starts processing data upon receiving this command under serial port.

With a parallel interface model, this command can not be executed when the

printer is busy.

This command should not be contained within another command that consists

of two or more bytes.

When the printer is disabled with ESC = (Select peripheral device), the error

recovery functions (DLE ENQ 1 and DLE ENQ 2) are enabled, and the other

functions are disabled.

When the pulse is output to the connector pin specified while ESC p or DEL

DC4 is executed while this command is processed, this command is ignored.

The printer executes this command upon receiving it under serial port.

With a parallel interface model, this command cannot be executed when the

printer is busy.

If print data includes the same character strings as this command, the printer

performs the same operation specified by this command. The user must

consider above condition.

This command should not be used within the data sequence of another

command that consists of 2 or more bytes.

This command is effective even when the printer is disabled with ESC = (Select

peripheral device).

[Reference] ESC p

8. ESC FF (*)

[Name] Print data in page mode

[Format] ASCII ESC FF

Hex 1B 0C

Decimal 27 12

[Description] In page mode, prints all buffered data in the printing area collectively.

[Details] This command is enabled only in page mode.

After printing, the printer does not clear the buffered data, setting values for

ESC T and ESC W, and the position for buffering character data.

[Reference] FF,ESC L,ESC S

9. ESC SP n

[Name] Set right-side character spacing

[Format] ASCII ESC SP n

Hex 1B 20 n

Decimal 27 32 n

[Range] 0 ≤n≤255

[Description] Sets the character spacing for the right side of the character to [ n  horizontal or

vertical motion units].

[Details] •When characters are enlarged n times, the right-side character spacing is n

times normal value.

•This command sets values independently in each mode (standard and page

modes).

•The horizontal and vertical motion unit are specified by GS P. Changing the

horizontal or vertical motion unit does not affect the current right-side spacing.

•The GS P command can change the horizontal (and vertical) motion unit.

However, the value cannot be less than the minimum horizontal movement

amount, and it must be in even units of the minimum horizontal movement

amount.

•In standard mode, the horizontal motion unit is used.

•In page mode, the horizontal or vertical motion unit differs in page mode,

depending on starting position of the printable area as follows:

1 When the starting position is set to the upper left or lower right of the

printable area using ESC T, the horizontal motion unit ( x) is used.

2 When the starting position is set to the upper right or lower left of the

printable area using ESC T, the vertical motion unit ( y) is used.

•The maximum right-side spacing is 31.91mm (255/203) inches. Any setting

exceeding the maximum is converted to the maximum automatically.

[Default] n= 0

[Reference] GS P

10. ESC ! n

[Name] Select print mode(s)

[Format] ASCII ESC ! n

Hex 1B 21 n

Decimal 27 33 n

[Range] 0 ≤n≤255

[Description] Selects print mode(s) using n as follows:

Bit 1/0 Hex Decimal Function

0 0 00 0 Character font A (12 ╳24).

1 01 1 Character font B (9 ╳17).

1 - - - Undefined.

2 - - - Undefined.

3 0 00 0 Emphasized mode not selected.

1 08 8 Emphasized mode selected.

4 0 00 0 Double-height mode not selected.

1 10 16 Double-height mode selected.

5 0 00 0 Double-width mode not selected.

1 20 32 Double-width mode selected.

6 - - - Undefined.

7 0 00 0 Underline mode not selected.

1 80 128 Underline mode selected.

[Details] •When both double-height and double-width modes are selected, quadruple size

characters are printed.

•The printer can underline all characters, but can not underline the space set by

HT or 90° clockwise rotated characters.

•The thickness of the underline is that selected by ESC  , regardless of the

character size.

•When some characters in a line are double or more height, all the characters

on the line are aligned at the baseline.

•ESC E can also turn on or off emphasized mode. However, the setting of the

last received command is effective.

•ESC — can also turn on or off underline mode. However, the setting of the last

received command is effective.

•GS ! can also select character size. However, the setting of the last received

command is effective.

•Emphasized mode is effective for alphanumeric and Kanji. All print modes

except emphasized mode is effective only for alphanumeric.

[Default] n= 0

[Reference] ESC -,ESC E,GS !

11. ESC $ nL nH

[Name] Set absolute print position

[Format] ASCII ESC $ nL nH

Hex 1B 24 nL nH

Decimal 27 36 nL nH

[Range] 0 ≤nL ≤255

0≤nH ≤255

[Description] Sets the distance from the beginning of the line to the position at which

subsequent characters are to be printed.

•The distance from the beginning of the line to the print position is

[( nL + nH ╳256) ╳ (vertical or horizontal motion unit)] inches.

[Details] •Settings outside the specified printable area are ignored.

•The horizontal and vertical motion unit are specified by GS P.

•The GS P command can change the horizontal (and vertical) motion unit.

However, the value cannot be less than the minimum horizontal movement

amount, and it must be in even units of the minimum horizontal movement

amount.

•In standard mode, the horizontal motion unit ( x) is used.

•In page mode, horizontal or vertical motion unit differs depending on the

starting position of the printable area as follows:

1 When the starting position is set to the upper left or lower right of the

printable area using ESC T, the horizontal motion unit ( x) is used.

2 When the starting position is set to the upper right or lower left of the

printable area using ESC T, the vertical motion unit ( y) is used.

[Reference] ESC \,GS $,GS \,GS P

12. ESC % n

[Name] Select/cancel user-defined character set

[Format] ASCII ESC % n

Hex 1B 25 n

Decimal 27 37 n

[Range] 0 ≤nL ≤255

[Description] Selects or cancels the user-defined character set.

•When the LSB of nis 0, the user-defined character set is canceled.

•When the LSB of nis 1, the user-defined character set is selected.

[Details] •When the user-defined character set is canceled, the internal character set is

automatically selected.

•nis available only for the least significant bit.

[Default] n= 0

[Reference] ESC &,ESC ?

13. ESC & y c1 c2 [x1 d1...d(y

╳

x1)]...[xk d1...d(y

╳

 xk)]

[Name] Define user-defined characters

[Format] ASCII ESC & y c1 c2 [

╳

1 d1...d(y

╳

x1)]...[xk d1...d(y

╳

xk)]

Hex 1B 26 y c1 c2 [

╳

1 d1...d(y ╳x1)]...[xk d1...d(y

╳

xk)]

Decimal 27 38 y c1 c2 [

╳

1 d1...d(y

╳

x1)]...[xk d1...d(y

╳

xk)]

[Range] y= 3

32 ≤c1 ≤c2 ≤126

0≤x≤12 Font A (12 ╳24)

0≤x≤9 Font B (9 ╳17)

0≤d1 ... d(y

╳

xk) ≤255

[Description] Defines user-defined characters.

•yspecifies the number of bytes in the vertical direction.

•c1 specifies the beginning character code for the definition, and c2 specifies the

final code.

•xspecifies the number of dots in the horizontal direction.

[Details] •The allowable character code range is from ASCII code <20>H to <7E>H (95

characters).

•It is possible to define multiple characters for consecutive character codes.

If only one character is desired, use c1 = c2.

•dis the dot data for the characters. The dot pattern is in the horizontal direction

from the left side. Any remaining dots on the right side are blank.

•The data to define a user-defined character is (y ╳x) bytes.

•Set a corresponding bit to 1 to print a dot or 0 to not print a dot.

•This command can define different user-defined character patterns by each

fonts. To select a font, use ESC !

•A user-defined character and a downloaded bit image cannot be defined

simultaneously. When this command is executed, the downloaded bit image is

cleared.

•The user-defined character definition is cleared when:

①ESC @ is executed.

②ESC ? is executed.

③FS q is executed.

④GS *is executed.

⑤The printer is reset or the power is turned off.

•When the user-defined characters are defined in font B (9 ╳17), only the most

significant bit of the 3rd byte of data in vertical direction is effective.

[Default] The internal character set

[Reference] ESC %,ESC ?

[Example]

•When font A (12 ╳24) is selected.

•When font B (9 ╳17) is selected.

14. ESC *m nL nH d1... dk

[Name] Select bit-image mode

[Format] ASCII ESC *m nL nH d1...dk

Hex 1B 2A m nL nH d1...dk

Decimal 27 42 m nL nH d1...dk

[Range] m= 0, 1, 32, 33

0≤nL ≤255

0≤nH ≤3

0≤d≤255

[Description] Selects a bit-image mode using m for the number of dots specified by nL and nH,

as follows:

mMode

Vertical Direction Horizontal Direction

Number of

Dots

Dot

Density

Dot

Density

Number of Data

(K)

0 8-dot single-density 8 67 DPI 100 DPI nL + nH

╳

256

1 8-dot double-density 8 67 DP 200 DPI nL + nH

╳

256

32 24-dot single-density 24 200DPI 100 DPI (nL + nH

╳

256)

╳

33 24-dot double-density 24 200 DPI 200DPI (nL + nH

╳

256)

╳

[dpi:dot/25.4mm{1”}]

[Details] •If the values of mis out of the specified range, nL and data following are

processed as normal data.

•The nL and nH indicate the number of dots of the bit image in the horizontal

direction. The number of dots is calculated by nL + nH

╳

256.

•If the bit-image data input exceeds the number of dots to be printed on a line,

the excess data is ignored.

•dindicates the bit-image data. Set a corresponding bit to 1 to print a dot or to 0

to not print a dot.

•If the width of the printing area set by GS L and GS W less than the width

required by the data sent with the ESC *command, the following will be

performed on the line in question (but the printing cannot exceed the maximum

printable area):

①The width of the printing area is extended to the right to accommodate the

amount of data.

②If step ①does not provide sufficient width for the data, the left margin is

reduced to accommodate the data.

•After printing a bit image, the printer returns to normal data processing mode.

•This command is not affected by print modes (emphasized, double-strike,

underline, character size or white/black reverse printing), except upside-down

printing mode.

•The relationship between the image data and the dots to be printed is as

follows:

•When 8-dot bit image is selected:

Inhaltsverzeichnis

Andere iDiPOS Drucker Handbücher

iDiPOS

iDiPOS AB-88H Bedienungsanleitung

Beliebte Drucker Handbücher anderer Marken

Lexmark

Lexmark 1400 Series Handbuch

Canon

Canon i70 Series Bedienungsanleitung

Evolis

Evolis Elypso Bedienungsanleitung

Kyocera

Kyocera FS-9530DN Bedienungsanleitung

Canon

Canon LASER SHOT LBP-1210 Bedienungsanleitung

Samsung

Samsung BIXOLON SRP-350plusF Bedienungsanleitung

Canon

Canon PIXMA PRO-1 Series Bedienungsanleitung

Canon

Canon PIXMA G3560 Einrichtungshandbuch

Dell

Dell Color Laser Printer 2130cn Bedienungsanleitung

Tektronix

Tektronix Phaser 840 Bedienungsanleitung

Epson

Epson ET-7750 Betriebsanleitung

Canon

Canon CLBR 460ps Bedienungsanleitung

Eltron

Eltron P210 Guide Bedienungsanleitung

Ricoh

Ricoh MD-P1 Bedienungsanleitung

Epson

Epson SC-F7100 series Bedienungsanleitung

Epson

Epson Stylus C40UX Bedienungsanleitung

Canon

Canon imagePASS-A2 Bedienungsanleitung

Canon

Canon S820D Bedienungsanleitung

iDiPOS TP-80 Fehlerbehebungshandbuch

Beliebte Drucker Handbücher anderer Marken
