Ikan LSC-004 Bedienungsanleitung
CHECKED BY
LSC-004
Quick Start Guide
2500 Watt HMI Fresnel Head (Lightstar)
What’s Included
1 x 2500 Watt Fixture Head
1 x Yoke
1 x Barn Doors
1 x Gel Holder
Ikan is the exclusive distributor of Lightstar products in the United States.
Instructions
The Lightstar LSC-004 2500 Watt HMI Fresnel Head is a compact, dual power, fresnel light.
The fixture uses 2500w 115v G38 socket metal handle lamps.
Safety Precautions
1. The LSC-004 fixture has been designed for professional use and must be operated by qualified personnel only.
2. The 2500W fixture can only be used with the Lightstar electronic ballast that supports 2500W.
Working Conditions
The best position is tilting the fixture 90° from horizontal.
The max ambient temperature limit is ±45° C (113°F).
Please keep a minimum distance of 2 feet when close to inflammable objects.
Do not cover the ventilation holes on the fixture housing. They are necessary for proper ventilation.
Use only original parts and accessories from Lightstar.
Before hanging the fixture, make sure the suspension points are properly rated to handle the weight of the fixture.
It is ALWAYS advisable to add a safety cable or chain through the yoke to properly suspend the fixture in place.
WARNING: DO NOT USE THE LSC-004 IN A SPACE WITH FLAMMABLE SUBSTANCES.
WARNING: UV RISK / HEALTH RISK. THE LAMPS USED WITH THE LSC-004 EMIT AN AMOUNT OF UV RADIATION WHICH CAN BE DANGEROUS TO
HUMAN HEALTH IF NOT PROPERLY SHIELDED AGAINST.
THE FIXTURE MUST NEVER BE USED IN SITUATIONS WHEN DIRECT LIGHT EMISSIONS FROM THE LAMP CAN OCCUR. (Ex: No front glass, no
intentional mirror, damaged front housing).
Lamp Installation & Replacement
1. Ensure the fixture is disconnected from the main power supply.
WARNING!! LAMP WILL STILL BE HOT TO THE TOUCH EVEN AFTER THE ALLOTED LAMP REST PERIOD.
THERMAL GLOVES ARE RECOMMENDED FOR WORKING WITH THE FIXTURE AND THE BULB.
2. Check to see that the new lamp is the correct wattage.
3. Release the lamp clamp level inside the front of the fixture.
4. To replace the lamp pull up and out to remove the old lamp.
Re-Lamp Procedures: Do not touch the bulb with your bare-hands. This can cause oil to accumulate on the glass and
reduce the performance of lamp life. The plastic/foam cover which protects the lamp should NOT be removed until after
the lamp is fitted into the fixture. If bulb becomes dirty due to hand contact or from any contaminant, it can be cleaned
with a cloth moistened with alcohol.
5. Re-tighten the lamp clamping device.
6. Close the lens door and securely latch.
Periodic Fixture Inspection
1. The condition of the internal wiring and ceramic base will need to be inspected and tested every 4000 working hours or at least once a year. This
frequency may need to be increased if the fixture has endured rough treatment. All internal components should only be replaced with Lightstar
spare parts.
2. The lamps should be checked every 100 working hours. The lamp should be changed if the lamp becomes deformed or damaged, otherwise
explosion might occur. Defer to instructions provided by the lamp manufacturer.
3. Always check the safety shield before every use.
4. All high-voltage components (ex: voltage wires, lamp ceramic, external shield, igniter must be inspected every 100 working hours or at least once a
year.
5. Outer door hinges and latching system must be checked every 250 working hours to ensure proper seating of the safety shield. This will allow
inspections of accessories and the holding clamps.
6. The condition of the internal mirror must be maintained every 250 working hours. It must be replaced whenever it becomes either cracked or
broken. It is essential for the performance of the fixture.
Specifications & Photometrics
LSC-004 Specifications
Beam Angle 7° to 60°
Build Material Aluminum
Color Temperature 5600K
Cooling System Air Cooled
Fixture Size 29 x 20.3 x 15.6 in.
Fixture Weight 43 lbs
Focusing Knob Control
Head Type HMI Fresnel 2500W
IP Class IP23
Lamp Base 2500W / 115V / G38
Lens Size Fresnel 9.8"
Yoke Cast Aluminum with 1 1/8" Pin
LUX
METERS 9M 12M 15M
18520 10410 6670
LUX
METERS 9M 12M 15M
1545 870 550
FC
FEET 29.5' 39' 49'
1720.5 967.1 619.7
FC
FEET 29.5' 39' 49'
143.5 80.8 51.1
Learn More
More dynamic information at official website: www.ikancorp.com
Support
CONDITIONS OF WARRANTY SERVICE
• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.
• The components and maintenance service fee will be charged if the warranty period is expired.
Free Service will not be Provided in the Following Situations:(*Even if the product is still within the warranty period.)
• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.
• Damage caused by natural disaster, abnormal voltage, and environmental factors, etc.
©2017 ikan Corporation. All rights reserved
