IHome IBTW38 Bedienungsanleitung

Model: iBTW38

instruction manual

Questions? Contact Customer Service at 1-800-288-2792

Dual Alarm Clock

Stereo Speaker System

with Qi Wireless Charging

iBTW38

Introduction

Thank you for purchasing the iHome iBTW38. This product is designed to provide high

quality wireless sound for your iPad, iPhone, iPod or other Bluetooth audio device. It will

also wirelessly charge compatible devices.

This instruction booklet explains the basic operation and care of the unit. Please read it

carefully and keep for future reference.

• Place the unit on a level surface away from sources of direct sunlight or excessive heat.

• Protect your furniture when placing your unit on a natural wood and lacquered ﬁnish.

A cloth or other protective material should be placed between it and the furniture.

• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger

cleaning agents, such as benzene, thinner or similar materials can damage the surface

of the unit.

Maintenance

iBTW38

Included

• iBTW38 system

• 100V-240V universal AC adapter

power adapter

iBTW38

Meet Your iBTW38

Top

Backup Battery Compartment

Bottom Back

Bluetooth

Pairing Button

Voice/Talk/End Button

Volume Up/

Volume Down Buttons

Snooze/Display Dimmer Button

Microphone

Alarm 1 Button

Alarm 2 Button

Sleep Button

Power Button

Play/Pause Button

DC Jack

USB Charging Port Time Set Button DST Button

+/– Settings

Buttons

Wireless charging pad

The Display

Setting Up the Unit

Connect the included AC adapter to the DC jack

located on the back of the unit and connect the

other end to a working wall outlet.

CR2450 3V battery is included for battery backup.

Install it in the backup battery compartment

located on the bottom of the unit before using the

unit. See page 11 for more on installing and

replacing backup batteries.

Alarm Active Indicator

Alarm Clock/Sleep Time/Date Indicator

Sleep Mode Indicator

Bluetooth

Pairing

Indicator

Wireless Charging

Indicator

PM Time Indicator

Wake to

Alarm/Tone Source Indicators

Time Display

Low Backup

Battery Indicator

Using the iBTW38

RESET

TEST

Setting the Clock

1. Press and hold the Time Set Button located on the back of the unit for 2 seconds until the

clock display ﬂashes and a beep sounds.

2. Press the –or +Buttons to adjust the clock to the current time (hold for rapid setting). Make

sure you set the correct AM/PM time. The PM indicator appears to the left of the display; there is

no AM indicator.

3. To toggle the clock display between standard 12 hour time and 24 hour (“military”) time display,

press the Alarm or Alarm Button while the display is ﬂashing during time setting.

4. Press and release the Time Set Button to conﬁrm the current time setting. The YEAR will

ﬂash on the display. Press the –or +Buttons to set the correct year.

5. Press and release the Time Set Button to conﬁrm the current year setting. The Date will ﬂash

on the display. Press the –or +Buttons to set the correct month and day(hold for rapid

adjustment).

6. Press and release the Time Set Button to conﬁrm the current date setting. 2 beeps will

sound to indicate time setting mode is complete.

Setting and Using the Alarm

This unit features dual alarms which can be set to dierent times and alarm sources. Each is set in

the same way. Instructions are given as “Alarm Button”; use Alarm Button or Alarm Button to

set respective alarms.

Note: Each step must be completed while display is ﬂashing or step will time-out with any changes

saved.

1. Press and hold the Alarm Button for 2 seconds until the time display and alarm icon ﬂash. A beep

sounds.

2. Press the –or +Buttons to adjust the alarm time to the desired time (hold for rapid setting).

Make sure you set the correct AM/PM alarm time. The AM/PM indicator appears to the right of

the alarm time display.

3. Press the Alarm Button to conﬁrm the alarm time setting. The wake-to schedule will ﬂash. Press

the –or +Buttons to set the desired alarm schedule. 7 Days (every day), 5 Days (week days

only) or 2 Days (weekends only)

Using the iBTW38

Setting and Using the Alarm (Cont’d)

4. Press the Alarm Button to conﬁrm the alarm schedule. The wake source indicator will

ﬂash on the display. Press the –or +Buttons to select the desired wake to alarm

source: Bluetooth or tone.

Wake to Bluetooth: You will wake to the currently linked Bluetooth device. If no device

is detected, the alarm will default to current Tone.

Wake to Tone: Press the Alarm Button to conﬁrm. Press the –or +Buttons as

needed to listen to and to select one of the four built-in wake-to

tones (1 - 4).

5. Press the Alarm Button to conﬁrm the alarm source. The volume display will ﬂash.

6. Press the or Buttons to adjust the alarm volume. Note that the alarm volume

setting is stored separately from other volume settings.

7. Press the Alarm Button to conﬁrm the alarm settings and exit alarm setting mode. 2

beeps will conﬁrm alarm setting is complete. The alarm icon will remain on the display,

indicating the alarm is armed.

Previewing the Alarm and Turning the Alarm On/O

1. Press and release the Alarm Button to view the current alarm time.

2. Press and release the Alarm Button as needed to toggle the alarm ON and OFF,

indicated by the alarm icon and a beep.

Using the iBTW38

Setting The Daylight Daving Time (dst) switch

This unit has a DST switch on the back of the unit to adjust the time for daylight saving

time and standard time. By default, it is set to Auto and will automatically adjust the time

at the start and end of daylight saving time. If you are located in an area that does not

observe daylight saving time or otherwise wish to adjust manually, slide the switch to +1

to add one hour or to –1 to subtract an hour.

Snooze/Display Dimmer Button

1. To program Snooze, press and hold the Snooze/Display Dimmer Button during normal

operation (when no alarm is sounding).

2. Press the –or +Buttons to select the desired snooze time (between 01 and 29 minutes).

3. Press and release the Snooze/Display Dimmer Button to conﬁrm Snooze setting. 2 beeps

will sound.

4. While the alarm is sounding, press and release the Snooze/Display Dimmer Button to

temporarily silence the alarm for the set duration (9 minutes is the default). Snooze can be

used several times during alarm.

5. To adjust the brightness of the display, press and release the Snooze/Display Dimmer

Button during normal operation (when no alarm is sounding) to cycle through the

brightness display settings.

Sleep Mode

This unit allows you to sleep to the current sound source for a set time before turning the unit

o.

1. To set Sleep time, press and release the Sleep Button as needed to cycle to the desired

sleep duration:120, 90, 60, 30 or 15 minutes or OFF (turns the unit o).

2. Press the or Buttons to adjust the sleep volume on the unit. Note that the sleep volume

setting is stored separately from other volume settings.

Using the iBTW38

Pairing Your Bluetooth Device

When AC power is connected, and the Button OR or Bluetooth Button is pressed,

the iBTW38 will announce “Looking for Bluetooth Signal” and attempt to autolink to a

previously paired device.

1. Turn on your Bluetooth device and make it “discoverable” by turning

on Bluetooth mode (check in Options or Settings).

2. Press the Button to turn on the iBTW38. The ﬁrst time the unit is

powered on it will enter pairing mode automatically. After this, you

will need to pair using the Pairing Button after powering on (see step

3 below).

3. Press and hold the Pairing Button on top of the iBTW38 for 2

seconds. The iBTW38 will announce “Pairing” and the Bluetooth icon

will ﬂash on the display, indicating the iBTW38 is in pairing mode.

4. “iHome iBTW38” should appear in your device’s Bluetooth menu. Select

“iHome iBTW38” to connect device. If prompted for a passcode, enter

“ “1234” on your device’s keypad.

5. If pairing is successful, the iBTW38 will announce “Connected” and the Bluetooth icon

will appear solid, indicating the iBTW38 is ready to play music. There should also be an

indication on your device. If no device is successfully paired within 3 minutes the iBTW38

will default to previous mode. Once the iBTW38 is paired to a device, it will attempt to

autolink when the device is within range (about 33 feet).

iHome

iBTW38

Using the iBTW38

Playing Audio Via Bluetooth

1. Press the Button to turn the unit ON, or press the Button. “BT” and the

Bluetooth icon appear on the display. To turn on in play mode, press the Button.

2. Press the Button on the unit to play audio from your linked Bluetooth device.

4. Press the –or +Buttons to go to the previous or next track.

5. Press the or Buttons to adjust the volume on the unit.

6. When done listening, press the Button to turn the unit o.

Using the Speakerphone feature

NOTE: The unit must be powered on and linked to a Bluetooth phone to receive a call.

1. When a call is received, playing music is muted to hear the ring tone.

“Call” will ﬂash on the display.

Press the Voice/Talk/End Button to answer the call; press and hold the Voice/

Talk/ End Button to ignore the call.

2. When a call is completed, press and hold the Talk/End Button to end the call and

resume previous function.
