300N Wireless Extender
Manual
COPYRIGHT
Copyright © 2012 - iiNet Limited. All rights reserved. No part of this
publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated
into any language or computer language, in any form or by any means, electronic, mechanical,
magnetic, optical, chemical, menu or otherwise, without the prior written permission of iiNet Limited.
iiNet Limited makes no representations or warranties, either expressed or implied, with respect to the
contents herein and specifically disclaims any warranties, merchantability or fitness for any particular
purpose. Any software described in this User Manual is sold or licensed ‘as is’.
Further, iiNet Limited reserves the right to revise this publication and to make changes from time to
time in the contents thereof without obligation to notify any person of such revision or changes.
Copyright applies to written, audio or visual intellectual property, ie. contents of this manual, not the
actual product.
Trademark or Registered Trademark is effectively the copyright on a product, ie. a patent.
iiNet 300N Wireless Extender - Manual 1
Contents
1. Welcome to iiNet’s Wireless Extender 3
1.1 Wireless LAN Extender Overview 4
1.2 System Requirements 6
1.3 Extender’s Wireless Mode Options 7
2. Overview of the advanced settings in the ‘extender’ mode 8
2.1 Connect to iiNet wireless extender web page 8
2.2 Mac Address Filtering 13
2.3 Finding Unknown MAC Addresses 16
2.4 Advanced Settings - System Utility 18
2.5 Backup Configuration Settings 22
2.6 Upgrading the iiNet Wireless Extender 23
iiNet 300N Wireless Extender - Manual 2
3. Client Mode 24
3.1 Web Browser Quick Setup 24
3.2 Connect to the Configuration Menu 27
3.3 Client Mode: Home settings 28
3.4 Client Mode: WPS Settings 29
3.5 Client Mode: Advanced Settings 32
4. AP Mode 33
4.1 AP Mode: Web Browser Quick Setup 33
4.2 Connect to the Web Configuration Menu 33
4.3 AP Mode: Home 35
4.3 AP Mode: WPS Setting 35
5. 300N Wireless Extender Specification 38
6. Glossary 39
iiNet 300N Wireless Extender - Manual 3
Welcome to The iiNet Wireless Extender
Hi,
The Extender is a portable device that will provide you with excellent
network performance and extend your Wi-Fi signal. You can now boost
the wireless coverage in any weak signal spots around your home.
This User Manual describes the Extender’s functionality in more detail
and its other modes and advanced settings.
If you want a quick and basic installation of the Extender, and be up
and running in no time, refer to the Quick Installation Guide first.
Its capacity as an 802.11b/g/n wireless extender with in-built power,
gives you more freedom to scale up your wireless network.
Inside your installation pack, you’ll find everything you need to set-up
your wireless connection to your Extender using your computer and
modem/router.
Enjoy your extended wireless coverage!
iiNet 300N Wireless Extender - Manual 3
1
iiNet 300N Wireless Extender - Manual 4
1.1 WIRELESS LAN EXTENDER OVERVIEW
A B
D
C
iiNet 300N Wireless Extender - Manual 5
View Feature Desciption
ALAN Ethernet LAN Port - 10/100M with Auto-MDI/
MDI-X. Connects to computer, switch or hub for
local network sharing.
BReset / WPS Button To start the WPS function - press and hold the
button for less than 5 seconds.
To reset Extender to factory default settings
while starting the WPS function - press and
hold the button for 10 seconds.
CAP/Repeater/
Client Mode selector
Move the switch to change operating mode to
Access Point, Extender or Client mode.
DON/OFF This is the power on/off switch and should
be switched on after the power-point is
switched on.
iiNet 300N Wireless Extender - Manual 6
1.2 SYSTEM REQUIREMENTS
Check you have the following computer system requirements necessary for the installation:
• A wireless network card which is compatible with 802.11b/g/n wireless network standard.
• Operating System – Windows 2000, 2003, XP, Vista, or Windows 7.
• CD-ROM drive
• At least 100MB of available disk space.
iiNet 300N Wireless Extender - Manual 7
1.3 EXTENDER’S WIRELESS MODE OPTIONS
The iiNet Wireless Extender has settings that provide three different modes of operation,
depending on your need at the time:
Repeater/
Extender
mode boosts and extends a weak Wi-Fi signal. (After installation,
this is the mode most frequently used as a starting point). This
is the most common function. For assistance in setting up this
option please refer to the ‘300N Wireless Extender – Quick
Installation Guide’ that was inserted in the box.
AP mode lets you use the Extender as a wireless Access Point. This
function would be used if your modem is not wireless. You can
plug your iiNet extender into a power socket near your modem;
run the yellow network cable from your modem’s LAN port and
into the iiNet wireless extender LAN port. Then select access
point mode on the side of the unit to enable your modem to act
as a wireless modem.
Client mode lets you use the Extender to turn a desktop or laptop into
a wireless desktop or laptop (client). Most computers today have
wireless in built. If however your PC does not already have wireless
you could plug your iiNet wireless extender into a power socket
near your PC, then run a LAN cable from your PC LAN port and
into the wireless extender LAN port; then select the client mode
on the switch on the side of your iiNet wireless extender.
iiNet 300N Wireless Extender - Manual 8
2
Overview of the advanced settings in the ‘extender’ mode
To access the advanced features of the iiNet wireless extender you first need to follow the
steps in the ‘300N Wireless Extender – Quick Installation Guide’ that was inserted in the box.
2.1 CONNECT TO IINET WIRELESS EXTENDER WEB PAGE
If you want to change the advanced settings and configure your Extender beyond the
normal functionality as shown in the quick install guide, you will need to access the
extenders’s user interface.
Step 1
Open your web browser and select the extender’s Quick Setup web page from your
Favorites or Bookmarks list (if you saved it successfully during the Quick setup). Double
click that link.
If you didn’t save the web page during the quick setup procedure then you’ll need to type
the following URL into your web browser’s address bar and press Enter.
Type: http://iiextender1234 and press enter
(replace ‘1234’ with the last four digits of your Extender’s MAC serial number).
You made a note of this in the previous step in this guide
The default IP address of the iiNet wireless extender is 192.168.2.254
In order to access this IP address you will need to manually configure your laptop to have
an IP address in the range of 192.168.2.x
