infinias S-SVR32-IMS-A Bedienungsanleitung
www.infinias.com IN_S-SVR32_H4_SQ
1/20/2014
This guide provides setup instructions for your innias server.
Save this document for future reference.
For more information, contact innias support at:
866.496.5783Toll Free • support@innias.com
S-SVR32-IMS-A Server Quick Start Guide
IP Access Control Management Systems
1. Getting Started
Unpacking the contents
The following are included with your system. Inspect
these and the other system components while unpacking.
• Quick Start Guide
• Server and documentation
• Server Activation License card(s)
(for use when starting your server)
• Intelli-M® Access DVD
• Microsoft® Windows 7 Professional DVD
• Example access cards
• Hex security key Allen wrench
• External Power Supply
Choose a proper location
Select a location for the server that meets the following
requirements.
Notice: Excessive heat can shorten the life of electronics.
• Adequate ventilation to avoid excessive heat (climate-
controlled environment)
• Uninterrupted Power Supply (UPS)
• Moisture-free environment
• A place away from direct sunlight
• An area with minimal dust or debris
2. About the Server
Drive Bay
(Not Used)
USB 2.0 Port
Vertical Stand
Power Button
Power Status
LED
HDD Status
LED
4-in-1 Card
Reader
Kensington
Lock
16GB USB Flash
Drive Installed
Here*
LAN Port
VGA Port
Power
Connector
(DC IN)
Headphone/
Line Out
USB 2.0
Ports (4)
Front Back
*NOTE: Do not remove the 16GB USB ash drive. Intelli-M Access will backup to this drive. This drive must be set as D:\ .
www.infinias.com
www.infinias.com
3. Setting Up Your Server
1. Connect your monitor to the VGA port. 2. Connect your keyboard and mouse. You can use any of
the available USB ports.
3. Connect the network cable. 4. Connect the power adapter to the computer, then plug it
into a standard 120 VAC outlet.
5. Power on the computer and monitor. 6. Setup the server.
Press Login to the system using the following credentials. Please
change your password to improve the security of your system.
Windows 7 Professional login:
Login username: inniasAdmin
Login password: 1nf!nIas
GETTING THE MOST OUT OF YOUR SERVER
2 YEAR WARRANTY
The server hardware comes with a 2 year return to innias warranty. For support, please contact innias in the USA at 866-496-5783.
CUSTOMER SUPPORT
For all software and operating system questions, contact innias support at 866-496-578. For questions about installation please
contact your dealer/systems integrator.
AUTOMATIC BENEFITS
The S-SVR32-IMS-A server will back up the Intelli-M Access databases nightly to the local drive in D:\. Files in this folder should be
copied to another computer or to removable storage on a regular basis.
SERVER SYSTEM FEATURES
• Intel® Atom™ processor D525 (dual core)
• 2GB memory
• 500GB hard disk drive
• 16GB USB ash drive for non-volatile storage
• 10/100/1000BASE-T LAN
• Desktop or VESA Mount (with additional purchase of VESA mounting bracket - contact innias sales)
• Microsoft Windows 7 Professional
• Intelli-M Access Essentials installed and licensed
• Database and key les automatically backed up
• Automatic event archiving
ADDITIONAL SYSTEM INFORMATION
• LOGGING IN - Connecting to Intelli-M Access:
From this computer: http://localhost/intellim
From another computer: http://<ipaddress>/intellim
http://<machinename>/intellim
where <ipaddress> and <machinename>
are the IP address and name of this server
• Intelli-M Access:
Username: admin
Password: admin
• Database management:
System administrator username: sa
System administrator password: 1nf!nIas Server Activation License card
(used during initial system startup)
Copyright © 2014 Innias, Inc. • Indianapolis, IN
866.496.5783Toll Free • support@innias.com • www.innias.com
