IiNet E5 Bedienungsanleitung

USB modem software

installation guide

Read

this

first

Get iiNet mobile broadband running on your PC or laptop

Thanks for choosing the E5.

This guide runs you through some of the E5 modem’s basic functions.

For details on your specific model, head to the ‘Help’ section of the

Web Management page.

Make sure your modem is stored in an environment with good

ventilation to avoid overheating from extended use. When the E5

modem overheats, it will switch off or disconnect automatically to

protect itself. If this happens, place the modem in a well-ventilated

location and restart.

Getting to Know Your E5

Your package should contain the following items. Some accessories are

optional and are not provided with your modem.

Quick Start Guide Main unit Battery Data cable Charger

Safety Information

If any items are missing, please contact us immediately.

Connection Scenarios

This modem will connect to the Internet via a Wi-Fi device or computer.

The way you connect depends on the operating system of your computer

or device. Connection scenarios are illustrated below for your reference.

Scenario 1: Multi-device access via Wi-Fi Scenario 2: One-device access via USB

Scenario 3: Multi-device access via

Wi-Fi and USB at the same time

 

  



Appearance

External antenna interface

Power button

USB connector

WPS button

Screen

3 4

Note:

• Wi-Fi: Wireless Fidelity

• WPS: Wi-Fi Protected Setup

 

Screen

Signal strength

Network

Wi-Fi enabled and number

of devices connected

Internet connection

New messages and

number of new messages

Battery level

Roaming status

1 2 3 4 5 6

8 M: Manual mode

A: Auto mode

Before You Start

Installing the SIM Card and the Battery

Caution: Do not use any SIM card that is not standard or is incompatible

with the E5. Otherwise, the E5 may be damaged.

Insert the SIM card in the card slot. Be sure that the SIM card is facing in

the right direction, as shown in figure 2, and then slide the SIM card into

the slot.

            

           

             

Installing the microSD Card

Note:

• The microSD card is an optional accessory. If amicroSD card did not

come with your modem, you may purchase one yourself.

• To remove the microSD card, press in the card gently. The microSD

card will pop out for removal.

•Do not remove the microSD card when it is in use. Doing so may

damage the card and the E5, and data stored on the card may be lost.

           

         

Charging the Battery

Note: If the battery has not been used for a long time, it must be charged first.

Method 1: Using the charger

Caution: Only use chargers compatible with the E5 and provided by a

designated manufacturer. Use of an incompatible charger or one from an

unknown manufacturer may cause the E5 to malfunction, fail, or could even

cause a fire. Such use voids all warranties, whether expressed or implied, on

the product.

Method 2: Connecting to a PC for charging

Connect the E5 to aPC using acompatible data cable.
