Imperial DABMAN i200 Bedienungsanleitung
45
44Operating Manual
E
Operating Manual
IMPERIAL® DABMAN i200
Dabmann I 200_DE_EN.indd 44 21.10.15 10:50
45
44
IMPERIAL DABMAN i200
E
INHALTSVERZEICHNIS
1. INTRODUCTION.................................. 46
2. SAFETY NOTICES ................................ 47
3. ITEMS SUPPLIED...................................51
4. ILLUSTRATIONS....................................52
5. REMOTE CONTROL ................................55
6. INSTALLATION.....................................56
7. OPERATION ..................................... 58
7.1. Configuration.....................................58
7.2. Lokal Station .....................................65
7.3. Internet Radio....................................66
7.4. Media-Center ....................................68
7.5. FM ..........................................69
7.6. DAB ..........................................70
7.6. Information- Center ...............................72
7.6. AUX ..........................................73
8. AIR MUSIC CONTROL APP ....................... 74
9. TROUBLESHOOTING ...............................78
10. DISPOSIAL NOTICE ...............................81
11. FEATURES AND TECHNICAL DATA.................82
12. SERVICE UND SUPPORT ..........................84
13. CE MARKING.....................................85
Dabmann I 200_DE_EN.indd 45 21.10.15 10:50
47
46Operating Manual
E1. INTRODUCTION
Thank you for purchasing the DABMAN i200. When you use the
DABMAN i200 for the rst time, please read these instructions
carefully, and retain them for reference in future. You will be able to
fully enjoy the many functions of the radio only if you follow the
instructions.
This operating manual will assist you with the
• correct
• safe
• optimal
use of the IMPERIAL DABMAN i200. We assume the user of the
radio has general knowledge related to the operation of consumer
electronics products.
Any person
• installing
• connecting
• operating
• cleaning
• disposing of
this radio must rst have taken notice of the entire contents of this op-
erating manual. Always keep this operating manual close to the radio.
Dabmann I 200_DE_EN.indd 46 21.10.15 10:50
47
46
IMPERIAL DABMAN i200
E
2. SAFETY NOTICES
Please read the safety notices carefully before operating the radio.
Please note all warnings and instructions both on the product and in
the operating manual.
2.1 Basic Safety notices
• In case of operating problems, disconnect the radio from the
power source.
• To avoid the risk of re or the danger of an electrical shock, do
not expose the radio to rain or to very humid, wet conditions.
• Do not open the housing of the product, otherwise you are at risk
of getting an electrical shock.
• Only connect the radio to the mains current via a correctly in-
stalled 220– 240 V~, 50–60 Hz mains outlet.
• If you will not be using the radio for an extended period, discon
nect the external mains adapter from the mains outlet. Only pull
out the adapter, do not pull on the cable.
• In case of an electrical storm, disconnect the mains adapter of
the radio from the mains outlet.
• Should liquid or foreign objects fall into the radio, immediately dis
connect the mains adapter from the mains outlet. Have the
product checked by qualied personnel before resuming
operation. Otherwise you are in danger of getting an electrical
shock.
Dabmann I 200_DE_EN.indd 47 21.10.15 10:50
49
48Operating Manual
E2. SAFETY NOTICES
• Please ensure the electrical outlet (plug) is easily accessible.
• Do not squeeze or sharply bend cable connections.
• If the mains cable is damaged, you must have the radio repaired
by an expert before using it again. Otherwise you are in danger of
getting an electrical shock.
• Never allow children to use the radio without supervision.
• Always leave maintenance or repair work to qualied personnel.
Ignoring this may endanger yourself and others.
• In case of operating problems, disconnect the radio from the
power supply.
• Obtain spare parts exclusively from the manufacturer.
• Changes to the product will result in a termination of liability by
the manufacturer.
• Remove protective foils/lms.
• Use only a dry cloth to clean the equipment
Note!
Note on disconnecting from mains supply. The product draws
power even when in standby mode. To completely disconnect the
product from the mains supply, the adapter must be
disconnected from the mains outlet.
Dabmann I 200_DE_EN.indd 48 21.10.15 10:50
49
48
IMPERIAL DABMAN i200
E
Correct positioning
• Place the radio on a rm, even surface.
• Avoid placing the radio close to sources of heat, e.g. radiators,
open res, e.g. candles, or devices with strong magnetic elds,
e.g. loudspeakers.
• Do not place any containers with liquids (e.g. vases) on the radio.
• Avoid places subject to direct sunshine or with a very high level
of dust.
• Do not cover the ventilation slots. Ensure adequate circulation of
air around the radio.
• Do not place any heavy objects on the radio.
• When moving the radio from a cold to a warm environment,
humidity may condense inside the radio. In this case you should
wait for an hour before operating the radio again.
• Place the mains cable in such a position that nobody will step on it
or trip over it.
2. SAFETY NOTICES
Dabmann I 200_DE_EN.indd 49 21.10.15 10:50
51
50Operating Manual
E
Correct handling of batteries
• Batteries may contain poisonous substances. Ensure batteries
are not handled by children. Children could place the batteries
in their mouth and swallow them. If a battery is swallowed, please
consult a doctor immediately.
• Leaking batteries may damage the remote control. If the radio is
not going to be used for an extended period, remove the
batteries.
• Batteries may contain poisonous substances. Batteries must be
disposed of in accordance with current legal regulations and with
consideration for the environment. Do not dispose of batteries in
your domestic waste.
• Do not expose batteries to open ames or extreme heat, as they
may explode.
• Always replace batteries by the same type.
2.2. Explanation of safety notices
You will nd the following categories of safety notices in the
operating manual:
Danger!
Notes marked with the word DANGER will warn you of possible
danger of injury to persons.
Instructions with the word NOTE will warn you of possible mate-
rial or environmental damage. These notes contain special advice
related to the economic operation of the receiver.
2. SAFETY NOTICES
Nr. Anzahl Erklärung
1 1 DABMAN i200
2 1 Remote control
3 1 External mains adapter
4 1 Operating manual
5 1 Guarantee card
Dabmann I 200_DE_EN.indd 50 21.10.15 10:50
51
50
IMPERIAL DABMAN i200
E
3. ITEMS SUPPLIED
1 2 3 4 5
Nr. Anzahl Erklärung
1 1 DABMAN i200
2 1 Remote control
3 1 External mains adapter
4 1 Operating manual
5 1 Guarantee card
Mit IMPERIAL®heute schon Zukunft hören
D
Bedienungsanleitung
IMPERIAL® DABMAN i200
Sehr geehrter Kunde,
wir bedanken uns, dass Sie sich für dieses hochwertige Produkt entschieden haben. Sollte es trotzdem
bei diesem Produkt zu einer Störung kommen, bitten wir Sie, sich zunächst an unsere technische Hotline
02102/1338-339 zu wenden. Sollten wir das Problem über diesen Weg nicht lösen können, senden Sie
das Produkt an folgende Anschrift ein:
GARANTIEKARTE
s
s
s
s
s
DigitalBOX Europe GmbH
Servicecenter
Am Weiher 14 (Industriegebiet)
D-56766 Ulmen
DigitalBOX Europe GmbH
Servicecenter
Am Weiher 14 (Industriegebiet)
D-56766 Ulmen
GARANTIEKARTE
s
s
s
s
s
Name
Absender BitteBlockschrift in GROSSBUCHSTABEN · Bitte Kästchen beachten
Vorname
PLZund Ort
Telefonmit Vorwahl
Unterschriftdes Käufers
Gerätetyp
Verbleibt beim Kunden
Garantiekarte_NORMA.indd 1 16.08.12 11:45
Dabmann I 200_DE_EN.indd 51 21.10.15 10:50
53
52Operating Manual
E
6
5
4
3
7
2
18
10
911
12
13
14
15 16
4. ILLUSTRATIONS
Dabmann I 200_DE_EN.indd 52 21.10.15 10:50
53
52
IMPERIAL DABMAN i200
E
4. ILLUSTRATIONS
1. Station memory keys 1-5
2. Power key on/off
Use this key to switch the radio on or to standby.
3. Menu key
Calls up the menu of the radio.
4. Mode
Here you can select the operating mode of the unit, bet
ween Internet radio, DAB+, FM, uPnP, AUX and USB.
5./6. Navigation/ station selection
Use these keys to navigate in the menu, or to select the
next station in the station list.
7. Volume control, confirmation key
Use the rotary dial to adjust the volume, or confirm menu
entries by pressing the key.
8. Display
9. Power switch
Here you can switch the radio on or off. The radio will be
disconnected from the power supply in position 0.
10. Mains adapter connection
Use this socket to connect the radio with the mains
adapter (supplied)
11. USB connection
Here you can connect the radio with a USB storage device
in order to reproduce music files from this.
12. LAN connection
Here you can connect the radio via a network cable with an
existing network in order to use the Internet radio function.
(Alternatively the radio can also be connected via
wi-fi/W-LAN.)
Dabmann I 200_DE_EN.indd 53 21.10.15 10:50
