Thank you for your purchase of Ikelite equipment. Please read this

instruction manual completely before attempting to operate or dive

with this product. Please refer to the back page of this manual to

Digital Housing

instruction manual

6182.71 Nikon 7100

Table of Contents

Specifications ..............................................................P. 4

ackage Contents ........................................................P. 4

reparation ..................................................................P. 4

Initial Camera Setup........................................................P. 5

Attach External Tray and Handle to Housing ..................P. 6

Housing Controls - Front View ........................................P. 7

Housing Controls - Back View ........................................P. 8

Opening the Housing ......................................................P. 9

Installing the Camera ......................................................P. 9

Attach Hotshoe to Camera ..............................................P. 9, 10

Attach Camera to Mounting Tray ....................................P. 9, 10

Using the Camera’s Built-in Flash ..................................P. 11

Closing the Housing ........................................................P. 11

Usage ............................................................................P. 12

Final Check ....................................................................P. 12

Zoom Control ..................................................................P. 12

Diffuser and Deflector Installation and Use ....................P. 13

Conversion Circuitry ........................................................P. 14

Attaching an Ikelite Strobe Arm to the Housing Handle..P. 14

Attaching a Sync Cord to the Housing ............................P. 15

Turn Camera On..............................................................P. 15

Entering the Water ..........................................................P. 16

Maintenance ................................................................P. 16

Lens Port ........................................................................P. 16

Table of Contents - continued

Lubricant..........................................................................P. 16

Housing Maintenance......................................................P. 17

Control Maintenance ......................................................P. 18

hoto Tips ..................................................................P. 20

Troubleshooting ........................................................P. 20

Spare arts ..................................................................P. 24

Recommended Accessories ....................................P. 24

EV Manual Controller Use ............................................P. 26

Technical Support ....................................................P. 26

Limited Warranty ........................................................P. 26

Returning roducts for Service ................................P. 27

roduct Registration ..................................................Back Cover

- Ikelite Digital Housing

- Silicone Lubricant

- Vinyl Port Cover

ackage Contents

- Diffuser

- Deflector

- Extra Control Tips

This product has been water pressure tested at the factory and is depth

rated to 200 ft. (60m). Thoroughly inspect and immerse the empty

housing completely in water before installing a camera. If any fogging

occurs or droplets of water enter the housing, do not install a camera.

Clean the housing main o-ring and retest to make sure that it is

watertight. Refer to the Troubleshooting section, page 21.

Please read your Canon camera manual thoroughly to have a full

understanding of each camera function.

If you are new to underwater photography, be sure to read the Photo

Tips section.

reparation

Width ......................7.5 in. (190mm) including controls

Height ....................6.8 in. (173mm) including controls

Depth ......................6.6 in. (168mm) including controls and lens port

Weight ....................4.8 lb (2177g) above water

Buoyancy ................Slightly negative in saltwater for stability

Specifications

Initial Camera Setup (before placing camera in housing)

1. Insert a fully charged battery and formatted memory card.

2. Set camera date and time.

3. Set Shooting Mode to “A” Aperture priority or “M” Manual. In “A”

Aperture Priority mode the shutter speed will lock at 1/30th second. If a

faster shutter speed is desired or picture blur occurs, use “M” Manual

mode. For Macro photography, set Aperture to f8 and engage “Macro

close-up” setting in the camera menu.

4. Set Metering to “Center-weighted.”

5. Set Continuous Mode to “S” Single.

6. Set AF area mode to “Center (normal).”

7. Set Autofocus mode to (AF-S) “Single AF.”

8. Set Flash exp. comp. to “0.0.”

9. Set noise reduction filter to NR “Normal.”

10. Set Wide-angle converter to “OFF.”

11. In the camera menu settings, set Flash control to “AUTO.” When using

external strobes, set to “Built-in off.”

12. Set Active D-Lighting to “OFF.”

13. Set Flash Mode to (lightning bolt in LCD).

14. Set White Balance PRE1 to “Auto (normal): AUTO1.”

15. Set ISO to “100.”

16. Set Image Quality to “FINE.”

17. Set Image Size to “10m”.

18. Set +/- Dial to “0.”

Flash is disabled in the following settings:

- BSS (Best Shot Selection), Continuous Shooting, Multi-shot 16, Auto

Bracketing, Continuous Flash, and Landscape AF Mode

Attach External Tray and Handle to Housing

Using a 9/16” open end or socket wrench, tighten the External Tray to the

Housing Base using the two 3/8-16 Nuts supplied in the accessory package;

tighten Nuts firmly.

External Tray & Handle

3/8-16 Nuts

Housing Controls - Front View

Housing Front Dial Control

The Housing Front Sub-command Dial Control rotates the G12 front dial.

This control is NOT applicable to a G11 camera and will sit idle.

Zoom

Control

Shutter

Release

ON/OFF Button

External Tray Mounts

Flash pop-up

Button

Mode

Dial

Lid Snap

Quick

Dial

Quick Menu Button

Sub-command

Dial

Lens ort

Ikelite

DIGITAL

12 13

Housing Controls

1. External Strobe Connector / Cap

2. Monitor Button

3. Main Command Button

4. AE-L, AF-L Button

5. Playback Button

6. Rotary multi-selector

7. Flash Mode ,

Housing Controls - Back View

8. Self-timer,

9. “O ” Apply Selection Button

10. AF Area Mode,

11. Focus Mode ,

12. Menu Button

13. Delete Button

Opening the Housing

Lid Snaps have a Lock.

To open housing, push Lid Snap

Lock forward and lift as shown.

eep pressure on the Lid Snap so it

does not fly open quickly.

Some Lid Snaps have a lot of

sp ing tension once they go ove

cente , so keep a fi m g ip on the Lid Snap.

Lid Snaps may be opened one at a time.

Push Forward

Lid Snap Lock

Lift

Installing the Camera

1. Pull out on each housing control until it stops. This will get the controls

out of the way for installation of the camera.

2. Remove the back from the housing.

3. Remove camera lanyard from camera if attached.

4. The mounting tray for the camera is secured to the housing back.

Position the camera on the tray.

5. Slide the housing Hotshoe Connector into the Camera Hotshoe Mount

- page 10, diagram A.

Slide the connector forward until it stops. This can

be done before or after the camera is secured with the mounting bolt

- page 10, diagram B.

Note: If you are using an EV Controller or slave strobe and NOT hardwiring

your strobes directly to the housing, leave the housing hotshoe

disconnected from the camera. You will also need to install the Flash

Deflector (supplied) into the external port groove to block and deflect the

camera flash to the EV controller - page 13. For additional information

regarding EV Controller Use, go to page 26.

6. Using a coin or screwdriver (preferred), secure the camera with the Tray

Mounting Bolt which threads into the camera’s tripod socket - page 10,

diagram B.

CAUTION:

Do not c oss

th ead o

ove tighten the

T ay Mounting

Bolt as you may

damage the

came a t ipod

socket th eads.

Diagram B

Attach Camera to Mounting Tray

Attach Hotshoe to Camera

Tray Mounting Bolt

Diagram A

Hotshoe Connector

Mounting

Tray

Housing Back

O-ring

External Strobe Connector

& Waterproof Cap

(Do not emove unde wate )

Nikon

Fn1
