Impact VC-500WL Bedienungsanleitung

INSTRUCTIONS

VC-500WL/VC-500WL220V

Digital Monolight

Thank you for choosing the Impact Digital Monolight. This

professional-grade studio lighting unit has a user-replaceable 250W

halogen modeling light, 500 w/s ash tube, and a lightning-fast 1.5

second recycle time. The monolight is constructed with a durable

housing, intelligent adaptive thermal control, and CMOS chip

circuitry.

The powerful Digital Monolight also has an integrated 2.4 GHz,

16-channel wireless radio receiver. When partnered with the

matching transmitter (available in the Digital Monolight kit), the

user has the ability to trigger the monolight from a distance of 328′

(100 m). Paired with the unit’s integrated group functions, the user

can arrange and digitally segment each of their remote devices as

needed. Additionally, the ash’s seven optical slave modes enable

the device to communicate with your on-camera master ashes,

seamlessly triggering after up to ve preashes.

This fan-cooled monolight is constructed with an adaptive S-mount,

which makes it available for pairing with any other S-mount

reector or light modier. Additionally, the standard 5/8″stand

mount has a built-in umbrella mount, expanding the number of add-

on options available for the unit.

Introduction

Features

• Fast recycle time and ash duration

• Integrated 2.4 GHz wireless receiver

• 250-watt, user-replaceable halogen modeling light

• Adaptive thermal control

• CMOS chip circuitry

• Compatible with Bowens mount (S-mount) accessories

• Low 5V trigger voltage

• Quiet fan cooling

Box Contents

• Digital Monolight

• Reector

• AC cord

Three-prong grounded plug (VC-500WL)

2-pin Euro connector (VC-500WL220V)

• Sync cord

• 250W modeling lamp

120V, 60 Hz (VC-500WL)

220~240V, 50/60 Hz (VC-500WL220V)

• 500W ash tube

• Protective cover

• Wireless transmitter with sync cord (kits only)

• User manual

• One-Year Limited Warranty

Precautions ⚠⚡

Please read and follow these instructions and keep this manual in a safe place.

• DANGER: high-voltage parts inside.

• There are no serviceable parts inside the unit. Only qualied service engineers should

access the inside of the casing.

• If the ash tube or modeling light becomes cracked or damaged in any way, replace

immediately.

• Keep this product away from water and any ammable gases or liquids.

• Use only the correct, recommended voltage.

• Avoid rapid, high-power ashing.

• Excessive heat shortens the life span of ash tubes, modeling lamps, and internal

components.

• If not used for two months, turn the unit on for 30 minutes and re the ash several

times to charge the capacitors.

• Always remove the protective cap before plugging in or powering on the unit.

• Never operate the ash with the protective cap on.

• Make sure this product is powered off when plugging it into a power source.

• Turn off the power and unplug the power cord from the unit and wall when the

monolight is not in use.

• Always remove the modeling lamp and attach the protective cap when transporting

the unit.

• Do not attempt to disassemble or repair this product. There are components inside

that can produce a hazardous electric shock.

• Handle this product with care.

• Do not stare at the lights when they are powered on.

• Clean this product with only a soft, dry cloth.

• Always wear cotton gloves when handling the ashtube.

• Keep this product away from children.

• Make sure everything is secure before proceeding.

• Make sure that this product is intact and that there are no missing parts before use.

• All photos are for illustrative purposes only.

Overview

Front Side:

1. Monolight

2. Mount release

3. Modeling lamp

4. Reector

5. Flashtube

Top Side:

6. Optical sensor

Back Side:

1. LCD screen

2. Slave mode button

3. Power input jack

4. Fuse bay

5. Modeling lamp output buttons

6. Audio button

7. Test button

8. 6.35 mm sync port

9. Power switch

10. Output adjustment dial

11. Stand mount

12. Stand mount adjustment knobs

13. Umbrella mount

14. Umbrella mount tightening knob

5 6 7

8 9 10

Overview

Remote Guide (Kit Only)

Top:

1. Up button

2. Down button

3. Test button

4. Group indicators

Right Side:

5. Group selector button

Left Side:

6. 3.5 mm sync port

Bottom:

7. Hot-shoe mount

8. Battery compartment

9. Channel DIP switches

LCD Screen Guide:

1. Ready beeper indicator

2. Modeling lamp mode

3. Flash indicator

4. Error indicator

5. Flash ready indicator

6. Modeling light indicator

7. Slave / Pre-ash indicators

8. Modeling lamp output level

9. Flash power output indicator

10. Power output level

MODEL

FLASH

READY

110V AC

FLASH

2 3

WARN

6 71

The Impact Digital Monolight includes a pre-installed ash

tube and a modeling lamp that's packed separately in the

box. Both lights are user-replaceable. Be careful not to

touch the ash tube with your bare hands since this could

cause damage to it. Please use cotton gloves or a soft, dry

cloth when touching or handling the ash tube.

The monolight’s modeling lamp is a halogen bulb within a glass sleeve. You may

touch this glass without cotton gloves. However, wiping it with a cotton cloth

after handling it is recommended. To install the modeling lamp, see Installation

and Replacement Guide on page 23.

The monolight ships with a protective cap. Always remove

the protective cap before plugging in or powering on the

unit. To remove the cap, hold down the mount release and

turn the cap counterclockwise. Pull the cap from the mount

and place it to the side for later use.

Attach the narrower end of the reector by aligning one of its protrusions with

a hole in the rim of the monolight. Hold down the mount release, fully insert the

reector, and turn it clockwise. You'll hear it click into place. Let go of the mount

release.

Mounting Accessories

Light Stand Mount

The Impact Digital Monolight has a standard 5/8″stand

mount with tilt and tightening knobs. To mount the monolight

on a light stand, place the stand mount onto a compatible

Preparing for Use

stand with a standard 5/8″top mount. Turn the tightening knob to secure. Turn

the adjustment knob counter-clockwise to adjust the tilt of the monolight. Turn

the knob clockwise to secure the monolight in place.

Accessory S-mount

The Digital Monolight has an S-mount for light-modifying accessories. This can

be used with such optional add-ons as speed rings for softboxes. The included

umbrella reector lines up with the unit’s umbrella mount located on the

monolight’s stand mount.

To use accessories with the monolight’s S-mount, simply align the accessory

with the mount and insert. Once inserted, rotate the accessory clockwise to

secure. To remove it from the mount, hold down the mount release and reverse

the above instructions.

Umbrella Mount

To mount an umbrella to the monolight, rst attach the umbrella reector dish

using the above instructions. Then run the umbrella rod through the dish’s

umbrella hole and into the monolight’s umbrella mount. Secure the umbrella

using the umbrella tightening knob.
