Infobit WP200-Kit Bedienungsanleitung

File No.

RD-I-20-012

Version

1.1

WP200-Kit User Manual

Effective Date

2020-01-06

Page

1/ 26

Record page

No.

Revised summary description

Version

Revise

person

Revised

Date

Initial version

1.0

Alex

2020-01-02

Connected the “Auto System” function description

V1.1

Alex

2020-01-06

Approval：

Date：

Approve by：

Date：

Issue：Alex

Date：2020/01/06

File No.

RD-I-20-012

Version

1.1

WP200-Kit User Manual

Effective Date

2020-01-06

Page

2/ 26

Multi-function AV intelligent

education system

Model: WP200-Kit

VER 1.1

File No.

RD-I-20-012

Version

1.1

WP200-Kit User Manual

Effective Date

2020-01-06

Page

3/ 26

Thank you for purchasing this product

For optimum performance and safety, please read these instructions carefully

before connecting, operating or adjusting this product. Please keep this manual

for future reference.

Surge protection device recommended

This product contains sensitive electrical components that may be damaged

by electrical spikes, surges, electric shock, lighting strikes, etc. Use of surge

protection systems is highly recommended in order to protect and extend the

life of your equipment.

Table of Contents

1. Introduction ...................................................................................................... 4

2. Features ............................................................................................................ 5

3. Package Contents .............................................................................................. 5

4. Specifications .................................................................................................... 6

5. Operation Controls and Functions...................................................................... 7

5.1 Transmitter Panel ...................................................................................... 7

5.2 Receiver Panel........................................................................................... 9

6. Web GUI User Guide........................................................................................ 10

7. System ON/OFF Subroutine ............................................................................. 23

8. Display ON/OFF Subroutine ............................................................................. 24

9. System Reset ................................................................................................... 25

10. Application Example ...................................................................................... 26

File No.

RD-I-20-012

Version

1.1

WP200-Kit User Manual

Effective Date

2020-01-06

Page

4/ 26

1. Introduction

The product is a multi-function AV intelligent education system. It offers 2HDMI and

VGA video extension, video switching, system control and analog audio amplification.

Uncompressed video and audio can be transmitted up to 230ft/70m. This design of

HDBaseT™ technology allows for full usage of HDMI and controls over CAT5e/6/6A

cable. The product supports Web GUI and panel button control.

Transmitter support HDCP 1.4, HDCP2.2 and can be switched manually, auto, hybrid

or priority. And the maximum distance can be up to 70m at 1920x1200@60Hz or up

to 40m at 4K @ 30 Hz.

Receiver support a microphone input, analog audio output, 2x30 at 4 ohms speaker

output, and Relay control to the projector screen rise and fall or RS-232 control to the

display power on and off. A USB port on the receiver will transmit interactive display

connections to the transmitter.

Control Panel supports volume control and system control. At the same time, it can

support 2 HDMI and one VGA input selection.

File No.

RD-I-20-012

Version

1.1

WP200-Kit User Manual

Effective Date

2020-01-06

Page

5/ 26

2. Features

☆ HDMI 1.4b, HDCP 2.2 and HDCP 1.4 compliant.

☆ Video resolutions up to 4K2K@30Hz, 1080p@120Hz and 1080P 3D@60Hz.

☆ Audio up to 7.1 channels of High Definition audio pass through (LPCM, Dolby

TrueHD, and DTS-HD Master Audio).

☆ HDBaseT™ over a single CAT5e/6/7 cable up to 230ft/70m distance.

☆ Support multi-VESA Standard VGA formats input.

☆ Supports MIC input.

☆ 2x30watts@4 ohms amplifier output.

☆ Supports interactive display USB pass-through.

☆ Supports Web GUI control.

☆ Supports control panel volume control and system control.

☆ Supports relay control.

☆ Supports RS-232 control.

3. Package Contents

① 1× HDMI Extender Transmitter

② 1× HDMI Extender Receiver

③ 1× 24V/3.75A DC Power Supply

④ 2× Mounting ears

⑤ 1× User Manual

File No.

RD-I-20-012

Version

1.1

WP200-Kit User Manual

Effective Date

2020-01-06

Page

6/ 26

4. Specifications

Technical

HDMI Compliance

HDMI 1.4

HDCP Compliance

HDCP 2.2/HDCP 1.4

Video Bandwidth

10.2 Gbps

Video Resolution

up to 4K2K@30Hz,1080P@120Hz and 1080P 3D@60Hz

Color Space

RGB, YCbCr 4:4:4, YCbCr 4:2:2

Color Depth

8/10/12-bit

HDMI AudioFormats

LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD,

DTS-HD Master Audio, Dolby Atmos, DTS:X

ESD Protection

Human body model — ±8kV (Air-gap discharge) &

±4kV (Contact discharge)

Connections

Inputs: 2x HDMI IN Type A [19-pin female]

1x VGA [DB15 VGA female]

1x AUDIO IN [3.5mm Stereo Mini-jack]

1x RS-232/POWER [RJ45]

Outputs: 1x HDBaseT Out [RJ45]

Receiver

Inputs: 1x HDBaseT In [RJ45]

1x MIC IN [Screw Terminal]

1x USB [USB A TYPE]

1x TCP/IP [RJ45]

Outputs: 1x HDMI OUT Type A [19-pin female]

1x RS-232 [Screw Terminal]

1x RELAY [Screw Terminal]

1x AUDIO OUT [Screw Terminal]

1x 2x30watts@4 ohms amplifier output [Screw Terminal]

Mechanical

Housing

Metal Enclosure

Color

Transmitter: White, Receiver: Black

Dimensions

Transmitter:

115.9mm [W] x 114.3mm [D] x 38.7mm [H]

Receiver:

250mm [W] x 104mm [D] x 30mm [H]

Weight

Transmitter: 305g, Receiver: 758g

Power Supply

Input: AC100 - 240V 50/60Hz, Output: DC 24V/3.75A

(US/EU standards, CE/FCC/UL certified)

Power Consumption

75W (max)

File No.

RD-I-20-012

Version

1.1

WP200-Kit User Manual

Effective Date

2020-01-06

Page

7/ 26

Operating

Temperature

32 - 104°F / 0 - 40°C

Storage Temperature

-4 - 140°F / -20 - 60°C

Relative Humidity

20 - 90% RH (no condensation)

5. Operation Controls and Functions

5.1 Transmitter Panel

File No.

RD-I-20-012

Version

1.1

WP200-Kit User Manual

Effective Date

2020-01-06

Page

8/ 26

Number

Name

Function description

HDCP LED

HDCP compliance indicator.

▪ OFF: HDMI input is not carrying HDCP content.

▪ ON: HDMI input is carrying HDCP content.

LINK LED

HDBaseT Link status indicator.

▪ OFF: No Link.

▪ GREEN: Link successful.

▪ Blink GREEN: Link abnormal.

VGA LED

VGA signal indicator.

▪ OFF: There is no +5V HPD or VGA signal detected on input.

▪ FLASHING: +5V HPD or VGA signal is detected.

▪ GREEN: VGA is active input and VGA signal is detected.

POWER LED

System power indicator.

VGA IN

Connect to VGA source.

ADUIO IN

Connect to external audio source for VGA signal.

HDMI 1 LED

HDMI 1 signal indicator.

▪ OFF: There is no +5V HPD or HDMI signal detected on input.

▪ FLASHING: +5V HPD or HDMI signal is detected.

▪ GREEN: HDMI is active input and HDMI signal is detected.

HDMI 1 IN

Connect to HDMI source device.

SOURCE

Press it to select one source.

TO PC

Connect PC to transmit USB control signal from the

Receiver USB device in.

HDMI 2 LED

HDMI 2 signal indicator.

▪ OFF: There is no +5V HPD or HDMI signal detected on input

▪ FLASHING: +5V HPD or HDMI signal is detected.

▪ GREEN: HDMI is active input and HDMI signal is detected

HDMI 2 IN

Connect to HDMI source device.

HDBaseT OUT

Connect to HDBaseT Receiver with a Cat5e/6/7 cable.

RS-232/POWER

Connect to Control Panel via CAT5e/6/7 cable.

24VDC

(OPTIONAL)

Connects 24V/1A adaptor to AC wall outlet for power supply.

Micro-USB

For firmware updated use.

DIP SWITCH

Select upgrade type.

File No.

RD-I-20-012

Version

1.1

WP200-Kit User Manual

Effective Date

2020-01-06

Page

9/ 26

5.2 Receiver Panel

Number

Name

Function description

MIC GAIN

Set the MIC input gain.

POWER LED

System power indicator.

LINK LED

HDBaseT Link status indicator.

▪ OFF: No Link.

▪ GREEN: Link successful.

▪ Blink GREEN: Link abnormal.

HDCP LED

HDCP compliance indicator.

▪ OFF: HDMI input is not carrying HDCP content.

▪ ON: HDMI input is carrying HDCP content.

ACT

System work indicator.

▪ OFF: System standby or power off.

▪ Blink GREEN: System working.

SERVICE

For firmware updated use.

TCP/IP

Connect to a PC access to the Web GUI for system setting.

HDBaset IN

Connect to HDBaseT Transmitter with a Cat5e/6/7 cable.

HDMI OUT

Connect to a HDMI display device.

USB DEVICE

Connect to an interactive display.

RS-232

RS-232 control for the display.

RELAY

To control the projector screen rise and fall.

AUDIO OUT

Connect to a speaker.

MIC LINE

SWITCH

▪ When the switch is set to “MIC”, the microphone input is

used to connect a dynamic microphone.

▪ When the switch is set to “LINE”, the microphone input is

used for connecting a line level audio source or wireless

microphone output.

MIC IN

Using Phoenix terminal cable to connect microphone input.

File No.

RD-I-20-012

Version

1.1

WP200-Kit User Manual

Effective Date

2020-01-06

Page

10 / 26

2X30 watts @4Ω

Connect to speaker out.

DC 24V

Connect 24V/3.75A adaptor to AC wall outlet for power supply.

6. Web GUI User Guide

The product can be controlled via Web GUI through TCP/IP port. The default

IP address is 192.168.2.100. When the product has finished connection. You

can set the IP address to your PC/laptop Internet Explorer and click “Search”

to enter Web GUI login page. In the login page, you need set the ‘User’ and

‘Password’. The default ‘User Name’ and ‘Password’ for the admin are

both

‘admin’. When you set it over and you need click ‘Login’ button to enter

Web GUI function page. The login page likes below:
