LP260 RS-232 Connection

The LP260 requires the serial control cable (part # 210-0203-xx) that comes with the projector.

Command Format

All commands consist of 3 alpha characters followed by a request, all enclosed in parentheses. The request can be a read request

(indicated by a "?") or a write request (indicated by 1 to 4 ASCII digits).

A read request example:

(AAA?) where

( starts the command

AAA denotes the command

? denotes the read request

) ends the command

A read command returns the range and the current setting, for example:

Read Command Examples

Function Command Response

Brightness (BRT?) (0-22, 10)

Volume (VOL?) (0-80, 0)

Lamp Hours (LMP?) (0-9999, 421)

A write request example:

(AAA####) where

( starts the command

AAA denotes the command

#### denotes the value to be written

(leading zeros not necessary)

) ends the command

Some commands have ranges, while others are absolute. If a number greater than the maximum range is received, it is

automatically set to the maximum number for that function. If a command is received that is not understood, a "?" is returned. With

absolute settings, "0" is off, 1-9999 is on. The one exception is the Power command, where 0 is off and 1 is on.

To assure the projector can process a command, wait 3 seconds before entering the next command.

Write Command Examples

Function Command Response

Brightness (BRT10) Sets the brightness

to 10

Freeze (FRZ1) or

(FRZ8888) Freezes the display

Power (PWR0) Turns power off

Power (PWR1) Turns power on

Error Conditions

Not all commands are supported for all projectors. If an unsupported command is issued, the command will be ignored. If a

command is received that is not understood, a ‘?’ character will be returned indicating the command was not understood.

Limitations

The CLI cannot respond to commands coming in at a high-rate. Therefore, a delay must occur between commands to ensure that

the command gets properly executed. To assure the projector can process a command, wait 3 seconds before entering the next

command.

LP260 RS-232/CLI Values

The following table lists the RS-232 command value ranges for controlling the LP260 projector.

Note: Specified commands and values apply to the LP260 with version 7.3 software or higher. Command values for LP260s with

earlier software versions may vary. If your LP260 does not have version 7.3 software or higher, go to the Software/Downloads

page to download and upgrade the projector software.

Note: The LP 260 requires a 9-pin DIN to a standard 15-pin serial connection available from most computer stores.

Source Independent Settings

Function/Setting CLI

Command REMARK

POWER ON C00

FORCED POWER OFF C01 POWER OFF with "POWER

OFF?"

POWER OFF C02 "POWER OFF?" and then

POWER OFF

VOLUME + C09 Same function as RC

VOLUME - C0A Same function as RC

SOUND MUTE ON C0B

SOUND MUTE OFF C0C

MENU ON C1C

MENU OFF C1D

POINTER RIGHT C3A Same function as key on the

set

POINTER LEFT C3B Same function as key on the

set

POINTER UP C3C Same function as key on the

set

POINTER DOWN C3D Same function as key on the

set

ENTER C3F Same function as key on the

set

FREEZE ON C43

FREEZE OFF C44

FINE SYNC + C49 Same function as RC

FINE SYNC - C4D Same function as RC

ZOOM C80 Same function as RC

FOCUS C87 Same function as RC
