INDUSTRY Magnum Bedienungsanleitung
Document version 1.4 Date: 2023-02-09
General Original User Manual
Magnum 3D-printer
User Manual
Date
2023-02-09
Page
2 (51)
This manual should be read at www.the-industry.se or from the
NFC tags next to the Magnum control panel, to get the latest
updated version of this manual.
User Manual
Date
2023-02-09
Page
3 (51)
Table of Contents
Table of Contents 3
1General 6
1.1 Overview 6
1.2 Field of Application 8
1.3 Description of the extruder 8
1.4 Description of the vacuum table 9
1.5 Description of personnel 10
1.5.1 Operator 11
1.5.2 Maintenance personnel 11
1.5.3 Certified electrician 11
2Description of security concept 11
2.1 Internal inspection 11
2.2 Emergency stops and power switches 11
2.3 Instructions for safe inspection and maintenance
12
2.4 Information about other hazards 13
2.5 Instructions regarding the use of personal protective
equipment 13
2.6 Prohibited usage 13
2.7 Details of noise and vibration 14
2.8 Alarm tower functions 14
2.9 Details of location for placement of the machine
15
2.9.1 Details of fire and smoke hazards 15
3Installation of the machine 16
3.1 Place the Magnum on a smooth and stable floor and remove
packaging material 16
3.2 Remove transportation support 16
3.3 Adjustment of machine feet 17
3.4 Detach extruder and linear modules 19
3.5 Mount the alarm tower 20
3.6 Directions for electricity 20
3.7 Directions for compressed air 20
3.8 Directions for cooling unit 21
3.9 Directions for material feeding system 21
User Manual
Date
2023-02-09
Page
4 (51)
3.10 Directions for calibration of table height 21
3.11 Activate main power switch 22
3.12 Directions for calibration of X/Y endpoints 22
3.13 Activate the material feeding system 22
3.14 Activate the cooling system 22
3.15 Activate the main switch for compressed air 23
3.16 Add a print sheet to the table 23
3.17 Remove window protection 24
4Manoeuvring and operation 24
4.1 Description of operating device 24
4.1.1 Operating device basic functions 25
4.1.2 Operating device location and operator workspace
25
4.2 Instructions for basic functions (on the operator’s panel)
26
4.2.1 Instructions for start: 26
4.2.2 Instructions for stop: 26
4.2.3 Control measures before initiating a program or manual
control 26
4.2.4 Instructions for activating vacuum for the vacuum table
27
4.2.5 Instructions for deactivating vacuum to vacuum table
27
4.2.6 Instructions for initiating a program 27
4.2.7 Instructions for emergency stop and restart 29
4.2.8 Directions for moving the extruder to the “start” position
30
4.3 Directions for changing the extruder nozzle 31
4.4 Directions for emptying extruder and the material transport
system 31
4.5 Directions for changing material 32
4.6 Directions for removing the printed model 32
4.7 Directions for troubleshooting and alarm tower reset
33
4.7.1 Instructions for troubleshooting 33
4.7.2 Directions for the alarm tower 36
4.8 Instructions for operator training 37
User Manual
Date
2023-02-09
Page
5 (51)
5Maintenance 37
5.1 Lubrication 37
5.1.1 Directions for changing the print sheet on the table
38
5.1.2 Directions for changing motor 38
5.1.3 Directions for changing extruderscrew 39
5.2 Directions and time intervals for inspecting protective
functions 42
5.3 Timetable and actions for inspection and maintenance
42
5.3.1 Directions for cleaning of extruder 42
5.3.2 Description for cleaning of the machine 43
5.4 Maintenance of constituent components 44
5.5 Specification of spare parts 44
5.5.1 Pneumatic system 44
5.5.2 Extruder system 44
5.5.3 Motor Cables Z 45
5.5.4 Motor Cables Y 45
5.5.1 Motor Cables X 46
5.5.2 Motor positions46
5.5.3 Gearbox positions 47
5.6 Directions for transport of the machine 48
5.7 Directions for shutting down, disassembly and disposal
50
6Camera 50
7Manufacturer 51
8Links to manuals of included products 51
User Manual
Date
2023-02-09
Page
6 (51)
1General
1.1 Overview
Magnum is a 3D-printer from The Industry Sweden AB. An overview of machine components can be seen in
figure 2. The printing volume of the machine is 1200mm (Width) x 1500mm (Length) x 1200mm (Height). The
machine is closed without any protruding mechanical parts to avoid pinch point hazards. The electrical cabinet
can be found at the back of the machine. The machine doors that provide access to the printing area are
situated at the opposite end. The machine has a heated vacuum table (fig 2 and 3) and one extruder for plastic
material fig 4). On the machine’s vacuum table, a 2 mm thick aluminium sheet is attached which has the same
length and width as the table. The plastic material extruder is fed by plastic granulate. The extruder is equipped
with water-cooled cooling inlets. Part of the machine comprises an external water-cooling unit, which controls
the temperature of the extruder’cooling inlets. Material feeding to extruder is handled by material tubes led
through a cable chain. For additional information about the material transport system, see 4.1.
Figure 1 (Weight: 2,5 tons. Hight without alarm tower: 2350 mm)
User Manual
Date
2023-02-09
Page
7 (51)
Figure 2 (Location general components)
User Manual
Date
2023-02-09
Page
8 (51)
Figure 3 (Vacuum table) Figure 4 (The extruder)
1.2 Field of Application
•The machine’s main field of application is the production of plastic parts.
1.3 Description of the extruder
There are 1 extruder on the machine. It is located in the machine gantry.
•The extruder is for nozzle sizes 2-8mm.
•For detailed information on the individual spare parts of the extruder, see fig 5.
•The extruder is equipped with a water-cooling system to prevent heat from the heating bands to reach
the material inlet. Should the material inlet become too hot, the material flow may become uneven
due to increase stickiness of material.
•The extruder has three 1200Watts heating bands and one temperature sensor for each heating band.
User Manual
Date
2023-02-09
Page
9 (51)
Figure 5 (The extruder)
1.4 Description of the vacuum table
The machine has a vacuum table which acts as the print table on which a print sheet will be placed upon. After
it has been equipped with a print sheet, it acts as a surface on which the machine will build 3D-objects with the
extruder. It is located at the center of the machine.
•The vacuum table has 1200 x 1500 mm area.
•There are milled grooves on the tables top surface which function as channels for the airflow in order
to generate vacuum.
User Manual
Date
2023-02-09
Page
10 (51)
Figure 6 (Top side of vacuum table)
•The grooves on the top surface lead to 4 outlets where the air is ejected via vacuum ejectors.
•All grooves must be covered by the print sheet to reach sufficient vacuum.
•The recommended material for the top sheet is aluminium.
•The recommended thickness for the top sheet is 2mm.
1.5 Description NFC tags
•Next to the control panel are 2 green badges with symbols. These contain an NFC tag. By holding a
mobile phone over the badge, the phone reads the NFC tag and directs you to Magnum's unique
product information. On the badge with gearwheel there is Magnum's Manual and information
relating to all Magnums and on the tray with an "i" there is information about your particular
Magnum.
1.6 Description of personnel
The relevant roles of personnel necessary for the full function of the machine:
