Ikan IB500 Bedienungsanleitung

IB500

500 Dual Color LED Studio Light QUICKSTART GUIDE

www.ikancorp.com

CONDITIONS OF WARRANTY SERVICE

• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.

• The components and maintenance service fee will be charged if the warranty period has expired.

Free Service will not be Provided in the Following Situations: (* Even if the product is still within the warranty period.)

• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.

• Damage caused by natural disaster, abnormal voltage, and environmental factors etc.

3903 Stoney Brook Dr. Houston TX 77063

1.713.272.8822

[email protected]

What’s included

Checked by

 IB500 LED Light

 AC Adapter + Power Cord

 Light Stand Adapter

 Handle

 Remote Control

IB500

500 Dual Color LED Studio Light QUICKSTART GUIDE

www.ikancorp.com 713-272-8822

Back View

Handle

(The handle can easily be mounted on any side of the fixture

- left, right, top or bottom. Simply slide it into one of the four

grooves, position it and tighten down into place.)

GETTING STARTED

1. Connect the included AC Adapter to power the IB500 light.

2. Turn the light on / off with the Power Switch.

3. Control the intensity of the light by adjusting the DIMMER up and down on the LCD control panel.

4. Control the color temperature of the light by adjusting the COLOR up and down on the LCD

control panel.

5. The IB500 can also be powered by pro battery (optional accessories).

FUSE

Power Switch

Fuse

Dimmer Adjustment

Color Temperature

Adjustment

DC PowerConnection

Light Stand Adapter

Vents

Mounting

Pro Battery

Option

IB500

500 Dual Color LED Studio Light QUICKSTART GUIDE

www.ikancorp.com 713-272-8822

SPECIFICATIONS

Operating Volts: 12v - 14.4v

Brightness: 3ft/2002 lux/3200 K

Color Temperature: 3200K - 5600K

Dimension: 13.8" x 7.5" x 2.8"

Weight (lbs): 6.1

Put it Where You Want It

The IB500 comes with a movable and detachable Light Stand Adapter and Handle allowing you

to mount your light either horizontally or vertically.

FUSE

IB500

500 Dual Color LED Studio Light QUICKSTART GUIDE

www.ikancorp.com 713-272-8822

Operation Indicator On/Off

Remote Control Button Functions

Press and hold A for 5 seconds to sync remote control to light

Press and hold A and B to power On/Off

Hold down A to increase light intensity

Hold down B to decrease light intensity

Hold down C to increase color temperature

Hold down D to decrease color temperature

Press and hold C and D for 5 seconds to enable/disable sound

Remote Control

IB500

500 Dual Color LED Studio Light QUICKSTART GUIDE

www.ikancorp.com 713-272-8822

IB500 LUX Drop Off

The right amount of light

The IB500 lux drop off (Vertical)

90 0 ft

1 meter

3 meters

6 meters

5560 fc / 216 lux

5540 fc / 480 lux

5560 fc / 2.51 lux

The right amount of light

The IB500 lux drop off (Horizontal)

90 0 ft

1 meter

3 meters

6 meters

5590 fc / 222 lux

5580 fc / 584 lux

5560 fc / 2.55 lux
