Inaxsys DX400UL Series Bedienungsanleitung

DX400UL,DX400ULPD4ECB, DX400ULPD8ECB,

DX400ULMOM8ECB, DX400ULACM4ECB.

FEBURARY 13 2018

PART NO:PX4000 Ver.01

12.

13.

Low Battery indication at 11.40/22.80 Volts.

14.

Low Battery disconnect at 10/20.2 Volts.

15.

Low Battery,Batterydisconnect, No Battery presence, battery

16.

17.

AC inputindication by Green LED. (LED on when AC is present).

18.

AC Fault CMOS Relay contact for AC failure

19.

DC output indication by Blue LED, on board and enclosure.

20.

Overload and short circuit protection on DC output.

22.

23.

Board Dimension: 195mm x 110mm

Enclosure Dimension: 338 x 448 x 110mm(HP346 for 12Ah Battery)

LEDs display on enclosure door (Green, Yellow, Blue).

Battery charging leads included.

Enclosure Dimension: 356 x 472 x 110mm(HP347 for 17.2Ah Battery)

charger trouble reporting. (See FAULT TABLE)

Input = 120 240VAC 50-60Hz, 1.8 Amp maximum, fuse at 4 Amp

Output 4 Amps continuous supply current PF 0.6 at nominal 12/24 VDC.

Built-in dedicated charger for sealed lead acid or gel cell type batteries.

.)gnitartnerructuptuoxamehtfotraptonMaximum battery charging current 1.5Amps (

Automatic switch over to stand-by battery upon AC failure or below 69.9VAC.

Battery presence detection within 10 seconds.

Temperature Compensated Battery Charger.(EN54-4 only,not UL evaluated)

Battery Charger Monitor.

Battery load test every 48hr.

Battery test result indication.

Battery Reversal protection.

Description

The DX400UL series of power supply/charger supplies a total of 4 amp nominal

leetsteehsegralanidellatsnisitI.stuptuoCDV42/21@tnerrucylppussuounitnoc

enclosure capable of accommodating one or two 12AH or 17.2AH lead acid rechargeable

batteries. The power supply models : DX400UL,DX400ULPD4ECB,DX400ULPD8ECB

have been evaluated for: CAN/ULC-S527,UL864,ULC-S318,UL603,UL294,

CAN/ULC-60839-11-1,CAN/ULC-S533. The above Power supplies are not intended to power

Fire Notification Appliances(Horns,Strobes & Bells). The power supply models:

DX400ULACM4ECB, DX400ULMOM8ECB have been evaluated for: UL294,

CAN/ULC-60839-11-1,CAN/ULC-S533.

General Specifications:

Power Supply / Charger

LED Indications

1. Green LED - AC indicator

a. On when AC present.

b. The AC fail Relay activates (opens) within 60 seconds after AC failure.

2. Blue LED – DC Power indicator

a. Powered directly from the power supply DC output and indicates output is

present.

3. Yellow LED – Battery Charging and Fault indicator

a. The Yellow LED flashing indicates the battery is charging and is also used

to indicate various Fault conditions. See the Fault Condition and Indication

4. Red LED –Battery/Charger test Indiicator for Pass or Failure.

Performance Ratings

UL 294 Performance Levels:

Model Line Security Destructive Attack Endurance Standby Power

III (when used with

12Ah battery

III (when used with

DX400ULMOM8ECB Power

Supply

I I IV

17.2Ah battery

Product

Type

DX400ULACM4ECB

Model Grade

3 (when used

with 12Ah battery)

DX400ULMOM8ECB

3 (when used

with 17.2Ah battery)

CAN/ULC-60839-11-1 Performance Grades:

Product

Type

Power

Supply

DX400ULACM4ECB

DX400ULPD4ECB

DX400ULPD8ECB

DX400UL

Grade Achievement

Connect AC & Battery Trouble Relay

Outputs to a Grade 3 Control Unit,

to achieve Grade 3.

a. The Red LED indicates a Battery test Failure or a Battery charger failure in

ehteeS.snoitidnoCtluaFrehtoetacidniotDELwolleYehthtiwnoitcnujnoc

Fault Conditions and Indication Table for details.

Table for details.

DX400ULPD4ECB

DX400ULPD8ECB

DX400UL

Output Voltage

13.8V/27.6V Nominal

Charging Current

Operating Temperature

Output Amperage 4 Amp

12/24 Vdc Regulated. Class E, unsupervised

0deg.C to 49deg.C

Technical Specification:

Battery Charging Voltage

Ripple 50 mVp-p max

1.5A Max, and not part of

max output rating

OFF

OPEN

OFF

1 SEC ON/OFF

3 FLASHES

REPLACED

BATTERY IS

REPEAT UNTIL

STOP 1 SECOND

5 RAPID FLASHES

60 SEC

WITHIN

OPEN

BATTERY LOW

AC FAIL

BATTERY TEST FAIL

BATTERY TEST OK

DISCONNECTED

BATTERY

OR NOT CONNECTED

BATTERY REVERSED

RELAY

ACBATT

LED-RLED-YLED-GFAULT

Relay Outputs:

Output Output Type Description

CMOS RELAY RATING: 30VDC 60mA 16 OHMS

BATTERY PROBLEM

NORMALLY CLOSED

OPEN = FAULT

TRIPS WITHIN 60 SEC. AFTER AC FAILS

OPEN = FAULT

NORMALLY CLOSED

Fault Condition & Indications:

CHARGER FAIL

AC FAIL

BATTERY

FAIL

AND REPEAT UNTIL OK

2 SECONDS STOP

10 RAPID FLASHES

LED-B

DC FAIL/OVERLOAD OFF

OPEN

Battery Operating Values

Parameter Output Description

Battery Disconnect voltage 10/20.2V When AC is off, the battery is

disconnected when the battery voltage

drops below this value.

The battery is only reconnected when

the AC is restored.

Minimum battery voltage to

pass battery test

11.50V

23.0V

Red Led Flash 1 sec ON/OFF during

2 minutes testing. Battery Fail 5 rapid

flashes and 1 sec pause. Replace

Battery

22.80V

If the output voltage drops below this

value a voltage low warning is generated.

See Fault Conditions and Indication table.

Optional Temperature Compensated Charging Voltages

for EN-54 only, not evaluated by UL

Temperature

Degrees Celsius

Charger Voltage

12 Volts

Charger Voltage

24 volts

-10

14.1

28.20

14.0

28.00

13.9

27.80

13.75

27.50

13.65

27.30

13.50

27.00

13.40

26.80

>50

Charger off

11.40V

Low Battery Voltage

Warning

1 Mount the power supply in the desired location using the 4 mounting holes.

NOTE: For use in Indoor Protected Area with Controlled Environment only.

Do not Install Power Supply on Exterior Doors.

2 With the Mains power disconnected, connect the leads to the AC Input Terminal

Block, respecting the wiring phase and polarity :

Ground/Earth=Green/Yellow, Neutral = Blue (White), Live =Black (Brown). This

equipment must be connected to the 120-240 Volt Mains via a readily dedicated accessible

external disconnect device with maximum 15 Amp branch protection. Select the operating

3Do not connect the battery at this time.

4 Switch ON the AC. Green LED will come ON indicating AC is present and the AC

Fault Relay will be energized “ON” (closed). When the AC is off the AC Fault Relay

will drop open within 60 seconds (Factory set) activating the CMOS output

contact “AC Fail”. Connect this output to relevant monitoring devices.

5 Verify the DC output voltage is correct = 13.20VDC or 26.40VDC max. Blue DC LED

will be ON to indicate DC output is OK.

6 Yellow LED will be on and the BAT FAULT CMOS relay open indicating the Battery is

not present or connected with reversed polarity.

7 Connect the Battery or Batteries respecting the polarity. Battery shall not be connected

if AC is not present first.

8 If the battery is connected with the correct polarities the Yellow LED will turn OFF

(See Fault Conditions and Indications Table). Within one minute the Battery Fault Relay

will restore and the Yellow LED will flash once every 2 seconds.

9 If the battery is connected reverse polarity, the Yellow LED will be ON. (See the Table Fault).

The CMOS relay will open indicating Battery Fault. Connect this output to relevant monitoring

Installation Instructions

This power supply should be installed in compliance with National Electrical Code,

NFPA70 as well NFPA72 National Fire Alarm Code, CSA C22.1, Safety Standard

for Electrical Installations, Canadian Electrical Code, Part I, CAN/ULC-S524,

and all applicable Local Codes. Installation to be performed by suitably qualified

personnel. The power supply shall not be installed in the fail secure mode unless

permitted by the local authority having jurisdiction, and shall not interfere with the

operation of Listed panic hardware.

SW1 ON=12VDC, SW1 OFF=24VDC.

output DC voltage 12/24 with the jumper SW1.

devices.

10 Connect the devices to be powered to the output terminals marked “Vo- Vo+”.

11 See below for installation of PD4ECB, PD8ECB, MOM8ECB and ACM4ECB

need 2 EOLR Resistors(2K2) provided. See Fig 1 & Fig 2.

12 If Tamper Switch is required use part # TSW1-02 or TWS2-02, see Fig 3.

13 Use 2K2 EOLR (end of line resistor) Part #EORL-PWX2K2

14 Connect the fault relays to FACP or ACP for trouble indication.

15 Secure the enclosure with the screw or with the Key Lock if provided.

Description:

The PD4ECB and the PD8ECB are distribution boards used for Fire Alarm, Bulglary,

Access Control and Egress Doors installation. The PD4ECB and PD8ECB board

have 4 and 8 outputs each rated max. 2.0Amp(max. total current 4 Amp), each with

Installation:

Connect the devices to be powered to the output terminals marked “ - DC +“ 1 to 4 or 1 to 8

of the PD4ECB and PD8ECB board. Red Led indicates output is live. Red Led OFF

indicates output is disabled due to overload or short, therefore the DC fail relay will open.

To reset the output, remove the Load or the Short and investigate the cause of

the trouble. Secure the enclosure with the screw and/or with the Key Lock if provided.

CMOS relay rating: 30Vdc, 60mA. 16ohms contact resistence.

The MOM8ECB is a distribution controller to be used with Access Control System,and Egress

Doors, It provides 12/24 vdc through 8 electronic over-current protected outputs, each rated

max. 2 amp(max. total current = 4 amp), each with electronic overcurrent. The 8 outputs will switch

ON or OFF security devices such as Magnetic Locks, Door Strikes, etc. It is to be connected

to FACP or ACP via a NO or NC configurable contact input with EOLR 2.2kohm.

(Part #EORL-PWX2K2) Also it has another input for Reversed Polarity triggering for older

version of Fire Alarm Control Panel. The MOM8ECB has 2 status relay output, one with

Dry Contact “Form C” to indicate output status and One Dry Contact “Form C” to indicate

DC Failure on any of the 8 outputs.

1. Output Connections

There are 8 selectable outputs suitable for FAIL Safe config and FAIL SECURE config.

1) For Fail Safe operation connect the device positive to DC STANDBY OUPUT (+)

on the MOM8ECB. DC power is present in normal condition and will switch OFF

when the FACP/ACP or Rev. Pol input is triggered. Fail Safe operation devices such

as Magnetic Lock should be connected to this output as show on Fig. 1.

2) For Fail Secure operation connect device positive to DC ALARM OUTPUT (+) on the

MOM8ECB. DC power is not present in normal condition and will switch ON when

the FACP/ACP input is triggered. Fail Secure Operation Devices such as Door Strikes

should be connected to this output.

Description:

Installation:

3) In either configuration connect the negative of the device to the NEGATIVE terminal CN8

PD4ECB, PD8ECB

MOM8ECB

electronic overcurrent protection set at 2.5 Amp.

2. Fire Alarm and Access Control interface connection

Normally Open (NO), Normally Closed (NC) input or Polarity Reverse (Rev. Volt.)

input are available to trigger the MOM8ECB operation. Connect the positive (+)

and Negative (-) from the FACP/ACP to the REV. VOLT terminals observing

the polarity,(polarity is referenced in alarm condition) or connect the NO or

NC from the FACP/ACP output to the “Fire Trigger Terminals”. Install a 2K2 Ohms (EOL)

PWX2K2 resistor at the FACP/ACP as show in Fig 1. Note: No ELOR on Rev. Pol.

3. Engineering RESET/REX Input

4. Relay Output

CD(ehtesuaclliwstuptuo8ehtfoeromroenotaliaftuptuoCD:liaFCD)a FAIL)

Trouble relay to open (De-energize). Connect this output to monitoring device. (28Vdc,

: :tuptuOsutatS)b FACP or ACP or Rev. Pol input will cause the dry contact Relay

“Form C” to open (de-energize). Connect this output to monitoring device. (28Vdc, 300mA)

5. Cascade Connection

Two(2) or more MOM8ECB units(maximum 20) can be connected together as follow:

Connect the status output relay Cand NC terminals from the 1st unit to the REMOTE

RESET INPUT of the 2nd unit(not polarity sensitive) and remove the JR of the 1st unit.

Install EOLR(2K2) on 2nd unit Fire Trigger terminal. If If a 3rd unit needs to connected

NOTE: If Latch Mode is used, only JL jumper on the first unit must be removed.

Engineering Reset will be performed from the 1st unit.

LD1 to LD8 RED LED when ON indicates that the output is ON (enable).

When OFF, the output is OFF, NO DC present (disable). The cause could be

Overload or short on the output. Note: all 8 outputs are current limited set at

2.5Amp, rated max 2.0Amp. LDF Fire Green Led is normally OFF. It will switch on

upon receiving an Input from the FACP/ACP. This led will stay ON following the

status of the FACP/ACP input. IF JL was removed this LED will stay ON until the manual

RESET circuit resets.

JL ON will cause the unit to follow the FIRE/ACP TRIGGER.

This option is avaliable when the Jumper JL is removed(JL OFF). This will cause the

MOM8ECB to latch upon receiving alarm from the FACP or ACP with this option in

place. When the FIRE/ACP TRIGGER resets, MOM8ECB will only reset by activating

the RESET/REX input.

Install the 2K2 EOLR

6. MOM8ECB LED Indication:

(end of line resistor) #EORL-PWX2K2 at the key Switch or Push Button to perform

This Operation.

300mA)

The

the JR of the 2nd unit must be removed and so on for any additional unit. Ref to Fig.1.

ACM4ECB

DESCRIPTION:

The ACM4ECB is a distribution controller to be used with card Access Control, Egress Doors.

It provides 12/24Vdc through 4 outputs rated 2.0A(max. 4A total) each with electronic over-current

protection set at 2.5A. The 4 outputs will switch ON or OFF security devices such as Magnetic Locks,

Door Strikes, etc. It is connected to FACP or ACP via a NO or NC configurable contact input

using 2K2 EOLR(Part #EORL-PWX2K2). Also it has input for Reversed Polarity triggering.

The ACM4ECB has 2 relay outputs, one Dry Contact “Form C” to indicate output status, and one

Dry Contact “Form C” to indicate DC failure on any of the 4 outputs, due to overcurrent or short.

Installation:

There are 4 selectable outputs suitable for FAIL Safe config and Fail Secure config.

For Fail Safe Operation connect the positive (+) lead of the device to normally

Closed (NC) and the negative lead to COM ”Neg”, connector CN1 to CN4. DC

power is present in normal condition and will switch OFF when FACP/ACP or

or Reverse Polarity input is triggered. Fail Safe operation devices such as,

Magnetic Lock should be connected to this output as show on Fig. 2.

1. Output Connections

2. Fire Alarm and Access Control Interface

Normally Open (NO), Normally Closed (NC) input or Polarity Reverse (Rev. Volt.) input

are available to trigger the ACM4ECB operation. Connect the positive(+) and Negative(-)

from the FACP or ACP to the REV. VOLT terminals observing the polarity,

(polarity is referenced in alarm condition) or connect the NO or NC from the FACP

or ACP output to the “Fire Trigger “terminals. Install PWX2K2 2k2 (EOLR) resistor

at the FACP or ACP as show in Fig. 1. Note: No ELOR on Rev. Pol.

3. Engineering RESET/REX Input

For Fail Secure operation connect device positive(+) lead to Normally Open (NO)

DC power is not present in normal condition and will switch ON when the

FACP or ACP or Reverse Polarity input is triggered. Fail Secure operation

devices such as Door Strikes should be connected to this output.

JL ON will cause the unit to follow the FIRE/ACP TIGGER.

(EOLR) resistor at the Key Switch or Push Button to perform this operation.

This option is avaliable when the Jumper JL is removed(JL OFF). This will cause

the ACM4ECB to latch opon receiving Input from the FACP or ACP with this option

in place and when the FIRE/ACP TRIGGER resets, ACM4ECB will only reset by

activating the RESET/REX input.

Install PWX2K2 2.2K

4. Relay Output

a) DC Fail: When one or more of the 4 outputs fail due to over current or short circuit

condition, the DC fail Relay will open. Connect this output to monitoring device. (28Vdc,

300mA)

b) Status Output:: When the FACP or ACP input activates this will cause the dry contact

Form “C” to change state (de-energize). Connect this output to monitoring device.

5. Cascade Connection

Two(2) or more ACM4ECB units can be connected together as follow: Connect the Status

Output relay Cand NC terminals from the 1st unit to the REMOTE RESET/REX INPUT

of the 2nd unit(not polarity sensitive) and remove the JR of the 1st unit. Install EOLR(2K2) on

2nd unit Fire Trigger terminal. If 3rd unit is connected, the JR of the 2nd unit must be

NOTE: If Latch Mode is used, only JL jumper on the first unit must be removed. Engineering

Reset will be performed from the 1st unit.

6. ACM4ECB LED INDICATION

L1 to L4 are the Output RED Led, when ON indicates DC is present (enable), and

the Output relays are energized.

When OFF, Relay is de-energized and the output is OFF, NO DC present (disable).

Current limited set @ 2.5Amp, rated at max 2.0Amp.

L9 Green Led is normally OFF. It will switch on upon receiving an alarm from the FACP/ACP.

This LED will stay ON following the status of the FACP/ACP input. If JL was removed this

LED will stay ON until the manual RESET circuit resets.

7. Access Control Panel (ACP)Trigger input.

8. FACP/ACP Input Programming

Selectable Output to be Irrelevant on Fire Activation

To have the output relay activation follow the FACP or ACP input place the DIP switch

corresponding to desired relay to the “OFF” position. In the “ON position, the correspondent

output relay will not be effected by the FACP,ACP or Rev. Pol input.

9. Isolated Output Configuration

If any of the outputs requires to be Isolated DRY CONTACT, remove the respective Jumper

J1 through J4 to achieve this configuration, Form “C”,(C NO NC) available to connectors CN1

through CN4. This connection is now isolated from the internal power source.

Relay Rating: 28Vdc, 2A. PF 0.6

Relay

(28Vdc, 300mA)

removed, and so on for any additional unit. Ref to Fig.1.

LD1 to LD4 Yellow LED indication denotes overload or short on the output. The outputs are

There are 4 inputs, CN10 through CN13 each with two terminals, IN and GND. Activation

of the inputs is achieved by shorting IN and GND terminals of the respective inputs.

battery jumper

BATTERY 1

BATTERY 2

AMP BATTERY

BATTERY CONNECTION NON POWER LIMITED

DX400

TO MONITOR POINT

RT2

CN3

CN2

CN6CN7

D16

Q12

D17

C11

C47

IC9

Q12

Q11

C66

C37

LED-B

D25

C54 Q18

IC13

IC12

D5A

Q3A

CY2

CY3

CY6

NTC

OUTPUT

D.C.

BATT.

TEMP

FAIL

BATTERY

GND NL

BATTERY

- + - +

SW1

12/24

PANEL LED LED-Y LED-R

LED9

T4A/ 250Vac

NTC

LED-G

CX2

DB1

Q30

CX1

L1A

MOV

PROGRAM

VR1

FAIL

CY5

SOFTWARE VER 1.8

DX-200W-PCB

TAMPER

SWITCH

N/C TAMPER OUT

CONNECTOR

HPVM3 ASSY

TOP LEVER

DX400UL

CABINET GROUND

AWG 14

EARTH

GROUND

STUD

ULC-S533, UL 294

COMMERCIAL FIRE

BURGLAR ALARM

ACCESS CONTROL

REGULATED POWER

SUPPLY CHARGER

FIRE ALARM AND SECURITY EQUIPMENT

21A6

SECURITY

SIGNALING

UL/ULC LISTED AS FOLLOWS:

UL2 94,CAN/ULC-60839-11-1,CAN/ULC-S533 FOR ACCESS CONTROL SYSTEM

REGULATED POWER SUPPLY CHARGER

UL864,CAN/ULC-S527 FOR COMMERCIAL FIRE

UL603, ULC-S318 FOR BURGLARY ALARM SYSTEM

NOTE: PLEASE REFER TO DX400UL INSTALLATION MANUAL, PART NO:PX4000 REV:01

For use in Indoor

Dry controlled

Environment

AC INPUT

120-240 VAC

50-60Hz 1.8A

G N L

Regulated 12/24 VDC 4.0Amp For wiring size use 22 to 14AWG

TESTED FOR:

ULC-S318, UL603

ULC-S527, UL 864

ULC-60839-11-1

KEEP POWER LIMITED WIRING FROM NON POWER LIMITED WIRING AT LEAST 0.25" INCH APART

FIRE PROTECTIVE SIGNALING

4 2 4

LOAD (A)

[V]

24V

12V

12AH BATTERY 17.2AH BATTERY

STANDBY OPERATION

[HOURS]

TIME

VOLTAGE

OUTPUT STANDBY OPERATION

[HOURS]

TIME

12 / 17.2

I.T.E. POWER SUPPLY

E220695

Battery capacity for loss of primary power

at least (see table below) hours for:

UL294, CAN/ULC-60839-11-1:

Grade 3"

STANDBY BATTERIES TIME/VOLTAGE CHARTS

OUTPUT

VOLTAGE

TIME

[HOURS]

STANDBY

(A)

ALARM

(A)

[MIN.] [MIN.] (A)

ALARM

(A)

STANDBY

17.2AH BATTERY12AH BATTERY

Calculation with 20% safety margin

4.0

150mA 3.0 4.0

150mA 3.0

FIRE ALARM & BURGLARY APPLICATION ULC-S318

PART NO:PX4001 REV:01

12 VOLT 12 VOLT

150mA 30 4.0 4.0

250mA 3.0 4.0

250mA 3.0

BURGLAR APPLICATIONS TO UL603

150mA 30 4.0

DATE OF MFG:

AWG14

LED’S PANEL

BAT

GRN

DOOR

PANEL GROUND STUD

YEL

BLU

For fire applications in US, all interconnecting wiring

are Class E, unsupervised. For fire applications in

Canada, interconnecting wiring shall be supervised

by interconnected fire alarm equipment or be limited

to 18 m run in a metallic conduit

SPECIAL LOCKING

ARRANGMENT

CSA C22.1, Safety Standard

for Electrical Installations,

Canadian Electrical Code,

Part I, CAN/ULC-S524

Code and all applicable codes.

as NFPA72 Nation a Fire Alarm

Electrical Code NFPA70, as well

in compliance with the National

This Product must be installed

REG# T1880475-02

REG# T1880475-01

Canada

Industry

REG# T1880475-03

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Inaxsys Stromversorgung Handbücher

Inaxsys

Inaxsys SW1210-16CB Technisches Handbuch

Beliebte Stromversorgung Handbücher anderer Marken

Monacor

Monacor PS-12CCD Bedienungsanleitung

VOLTIMA

VOLTIMA MagicBox 15 Bedienungsanleitung

Agilent Technologies

Agilent Technologies 6032A Bedienungsanleitung

Miller

Miller Auto Deltaweld 452 Bedienungsanleitung

BCP

BCP PUOUBK Merkblatt

HC 2210 Bedienungsanleitung

Puls

Puls CT5.241 Bedienungsanleitung

OCZ

OCZ ZX1250W Bedienungsanleitung

iseg

iseg ECH 238 Bedienungsanleitung

Power

Power XXL A Series Bedienungsanleitung

Agilent Technologies

Agilent Technologies 6631B Bedienungsanleitung

Renogy

Renogy PHOENIX 300 Bedienungsanleitung

HP 6200B Service-Handbuch

Epson

Epson Stylus Scan 2500 Betriebsanleitung

Pulsar

Pulsar GREEN POWER CCTV PoE POE044816 Bedienungsanleitung

Puls

Puls MiniLine ML50.100 Bedienungsanleitung

Puls

Puls AS-Interface SLA4.100 Bedienungsanleitung

Kenwood

Kenwood PS-60 Bedienungsanleitung
